Cabletron Systems 9F120-08 Technical document

9031372-01
SmartSwitch 9000
9F120-08 / 9F122-12 / 9F125-08
Local Management Appendix

1
Appendix
9F120-08 / 9F122-12 / 9F125-08
Module Specific Information
Introduction
This appendix contains local management information that is specific to the
9F120-08, 9F122-12 and 9F125-08 MicroLAN modules.
Default Interface Codes
The Default Interface field on the General Configuration Screen allows you to
enter a number (one through three). Each number represents a default interface
for the selected module. The table below lists the numbers you can enter, each
number’s corresponding interface, and a brief description of that interface. The
default for this field is NONE, meaning no default interface selected.
Table 1. 9F12x-xx MicroLAN Module Default Interface Codes
Number Interface Description
1 SMB-1 1 mbps System Management Bus
2 SMB-10 10 mbps System Management Bus
3 FNB Flexible Network Bus (dual attached)

9F120-08 / 9F122-12 / 9F125-08 Module Specific Information
2
FNB Resource Configuration Codes
All of the MicroLAN Modules described in this appendix physically attach to the
FNB-1 and the FNB-2 on the SmartSwitch 9000 backplane. By default, the module
inserts into four rings (the primary and secondary rings of the FNB-1 and the
FNB-2). The FNB Resource Configuration Screen allows you to customize this
configuration to your particular needs.
The FNB Resource Configuration Screen allows you to:
• Select the rings (primary or secondary) of each FNB to which the module will
attach
• Determine whether the module will insert into those rings or bypass them
• Select the ring where the MAC will reside
The terms INSERT and BYPASS refer to relays that are located on the module.
INSERT causes a relay to connect the module’s front panel ports to the selected
ring. BYPASS causes a relay to disconnect the module’s front panel ports from the
selected ring.
INSERT:
BYPASS:
The FNB Resource Configuration Screen lists all possible connections a module
can support on the FNB, displays the current connection, and allows you to
change the connection. Table 2 lists and describes the FDDI Connections from
which you can select.
Front FNB Ring
Relay
Panel
Ports
Front
Panel
Ports
FNB Ring
Relay

3
9F120-08 / 9F122-12 / 9F125-08 Module Specific Information
Table 2. 9F12x-xx MicroLAN Module FNB Resource Configuration Codes
Configuration
ID FDDI Connections Description
1 FNB 1 Pri. (MAC) Byp. ,
FNB 2 Pri. (No MAC) Byp.
The module is attached, but not inserted, to
the primary ring on the FNB-1. The module is
attached, but not inserted, to the primary ring
on the FNB-2. The MAC resides on FNB-1.
2 FNB 1 Pri. (MAC) Byp. ,
FNB 2 Pri. (No MAC) Ins.
The module is attached to the FNB-1 primary
ring and the FNB-2 primary ring. The switch
that inserts the module into the FNB-1 is
turned off. The switch that inserts the module
into the FNB-2 is turned on. The MAC resides
on FNB-1.
3 FNB 1 Pri. (MAC) Ins. ,
FNB 2 Pri. (No MAC) Byp.
The module is attached to the FNB-1 primary
ring and the FNB-2 primary ring. The switch
that inserts the module into the FNB-1 is
turned on. The switch that inserts the module
into the FNB-2 is turned off. The MAC resides
on FNB-1.
4 FNB 1 Pri. (MAC) Ins. ,
FNB 2 Pri. (No MAC) Ins.
The module is attached to the FNB-1 primary
ring and the FNB-2 primary ring. The switch
that inserts the module into the FNB-1 is
turned on. The switch that inserts the module
into the FNB-2 is turned on. The MAC resides
on FNB-1.
5 FNB 1 Pri. (No MAC) Byp. ,
FNB 2 Pri. (MAC) Byp.
The module is attached to the FNB-1 primary
ring and the FNB-2 primary ring. The switch
that inserts the module into the FNB-1 is
turned off. The switch that inserts the module
into the FNB-2 is turned off. The MAC resides
on FNB-2.
6 FNB 1 Pri. (No MAC) Byp. ,
FNB 2 Pri. (MAC) Ins.
The module is attached to the FNB-1 primary
ring and the FNB-2 primary ring. The switch
that inserts the module into the FNB-1 is
turned off. The switch that inserts the module
into the FNB-2 is turned on. The MAC resides
on FNB-2.

9F120-08 / 9F122-12 / 9F125-08 Module Specific Information
4
7 FNB 1 Pri. (No MAC) Ins. ,
FNB 2 Pri. (MAC) Byp.
The module is attached to the FNB-1 primary
ring and the FNB-2 primary ring. The switch
that inserts the module into the FNB-1 is
turned on. The switch that inserts the module
into the FNB-2 is turned off. The MAC resides
on FNB-2.
8 FNB 1 Pri. (No MAC) Ins. ,
FNB 2 Pri. (MAC) Ins.
The module is attached to the FNB-1 primary
ring and the FNB-2 primary ring. The switch
that inserts the module into the FNB-1 is
turned on. The switch that inserts the module
into the FNB-2 is turned on. The MAC resides
on FNB-2.
9 FNB 1 Pri. (MAC) Byp. ,
FNB 2 Sec. (No MAC) Byp.
The module is attached to the FNB-1 primary
ring and the FNB-2 secondary ring. The
switch that inserts the module into the FNB-1
is turned off. The switch that inserts the
module into the FNB-2 is turned off. The
MAC resides on FNB-1.
10 FNB 1 Pri. (MAC) Byp. ,
FNB 2 Sec. (No MAC) Ins.
The module is attached to the FNB-1 primary
ring and the FNB-2 secondary ring. The
switch that inserts the module into the FNB-1
is turned off. The switch that inserts the
module into the FNB-2 is turned on. The MAC
resides on FNB-1.
11 FNB 1 Pri. (MAC) Ins. ,
FNB 2 Sec. (No MAC) Byp.
The module is attached to the FNB-1 primary
ring and the FNB-2 secondary ring. The
switch that inserts the module into the FNB-1
is turned on. The switch that inserts the
module into the FNB-2 is turned off. The
MAC resides on FNB-1.
12 FNB 1 Pri. (MAC) Ins. ,
FNB 2 Sec. (No MAC) Ins.
The module is attached to the FNB-1 primary
ring and the FNB-2 secondary ring. The
switch that inserts the module into the FNB-1
is turned on. The switch that inserts the
module into the FNB-2 is turned on. The MAC
resides on FNB-1.
Table 2. 9F12x-xx MicroLAN Module FNB Resource Configuration Codes (Continued)
Configuration
ID FDDI Connections Description

5
9F120-08 / 9F122-12 / 9F125-08 Module Specific Information
13 FNB 1 Pri. (No MAC) Byp. ,
FNB 2 Sec. (MAC) Byp.
The module is attached to the FNB-1 primary
ring and the FNB-2 secondary ring. The
switch that inserts the module into the FNB-1
is turned off. The switch that inserts the
module into the FNB-2 is turned off. The
MAC resides on FNB-2.
14 FNB 1 Pri. (No MAC) Byp. ,
FNB 2 Sec. (MAC) Ins.
The module is attached to the FNB-1 primary
ring and the FNB-2 secondary ring. The
switch that inserts the module into the FNB-1
is turned off. The switch that inserts the
module into the FNB-2 is turned on. The MAC
resides on FNB-2.
15 FNB 1 Pri. (No MAC) Ins. ,
FNB 2 Sec. (MAC) Byp.
The module is attached to the FNB-1 primary
ring and the FNB-2 secondary ring. The
switch that inserts the module into the FNB-1
is turned on. The switch that inserts the
module into the FNB-2 is turned off. The
MAC resides on FNB-2.
16 FNB 1 Pri. (No MAC) Ins. ,
FNB 2 Sec. (MAC) Ins.
The module is attached to the FNB-1 primary
ring and the FNB-2 secondary ring. The
switch that inserts the module into the FNB-1
is turned on. The switch that inserts the
module into the FNB-2 is turned on. The MAC
resides on FNB-2.
17 FNB 1 Sec. (MAC) Byp. ,
FNB 2 Pri. (No MAC) Byp.
The module is attached to the FNB-1
secondary ring and the FNB-2 primary ring.
The switch that inserts the module into the
FNB-1 is turned off. The switch that inserts the
module into the FNB-2 is turned off. The
MAC resides on FNB-1.
18 FNB 1 Sec. (MAC) Byp. ,
FNB 2 Pri. (No MAC) Ins.
The module is attached to the FNB-1
secondary ring and the FNB-2 primary ring.
The switch that inserts the module into the
FNB-1 is turned off. The switch that inserts the
module into the FNB-2 is turned on. The MAC
resides on FNB-1.
Table 2. 9F12x-xx MicroLAN Module FNB Resource Configuration Codes (Continued)
Configuration
ID FDDI Connections Description

9F120-08 / 9F122-12 / 9F125-08 Module Specific Information
6
19 FNB 1 Sec. (MAC) Ins. ,
FNB 2 Pri. (No MAC) Byp.
The module is attached to the FNB-1
secondary ring and the FNB-2 primary ring.
The switch that inserts the module into the
FNB-1 is turned on. The switch that inserts the
module into the FNB-2 is turned off. The
MAC resides on FNB-1.
20 FNB 1 Sec. (MAC) Ins. ,
FNB 2 Pri. (No MAC) Ins.
The module is attached to the FNB-1
secondary ring and the FNB-2 primary ring.
The switch that inserts the module into the
FNB-1 is turned on. The switch that inserts the
module into the FNB-2 is turned on. The MAC
resides on FNB-1.
21 FNB 1 Sec. (No MAC) Byp. ,
FNB 2 Pri. (MAC) Byp.
The module is attached to the FNB-1
secondary ring and the FNB-2 primary ring.
The switch that inserts the module into the
FNB-1 is turned off. The switch that inserts the
module into the FNB-2 is turned off. The
MAC resides on FNB-2.
22 FNB 1 Sec. (No MAC) Byp. ,
FNB 2 Pri. (MAC) Ins.
The module is attached to the FNB-1
secondary ring and the FNB-2 primary ring.
The switch that inserts the module into the
FNB-1 is turned off. The switch that inserts the
module into the FNB-2 is turned on. The MAC
resides on FNB-2.
23 FNB 1 Sec. (No MAC) Ins. ,
FNB 2 Pri. (MAC) Byp.
The module is attached to the FNB-1
secondary ring and the FNB-2 primary ring.
The switch that inserts the module into the
FNB-1 is turned on. The switch that inserts the
module into the FNB-2 is turned off. The
MAC resides on FNB-2.
24 FNB 1 Sec. (No MAC) Ins. ,
FNB 2 Pri. (MAC) Ins.
The module is attached to the FNB-1
secondary ring and the FNB-2 primary ring.
The switch that inserts the module into the
FNB-1 is turned on. The switch that inserts the
module into the FNB-2 is turned on. The MAC
resides on FNB-2.
Table 2. 9F12x-xx MicroLAN Module FNB Resource Configuration Codes (Continued)
Configuration
ID FDDI Connections Description

7
9F120-08 / 9F122-12 / 9F125-08 Module Specific Information
25 FNB 1 Sec. (MAC) Byp. ,
FNB 2 Sec. (No MAC) Byp.
The module is attached to the FNB-1
secondary ring and the FNB-2 secondary ring.
The switch that inserts the module into the
FNB-1 is turned off. The switch that inserts the
module into the FNB-2 is turned off. The
MAC resides on FNB-1.
26 FNB 1 Sec. (MAC) Byp. ,
FNB 2 Sec. (No MAC) Ins.
The module is attached to the FNB-1
secondary ring and the FNB-2 secondary ring.
The switch that inserts the module into the
FNB-1 is turned off. The switch that inserts the
module into the FNB-2 is turned on. The MAC
resides on FNB-1.
27 FNB 1 Sec. (MAC) Ins. ,
FNB 2 Sec. (No MAC) Byp.
The module is attached to the FNB-1
secondary ring and the FNB-2 secondary ring.
The switch that inserts the module into the
FNB-1 is turned on. The switch that inserts the
module into the FNB-2 is turned off. The
MAC resides on FNB-1.
28 FNB 1 Sec. (MAC) Ins. ,
FNB 2 Sec. (No MAC) Ins.
The module is attached to the FNB-1
secondary ring and the FNB-2 secondary ring.
The switch that inserts the module into the
FNB-1 is turned on. The switch that inserts the
module into the FNB-2 is turned on. The MAC
resides on FNB-1.
29 FNB 1 Sec. (No MAC) Byp. ,
FNB 2 Sec. (MAC) Byp.
The module is attached to the FNB-1
secondary ring and the FNB-2 secondary ring.
The switch that inserts the module into the
FNB-1 is turned off. The switch that inserts the
module into the FNB-2 is turned off. The
MAC resides on FNB-2.
30 FNB 1 Sec. (No MAC) Byp. ,
FNB 2 Sec. (MAC) Ins.
The module is attached to the FNB-1
secondary ring and the FNB-2 secondary ring.
The switch that inserts the module into the
FNB-1 is turned off. The switch that inserts the
module into the FNB-2 is turned on. The MAC
resides on FNB-2.
Table 2. 9F12x-xx MicroLAN Module FNB Resource Configuration Codes (Continued)
Configuration
ID FDDI Connections Description

9F120-08 / 9F122-12 / 9F125-08 Module Specific Information
8
31 FNB 1 Sec. (No MAC) Ins. ,
FNB 2 Sec. (MAC) Byp.
The module is attached to the FNB-1
secondary ring and the FNB-2 secondary ring.
The switch that inserts the module into the
FNB-1 is turned on. The switch that inserts the
module into the FNB-2 is turned off. The
MAC resides on FNB-2.
32 FNB 1 Sec. (No MAC) Ins. ,
FNB 2 Sec. (MAC) Ins.
The module is attached to the FNB-1
secondary ring and the FNB-2 secondary ring.
The switch that inserts the module into the
FNB-1 is turned on. The switch that inserts the
module into the FNB-2 is turned on. The MAC
resides on FNB-2.
Table 2. 9F12x-xx MicroLAN Module FNB Resource Configuration Codes (Continued)
Configuration
ID FDDI Connections Description

9
9F120-08 / 9F122-12 / 9F125-08 Module Specific Information
Module Specific Configuration Screen
In the FNB Resource Configuration Screen, you determine which of the two FNB
rings contains the MAC. The 9F120 MicroLAN Module Specific Configuration
Screen allows you to assign one of the two FNB rings (either the ring that contains
the MAC or the ring that does not contain the MAC) to each of the module’s M-
ports. The default ring that is assigned to each of the module’s M-ports is the ring
that contains the MAC.
Figure 1. 9F120 MicroLAN Module Specific Statistics Screen
To assign an FNB ring to a module’s M-port:
1. Use the arrow keys to highlight the PATH field next to the desired port.
2. Press the SPACE BAR to toggle to the desired ring (either MAC-1 or No
MAC).
3. Press the Return key. Repeat steps 1-3 to assign an FNB ring to other M-ports.
4. Use the arrow keys to highlight SAVE at the bottom of the screen and press
the Return key. When the message “SAVED OK” appears, the edits you have
made are saved. If you exit without saving, the message “NOT SAVED --
PRESS SAVE TO KEEP CHANGES” appears. If you proceed to exit without
saving, your edits will be lost.
5. Use the arrow keys to highlight RETURN and press the Return key.
SmartSwitch 9000 LOCAL MANAGEMENT
Module Specific Configuration
Module Name: 9F120-08 Firmware Revision: 01.01.01
Slot Number: 12 BOOTPROM Revision: 00.00.04
FNB 1 Pri. (MAC) Ins. , FNB 2 Pri. (No MAC) Ins.
PORT# PATH CONNECT STATE
1 [MAC-1] CON
2 [MAC-1] CON
3 [MAC-1] CON
4 [MAC-1] CON
5 [MAC-1] CON
6 [MAC-1] CON
7 [MAC-1] CON
8 [MAC-1] CON
SAVE RETURN

9F120-08 / 9F122-12 / 9F125-08 Module Specific Information
10
