Cabletron Systems 6A000/ZX-250 User manual

SmartCell 6A000/ZX-250
Reference Manual
35 Industrial Wa
y
Rochester, NH 03866-5005
USA
[phone]
Part # 04-0044-02 Rev. A
Order # 9032400

ii SmartCell 6A000/ZX-250 Reference Manual
NOTICE
Cabletron Systems reserves the right to make changes in specifications and other information contained in this
document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any
such changes have been made. The hardware, firmware, or software described in this manual is subject to change
without notice.
IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL,
OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING, BUT NOT LIMITED TO, LOST PROFITS)
ARISING OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION CONTAINED IN IT, EVEN IF
CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR SHOULD HAVE KNOWN THE
POSSIBILITY OF SUCH DAMAGES.
Copyright 1997 by Cabletron Systems, Inc., P.O. Box 5005, Rochester, NH03866-5005
All Rights Reserved
Printed in the United States of America
SmartCell 6A000/ZX-250 Reference Manual
Part # 04-0044-02 Rev. A
Order # 9032400
SmartCell, SPECTRUM, LANVIEW, MicroMMAC, and BRIM are registered trademarks and Element Manager,
EPIM, EPIMA, EPIM-F1, EPIM-F2, EPIM-F3, EPIM-T, EPIM-X, FOT-F, FOT-F3, HubSTACK, SEH, SEHI, and
TMS-3 are trademarks of Cabletron Systems, Inc. All other product names mentioned in this manual may be
trademarks or registered trademarks of their respective companies.
SmartCell, SPECTRUM, LANVIEW, MicroMMAC, and BRIM are registered trademarks and Element Manager,
EPIM, EPIMA, EPIM-F1, EPIM-F2, EPIM-F3, EPIM-T, EPIM-X, FOT-F, FOT-F3, HubSTACK, SEH, SEHI, and
TMS-3 are trademarks of CSI ZeitNet, Inc. All other product names mentioned in this manual may be trademarks or
registered trademarks of their respective companies.

SmartCell 6A000/ZX-250 Reference Manual iii
REVISION HISTORY
Document Name: SmartCell 6A000/ZX-250 Reference Manual
Document Order Number: Order # 9032400
Document Part Number: Part # 04-0044-02 Rev. A
Author: Bruce Jordan
Editor: Carre Gibson
Date Revision Descri
p
tion
October 1997 A Initial release

iv SmartCell 6A000/ZX-250 Reference Manual

SmartCell 6A000/ZX-250 Reference Manual v
TABLE OF CONTENTS
1 Introduction 1-1
Audience and Scope 1-1
Definitions 1-1
Content 1-1
Sections 1-2
Conventions 1-2
Abbreviations 1-3
Help Options 1-4
Other Reference Options 1-4
Switch Attribute 1-5
List of Commands and Possible Switch Attributes 1-9
2 Console Commands 2-1
Alarm 2-1
AlarmConfig 2-6
AlarmVerbose 2-9
BUSClient 2-10
BUSELAN 2-12
BUSLECStat 2-16
BUSStat 2-18
CACParams 2-20
CACStat 2-22
Client 2-24
ClientARP 2-28
ClientStat 2-30
ClientVC 2-35
Community 2-37
Config 2-39
ELAN 2-41
Exit 2-45
Firmware 2-46
History 2-48
IISPRoute 2-49
ILMIAdminStatus 2-52
IPAddress 2-54
IPATMARP 2-56
IPATMClient 2-57
IPATMPVC 2-61

vi SmartCell 6A000/ZX-250 Reference Manual
Table of Contents
IPATMStat 2-64
LANEClient 2-66
LECS 2-68
LECSAddress 2-70
LECSELAN 2-72
LECSELANLEC 2-75
LECSStat 2-78
LECSTLVParam 2-81
LECSTLVSet 2-83
LECSVCC 2-88
LES 2-90
LESARP 2-91
LESClient 2-92
LESELAN 2-94
LESLECStat 2-98
LESStat 2-100
Log 2-103
LogAlarmMask 2-104
LogBuffer 2-106
LogBufferSize 2-108
LogPrint 2-109
LogTrace 2-111
MyNMAddr 2-124
NetPrefix 2-126
Passwd 2-128
Ping 2-129
PortAutoDetect 2-130
PortConfig 2-132
PortMode 2-137
PortStat 2-140
PortTrafficCongestion 2-143
Privilege 2-145
Prompt 2-147
PVC 2-148
PVCByID 2-157
Reboot 2-159
Route 2-161
Rows 2-163
SARStat 2-164
Shutdown 2-167
SigConfig 2-168
SigFlags 2-171
SigStat 2-172
SSCOPConfig 2-175
SVC 2-177

SmartCell 6A000/ZX-250 Reference Manual vii
Table of Contents
Switch 2-182
SwitchConfig 2-184
SwitchName 2-188
SwitchTrafficCongestion 2-189
TrafficDescriptor 2-197
TrustedNMS 2-199
UNIRoute 2-201
VCCMask 2-204
WellKnownAddress 2-206
3 Boot Load Commands 3-1
Accessing the Boot Load Commands 3-2
chpi 3-3
clfs 3-4
dcfg 3-5
df 3-6
go 3-7
he 3-8
ponf 3-9
A Acronyms A-1
B Cause Codes B-1
C Technical Support C-1
Telephone Assistance C-1
FAX Service C-1
Electronic Services C-1
Placing A Support Call C-1
Hardware Warranty C-2
Software Warranty C-2
Repair Services C-2
Index I-1

viii SmartCell 6A000/ZX-250 Reference Manual
Table of Contents

SmartCell 6A000/ZX-250 Reference Manual ix
LIST OF TABLES
1-1 List of Operators 1-5
1-2 Operator Table Explanation 1-6
1-3 Parameter Table Explanation 1-7
1-4 Description Table Explanation 1-8
1-5 Description Table Example 1-8
2-1 Filter Flags 2-113
2-2 Software Modules for LogTrace 2-116
2-3 Software Submodules for LogTrace 2-117
2-4 Traffic Descriptor Defining Entry Combinations 2-194
B-1 Cause code values and meanings B-1

x SmartCell 6A000/ZX-250 Reference Manual
List of Tables

SmartCell 6A000/ZX-250 Reference Manual 1-1
1 INTRODUCTION
This reference manual describes the console commands for the SmartCell 6A000 and SmartCell ZX-250 ATM
switches. The two switches share a common console interface and are referred to in this manual as the SmartCell
6A000/ZX-250.
Audience and Scope
The manual is intended for network administrators and others responsible for maintaining the SmartCell
6A000/ZX-250. You do not need to read the manual from start to finish. You can use it to study the console commands
you use.
Definitions
The manual is organized alphabetically by switch attribute.
•The definition of a switch attribute is a function that manipulates the switch in a specific way. For
example, buselan.
•The definition of an operator is the active verb that makes the switch attribute perform a specific
task. For example, show.
•The definition of a command is the combination of an operator plus a switch attribute. For example,
show buselan.
Content
•Chapter 2,"SmartCell 6A000/ZX-250 Commands," gives definitions, descriptions, and examples of
all available commands on the SmartCell 6A000 and SmartCell ZX-250 switches.
•Chapter 3, “Boot Load Commands” gives definitions, descriptions, and examples of the low-level
boot load commands.
•Appendix A, "Acronyms," spells out the ATM acronyms used in this manual as well as those found
in the SmartCell 6A000 User Guide, SmartCell ZX-250 User Guide, and SmartCell ZX
Administrator Installation Guide.
•Appendix B, “Cause Codes,” describes the codes that appear in some console messages.
•Appendix C, "Technical Support," gives instructions for contacting Cabletron by telephone, fax,
electronic mail, and the World Wide Web.

1-2 SmartCell 6A000/ZX-250 Reference Manual
Introduction
Sections
Read "Switch Attribute" for an example and definition of the various sections under each switch attribute as well as a
description of how the manual is organized.
Each section begins with a switch attribute heading (for example, "PVCByID"). Then come the details of relevant
operators, parameters, and commands.
Most sections have two parameter tables—one for input and another for output. The tables contain the parameter
names, descriptions, and definitions of their values, field sizes, and defaults.
The section ends with examples copied from the switch console for each console command for that switch attribute.
Conventions
The SmartCell 6A000/ZX-250 Reference Manual uses the following conventions to convey instructions and
information:
•Information you enter (console commands and input parameters) is shown in bold Courier 10 font
and requires a space between operator and switch attribute.
•Input and output parameters are shown in [Square Brackets].
•Input definitions are shown in <anglebrackets>, as joined text and not case sensitive.
•Filter flags </s> (summary) or </d> (detail) are available with certain show commands and apply to
different information viewing levels. Filter flags require a space between them and the full
command. For example, show client /d. The/s option is the same as the standard default option. You
can find more details at the relevant switch attribute sections. See the following examples:
switch_prompt # show client
ClientNumber(ALL) :
Client Type IP Address Server Type Server Conn Status
==============================================================================
1 LANE 90.1.1.186 LECS Established Operational
3 IP/ATM 90.1.1.124 Local Established Operational
switch_prompt #
switch_prompt # show client /s
ClientNumber(ALL) :
Client Type IP Address Server Type Server Conn Status
==============================================================================
1 LANE 90.1.1.186 LECS Established Operational
3 IP/ATM 90.1.1.124 Local Established Operational
switch_prompt #
switch_prompt # show client /d
ClientNumber(ALL) :
LANE Client 1
==============================================================================
Client State : Operational
Client Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:20:D4:14:15:00:00
LAN Name : elan1
LECS Addr Source : ILMI
LECS Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:20:D4:14:15:00:01
LES Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:20:D4:14:15:00:02
LAN Type : 802.3
MTU : 1516
IP Address : 90.1.1.186

SmartCell 6A000/ZX-250 Reference Manual 1-3
Introduction
IP NetMask : 255.255.255.0
IP/ATM Client 3
==============================================================================
Client State : Operational
Client Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:00:5A:01:01:7C:00
Server : is local
Server Connection : Established
MTU : 9180
IP Address : 90.1.1.124
Abbreviations
Pay close attention to how switch attributes appear in each section heading. Switch attributes are not case sensitive. If
the heading states BUSStat, you must type busstat and not busstats, because the switch will not recognize the latter.
See the following example:
switch_prompt # show busstats
Command busstats not Valid for Action show
Type Help <command> for help
switch_prompt #
switch_prompt # show busstat
ELANNumber(ALL) :
BUS ELANs
============================================================================
ELAN ELAN000 Statistics
Out Octets : 0
Out Unicast : 0
switch_prompt #
You can, however, abbreviate the switch attribute to the extent that it is unique. For example, instead of typing show
porttrafficcongestion, you can just type show portt. The same can be done with operators. Instead of typing modify,
you can type mod. You should type at least three characters for any operator. For example,
switch_prompt # modify portmode
PortNumber(ALL) :
PortMode(SONET) :
switch_prompt #
switch_prompt # mod portm
PortNumber(ALL) :
PortMode(SONET) :
switch_prompt #
See "Switch Attribute" for an explanation of how the sections are organized.

1-4 SmartCell 6A000/ZX-250 Reference Manual
Introduction
Help Options
If you want information on a specific command, type ?or help before typing the command and you will get a brief
description of the command and all its input parameters. If you want information about a specific input parameter while
executing a command, type ?or help after it appears on the console and it will give you details relating to that
parameter. For example,
switch_prompt # ? add lecselan
Create/Add ELAN for LECS(LECSELAN)
============================================================================
ELANNumber ELAN Number in the range 0-127
ELANName ELAN Name ( max. length 32 characters)
LESAddress ATM Address for the LES
ELANType 802.3 : Ethernet or 802.5 : TokenRing
MTU Maximum Frame Size - 1516(def for 802.3), 4544(def for 802.5), 9234
TLVSet TLV Set Number in the range 1-65535
switch_prompt #
switch_prompt # add lecselan
ELANNumber(0) : ?
ELAN Number in the range 0-127
ELANName(ELAN000) : ?
ELAN Name ( max. length 32 characters)
LESAddress(39:00:00:00:00:00:00:00:00:00:14:15:00:00:20:D4:14:15:00:02): ?
ATM Address for the LES
ELANType(802.3) : ?
802.3 : Ethernet or 802.5 : TokenRing
MTU(1516) : ?
Maximum Frame Size - 1516(def for 802.3), 4544(def for 802.5), 9234
TLVSet() : ?
TLV Set Number in the range 1-65535
LECSELAN 0 already exists
switch_prompt #
Other Reference Options
You will find a list of acronyms, details about technical support, and an index at the back of this manual. The index
contains page references for all switch attribute sections, command parameters, operators, command descriptions and
command examples. There is also a table of commands at the end of this chapter. It lists all switch attributes by their
operator.
See the SmartCell 6A000 User Guide and SmartCell ZX-250 User Guide for details on how to use the switch. The user
guides contain information about switch configuration, maintenance, and SNMP (simple network management
protocol), as well as an overview of switch capabilities.

SmartCell 6A000/ZX-250 Reference Manual 1-5
Introduction
Switch Attribute
This section—immediately below the heading—gives a brief description of what the switch attribute does. A detailed
description of each command is available under "Descriptions."
"X" under any of these headings indicates the switch attribute is applicable to that software type.
Parameters
Operators make the switch attribute work. Operators pertaining to each switch attribute are listed immediately below
the "Operators" heading. The command is the switch attribute combined with the operator. A list of possible switch
operators follows. You can use an alias when a word in parentheses appears. However, only the operators not in
parentheses are used in this manual.
SERVER SVC
XX
Table 1-1 List of Operators
Operator Action
add (create) Adds new object
activate Activates an existing but deactivated object
backup Backs up switch configuration
clear Clears (initializes to 0) properties of an object
disable Lowers privilege level
deactivate Deactivates an existing object
delete (remove) Deletes existing object
enable Raises privilege level
exit Exits from console
flush Flushes all entries
history Shows past console commands
modify (set) Sets properties of an existing object

1-6 SmartCell 6A000/ZX-250 Reference Manual
Introduction
Operators
Parameters appear in the parameter tables in the same order and spelling as the switch shows them.
Most switch attribute descriptions show two tables—Input Parameter and Output Parameter. If the parameter has
already been described in the input parameter table, no reference to it appears in the output parameter table. The output
parameter table contains only parameters that have not been described in the input parameter table or that are written
very differently on output despite having the same meaning.
passwd Changes passwords
reboot Reboots the switch
restart Restarts LANE and IP-ATM clients
restore Restores switch configuration
setup Sets up switch
show (display) Shows properties of an object
OPERATOR ACTION
shutdown Shuts down switch
start Starts server
stop Stops server
update Upgrades firmware
Table 1-2 Operator Table Explanation
Parameter Description Value/Field Size Default
[InputorOutputField]
(</d>) What the switch puts on your screen (either as input or output) relating to the console command you are
executing. The [InputParameter] is an entry you
need to complete if you do not accept the default.
The [OutputParameter] shows information from the
switch. Requires no input. This example is available
only within the detailed information table.
Unit of measurement/
Maximum field size
for input entry.
Option
offered by
the switch.
Table 1-1 List of Operators
(
Continued
)
Operator Action

SmartCell 6A000/ZX-250 Reference Manual 1-7
Introduction
Only one parameter table in a switch attribute section means either that switch attribute uses only input parameters or
that the output parameters are identical to the input parameters. The heading of the table indicates which is the case. If
the table heading says Input Parameter or Output Parameter, only input or output parameters apply to this switch
attribute. However, if the table heading says Parameter, the table contains both input and output parameters, and their
field names and definitions are identical.
Some output parameters show either (</d>) or (</s>) to indicate that a filter flag is available and that parameter is
available only when you type either /d (detailed information) or /s (summarized information) after the command. If
you do not type these command extensions, the parameters do not appear. Further explanations are given at relevant
sections. See "SVC" for an example.
The following table gives details about several of the most common parameters in this manual; a shorter description
of these parameters appears at the relevant sections within the manual:
With [IndexNumber], [PortNumber], [Client Number], and other parameters that default to"ALL", unless youspecify
a number at that input field, the switch gives ALL information pertaining to that parameter field.
Table 1-3 Parameter Table Explanation
Parameter Description Value/Field Size Default
[PortNumber] Port number on the switch. Port
numbers can be any of the physical
ports on the local switch. Specifying
"ALL" causes all related values for the
ports to be affected by the command.
Port B4 is the CPU port. The
SmartCell 6A000/ZX-250 reserve
this port foruse by the CPU forlocal
servers and clients. Therefore, B4
port is usually not listed. Only ALL,
A1-A4, B1-B3, C1-C4, and D1-D4
are listed.
ALL or A1
[ATM Address] ATM address assigned to the port,
client, or server according to ATM
Forum specifications.
13-20 bytes. Hex-based,
dot-decimal format separated by
colons/
59 characters
usually no default
[ClientNumber] Number of the client. Each client on
the switch must have a unique client
number. Client numbers are shared
between LAN emulation (LANE)
clients and IP/ATM (IP over ATM)
clients.
0 through 127/
Up to 3 characters ALL

1-8 SmartCell 6A000/ZX-250 Reference Manual
Introduction
Descriptions
The following is an example of a description section. It is located under "BUSELAN." Note the detailed description
of the command following the table.
Examples
Examples are copied exactly from the switch console to show you what you should see. They appear at the end ofeach
section in the same order as the operators are listed at the start of each section. There is no significance to the order in
which the examples appear, except that show usually appears after the other command examples to demonstrate how
a command can change a characteristic of the switch. Unless they fit on the current page, examples usually begin at
the top of a page. The location of every command example appears in the index under "Examples".
Examples show how you must enter console commands at the switch prompt (indicated in bold - modify buselan
(console command)). The other bold text (1, 103, pvc, 802.5, 4544) is the input parameters that modify this switch
attribute (BUSELAN). The text in brackets (immediately following the parameter field - for example,
ELANType(802.3)) indicates the current default. See the following examples.
switch_prompt # modify buselan(console command)
ELANNumber(0) :103(input entry)
ELANName(ELAN102) :elan103(input entry)
ConnectMethod(SVC) :pvc(input entry)
ELANType(802.3) :802.5(input entry)
Multipoint(YES) : (accept default)
MTU(1516) :4544 (input entry)
switch_prompt #
Table 1-4 Description Table Explanation
Operator Parameters/Permissions Description
console
command [InputParameter] <whatyoutype>
(Privilegelevelthisconsolecommand
allows:)
Administrator or All
This section provides detailed descriptions of the command
(operator and switch attribute) and discusses what the
command does andhow and when it is used. Other relevant
information appears here.
Table 1-5 Description Table Example
Operator Permissions/Parameters Description
modify buselan [ELANNumber] <elannumber>
[ELANName] <elanname>
[ConnectMethod] <connectmethod>
[ELANType] <elantype>
[Multipoint] <distributevcctpe>
[MTU] <maximumframesize>
Administrator
Changes the behavior of the BUS parameters for a
specified ELAN. The specified ELAN is then
deleted and recreated. If the corresponding
LESELAN exists, then the modified BUSELAN
should have the same characteristics as that
existingLESELAN becausetheirparameters need
to match.

SmartCell 6A000/ZX-250 Reference Manual 1-9
Introduction
switch_prompt # show buselan
ELANNumber : 103
ELAN : elan103
ELAN Number : 103
ELAN Name : elan103
ATM Address :39:00:00:00:00:00:00:00:20:D4:14:15:00:00:20:D4:14:15:66:02
Max Frame Size : 4544
Connection Method : PVC
Distribute VPI/VCI: 0/50
LAN Type : 802.5
Multipoint : YES
switch_prompt #
List of Commands and Possible Switch Attributes
add (create)
delete (remove)
AlarmConfig BUSELAN Community ELAN
IISPRoute IPATMClient IPATMPVC LANEClient
LECSAddress LECSELAN LECSELANLEC LECSTLVSET
LESELAN PVC Route TrafficDescriptor
TrapCommunity UNIRoute WellKnownAddress
BUSClient BUSELAN Client Community
ELAN IISPRoute IPATMPVC LECSAddress
LECSELAN LECSELANLEC LECSTLVPARAM LECSTLVSET
LESClient LESELAN PVC PVCByID
Route TrafficDescriptor TrapCommunity UNIRoute
WellKnownAddress

1-10 SmartCell 6A000/ZX-250 Reference Manual
Introduction
modify (set)
AlarmConfig AlarmVerbose BUSELAN CACParams
ILMIAdminStatus IPAddress IPATMClient LANEClient
LECSAddress LECSELAN LECSELANLEC LECSTLVSET
LESELAN LogAlarmMask LogBuffer LogPrint
LogTrace MyNMAddr NetPrefix PortAutoDetect
PortConifg PortMode PortTrafficCongestion Prompt
Rows SigConfig SwitchConfig SwitchName
SwitchTrafficCongestion TrustedNMS VCMask
