8H02-16 User’s Guide 1-1
CHAPTER 1
INTRODUCTION
Welcome to the Cabletron Systems 8H02-16 SmartSwitch 10/100
User’s Guide
. This guide describes the 8H02-16 SmartSwitch and
provides information concerning network requirements, installation,
troubleshooting, and the use of Local Management for device local
control and management.
1.1 USINGTHIS GUIDE
Read through this guide completely to understand the 8H02-16
SmartSwitch features, capabilities, and Local Management functions. A
general working knowledge of Ethernet and IEEE 802.3 type data
communications networks and their physical layer components is helpful
when using Local Management.
NOTE
In this document, the 8H02-16 SmartSwitch is referred to as
either the “8H02-16” or the “device.”

Chapter 1: Introduction
1-2 8H02-16 User’s Guide
1.2 STRUCTURE OFTHIS GUIDE
This guide is organized as follows:
Chapter 1,
Introduction , outlines the contents of this manual and briefly
describes the 8H02-16 features. Directions about how to receive
additional help and a list of related manuals are also included.
Chapter 2,
Network Requirements , explains the network requirements
to consider before installing the 8H02-16.
Chapter 3, Installation , provides instructions on how to install the unit
and connect segments to the device.
Chapter 4, Troubleshooting , details the 8H02-16 LANVIEW LEDs that
enable you to quickly diagnose network/operational problems.
Chapter 5, COM Port and Telnet Connections , describes how to attach
a management console to the 8H02-16 to access Local Management (LM)
or attach an uninterruptible power supply (UPS).
Chapter 6,
Local Management , describes how to access Local
Management and use the Local Management screens to manage the
8H02-16.
Appendix A,
Specifications , contains information on functionality and
operating specifications, connector pinouts, environmental requirements,
and physical properties.
Appendix B,
FE-100TX and FE-100FX Specifications , contains
information about FE-100TX pinouts and information concerning cable
types used with the FE-100FX.
Appendix C,
Optional Installations and Mode Switch Bank Settings ,
describes how to remove the top cover to gain access to and set the Mode
Switch Bank, and install optional Fast Ethernet Interface Modules.

8H02-16 Overview
8H02-16 User’s Guide 1-3
1.3 8H02-16 OVERVIEW
The 8H02-16 is a standalone 16-port high-speed network switch device
that supports traditional switching (bridging). Ports 15 and 16 support
optional Fast Ethernet Interface Modules and can provide uplinks to
100BASE-TX or 100BASE-FX fast Ethernet networks.
The 8H02-16 is used to connect individual high-bandwidth user devices,
such as workstations, and provide a central switching point for multiple
Ethernet segments built using devices such as Cabletron Systems
HUBSTACK or other third party stackable devices.
The 8H02-16 is a tabletop unit that can also be installed in a standard
19-inch rack using the supplied rack mounting hardware.
The 8H02-16 has a universal ac power supply with automatic voltage
sensing that allows operation using 100–125 or 200–250 Vac, 50/60 Hz.
1.3.1 8H02-16 Features
The 8H02-16, shown in Figure 1-1, has the features listed below.
Figure 1-1 The 8H02-16
• Intel i960 RISC processor control
• 14 Port High-Speed Workgroup Switch with two optional ports for
Fast Ethernet Interface Modules providing high speed uplinks to
100 Mbps fast Ethernet technologies
PWR
CPU
RESET
8H02-16
COM
SmartSwitch 10/100
WITH S ECURE F AST VIRTUAL NETWORKING
1X 2X 3X 4X 5X 6X 7X 8X 9X 10X 11X 12X 13X 14X 15 16
Smart
SWITCH
RESET Button
COM Port
System LEDs
Port Status LEDs
Network Ports 1-14
Fast Ethernet Interface
Module Ports 15 & 16
174248
MMAC

Chapter 1: Introduction
1-4 8H02-16 User’s Guide
• Full Duplex Switched Ethernet (FDSE) support for 20 Mbps links to
bandwidth intensive users/servers
• Runtime IP Address Discovery that allows the 8H02-16 to send out a
RARP or BootP request to determine its IP address
• Manageable using Simple Network Management Protocol (SNMP)
and Remote Monitoring (RMON)
• Support for traditional switching services as well as for Cabletron
Systems S
ECURE F AST Switching Virtual Network technology
• Possible linking of existing stackable or third party hubs to 100 Mbps
Fast Ethernet backbones
• IEEE 802.3 compatibility with support for IEEE 802.1d and DEC
Spanning Tree Algorithms
• LANVIEW Diagnostic LEDs
1.3.2 Connectivity
The 8H02-16 connects to Ethernet networks or workstations through
fourteen RJ45 ports on the front panel. These ports support Unshielded
Twisted Pair (UTP) and Shielded Twisted Pair (STP) cables at lengths up
to 100 meters. The ports are IEEE 802.3 10BASE-T compliant.
The 8H02-16 has two front panel slots (ports 15 and 16) for optional Fast
Ethernet Interface Modules to support an uplink to 100 Mbps Ethernet
backbones or a high speed connection to a local server.
1.3.3 Full Duplex Switched Ethernet
Each switched Ethernet port supports full wire-speed Ethernet
communications and can be configured to operate in Full Duplex
Switched Ethernet mode.

8H02-16 Overview
8H02-16 User’s Guide 1-5
1.3.4 Management
Management of the 8H02-16 is accomplished using Local Management
tools or remote SNMP management stations. Out-of-band local
management is provided through the RS232 COM port on the front panel
using a VT100 terminal or a VT100 terminal emulator. In-band remote
management is possible through any SNMP compliant Network
Management Software.
1.3.5 Traditional Switching
The 8H02-16 provides traditional Switching or S ECURE F AST Switching
Virtual Network Services between all of the front panel interfaces
including the optional ports 15 and 16.
Through Cabletron Systems Synthesis framework, the 8H02-16 supports
operations in traditional Switching mode or S
ECURE F AST Switching
mode. S
ECURE F AST Switching allows for future migration to Virtual
Network technologies without requiring the replacement of existing
equipment.
1.3.6 Standards Compatibility
The 8H02-16 provides IEEE 802.1d Spanning Tree Algorithm (STA)
support to enhance the overall reliability of the network and protect
against “loop” conditions. The 8H02-16 supports a wide variety of
industry standard MIBs including RFC 1213 (MIB II), RFC 1271
(RMON), RFC 1371 (RS232 MIB), RFC 1493 (Bridge MIB) and RFC
1354 (FIB MIB). A full suite of Cabletron Systems Enterprise MIBs
provide a wide array of statistical information to enhance troubleshooting.
1.3.7 LANVIEW Diagnostic LEDs
LANVIEW diagnostic LEDs serve as an important troubleshooting aid by
providing an easy way to observe the status of individual ports and overall
network operations. Chapter 4 provides details about the 8H02-16
LANVIEW LEDs.

Chapter 1: Introduction
1-6 8H02-16 User’s Guide
1.4 LOCAL MANAGEMENT FEATURES
Local Management provides the tools that allow management of the
8H02-16 and any of the optional Fast Ethernet Interface Modules
installed as ports 15 and 16. It also allows the following tasks to be
performed:
• Assign an IP address and subnet mask to the 8H02-16.
• Select a default gateway and default interface.
• Control local and remote access.
• Designate workstations to receive SNMP traps from the 8H02-16.
• Configure module specific SNMP MIB objects including the IETF
Bridge MIB objects and many of the RMON MIB objects.
Chapter 6 provides detailed information about Local Management.
1.5 OPTIONAL FEATURES
The two optional Memory Upgrade Kits for the 8H02-16 SmartSwitch
are listed below:
• The 8H02-16-MEM-UGK Memory Upgrade Kit provides an 8 MB
DRAM SIMM that allows the 8H02-16 to run SFS (Secure Fast
Switching) and all groups of RMON.
• The 8H02-8D/4F-ADV Advanced Memory Upgrade Kit provides
8 MB DRAM, 4 MB of FLASH with a preloaded image, and image
diskettes that allows the 8H02-16 to run VLAN (Virtual Local Area
Network), SFS, and RMON.

Document Conventions
8H02-16 User’s Guide 1-7
• Cabletron Systems provides Fast Ethernet Interface Modules to
support uplinks to 100 Mbps Ethernet backbones or high speed
connections to local servers. The Fast Ethernet Interface Modules are
listed in Table 1-1.
1.6 DOCUMENT CONVENTIONS
The following conventions are used throughout this document:
Table 1-1 Fast Ethernet Interface Modules
P/N Description Application
FE-100TX Uses RJ45
connector Supports Unshielded Twisted Pair (UTP) cabling.
FE-100FX Uses SC
connector Supports multimode fiber optic cabling.
NOTE
Note symbol. Calls the reader’s attention to any item of
information that may be of special importance.
TIP
Tip symbol. Conveys helpful hints concerning procedures or
actions.
!
CAUTION
Caution symbol. Contains information essential to avoid
damage to the equipment.
Electrical Hazard Warning symbol.Warns against an action
that could result in personal injury or death due to an electrical
hazard.
WARNING
Warning symbol.Warns against an action that could result in
personal injury or death.

Chapter 1: Introduction
1-8 8H02-16 User’s Guide
1.7 GETTING HELP
If you need additional support related to this device, or if you have any
questions, comments, or suggestions concerning this manual, contact
Cabletron Systems Technical Support:
Before calling Cabletron Systems Technical Support, have the following
information ready:
• A description of the failure
• A description of any action(s) already taken to resolve the problem
(e.g., changing mode switches, rebooting the unit, etc.)
• A description of your network environment (layout, cable type, etc.)
• Network load and frame size at the time of trouble (if known)
• The serial and revision numbers of all Cabletron Systems products in
the network
• The device history (i.e., have you returned the device before, is this a
recurring problem, etc.)
• Any previous Return Material Authorization (RMA) numbers
Phone [phone]
Monday – Friday; 8 A . M . – 8 P . M . Eastern Time
CompuServe GO CTRON from any ! prompt
Internet mail [email protected]
FTP ctron.com (134.141.197.25)
Login
anonymous
Password your email address
BBS [phone]
Modem setting 8N1: 8 data bits, 1 stop bit, No parity
For additional information about Cabletron Systems products, visit our
World Wide Web site: http://www.cabletron.com/

Related Manuals
8H02-16 User’s Guide 1-9
1.8 RELATED MANUALS
The following manuals may help the user to control and manage the
8H02-16 using SNMP network management systems:
Cabletron Systems SPECTRUM Element Manager for Windows
Cabletron Systems SPECTRUM and SPECTRUM Portable Management
Applications
(SPMA) products
Third Party SNMP compliant Network Management Packages

Chapter 1: Introduction
1-10 8H02-16 User’s Guide
