Cadillac 2011 SRX CROSSOVER User manual

Overview ........................................................ 1-1
Overview .................................................. 1-2
Features and Controls ..................................... 2-1
Features and Controls ................................ 2-2
Navigation Audio System ................................ 3-1
Navigation Audio System ............................ 3-2
Voice Recognition ........................................... 4-1
Voice Recognition ...................................... 4-2
Vehicle Customization ..................................... 5-1
Vehicle Customization ................................. 5-2
Index ................................................................ 1
2005 Cadillac SRX Navigation System M

GENERAL MOTORS, GM and the GM Emblem,
CADILLAC and the CADILLAC Crest & Wreath and the
name SRX are registered trademarks of General
Motors Corporation.
The information in this manual supplements the owner
manual. This manual includes the latest information
available at the time it was printed. We reserve the
right to make changes in the product after that
time without notice.
Keep this manual with the owner manual in the vehicle,
so it will be there if it is needed while you are on the
road. If the vehicle is sold, leave this manual and
the owner manual with the vehicle.
Litho in U.S.A.
Part No. 25769279 A First Edition ©Copyright General Motors Corporation 05/14/04 All Rights Reserved
ii

Overview .........................................................1-2
Navigation System Overview ............................1-2
Getting Started ...............................................1-4
Section 1 Overview
1-1

Overview
Navigation System Overview
1-2

A. BAND Key. See “Finding a Station” under Navigation
Audio System on page 3-2
.
B. CD Key. See
Navigation Audio System on page 3-2
or CD/DVD Player on page 3-21 .
C. DVD Key. See “Playing a DVD” under
CD/DVD
Player on page 3-21
.
D. TUNE/SEEK Key. See “Playing the Radio” under
Navigation Audio System on page 3-2 .
E. Audio/Adjust Key. See “Main Audio Menu” under
Navigation Audio System on page 3-2 .
F. Power-Volume Knob. See “Hard Keys” under
Using
the Navigation System on page 2-2
.
G. Navigation System Screen
H. RPT (Repeat) Key. See “Hard Keys” under
Using
the Navigation System on page 2-2
.
I. MAP Key. See “Hard Keys” under
Using the
Navigation System on page 2-2
.
J. ROUTE Key. See “Hard Keys” under
Using the
Navigation System on page 2-2
.
K. MENU Key. See “Hard Keys” under
Using the
Navigation System on page 2-2
.
L. TILT Key. See “Hard Keys” under
Using the
Navigation System on page 2-2
.
1-3

Getting Started
Before you begin to operate the navigation system, read
this manual thoroughly to become familiar with it and
to understand how the system works.
The navigation system allows you to do the following:
•Plan a route with provided turn-by-turn route
and map guidance with voice prompts. See
Plan Route on page 2-10 for more information.
•Select a destination using various methods
and choices.
•Receive broadcast announcements on traffic and
emergency alert communications.
The information in the system may not always be
complete. Road conditions such as prohibited turns,
detours, and construction zones, change frequently. It is
important to consider whether you can follow the
directions given by the system for the current conditions.
When getting started, you may set the navigation
system to your preference using various options. To do
so, reference the following topics:
•To adjust screen appearance, language, clock,
English/metric measurements, or other options, see
“Main Audio Menu” under
Navigation Audio
System on page 3-2
.
•To adjust voice guidance volume or other navigation
settings, see
Setup Menu on page 2-4 .
1-4

Features and Controls ......................................2-2
Using the Navigation System ...........................2-2
Setup Menu ...................................................2-4
Plan Route ..................................................2-10
Edit Memory Point ........................................2-10
Edit Waypoint ...............................................2-14
Edit Avoid Point/Area ....................................2-17
Enter Destination ..........................................2-19
Route Preference ..........................................2-28
Maps ..........................................................2-30
Symbols ......................................................2-33
Remote Keyless Entry System ........................2-39
OnStar
®
System ...........................................2-39
Global Positioning System (GPS) ....................2-39
Vehicle Positioning ........................................2-40
Problems with Route Guidance .......................2-41
If the System Needs Service ..........................2-41
Ordering Map DVDs ......................................2-41
Database Coverage Explanations ....................2-41
Section 2 Features and Controls
2-1

Features and Controls
Using the Navigation System
This section presents basic information you will need to
know to operate the navigation system.
Use the keys located on each side of the navigation
screen, as well as the available touch-sensitive screen
buttons, to operate the system. See
Navigation
System Overview on page 1-2
for more information
on location.
Once the vehicle is moving, various functions will be
disabled to reduce driver distraction.
Hard Keys
The following hard keys are located to the left of the
navigation screen:
BAND: Press the BAND key to access the band screen
and switch between AM, FM1, FM2, XM1, XM2, and
WX, if equipped. See “Finding a Station” under
Navigation Audio System on page 3-2 .
CD: Press the CD key to play a CD. The CD screen
will be displayed. See
Six-Disc CD Changer on
page 3-18
or CD/DVD Player on page 3-21 .
DVD: Press the DVD key to play a DVD. The DVD
screen will be displayed. See CD/DVD Player on
page 3-21
.
yTUNE/SEEK z:Press the TUNE/SEEK up or
down arrows to go to the next or previous radio station
and stay there. See “Finding a Station” under
Navigation Audio System on page 3-2 .
e/z:Press the audio/adjust key to view the main
audio menu. See “Main Audio Menu” under
Navigation
Audio System on page 3-2
.
PWR-VOL (Power/Volume Knob): Press the
power/volume knob to turn the audio and navigation
systems on and off. Turn the knob to increase or
decrease the volume to the audio system.
The following hard keys are located to the right of the
navigation screen:
RPT: Press the repeat key to repeat the current voice
guidance navigation prompt.
2-2

MAP: Press the MAP key to view the map screen
showing current vehicle position.
The map screen can also display the following
information:
•North or Heading Up symbol. See Symbols on
page 2-33
.
•Map scale. See Maps on page 2-30 .
•Distance to destination.
•GPS symbol if GPS signal is not being received.
See
Global Positioning System (GPS) on
page 2-39
.
•Options you have selected for reaching your
current destination.
•Driver Information.
•Radio band and presets.
ROUTE: Press the ROUTE key to display the PLAN
ROUTE menu. See
Plan Route on page 2-10 .
MENU: Press the MENU key to display the SETUP
MENU. See Setup Menu on page 2-4 .
TILTX:Press the TILT key to open the navigation
system faceplate for loading or removing the map DVD,
a video DVD, or an audio CD. This key can only be
used while the vehicle is in PARK (P).
Alpha-Numeric Keypad
Letters of the alphabet, symbols, punctuation, and
numbers, when available to you, will be displayed on
the navigation screen as an alpha or numeric keypad.
The alpha keypad will be displayed when the system
needs you to input a city or street name. You can also
touch Char at the bottom of the alpha keypad to
access the numeric keypad when inputting a house
address, punctuation mark, or other character.
Touch A - Z to return to the alpha keypad.
All characters are touch-sensitive screen buttons.
Touch a character to select it.
Select the space symbol to enter a space between
characters or the words of a name.
V:Select the backspace symbol if you have selected
an incorrect character.
To make your name selections easier, the system will
only allow you to select a character which can follow the
last one entered. For example, if you enter Z, you
would not be allowed to follow it with T. The system will
highlight the available characters and darken the
unavailable characters.
2-3

If you are unsuccessful when inputting a name, it may
need to be selected differently. It is also possible that the
map DVD database may not contain that information
or the correct search area has not been selected.
See
Database Coverage Explanations on page 2-41 for
more information.
Touch Sensitive Buttons
Touch-sensitive buttons, or screen buttons, are located
on the screen. When you have successfully selected
a screen button, a beep will be heard. These buttons will
be highlighted when a feature is available and dim
when they are unavailable. There are some toggle
screen buttons that will be light blue when active and
dark blue when inactive.
Setup Menu
MENU: Press the MENU key located to the right of the
navigation screen to access the SETUP MENU.
The SETUP MENU allows you to adjust such things as
map appearance, navigation settings, and voice
guidance volume.
2-4

Navigation Settings
This menu allows you to change the following options
for the navigation system.
Restore Default Settings
This feature will automatically reset the system to the
default values.
To restore the default settings, do the following:
1. Touch the Restore Default Settings screen button.
2. Touch Enter.
3. Touch Return to exit this menu.
System Configuration
This feature allows you to reconfigure the navigation
system. If you begin to drive your vehicle during
this procedure, the system will not be able to adjust the
position or direction of your vehicle.
Touch the System Configuration screen button to view
the following choices:
Adjust Vehicle Position: To correct the position of
your vehicle on the map or to change vehicle position,
do the following:
1. Touch the Adjust Vehicle Position screen button.
The system will display Position Adjustment. The
vehicle location symbol and the scroll symbol
will appear on the map.
2. Use the scroll symbol and the zoom in/zoom out
feature to locate the vehicle position on the map.
3. Touch Enter to set the vehicle position. The system
will display Position Adjustment and two arrows will
appear on the map screen.
4. Touch the arrows to adjust the direction of the
vehicle. As you touch the arrows, you will see
the vehicle symbol direction changing.
5. When you have set the vehicle to the correct
direction, touch Enter. Relocation Complete
will be displayed.
6. Touch Return to exit this menu.
2-5

Calibrate Vehicle Speed Signal: If there are tire
pressure differences or if a spare tire is installed, the
navigation system will automatically recalibrate the
system. You may also choose to calibrate it yourself by
doing the following:
1. Touch Start to begin calibration.
2. Touch Return to exit this menu.
Time to Destination
This feature allows you to view the estimated time to
travel from your current position to the destination, and
to reset the average speed to factory default settings.
Estimated travel time is based on calculated route
information and the vehicle’s average speed. Touch ON
to turn this feature on, OFF to turn this feature off, or
Reset to restore vehicle speed default settings. With this
feature on, the estimated travel time to destination will
display along with the distance to destination.
Quick POI (Point of Interest) Selection
This menu allows you to choose a point of interest (POI),
such as gas stations, restaurants, hotels, etc. to be
displayed on the map screen. You can also set a
destination to a specific POI.
2-6

Setting the Quick POI menu
To set the Quick POI list displayed on the map screen,
do the following:
1. Select the category you would like to replace.
2. Select a Quick POI category from the Quick POI
selection menu list. The system will return to the
Quick POI selection screen when a POI is selected.
3. Touch Return to save the setting and return
to previous menu.
Displaying Quick POI Icons
To display POI icons of a category on the map screen,
do the following:
1. Touch the map screen once.
2. Touch the POI button. The Quick POI Selection list
will be displayed.
3. Select a category type or touch List Categories Or
All Local POIs to display the icons of the selected
category on the map screen.
Removing Quick POI Icons
To remove POI icons from the map screen, do the
following:
1. Touch the map screen once.
2. Touch the POI OFF screen button. The current POI
icons will be removed from the map screen.
Setting a Destination Using Quick POI
This feature will allow you to choose a POI as your
destination. To set a destination using a POI, do
the following:
1. Touch the POI icon on the map screen that you
wish to set as a destination.
The selected icon will be surrounded by a blinking
box, and the name of the icon will be displayed.
You may also touch INFO to view the POI name,
address, city, and phone number, if available.
2. Touch the ENT DEST screen button.
If a final destination has already been entered, you
can add the POI as a waypoint. See
Edit Waypoint
on page 2-14
for more information.
3. Touch Enter to start planning your route.
4. To start route guidance, touch Start or begin driving
the vehicle. Route guidance will automatically begin
after a short distance.
If you wish to cancel the route you have just set, do the
following:
1. Press the ROUTE hard key.
2. Touch the Route Preference screen button.
3. Touch the Cancel Route screen button.
4. Select YES to cancel or NO to continue.
2-7

Guidance Appearance
This menu allows you to set the guidance appearance
screen options. This screen is displayed on the map
while on a planned route. The current settings will
appear as light blue.
Split Map: Select this feature to display the guidance
screen on the map at all times.
Full Screen: Select this feature to display the guidance
screen on the map when approaching a maneuver.
Turn List: Select this feature to have the guidance
screen display several upcoming turns. Directional
arrows, street name, and distance to the next turn will
be displayed. As you approach the next turn, the system
will display a closer view of the upcoming maneuver.
Arrow: Select this feature to have the guidance screen
display the next turn. A directional arrow, street
name, and distance to the turn will be displayed. As you
approach the turn, the system will display a closer
view of the upcoming maneuver.
2D: Select this feature to display the guidance screen
as a two-dimensional view.
3D: Select this feature to display the guidance screen
as a three-dimensional view.
2-8

Map Appearance
This menu allows you to set the map appearance
screen options. The current setting will appear as
light blue.
2D: Select this feature to display the map as a
two-dimensional view.
3D: Select this feature to display the map as a
three-dimensional view.
Set 3D Viewing Angle: This feature allows you to
adjust the 3D viewing angle. To do so, do the following:
1. Touch 3D on the MAP APPEARANCE menu.
2. Touch Set 3D Viewing Angle.
The map screen with the 3D viewing angle bar will
be displayed.
3. Touch the up or down arrows to set the
viewing angle.
4. Touch Return to save your settings and to exit this
menu or touch Reset to restore the viewing angle to
the default setting.
Voice Guidance Volume Settings
This feature allows you to set the voice prompt volume
level or to turn voice prompts on or off.
Set the voice prompt volume level by touching the
numbered buttons to increase or decrease the volume
level. You may also choose to turn the voice prompts off.
Then touch Return to save your setting and to return
to the SETUP MENU.
If a voice prompt is active while the audio system
is on, the audio system volume will decrease and the
voice prompt will be heard through the driver’s side
front speaker.
Voice prompts will not be heard while using voice
recognition.
2-9

Plan Route
To plan a route, press the ROUTE key. The PLAN
ROUTE menu will be displayed.
You may use one of several destination entry methods
to plan a route. See
Enter Destination on page 2-19
for more information.
Edit Memory Point
This feature allows you to store, delete, and edit
memory points. Touch the Edit Memory Point screen
button from the PLAN ROUTE menu to access the EDIT
MEMORY POINT screen.
You can store memory points in four different categories,
personal, business, entertainment, and marked point.
2-10

Memory points are stored when you select either
START or MARK when setting a destination on the map
or when you are storing destinations in memory.
A total of 60 locations can be stored. The last
10 destinations entered will be stored under Previous
Destination. In addition, one memory point can be stored
under the Home category.
If all 60 stored points are entered, the system will notify
you that there is no available storage left in memory
points. A memory point must be removed before storing
additional memory points.
Registering Memory Points
To store a memory point, do the following:
1. Select a category from the EDIT MEMORY
POINT menu.
2. Touch REGISTER.
3. Select a method for entering a destination. A map
will appear displaying the memory point’s location.
4. If available, touch INFO to view the address
information for the memory point.
5. Touch Enter to store the point.
Editing Memory Points
This feature allows you to edit the contents stored in
memory. The following options are available:
Icon Editing of a Memory Point
Each memory point is displayed with a default icon.
To edit an icon, do the following:
1. Select the category of the memory point.
2. Select the item you want to edit.
3. Touch the icon. The EDIT MEMORY POINT icon
screen will appear.
4. Touch the icon you would like to use. The
system will then return to the EDIT MEMORY
POINT menu.
5. Touch Return to go back to the previous screen.
You will see the new memory point icon on the map.
When selecting an icon, you can choose from
18 different icons, three of which are sound icons.
The same icon may be used for other memory points
as well.
2-11

Name Editing of a Memory Point
To modify the name of a stored memory point, do the
following:
1. Select the category of the memory point.
2. Select the item you want to edit.
3. Touch the NAME screen button and use the alpha
keypad to edit the name. Names may contain up to
15 alpha and/or numeric characters.
4. Touch Return to go to the previous screen.
Moving Memory Points
To move a memory point from one category to another,
do the following:
1. Select the category of the memory point.
2. Select the memory point you want to edit.
3. Touch CATEGORY. A list of categories will appear.
The current category for the item will be highlighted
and cannot be selected.
4. Touch the screen button for the category you want
the memory point placed in. A pop-up window will
appear displaying the change in category.
5. Touch Return to go back to the previous screen.
Adjusting a Memory Point
To relocate a memory point’s location, do the following:
1. Select the category of the memory point.
2. Select the memory point you want to edit.
3. Touch POSITION. A map screen with the position
of this memory point will appear.
4. Touch anywhere on the screen to activate the scroll
feature and relocate the memory point. See
Maps
on page 2-30
.
5. Touch Enter to save the memory point’s
new location.
6. Touch Return to go back to the previous screen.
Changing the Phone Number of a
Memory Point
To edit or add the phone number of a memory point, do
the following:
1. Select the category of the memory point.
2. Select the memory point you want to edit.
3. Touch PHONE and use the numeric keypad to edit
or add the number.
4. Touch the RETURN button to take you back to the
previous screen when you have finished.
2-12

Deleting Single Memory Points
To delete a single memory point, do the following:
1. Press the ROUTE key.
2. Touch EDIT MEMORY POINT.
3. Select the category of the memory point.
4. Touch DELETE.
5. Select the memory point you want to delete.
A confirmation window will appear.
6. Touch YES to delete the memory point or NO to
return to the previous menu.
7. Touch Return to go back to the previous screen.
Deleting All Memory Points
To delete all of the memory points in a category, do
the following:
1. Press the ROUTE key.
2. Touch EDIT MEMORY POINT.
3. Select the desired category.
4. Touch the DELETE ALL screen button.
A confirmation window will appear.
5. Touch YES to delete the memory points or NO to
return to the previous menu.
6. Touch Return to go back to the previous screen.
Edit Category
To edit the name of a category, do the following:
1. Press the ROUTE key.
2. Touch EDIT MEMORY POINT.
3. Select the category you want to edit.
4. Touch the EDIT CATEGORY screen button and
use the alpha keypad to edit the category name.
The name can consist of up to 15 alpha and/or
numeric characters.
5. Touch Return to go back to the previous screen.
Marked Point
A marked point is a memory point which has been
stored by selecting the MARK screen button while
traveling on a planned route. You can also use the scroll
feature to plan a destination on the map after reaching
the destination, or by moving a memory point to a
marked point category. See “Editing Memory Points”
earlier in this section for more information.
2-13

Previous Destination Memory
Each time you select Start from the map screen, that
destination will be stored as a memory point under
PREVIOUS DESTINATION. This category will store
up to 10 destinations.
When the Previous Destination category contains
more than 10 destinations, the system will remove the
oldest destination stored and add the most recent
one selected to the list.
If you do not want a previous destination to be lost, you
must move the destination into a memory point
category. See “Moving Memory Points” earlier in this
section for more information.
Home Memory
This memory point is stored by selecting Home from the
EDIT MEMORY POINT screen. See “Registering
Memory Points” earlier in this section and “Home” under
Enter Destination on page 2-19 for more information.
Edit Waypoint
Waypoints are destinations you can set along the way
to your final destination. This feature allows you to
add, edit, and delete waypoints.
You may set up to five waypoints on the way to your
final destination.
To access the WAYPOINT menu, do the following:
1. Press the ROUTE key.
2. Touch Edit Waypoint.
2-14
