Cafection Encore lite User manual

SERVICE & INSTALLATION MANUAL
Manufactured by:
Cafection Ventures Inc.
2355, avenue Dalton, Québec (Québec) G1P 3S3 Canada
Tel.: [phone] Fax: [phone]
[email protected] www.cafection.com ELINSA - Revision 3
05/2018
Images may vary from the actual product.

ENCORE LITE Rev. 3 05/2018
www.cafection.com 800-561-6162
2
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
Table of Contents
1 SAFETY INSTRUCTIONS ........................................................................................................................ 5
1.1 Food-Contact Parts ................................................................................................................... 5
1.2 Warnings.................................................................................................................................... 5
1.3 Power Supply ............................................................................................................................ 5
1.4 Disconnect the equipment if:...................................................................................................... 5
2 WARRANTY ............................................................................................................................................. 6
2.1 Warranty Policy .......................................................................................................................... 6
2.2 Warranty Return Procedure........................................................................................................ 7
2.3 Shipping Liabilities...................................................................................................................... 7
3 REFERENCE DRAWINGS ....................................................................................................................... 8
3.1 External View ............................................................................................................................. 8
3.2 Rear View .................................................................................................................................. 9
3.3 Internal View ............................................................................................................................ 10
3.4 Brew Group Assembly ............................................................................................................. 11
3.5 Brewing Process...................................................................................................................... 12
3.6 Main Board .............................................................................................................................. 13
3.6.1 Main Board (PCB) Description ................................................................................. 14
3.7 Hot Water Tank ........................................................................................................................ 15
3.8 Bean Hopper Installation .......................................................................................................... 16
3.9 Water Temperature................................................................................................................... 17
4 INITIAL SETUP ...................................................................................................................................... 18
4.1 On-Site Installation Requirements............................................................................................. 18
4.1.1 Operating Environment ............................................................................................ 18
4.1.2 Power Supply .......................................................................................................... 18
4.1.3 Water Supply........................................................................................................... 18
4.1.4 Tools Required......................................................................................................... 18
4.1.5 Clearance ................................................................................................................ 18
4.2 Specifications........................................................................................................................... 19
4.2.1 Hopper & Canisters Capacities ................................................................................ 19
4.2.2 Water Tank .............................................................................................................. 19
4.2.3 Electrical Requirements............................................................................................ 19
4.3 Unpacking ............................................................................................................................... 20
4.4 Leveling the Equipment............................................................................................................ 21
4.5 Drip Tray Installation ................................................................................................................. 21
4.6 Adjusting the Tank Overflow Cup.............................................................................................. 22
4.7 Water Line Connection............................................................................................................. 23
4.8 Electrical Connection ............................................................................................................... 24
4.9 Loading Products..................................................................................................................... 25
4.9.1 Soluble Canisters..................................................................................................... 25
4.9.2 Bean Hopper ........................................................................................................... 25
4.10 Filter Paper Installation ............................................................................................................. 26
4.11 Chute Kit Installation (Optional)................................................................................................. 27
4.12 Installation Verification .............................................................................................................. 28
4.13 Coin Changer and Bill Acceptor ............................................................................................... 28
Table of Contents

ENCORE LITE Rev. 3 05/2018 3
www.cafection.com 800-561-6162
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
Table of Contents
5 USER INTERFACE.................................................................................................................................29
5.1 Selection Screen Interface........................................................................................................29
5.2 Carafe Mode............................................................................................................................30
5.3 Iced Coffee ..............................................................................................................................31
5.4 Selection Keyboard for People with Disabilities (Optional).........................................................32
6 SERVICE MODE ....................................................................................................................................33
6.1 Users Levels ............................................................................................................................33
6.2 Service Tab ..............................................................................................................................34
6.3 Status Tab................................................................................................................................37
6.4 Password Pop-Up ...................................................................................................................38
6.5 Recipes Tab .............................................................................................................................38
6.5.1 Customization Sub Tab............................................................................................38
6.5.2 Information Sub Tab................................................................................................. 39
6.5.3 Liquids & Ingr. (Ingredients) Sub Tab ........................................................................40
6.5.4 Brew Cycles & Fast Settings Sub Tab ......................................................................41
6.6 System Tab..............................................................................................................................43
6.6.1 System1 Sub Tab ...................................................................................................43
6.6.2 System2 Sub Tab ...................................................................................................44
6.6.3 Tools Sub Tab.......................................................................................................... 46
6.6.4 Network Sub Tab ..................................................................................................... 47
6.6.5 Screen Saver Sub Tab .............................................................................................51
6.6.6 Admin Sub Tab ........................................................................................................ 52
6.7 Media Tab ................................................................................................................................54
6.7.1 Current Playlist Sub Tab........................................................................................... 54
6.7.2 Next Playlist Sub Tab ...............................................................................................54
6.7.3 Video Storage Sub Tab ............................................................................................ 55
6.8 Audit Tab..................................................................................................................................55
6.8.1 Permanent Sales Count...........................................................................................55
6.8.2 Erasable Sales Count............................................................................................... 55
6.8.3 Users Sales Count................................................................................................... 56
7 CLEANING AND SANITIZING ...............................................................................................................57
7.1 "Auto Rinse" Button .................................................................................................................57
7.2 "Cleaning & Sanitizing" Button..................................................................................................57
7.3 Cleaning and Sanitizing Instructions .........................................................................................58
7.4 Recommended Cleaning Tools.................................................................................................59
7.5 Cleaning and Sanitizing Schedule.............................................................................................59
7.6 Overall Cleaning .......................................................................................................................60
7.7 Exterior Cleaning......................................................................................................................60
7.7.1 Touch Screen .......................................................................................................... 60
7.7.2 Drip Tray .................................................................................................................. 60
7.7.3 Waste Bin ................................................................................................................ 61
7.8 Interior Parts Cleaning & Sanitizing ...........................................................................................62
7.8.1 Bean Hopper ...........................................................................................................62
7.8.2 Bean Hopper Plastic Funnel..................................................................................... 63
7.8.3 Soluble Canisters..................................................................................................... 64
7.8.4 Brew Group............................................................................................................. 65
7.8.5 Fan ..........................................................................................................................66
7.8.6 Stainless Steel Coffee Chute.................................................................................... 67

ENCORE LITE Rev. 3 05/2018
www.cafection.com 800-561-6162
4
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
Table of Contents
8 PREVENTIVE MAINTENANCE .............................................................................................................. 68
8.1 Preventive Maintenance (PM) Schedule ................................................................................... 68
8.2 Brew Group Assembly ............................................................................................................. 69
8.3 Outlet Valves ........................................................................................................................... 70
8.4 Hot Water Tank ........................................................................................................................ 71
8.5 Grinder..................................................................................................................................... 72
9 PARTS MAINTENANCE......................................................................................................................... 73
9.1 Hot Water Tank Draining........................................................................................................... 73
9.2 Shutdown and Storage ............................................................................................................ 74
9.2.1 Storing the Brew Group........................................................................................... 74
9.3 Brew Group Assembly ............................................................................................................. 75
9.4 Main Board .............................................................................................................................. 76
9.5 Flash Card Replacement.......................................................................................................... 77
10 TROUBLESHOOTING............................................................................................................................ 78
10.1 Warning Messages List ............................................................................................................ 78
10.2 Error Messages List ................................................................................................................. 79
ANNEX 1 full maintenance schedule................................................................................................... 81
ANNEX 2 monthly maintenance schedule .......................................................................................... 82
ANNEX 3 weekly maintenance schedule ............................................................................................ 83
ANNEX 4 WASTE CHUTE POSITION................................................................................................... 84
ANNEX 5 REQUIRED CLEARANCE ..................................................................................................... 85

ENCORE LITE Rev. 3 05/2018 5
www.cafection.com 800-561-6162
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
Safety Instructions
1 SAFETY INSTRUCTIONS
Basic safety precautions should always be followed when using electrical appliances.
Read all instructions before using this brewing equipment.
1.1 Food-Contact Parts
Cafection recommends cleaning and sanitizing all parts in contact with food prior to installation
and use.
See Cleaning and Sanitizing (section7) for more details.
1.2 Warnings
To minimize the risk of fire or electric shock, do not expose this equipment to rain or moisture.
Do not immerse this equipment in water; it could lead to electric shock or other malfunctions.
Do not use this equipment other than for its intended use.
This equipment contains hot water. Never move it when full.
This brewing equipment is intended for indoor use only.
1.3 Power Supply
Always use a grounded 120VAC60Hz socket outlet rated for 15A service.
Each brewing equipment must have its own electrical outlet, on a dedicated circuit.
Extension cords must not be used.
This brewer is equipped with a polarized alternating current line plug (one blade wider than the
other).
Only use this plug with an outlet in which the prongs can be fully inserted.
1.4 Disconnect the equipment if:
- Damage is done to the power cord.
- The equipment does not work properly.
- The temperature of the power cord or plug increases dramatically during use.
- Unusual conditions occur.
- Whenever a part has to be changed, plugged or unplugged.
FAILURE TO COMPLY CAN CAUSE EQUIPMENT DAMAGE, FIRE OR SERIOUS
INJURIES.
''INITIAL SETUP'' SECTION OF THIS MANUAL MUST BE COMPLETED BEFORE
PLUGGING IN THE BREWER.

ENCORE LITE Rev. 3 05/2018
www.cafection.com 800-561-6162
6
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
2 WARRANTY
2.1 Warranty Policy
Cafection hereby guarantees that the products it manufactured are, to the best of its knowledge,
free from all defects and faulty workmanship. The following warranties and conditions are
applicable:
• All parts in contact with water (outlet valves, heating element, probe, inlet valve, thermostat
and tank float) are warranted against material defects for a period of 90days from the date
of shipment.
• All remaining parts of the brewer are warranted against material and workmanship defects
for one(1)year from the date of shipment.
All warranted parts, services and returns must have prior authorization from Cafection. Please
contact Cafection’s Customer Service at 800-561-6162, ext.310.
The following circumstances will void the warranty policy:
• Use of substitute parts not manufactured or approved by Cafection.
• Improper installation or operation of the equipment.
• Abuse or neglect, including (but not limited to) failure to follow the preventive maintenance
schedule.
• Variation in equipment performance due to excessive mineral deposit or local water
conditions.
• Equipment altered in any way and/or dates, codes or serial numbers removed or modified.
• Equipment damaged in shipment from the customer to Cafection due to improper
packaging.
Please note that labor is not covered by the warranty and that the repair protocol is limited to
replacing the defective part(s). Should any additional repairs need to be done, they will be charged
to the customer.
Equipment or parts will not be accepted without a prior notification to Cafection.
Warranty
2355, avenue Dalton, Québec (Québec) G1P 3S3
Tel.: [phone] - Fax: [phone]
[email protected]
Customer Service Business Hours (EST):
Monday to Thursday: 8am to 8pm
Friday: 8am to 5pm

ENCORE LITE Rev. 3 05/2018 7
www.cafection.com 800-561-6162
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
2.2 Warranty Return Procedure
In order to always offer better, faster service, Cafection requests your cooperation for the return of
parts under warranty. Cafection thanks you in advance for taking the time to follow this procedure:
Contact the Customer Service department to obtain a Return Merchandise Authorization(RMA)
number.
Send a copy of the original invoice to Cafection by fax at 800-463-2739 or by email at
[email protected] for approval.
No parts must be destroyed before receiving a written confirmation from Cafection about credit or
exchange possibilities.
Keep a copy of the original invoice for your records. A copy of the original invoice must be
included with your parts return.
Cafection will not be held responsible for any loss or damage occurring during transport.
MAKE SURE THE MERCHANDISE IS WELL PACKED!
Please use original packaging.
Upon receipt, Cafection will check the merchandise and authorize the repair or replacement by
identical or equivalent parts, if warranty is applicable. Only warranted parts are authorized for
return.
Cafection suggests keeping replacement parts on hand.
The warranty covers regular shipping only. Overnight shipping charges will be applied to your order
when required. Orders must be received before noon (12:00pm EST) to be shipped the same day*.
All returned parts showing no sign of malfunctioning will be subject to
administrative and test fees of $35, plus freight charges associated with the return.
A part returned in unacceptable condition will also be subject to this $35fee and its
warranty may be refused.
*Some conditions may apply.
2.3 Shipping Liabilities
YOU ARE RESPONSIBLE, SHIPMENT MUST BE INSPECTED!
You can refuse delivery if a shipment is damaged. Do not sign the shipment without proper
inspection. Should you choose to accept the delivery, it is mandatory that you record any
significant information on the delivery slip. Remember that you take responsibility of the
merchandise once you have signed the delivery receipt.
You have 24 hours to report and file a claim for concealed damages to the transportation
company.
Failure to comply with this procedure could lead to a claim refusal by the carrier.
FOR MORE INFORMATION, PLEASE CALL CUSTOMER SERVICE AT 800-561-6162, ext.310.
Warranty

ENCORE LITE Rev. 3 05/2018
www.cafection.com 800-561-6162
8
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
3 REFERENCE DRAWINGS
3.1 External View
Drip tray grill
Drip tray
Back splash
Touch screen
Door lock
Metal door
Plastic front
(fascia)
Bean hopper
Top lid
Reference Drawings

ENCORE LITE Rev. 3 05/2018 9
www.cafection.com 800-561-6162
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
3.2 Rear View
Water tank
Outlet valve
Water inlet
Electric box
Back panel
Leveling glides
Overflow tray
Antenna
Reference Drawings

ENCORE LITE Rev. 3 05/2018
www.cafection.com 800-561-6162
10
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
3.3 Internal View
Filter paper
Soluble mixing
chamber
Brew group
Spout
Internal
waste bin
Main board
(see section3.6)
Coffee grinder
(behind the filter paper
roll and protector)
COM connection
Flash card
Fan
Coffee
Hot water
Soluble products
#1 and #2
Soluble
canisters
S
p
o
u
t
-
T
o
p
V
i
e
w
Reference Drawings
Overflow cup

ENCORE LITE Rev. 3 05/2018 11
www.cafection.com 800-561-6162
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
3.4 Brew Group Assembly
Brew chamber
Cylinder
Piston
Coffee spillway
Aluminum frame
Wheel
Manufacturing date
(on the back)
Funnel
Yoke
Reference Drawings

ENCORE LITE Rev. 3 05/2018
www.cafection.com 800-561-6162
12
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
3.5 Brewing Process
Step1 | Rise of the Piston
The ground coffee and the water are dispensed into the brew
chamber during the rise of the piston. This action compresses
the air in the cylinder and forces it through the coffee mixture
in the brew chamber, thereby agitating the brewing coffee.
Step2 | Pause
Once the piston has reached its top point, it will pause to allow the
coffee to brew to the appropriate strength. At the end of the pause
time, there will be one shot of water to clean the brew chamber.
Step3 | Descent of the Piston
The descent of the piston creates a vacuum allowing to extract
the coffee from the grounds through the filter paper and into
the cylinder. The piston makes another pause time, allowing
all the coffee to drain from the brew chamber.
Step4 | Coffee Delivery
The piston follows its course heading to its lowest point. Distribution
of coffee through the spout begins once the piston has lowered below
the coffee spillway. Meanwhile, the brew chamber lifts to allow the
filter paper to move and discard the spent grounds into the internal
waste bin or coffee chute.
1
2
3
4
Reference Drawings

ENCORE LITE Rev. 3 05/2018 13
www.cafection.com 800-561-6162
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
The equipment should always be
unplugged from the electrical outlet
before servicing any component on
this main board.
This is a schematic reference
drawing only. Not to scale.
3.6 Main Board J11 - MDB port - Coin changer / bill acceptor / card reader
J12 - Thermostat board
J22 -
Numeric input
(switches)
J21 - COM port-
Link to touch screen
computer (option 1)
J14 - COM port-
Link to touch screen
computer (option 2)
J18 - 24V DC
output
J6 - 24V DC output - Fan
J2 - 120V AC
input
J19 - 120V AC
output
HIGH VOLTAGE AREA
J3 - 24V DC input
(adjusted to 27V DC)
J27 - 24V DC
output
SW1 - Setup button (white)
SW2 - Service button (black)
Reference Drawings
17ELN01

ENCORE LITE Rev. 3 05/2018
www.cafection.com 800-561-6162
14
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
3.6.1 Main Board (PCB) Description
Interactive Switches and Buttons
1. SW1 Setup Button (White)
This button gives access to the
parameters of the machine and
products through Service mode
(see section6.2 for details).
2. SW2 Service Button (Black)
There are two functions for this
button:
-In Selection mode, pressing this
button will enter the touch screen
calibration utility.
-In Service mode, pressing this
button will display the Factory reset
pop-up menu. This menu allows the
user to reset several settings back
to factory: configuration, passwords
and drink settings.
LEDs light up to indicate
the following statuses:
DS1 Power5V OK
DS15 Low water level
DS13 Brew group out of park position
DS14 Filter paper roll detected
DS18 Water detected in the overflow tray
DS20 Power 3.3V
DS30 Computer COM indicator
LEDs light up to indicate
the following parts are in use:
24VDC Outputs:
DS2 Ingredients motor (coffee # 1)
DS3 Ingredients motor (coffee # 2)
DS4 Ingredients motor (soluble #2)
DS5 Ingredients motor (soluble #1)
DS6 Hot water valve (coffee)
DS7 Hot water valve (soluble)
DS8 Hot water dispensing valve
DS21 N/A
DS23 Auxiliary
DS24 Ingredients motor (coffee # 3)
DS25 Fan
DS29 Soluble whipper motor
120V AC Outputs:
DS9 Brew group motor
DS12 N/A
DS11 Coffee bean grinder
DS10 Water inlet valve
Reference Drawings

ENCORE LITE Rev. 3 05/2018 15
www.cafection.com 800-561-6162
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
3.7 Hot Water Tank
Make sure the equipment is unplugged when servicing.
Access the hot water tank by removing the back panel.
See images below for tank lid details.
See section8.4 for preventive maintenance.
Heater safety
switch
Water level switch
(float)
Heating element wire
Heater safety switch
Left Side View
Water level switch (float)
Right Side View
Probe
Heating element
connector
Reference Drawings
Water tank

ENCORE LITE Rev. 3 05/2018
www.cafection.com 800-561-6162
16
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
3.8 Bean Hopper Installation
The hopper is already installed on the
brewer when shipped. To remove it,
follow the steps below.
1. Unlock the bean hopper. The lock is
located on top of the lid.
2. Remove the bean hopper back plate.
3. Push the bean hopper backward and
then lift it.
4. Repeat steps in reverse order to
reinstall.
Transmissions (3x)
Motors (3x)
Bean hopper
Bean hopper
back plate
Bean hopper
door lock
Reference Drawings

ENCORE LITE Rev. 3 05/2018 17
www.cafection.com 800-561-6162
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
3.9 Water Temperature
This equipment has a coffee brewing setpoint of 200°F water temperature to ensure a consistent
beverage quality. There is a +/- 2°F tolerance.
This value represents an average and will not correspond to the temperature of a manual
measurement. The actual water temperature fluctuates because cold water is added to the
tank after every beverage delivery and time is needed to heat the new incoming water up to the
setpoint.
Water’s brewing temperature can also be taken manually by ordering a cup of hot water and
measuring its temperature with a thermometer. There may be a slight difference from the tank
reading. This is normal.
If the temperature measurements show a large temperature differential, verify that the tank is clean
and not obstructed by mineral deposits and scale.
Unit Safety Measures
In the event of a temperature probe failure, water in the tank might start to boil. This will cause it to
overflow into the overflow cup and will automatically shut the machine off. However, the computer
screen will remain active (ON).
Electronic
thermostat board
Access from the back of the machine.
Temperature can be set by the user in the System1 sub tab (see section 6.6.1).
Reference Drawings

ENCORE LITE Rev. 3 05/2018
www.cafection.com 800-561-6162
18
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
4 INITIAL SETUP
Before the installation of the brewer on location, it is strongly suggested to unpack, inspect and bench test
the machine before it leaves the warehouse.
4.1 On-Site Installation Requirements
4.1.1 Operating Environment
Equipment is for indoor use only.
4.1.2 Power Supply
Make sure each unit has its own electrical circuit and is located within 6 feet of the
dedicated electrical outlet.
Use only a polarized grounded receptacle.
Domestic 120V AC / 60Hz- 15 A circuit.
4.1.3 Water Supply
Use a plastic 1/4” or 3/8” (outside diameter) dedicated line branched off a larger line. An
easily accessible shut off valve up stream of the unit is highly recommended for ease of
installation.
Cold tap water pressure should be at least 20 psi and no more than 80 psi.
4.1.4 Tools Required
- #2 Phillips screwdriver
- Regular medium pliers
- Adjustable wrench
- Level indicator
Other tools may be required depending on the type of water supply tubing and
location.
4.1.5 Clearance
Unit Clearances Allowance for
Height 39 1/4” 45 1/4” Opening bean hopper.
Width 11 5/8” 23 5/8” Accessing lock (left side) and opening door (right side).
Depth 25 3/4” 37 1/2” Opening door (front) and back clearance.
Back
Clearance
2 1/2”
6”
Clearance for water hookup, hoses and adequate air
circulation.
Needed only if a filtration system is installed behind
the machine.
See Annex4 for waste chute positioning.
See Annex5 for a diagram illustrating required clearance.
Initial Setup

ENCORE LITE Rev. 3 05/2018 19
www.cafection.com 800-561-6162
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
Initial Setup
4.2 Specifications
4.2.1 Hopper & Canisters Capacities
Whole bean hopper, left section: 3.7 lbs (1.7kg)
Whole bean hopper, middle section: 2.3 lbs (1kg)
Whole bean hopper, right section: 3.5 lbs (1.6kg)
Soluble, hot chocolate: 2.5 lbs (1.1kg)
Soluble, vanilla powder: 2 lbs (0.9kg) (or 1 lb (0.45kg) of soluble milk powder)
4.2.2 Water Tank
Capacity: 0.8 gallon US (3.0L)
Water valves: 1 single valve; 1 double valve
Heating element: 1250 watts
4.2.3 Electrical Requirements
120V AC
15 A circuit
60Hz

ENCORE LITE Rev. 3 05/2018
www.cafection.com 800-561-6162
20
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite
4.3 Unpacking
To remove the unit from the box, carefully cut the straps holding the box in place on the skid.
Remove all staples from the box (top and bottom). Remove the top of the box, then the two (2)
side sleeves. Inspect the unit to see if any damage has occurred during shipment.
Some parts and accessories need to be installed on the equipment. Those were placed inside the
machine for shipment. Here is a list of all accessories and parts you should find in your machine.
In the machine:
1. Internal Waste Bin
2. Drip Tray Grill
3. Drip Tray
4. 3/8'' Inlet Fitting
5. 3/8'' to 1/4'' Inlet Fitting
6. "Milk" Sticker for Soluble Canister
7. Filter Paper
8. Microfiber Cloth
9. Keychain
10. Service & Installation Manual
11. Chute Brush
Optional:
12. Plastic Chute Kit (Chute Base and Chute)
One of the machine keys is attached to the power cord at the back of the
machine. A second key is taped on the filter paper roll, located in the internal
waste bin.
12
1
75 11
32
4
Initial Setup
