Caffitaly System S04 User manual

Model S04
Manuale di istruzioni
Instruction book
Mode d'emploi
Bedienungsanleitung
Italiano English Français Deutsch

22
Table of contents
Introduction
Intended use ............................................................................................3
Warning symbols.....................................................................................3
Your Cataly System contact ...............................................................3
Safety warnings.......................................................................................4
Instructions for use and disposal.....................................................................5
Description of machine components .................................................6
Installation
First use or after a long period of disuse ............................................7
Turning on the appliance.......................................................................8
General operating indications..............................................................9
Adjusting the cup/mug height ........................................................... 11
Dispensing the product
Dispensing coee.................................................................................. 12
Dispensing other beverages ............................................................... 13
Programming the quantity of coee in a cup.................................. 14
Cleaning and Maintenance
Daily maintenance ................................................................................ 15
Descaling ................................................................................................ 16
Miscellaneous
Troubleshooting.................................................................................... 20
Technical data ........................................................................................ 20
2
1
3
4
5
6
7
8
9
10
11

23
Introduction
Dear Customer,
Thank you for having chosen our product and for your condence in our company.
You can savour your favourite hot beverages at any time of the day with our appliance by choosing one
of the capsules that Cataly oers you. For example: An espresso, a cocoa-avoured beverage or a tea
will be ready in just a few seconds.
Intended use
This appliance is intended to be used in domestic and similar applications such as, for example:
- sta cooking areas in shops, oces and other work environments;
- holiday farms;
- by guests staying at hotels, motels and other residential facilities;
- facilities like bed and breakfasts.
Use only Cata System capsules. Use of the appliance in any manner other than as directed herein
could cause harm to persons and void the guarantee.
The manufacturer will not be responsible for injury or damage resulting from improper use of the
appliance.
Warning symbols
CAUTION
This is the safety warning symbol. It is used to call your attention to possible risks of
personal injury. Abide by the safety messages provided in order to avoid possible injury
or death.
NOTE
This is the symbol used to highlight some actions that will optimise use of the
appliance.
Not dishwasher safe Maintenance tips
This symbol is used to highlight a WHITE light indication.
This symbol is used to highlight a RED light indication.
This symbol is used to highlight an ORANGE light indication.
Your Cataly System contact info@cata.com

24
Introduction
Safety warnings
Carefully read the following instructions! In this way you will avoid the risk of personal injury and
damage to the appliance.
After removing the packaging, make sure that the appliance is intact. If it is damaged, or at
the rst sign of faulty operation (unusual noises or odours), or if any problem arises inside the
appliance, do not use it. Contact an Authorised Service Centre.
The packaging elements (plastic bags, etc.) must not be left within reach of children as they are
potential sources of danger.
Only use the appliance if the power cord is intact. If the cord is damaged, it should be replaced:
contact an Authorised Service Centre. Lethal danger of electric shocks.
Only use and store the appliance indoors. Make sure the electrical elements, plug and cord are
dry. Never submerge the appliance in water. Protect the appliance from sprays and drips. Water
and electricity together constitute a risk of electrocution.
Only connect the appliance to power outlets complying with the requirements of the law. Make
sure that the power supply voltage matches the rating shown on the data plate on the bottom
of the appliance.
The surface on which the machine is installed must be level, solid, stable and heat-resistant;
amaximum incline of 2° is permitted for the surface on which the appliance is placed.
Do not allow the appliance to be used by children or persons with impaired mental, physical
or sensory faculties or insucient experience and/or skills, unless they are under the careful
supervision and guidance of a person responsible for their safety. Children must be kept under
supervision to prevent them from playing with the appliance.
Do not leave the power cord near hot surfaces, sharp edges or other sharp objects.
Never place your hands inside the capsule compartment. Danger of injury
Always close the lever. Never open the lever while the appliance is operating.
Never remove parts of the appliance. Do not insert objects into the openings. This could cause
electric shocks! Any operation that is not described in this instruction manual should only be
performed by an Authorised Service Centre!
Do not pull on the power cord to disconnect it. Remove the plug to avoid damage to the outlet.

25
Instructions for use and disposal
Introduction
The appliance has been manufactured using high quality materials that can be reused
or recycled. Dispose of the appliance in a suitable waste collection centre.
To rule out any abuse and dangers involved, ensure that the machine cannot be
plugged into the mains before delivering it to the scrapping service.
To achieve this, unplug the appliance from the outlet and cut the power cord as close
as possible to the machine.
Directions for correct disposal of the product according to European Directive
2002/96/EC and Italian Legislative Decree no. 151 dated 25 July 2005. At the end of
its useful life, the product should not be disposed of with unsorted household waste.
It should be taken to a suitable selective waste collection centre set up by the local
authorities or returned to a retailer who provides this service. Separate collection
of an electric household appliance avoids a possible negative impact on the envi-
ronment and health arising from improper disposal and enables the materials it is
made of to be recovered so as to achieve signicant savings of energy and resources.
The crossed-out wheelie bin symbol applied on the product highlights the need to
dispose of electric appliances separately. Improper disposal of the product by the user
shall be subject to specic administrative sanctions as provided for under current
regulations. The packaging is made from recyclable materials. Contact the competent
authorities for information regarding local legislation.
Descale the appliance regularly, following the instructions provided. If you do not, the appli-
ance may be damaged and may become harmful to your health.
Clean the appliance carefully and regularly. If it is not cleaned, the build-up that forms may be
hazardous to your health. Unplug the appliance and allow it to cool before cleaning.
If you do not expect to use the appliance for a long period of time (leaving on vacation, etc.),
unplug it.

26
Electric cord Power on/o switch
"Multifunction"
indicator light
"Descaling"
indicator light
"Filter coee"
dispensing button
"Long coee"
dispensing button
"Espresso"
dispensing button
Drip tray
Coee dispenser
Lever for opening capsule
compartment
Used capsule
drawer
Capsule compartment
Water tank
Water tank cover
Description of machine components
Introduction

27
First use or after a long period of disuse
NOTE:
If the coee buttons and the multifunction indicator light continue to blink
after the lling procedure has ended, repeat the steps in point 5.
3
5 6
1
4
2
Fill the tank with fresh,
still water.
Plug in the appliance and turn it on.
The buttons (espresso, long coee and lter
coee) and the multifunction indicator light
blink at the same time.
Place a large container under the dispensing
spout.
Press one of the coee buttons (espresso,
long coee or lter coee).Wait for the
machine to complete the priming cycle and ll
with water. The multifunction indicator light
switches o.
The buttons (espresso, long coee and lter
coee) blink at the same time; the machine is
warming up.
1

28
Turning on the appliance
2Turning on the appliance
At the end of this operation, empty out the
water from the used capsule drawer.
When the buttons (espresso, long coee,
lter coee) turn on and remain steadily
lit, rinse twice by pressing the lter coee
button.
Wait for the machine to complete the rinse
cycle.
Fill the tank with fresh,
still water. Turning on the appliance
The buttons (espresso, long coee and lter
coee) blink at the same time; the machine is
warming up. When the buttons remain steadily
lit, the appliance is ready for operation.
8
7
1 2
2

29
General operating indications
Descaling signal Heating
When the water runs out during operation
The water tank is empty when the multifunc-
tion indicator light blinks in RED and the
appliance emits 3 beeps followed by a single
intermittent beep.
Fill the tank with fresh, still water.
When the buttons remain steadily lit, the ap-
pliance is ready for operation.
Press one of the coee buttons (espresso,
long coee or lter coee).Wait for the
machine to complete the priming cycle and
ll with water.
3 4
1
2
When the descaling indicator light blinks
ORANGE and the machine emits 3 beeps, it is
recommended to perform the descaling cycle
(see Ch. 9).
The buttons (espresso, long coee and lter
coee) blink at the same time.
3

30
If the lever is raised while a product is being
dispensed.
General operating indications
CAUTION!
Raising the lever incorrectly while dispensing a product may cause brief
splashes of hot water.
Danger of scalding!
If the lever is raised
The multifunction indicator light blinks in RED
and an intermittent beep sounds.The appliance
will immediately stop dispensing.
Close the lever. Press a button to reset the alarm.
The appliance is ready for use.
3
12
4
3

31
Adjusting the cup/mug height
The appliance can be adjusted for the use of
mugs or espresso cups.
The appliance is initially set for the use of large
cups or mugs.
In order to use espresso cups, you must lift and
turn the grid on top of the drip tray.
The grid must be positioned over the turned
drip tray.
1
3
5
4
2
In this way you can obtain the best results
when using small espresso cups.
4

32
Dispensing coee
Raise the lever to open the capsule compart-
ment.
Insert the capsule, pressing it gently into place.
Close the lever rmly. Place a cup or mug under the coee dispensing
spout.
Press the desired coee button only once. The selected coee button will blink. The
appliance will stop dispensing on reaching the
programmed quantity and emit a beep.
12
3 4
5 6
Caution! Before you
start brewing, make
sure the capsule container is
not full.
5

33
Dispensing other beverages
Raise the lever to eject the used capsule into
the drawer. Close the lever.
Dispensing other beverages
Capsules for preparing beverages such as tea, chamomile tea, lter coee, etc. are available.
For their use, proceed as directed in the previous chapter; on reaching step 5, press "Filter coee".
To prepare beverages using barley capsules, cocoa drinks, etc., proceed as directed in the
previous chapter; on reaching step 5 press the "Espresso" or "Long coee" button, depending
on the desired quantity.
NOTE:
Traces of product just dispensed may remain in the circuit of the machine.
When switching from one product to another, in order to fully enjoy the avour of
the beverage we suggest rinsing the machine by pressing the coee button as if
to dispense a coee without inserting a capsule.
NOTE:
The quantity of coee dispensed can be reprogrammed according to
personal taste, and in accordance with the size of the cup or mug used.
Please refer to chapter 7 for reprogramming instructions.
7
8
6
6

34
Programming the quantity of coee in a cup
Raise the lever to open the capsule compart-
ment.
Insert the capsule, pressing it gently into place.
Close the lever rmly. Place a cup or mug under the coee dispensing
spout.
On reaching the desired amount of coee in a
cup, release the button. Now the button is pro-
grammed. To reprogram the button or program
another button repeat the above steps.
The quantity of coee dispensed can be
programmed up to a maximum of 250 ml.
Press the desired coee button and keep it
pressed down.
12
3
4
5 6
Caution! Before you
start brewing, make
sure the capsule container is
not full.
7

35
Remove the drip tray and used capsule drawer.
Remove the grid. Empty the drip tray and rinse
it out with fresh water.
Lift the capsule drawer; empty and rinse it.
21
3 4
Daily maintenance
Remove the water tank. Empty and rinse out
the tank. The water tank is NOT dishwasher
safe.
Use a soft cloth and a neutral
detergent to clean the surfaces of the
appliance.
Do not spray the appliance with jets
of water when cleaning.
The plastic parts of the appliance are
not dishwasher safe.
8

36
Descaling
Turn o the machine. Empty and rinse out the used capsule drawer
and drip tray.
1 2
9
CAREFULLY read the directions for use on the package of the descaling agent. Avoid
contact with eyes, skin and machine surfaces. Switch the appliance o during descal-
ing, and do not lift the lever.
A person must be present during the operation.
Do not use vinegar: it could damage your appliance!
It is advisable to use the Cata System descaling agent. It has been studied to com-
ply with the technical characteristics of the appliance, in full observance of consumer
safety. The descaling agent must be disposed of in compliance with manufacturer
instructions and/or with current regulations in force in the country where the appli-
ance is used.
The machine features an
advanced program that moni-
tors how much water is used
to dispense beverages.This
measurement provides the user
with indications as to when the
machine needs to be descaled.
Specic indications are given in
chapter 3.
When the descaling indicator light blinks
ORANGE and the machine emits 3 beeps, it is
recommended to perform the descaling cycle
(see Ch. 9).

37
Descaling
Place a container (at least 250 ml) under the
coee dispensing spout.
Keep the buttons pressed down (espresso and
long coee) and at the same time turn on the
machine by pressing the power on/o switch.
Make sure the lever is lowered.
As well as the long coee button, the multi-
function indicator light also blinks alternately
(RED and ORANGE). Press the long coee
button to start the descaling cycle.
5
7
8
6
9
Remove and empty the water tank. Mix the descaling agent with water as
instructed on the package and pour the
solution into the tank.
3
4

38
Descaling
When the cycle is complete, as well as the long
coee button, the multifunction indicator
light also blinks alternately (RED and ORANGE).
Carefully rinse out the water tank and ll it
with fresh drinking water.
Empty and rinse out the used capsule drawer
and drip tray. As well as the long coee button, the multi-
function indicator light also blinks alternately
(RED and ORANGE). Press the long coee
button to start the rinse cycle.
12
11
13 14
The appliance dispenses the descaling solution
at intervals (5 doses with a 10 minute
pause between each one, for a total dura-
tion of about 45 minutes). During this step,
when the buttons must not be pressed,
the multifunction indicator light blinks alter-
nately (RED and ORANGE).
If the container lls up, empty it out.
10
9
9

39
Descaling
Use a soft cloth and a neutral
detergent to clean the surfaces of the
appliance.
When the rinse cycle is complete, in addition
to the long coee button, the multifunction
indicator light also blinks alternately (RED and
ORANGE). The machine will emit a beep.
Carefully rinse out the water tank and ll it
with fresh drinking water.
Empty and rinse out the used capsule drawer
and drip tray. Press the long coee button to quit the cycle.
17
18
19 20
Rinse water will be run through the machine.
During this step the multifunction indicator
light blinks alternately (ORANGE and RED twice
in a row).
If the container lls up, empty it out.
16
15
9

40
The materials and
objects in contact with
food products comply
with the requirements
of European Regulation
1935/2004.
11 Technical data
Troubleshooting - 11 Technical data
PROBLEM CAUSE SOLUTION
- No coee is brewed. - The water tank is empty, the
multifunction indicator light
is lit in RED.
- Fill the tank with fresh water. Press
one of the coee buttons to ll the
circuit.
- The coee is not hot
enough.
- Cold cups / mugs.
- Scale build-up in machine.
- Preheat cup / mug.
- Descale.
- The lever cannot be
lowered.
- The used capsule drawer is
full.
- Capsule stuck inside the
machine.
- Empty out the used capsule drawer.
- Remove the used capsule.
See the data plate on the bottom of the
machine
Max. 15 bar
about 4 kg
< 70dB A
1,2 litres
ambient temperature: 10°C ÷ 40°C
170 mm 260 mm 320 mm
10
