Caimore CM530-8 1F User manual

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Tel:[phone] Web: www.caimore.com/emain.asp
Caimore 3G/4G MNVR User Manual
Copyright :
All contents in the files are protected by copyright law,and all copyrights are
reserved by Xiamen Caimore Communication Technology Co.,Ltd, without written
permission,all commercial use of the files from Caimore are forbidden,such as
copy,distribute, reproduce the files etc, but non-commercial purpose, downloaded or
printed by individual(all files shall be not revised,and the copyright and other
proprietorship notice shall be reserved) are welcome.
Trademarks :
Caimore are trademarks of Xiamen Caimore Communication Technology Co.,Ltd. All
other trademarks mentioned in this file are the property of their respective holders.
Notice:
The information in the file is subject to change without notice.Every effort has been
made in the preparation of this file to ensure accuracy of the contents, but all
statements,information,and recommendations in this file do not constitute the warranty
of any kind,express or implied.
Version :
Document
version
Modification instruction
Release
date
Author
issue
V1.0
1st official issue
2013-11-26
luolw
V1.1
Modify structure,add features
2014-05-14
chenjz
V1.2
Modify structure,add features
2014-08-24
chenjz
V1.3
Modify structure,add features
2014-10-9
chenjz
V1.4
Modify structure,add features
2015-1-9
chenjz

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Tel:[phone] Web: www.caimore.com/emain.asp
Technical support :
Add：2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Web：http://www.caimore.com
Tel：[phone]
Fax：[phone]
Mail：[e-mail]

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Tel:[phone] Web: www.caimore.com/emain.asp
Content
1 Preface....................................................................................................................................................... 2
1.1 Model statement.................................................................................................................................... 2
1.2 Purpose of the Manual................................................................................................................. 3
1.3 Audience......................................................................................................................................... 3
1.4 Notice................................................................................................................................................. 3
2 Product instruction.......................................................................................................................................4
2.4 Interface and accessory appearance.........................................................................................7
3 User Manual................................................................................................................................................. 9
3.1 Local network connect configuration..........................................................................................9
3.2 Login configuration....................................................................................................................10
3.3 Date and time seeting................................................................................................................ 12
3.4 Network parameter configuration............................................................................................. 12
3.4.1 Video server configuration............................................................................................. 12
3.4.2 Flow server configuration............................................................................................... 13
3.5 View MNVR.................................................................................................................................. 14
3.5.1 Flow view video..............................................................................................................14
3.5.1.1 Login operation and maintenance system....................................................... 14
3.5.1.2 Download and install the player controls.......................................................15
3.5.1.3 Video review..........................................................................................................16
3.5.2 Monitoring station review video.....................................................................................17
3.5.2.1 Monitoring station install......................................................................................17
3.5.2.2 Monitoring station login....................................................................................... 19
3.5.2.3 Create Group........................................................................................................ 20
3.5.2.4 Add video server...................................................................................................21
3.5.2.5 Video Review........................................................................................................ 24
4 Configuration Options............................................................................................................................... 26
4.1 Basic Setting................................................................................................................................ 26
4.1.1 Date and Time..................................................................................................................27
4.1.2 Video server information.................................................................................................28
4.1.3 User management........................................................................................................... 29
4.1.4 Restore backup................................................................................................................ 29
4.1.5 Reset..................................................................................................................................29
4.1.6 System upgrade...............................................................................................................30
4.2 Network Parameter.....................................................................................................................30
4.2.1 Video server......................................................................................................................30
4.2.2 Streaming server..............................................................................................................31
4.3 Video parameter..........................................................................................................................31
4.3.1 OSD region superimposition..........................................................................................32
4.3.2 GPS Parameter................................................................................................................32
4.3.3 Video code configuration................................................................................................33
4.3.4 Video Effect Adjustment..................................................................................................34
4.3.5 Audio code configuration................................................................................................ 34

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Tel:[phone] Web: www.caimore.com/emain.asp
4.3.6 PTZ configuration............................................................................................................ 35
4.4 Alarm parameter..........................................................................................................................35
4.4.1 Alarm configure................................................................................................................ 36
4.4.2 IO Alarm Event Definition............................................................................................... 37
4.4.3 IO alarm response configure......................................................................................... 38
4.4.4 IO alarm status.................................................................................................................38
4.5 Front End Parameter..................................................................................................................39
4.5.1 Camera status..................................................................................................................39
4.5.2 Capture configure............................................................................................................ 40
4.5.3 Recorder configure..........................................................................................................40
4.5.4 Scheduled recording....................................................................................................... 41
4.5.5 Front storage device....................................................................................................... 41
4.5.6 Formatting storage devices............................................................................................42
4.6 DTU parameters..........................................................................................................................42
4.6.1 center parameters............................................................................................................43
4.6.2 Serial parameters configure...........................................................................................43
4.6.3 Other parameters configure...........................................................................................44
4.7 System debugging...................................................................................................................... 46
Appendix I LED indicators description................................................................................................... 48
Appendix II Serial/ IO port terminal definition..........................................................................................49

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
2
2
1 Preface
1.1 Model statement
Classify the product as follow according to different interface configuration
Name
Model
Network
type
1 3G/4G
antenna、
1 LANport
UIM
Slot
4 Video/
4 Audio
Input
interface
1 Video/
1 Audio
Output
interface
GPS
position
SD
card
Wth
hard
disk
MDVR
CM530-8
1E
EV-DO
√
√
√
√
√
√
CM530-8
1F
LTE-FDD
√
√
√
√
√
√
CM530-8
1S
TD-SCD
MA
√
√
√
√
√
√
CM530-8
1T
TD-LTE
√
√
√
√
√
√
CM530-8
1W
WCDMA
√
√
√
√
√
√
CM530-8
2E
EV-DO
√
√
√
√
√
√
√
CM530-8
2F
LTE-FDD
√
√
√
√
√
√
√
CM530-8
2S
TD-SCD
MA
√
√
√
√
√
√
√
CM530-8
2T
TD-LTE
√
√
√
√
√
√
√
CM530-8
2W
WCDMA
√
√
√
√
√
√
√

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
3
3
1-1 Model Table
1.2 Purpose of the Manual
The manual describes the installation, configuration and use methods . By reading the
manual, user can set up and use the product according to their requirement.
1.3 Audience
The manual suitable for the following person:
Technical support
Device install person
Device user
1.4 Notice
1 . Don't disassemble it, install the hard disk please ask professionals .
2 . Stay away from high temperature ; Avoid direct sunlight.
3 . Pay attention to water, when water contacts the device please turn off immediately.
4 . Do not use in excessively humid environment, use within the reference of applicable humidity
range (85% RH or less) .
5 .Avoid use in hot or cold environment, use in the reference temperature range (-25 ℃~ +80 ℃).
6 . The machine should be installed horizontally or wall mounted, avoid vibration place, do not put
other devices on the machine.
7 . Our package through seismic design and test, to ensure any damaged during transport s, so
when you move the machine, it is best to use the original packing materials.
8 . Avoid moving servers in extremely cold and hot places to avoid condensation inside the
machine, affecting the life .
9 . Move the machine with electric is prohibited, otherwise it will damage the hard disk and the
motherboard.

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
4
4
2 Product instruction
2.1 Brief instruction
Xiamen Caimore SD Card 3G/4G wireless Monitoring is an integration intelligent terminal, which is
independent researched and developed by Xiamen Caimore communication Technology Co.,Ltd.
The device combines multiple high technologies, such as,3G/4G wireless communication
technology, video capture, video overlap, voice and intercom, alarm, GPS positioning, image
capture, PTZ control, disk storage, SD storage and remote playback etc.
The wireless monitoring supports smart sensor connecting to achieve on-site monitoring and
alarm processing includes intrusion detection, proximity, occlusion，temperature and humidity，
smog, gas detection etc.
To assure that the users have a better remote operation, Caimore developed a management
platform, which has a stable system and rich functions to meet different needs. The user can have
a real-time online checking on the remote video monitoring by logging in Caimore monitoring
platform. Besides, the platform supports functions of video replay, image capture, GPS positioning,
voice intercom and PTZ control etc.
The equipment adopts high-powered industrial embedded processor ARM9 with large memory to
cache data and instruction ;has a high-speed data accessing and instruction processing,
successfully solved the difficult problems ,such as, "fake online", "fake death", "crash" etc.
Meanwhile, it adopts strong realtime and stable Linux operating system.
The product is strictly designed in accordance with the requirement of industrial grade and its
exterior adopts the design philosophy of fully closed and aluminum structure, with advanced
patented technology of anti-vibration and dust proof and heat dissipation. System designed with
watchdog( WDT) protection, while loaded System Watch Protection SWP (System Watch
Protect); If it appears that the network is abnormal or system receives Strong interference anomaly,
the system will auto reset, which thoroughly solve the problem that it needs maintainer to pull out
electric when the system appears abnormally in the industry, and ensure that the system is stable
and reliable. Meanwhile the products passed 3000V power shock test, particularly suitable for
harsh industrial environment. The device adopts the patented technology to maintain the system
stable and ensure it always on-line. After rigorous design, testing and 8 years practical
application, the products show stable and reliable performance.
The products are especially applicable for Video Surveillance, such as, Traffic lights control and

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
5
5
photograph transmission, Bus monitoring, High-way monitoring, environmental monitoring, vehicle
moving, Fire passage, and Comprehensive alarm etc.
2.2 Product function
Support video encryption
Support 1-4 CH real-time video recording, has two resolutions 1080P@100fps；720P@100fps and
can figure the frame rate, data rate ,I frame interval etc.
Support 3G/4G Wireless communication and Ethernet communication.
Support Voice transmission and Voice intercom.
Support GPS positioning.
Video saved on the hard drive or TF card, TF card can be up to 64G and the hard drive can be up
to 2T （2000G）,the video files can be overwritten.
Support checking SD card storage and formatting the memory card.
Support browsing video through streaming video, TV wall, mobile phone and local monitoring.
Support regular video recording, motion detection video recording, planning video recording,
alarm video recording and video tracks
Support video power-off protection
Support 4 LAN router
Support HDMI and VGA
Support motion detection alarm, occlusion alarm and IO alarm etc.
Support manually capture and time capture
Support OSD video overlay, such as the channel name and time etc.
Support 2 CH CVBS output.
Video effects are adjustable, including brightness, chroma, contrast and saturation etc.
Support PTZ control to move it up and down, left and right
Support 1 CH RS232 communication, RS232 can be used as DTU to achieve TCP/UDP
transparent transmission.
Support 1 CH RS485 communication, RS232 can be used as DTU to achieve TCP/UDP
transparent transmission.
Support I/O port and 7 CH High/Low level triggered input with photoelectric-isolation, 2 CH
High/Low level triggered output, 1 CH on-off /dry contact output.
Support debugging function;
Support factory reset.
Support checking the camera.
Support remote configuration, upgrade and centralized management.
Support local configuration and upgrade.
2.3 Parameters and interface type
Syst
em
Main processor
Hi3515a

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
6
6
Operation system
Embedded Linux system
Operation language
Chinese
Operation interface
WEB configuration interface
Password Security
User，password，management
Video
Video input
4CH video input
Video output
2CH CVBS output
Video standard
PAL standard
Codec capabilities
1080P@100fps；720P@100fps
Image compression
standard
H.264
Audio
Audio input
4CH Audio input
Audio output
1CH Audio output
process
Image format
1080P/720P
Interface
type
IO interface
7CH IO port
Hard disk interface
1 Interface , Max storage 2T
Sd card slot
1 SD Interface , Max storage 32T
3G/4G
1 MINI PCI-interface
Ethernet
4 MINI PCI-E interface
Serial
1 RS485serial, 3 RS232 interface
Data bit：7、8
Stop bits：1、2
Parity：none
Serial rate：115200bps
Flow：NO
Indicator
Power

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
7
7
3G/4G
GPS
LINK/ACT
Recording
Antenna interface
1 3G/4G antenna interface，1 GPS
antenna interface
UIM card slot
1.8V/3V/5V Standard pusher user
card interface, embedded 15KV
ESD protection
Power interface
Standard 3pin
Power
Power input
DC：+6V ~ +36V，Typical 12V
Power output
+12V@2A
Working
environment
Working temperature
-30℃~ +75℃
2.4 Interface and accessory appearance
The series adopts industry-standard, fully enclosed, all-aluminum structure design, thermal
performance, with a dustproof, radiation protection, anti-electromagnetic interference function, and
beautiful appearance.
Whole View
Front View
Rear View
Pic. 2-1 Product appearance

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
8
8
Pic. 2-2 Interface diagram
WLAN
LAN1 LAN2 LAN3 LAN4
VGA
USB
HDMI
Audio Output
Audio Input
SIM Card Slot
SD Card Slot
Record GPS 3G/4G Link Power
GPS
Power
Reset
232/485/IO

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
9
9
AC/DC Adapter
Power Cable
Serial/IO
GPS ANT
3G/4G ANT
Ethernet Cable
Pic. 2-3 Product accessory
3 User Manual
When you get the device, first set all cable like pic. 2-2, then connect the device to the
computer with a network cable or the equipment and computer lines respectively connected to the
same router. After power supply,follow these steps to complete setting before first use
3.1 Local network connect configuration
Default Gateway 192.168.9.255，IP address some with gateway，like pic. 3-2.

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
10
10
Pic. 3-1
Before local network connect configuration Pic 3-2 After local network connect
configuration
3.2 Login configuration
Open IE（Suggest up IE6.0 ），put：http://192.168.9.1in Address bar，which is the factory
default IP address,system prompts login like pic. 3-3

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
11
11
Pic. 3-3 WEB Login
The default user name and password;
user name：caimore password：caimore
Enter WEB parameter configuration main interface，like pic. 3-4.There are 6 Video
configurations and system debugging features: Basic configuration, network
parameter , video parameter ,alarm parameter ,front-end parameter,DTU parameter
Pic. 3-4 WEB main interface
Notice：
Most parameter take effect whrn you click “OK”,but some parameter need to restart the
device ,when you setting it please notice the word . Restart the device please click

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
12
12
3.3 Date and time seeting
Pic. 3-5 Date and time setting
Click【Synchronized with the PC system time】，make device time consistent with the PC
system time.
3.4 Network parameter configuration
Configure network parameters is provided to enable the device to connect to
our server, complete the following configuration.
3.4.1 Video server configuration
The device supports 3G / 4G wireless networks and wired networks three access ways to
real-time view video and Recording.Users choose the corresponding mode in "Network
preference" item according their requirement .For further convenient configuration，please set the
device IP address same to computer,same gateway with The IP address option to set the device to
the local computer in the same segment of the IP address, gateway and PC Default Gateway .（IP
address and default gateway is the IP address and default gateway before local network
connection configuration .)After that you just put in “http://IP after configuration”when you
login .
For example :

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
13
13
Pic. 3-6 3G Wireless network setting
Pic. 3-7 4G Wireless network setting
Pic. 3-8 WLAN Wired network setting
3.4.2 Flow server configuration
Pic.3-9 Flow server
Flow server IP：110.80.17.74

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
14
14
Server port：10086
The default server address and port of the Company, factory set up already , do not change!
3.5 View MDVR
After below configuration ，click “reset”to restart the device,put PC IP,default gateway ect.
Local network connection back to the configuration before local network connection.
3.5.1 Flow view video
3.5.1.1 Login operation and maintenance system
Insert sever address：http://110.80.17.74:8030 to login ，like pic. 3-10 shows：
Pic.3-10 Intelligent monitoring alarm system of operation and maintenance login
Use assigned user name and password to login intelligent monitoring alarm system of
operation and maintenance 。After landing successfully，enter into monitoring station browsing
mode(default)like 3-11shows：

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
15
15
Pic. 3-11 Main interface
Pic. 3-11 Main interface including:
1、Display area: display the video area. (Green Box range)
2、Status Bar: The Browse mode (GIS mode and monitoring console mode). (Blue box range)
3、Project Panel: Displays the video server list and PTZ control. (Red frame range)
4、Toolbar: rapid application function keys. (Yellow frame range)
3.5.1.2 Download and install the player controls
In the status bar of [Video List] - [Video Server] on the right-click to pop-up control
download dialog:

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
16
16
Pic. 3-12 Control download Inquiry
Click [Run] or [Save] then displaying download progress
:
Pic.3-13 Control download speed
After the download is complete, install the player controls.
3.5.1.3 Video review
Double-click "default group"will show video server name , click on the required play channel,
you can play real-time video channel:
Pic. 3-14 real-time video player interface

Xiamen Caimore Communication Technology Co.,Ltd
2 F, 37#, Wanghai Road, Software Park 2, Xiamen,China (361009)
Add:2 F, 37#, Wanghai Road, Xiamen Software Park 2, Xiamen,China (361009)
Tel: [phone] Fax:[phone]
Web: http://www.caimore.com
17
17
3.5.2 Monitoring station review video
3.5.2.1 Monitoring station install
Open the companion CD, enter into [VIDEO- wireless video system ] [product software tools]
folder, copy MonitorInstall.rar to the computer to decompress , double-click the decompressed
MonitorInstall.exe, it will show as below:
Pic. 3-15 Install window
Click【next】，pops up Installation Location dialog box ,it will shows：
Pic. 3-16 Select the installation directory
