Caimore CM550-5 Series User manual

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
User Manual
CM550-5x Series RTU
This manual is suitable for:
Feature
Model
ETHERNET
CM550-52G/W/F
ETHERNET & GPS
CM550-55W/F
ETHERNET & ZIGBEE
CM550-56W/F
Xiamen Caimore Communication Technology Co.,Ltd
Add: 3F, 1st Building, 23# Wanghai Road, Xiamen
Tel：[phone] Fax：[phone] P：361009
Web：www.caimore.net Email:[e-mail]
版权所有2003-2009
---- 才茂通信 通畅天下 ----

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
Statement
Copyright Statement：
All contents included in this user manual are protected by copyright law, any organization
or person has no right to copy, reproduce and spread by any method, unless gets the written
authorization from Xiamen Caimore communication technology co.,Ltd.
Trademark：
Caimore and other Caimore brands are possessed by Xiamen Caimore communication
technology co.,Ltd. Other brands or registered brands mentioned in this page are possessed
by their owner.
Notice:
The file will be updated because of the unscheduled upgrade of products and other
reasons. Unless there are other agreement, the file is only used as the manual guide, the
information and suggestion included in this page do not constitute any express or implied
warranty.

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
Catalog
1. Installation......................................................................................................................................................... 1
1.1 Overview................................................................................................................................................1
1.2 Unpacking.............................................................................................................................................. 1
1.2.1 CM550-52X standard parts list................................................................................................. 2
1.2.2 CM550-55X standard parts list................................................................................................. 2
1.2.3 CM550-56X standard parts list................................................................................................. 3
1.3 Installation and Cable Connection......................................................................................................... 3
1.3.1 Installation of Antenna and SIM Card...................................................................................... 3
1.3.2 Interface Definition................................................................................................................... 4
1.4 Power Supply......................................................................................................................................... 8
1.5 Indicator Light Instructions....................................................................................................................8
2. Configuration.....................................................................................................................................................9
2.1 Basic.......................................................................................................................................................9
2.1.1 WAN......................................................................................................................................... 9
2.1.3 LAN.........................................................................................................................................10
2.1.3 DDNS...................................................................................................................................... 10
2.1.4 Keep Alive...............................................................................................................................12
2.2 Advance............................................................................................................................................... 12
2.2.1 Filter........................................................................................................................................ 12
2.2.2 NAT/DMZ...............................................................................................................................16
2.2.3 Route....................................................................................................................................... 18
2.3 VPN......................................................................................................................................................19
2.3.1 GRE.........................................................................................................................................19
2.3.2 PPTP........................................................................................................................................19
2.3.3 IPSEC/L2TP............................................................................................................................21
2.4 RTU......................................................................................................................................................24
2.4.1 Server...................................................................................................................................... 24
2.4.2 RTU Custom Registered Package........................................................................................... 26
2.4.3 PWM/Relay.............................................................................................................................26
2.4.4 Digital Input/Count................................................................................................................. 27
2.4.5 Digital Output..........................................................................................................................29
2.4.6 Analog Input............................................................................................................................30
2.4.7 Alarm.......................................................................................................................................31
2.4.8 Mobile SMS Query/Control RTU........................................................................................... 33
2.5 DTU..................................................................................................................................................... 36
2.5.1 DTU(for RS232)..................................................................................................................... 36
2.5.2 DTU(for RS485)..................................................................................................................... 38
Technical Support................................................................................................................................................38

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
1
1. Installation
1.1 Overview
To meet the design function, RTU must be installed correctly. Usually, the installation
should be under the guidance of qualified engineer who is approved by Xiamen Caimore
communication technology co.,Ltd.
Notice：Please install the RTU without power!
Installation diagram of back：
Installation diagram of front：
1.2 Unpacking
To ensure the safe transportation, RTU should be packed reasonably. Please keep the
package material when you open the box so as to use them again when before transporting
in the future.
Notice：Please confirm that the accessories coincides with packing list when you
open the product box.

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
2
1.2.1 CM550-52X standard parts list
NO.
Material
NO.
Name
Specifications and models
Quantity
Unit
1
WY.0081
WY.0001
WY.0080
Antenna
3G 1.5m sucker antenna
1M vehicle antenna-2G
LTE 4G 1.5m sucker antenna
1
PCS
2
PK.0015
Power adapter
Power adapter: 9V 1.5A (1CM
tinning)
1
PCS
3
XL.0042
Data line
Single DB9 data line 1M (one side
is DB9 and the other side is lead)
1
PCS
4
XL0004
Data line
Ethernet straight-through line
(RJ450RJ45) 1M
1
PCS
5
BP.0055
CD
CD
1
PCS
6
BP.0056
CD cover
CD cover
1
PCS
7
BP.0057
Certification
Certification
1
PCS
8
EZ.0002
Cutting ferrule
SIM drawer type cutting ferrule
1
PCS
1.2.2 CM550-55X standard parts list
NO.
Material
NO.
Name
Specifications and models
Quantity
Unit
1
WY.0081
WY.0001
WY.0080
Antenna
3G 1.5m sucker antenna
1M vehicle antenna-2G
LTE 4G 1.5m sucker antenna
1
PCS
2
PK.0015
Power adapter
Power adapter: 9V 1.5A (1CM
tinning)
1
PCS
3
XL.0042
Data line
Single DB9 data line 1M (one side
is DB9 and the other side is lead)
1
PCS
4
BP.0055
CD
CD
1
PCS
5
BP.0056
CD cover
CD cover
1
PCS
6
BP.0057
Certification
Certification
1
PCS
7
EZ.0002
Cutting ferrule
SIM drawer type cutting ferrule
1
PCS
8
WY.0047
Antenna
3M GPS antenna
1
PCS
9
XL.0004
Data line
Ethernet straight-through line
(RJ45-RJ45) 1M
1
PCS

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
3
1.2.3 CM550-56X standard parts list
NO.
Material
NO.
Name
Specifications and models
Quantity
Unit
1
WY.0081
WY.0001
WY.0080
Antenna
3G 1.5m sucker antenna
1M vehicle antenna-2G
LTE 4G 1.5m sucker antenna
1
PCS
2
PK.0015
Power adapter
Power adapter: 9V 1.5A (1CM
tinning)
1
PCS
3
XL.0042
Data line
Single DB9 data line 1M (one side
is DB9 and the other side is lead)
1
PCS
4
BP.0055
CD
CD
1
PCS
5
BP.0056
CD cover
CD cover
1
PCS
6
BP.0057
Certification
Certification
1
PCS
7
EZ.0002
Cutting ferrule
SIM drawer type cutting ferrule
1
PCS
8
WY.0069
Antenna
2.4G 1.5m small sucker antenna
(dedicated for ZigBee)
2
PCS
9
XL.0004
Data line
Ethernet straight-through line
(RJ45-RJ45) 1M
1
PCS
1.3 Installation and Cable Connection
1.3.1 Installation of Antenna and SIM Card
The antenna interface of the equipment is a SMA female socket. Rotate the SMA male
head of the supporting antenna to the antenna interface of the equipment, and make sure it is
tightened, so as not to affect the signal quality.
When installing or removing the SIM card, insert the small yellow spot on the right side
of the SIM card seat with the spike and the SIM card holder will pop out. When installing
the SIM card, place the SIM card into the card holder first, and make sure the metal contact
surface of the SIM card is facing out, and then insert the SIM card holder into the drawer,
and make sure it is inserted in place.

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
4
1.3.2 Interface Definition
Interface as follows:
Definition of Interface:
NO.
Name
Function
Default Function
Extension
1
PWR
Power
Power input positive pole, built-in power inverter protection and
overcurrent protection, voltage range DC 6V to DC 32V.
-
2
GND
Power input negative pole
-
3
EN
Enable Pin
During the normal operation of RTU, when the Power input pin
positive voltage is applied to this pin (the same voltage as PWR pin),
the entire RTU will be cut off and the Power lights will go out. When
the pin is applied with 0V voltage or suspended, the RTU is normally
energized.
-
4
D/RX
RS232(Debug)
Data receiver pin
-
5
D/TX
Data sender pin
-
6
GND
Ground
-
7
A
RS485
(Communicating)
RS485 communication interface positive pole
-
8
B
RS485 communication interface negative pole
-
9
U/RX
RS232
(Communicating)
Data receiver pin
-
10
U/TX
Data sender pin
-
11
GND
Ground
-
12
DIG
Switch Input
/ Counter Input
Ground
Ground
13
DI1
Switch input 1~8
Input range: low level is 0-3.3V,high level is
5-30V
-
14
DI2
-
15
DI3/C
Counting channel 1~6
Counting frequency is 0~1KHz
16
DI4/C
17
DI5/C
18
DI6/C
19
DI7/C
20
DI8/C

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
5
21
PWMG
PWM
Ground
-
22
PWM1
PWM output 1~2, open collector output, maximum support 30V,
maximum current is 40mA, maximum power is 125mW, output
frequency is 0~1KHz, duty ratio adjustable.
-
23
PWM2
-
24
COM
Optocoupler
Output / Digital
Output
Common
-
25
DO1
Optocoupler output 1~4, remote control output high and low level,
square wave.
Open collector output, maximum support 30V, maximum current is
40mA, maximum power is 125mW, output frequency is 0~1KHz,
duty ratio adjustable.
-
26
DO2
-
27
DO3
-
28
DO4
-
29
K1+
Relay Output
Drive capability 5A/30VDC,5A/250VAC
-
30
K1-
-
31
K2+
-
32
K2-
-
33
K3+
-
34
K3-
-
35
K4+
-
36
K4-
-
37
AG
Analog Input
Ground
-
38
A1
Analog input 1~8, resolution up to 16bit, input voltage (-10V ~ +10V),
input current (0~20mA), accuracy is ±0.5%.
-
39
A2
-
40
A3
-
41
A4
-
42
A5
-
43
A6
-
44
A7
-
45
A8
-
Connection:
(1) Power & Data interface cable
1Power(12VDC/0.5A)
Color of Wire
Polarity of power supply
Black alternating with white
Anode
Black
Cathode
2RS232
Color of Wire
Corresponding DB9 female pin
Brown
D/TX

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
6
Blue
D/RX
Black
GND
3RS485
Color of Wire
Definition of signal
Red
RS485 anode (A)
Black
RS485 cathode (B)
Connection:
(2) DI(Only support wet)

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
7
(3) Optocoupler Output / Digital Output
(4) Relay Output
(5) Analog Input

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
8
1.4 Power Supply
The devices usually apply in the complicated external environment. To adapt to the
complication application environment, improving the stability of system, our devices adopt
advanced power supply technology. Users can supply the power for device with standard
+9VDC/1.5A power adapter, or with the 7~35V direct current. When users supply the
power with additional power supplier, they must guarantee the stability of power supply
(the ripple wave is less than 300mV, and ensure the transient voltages is less than 30V), and
please ensure the power is more than 4W.
Recommend the standard +9VDC/1.5A power supply.
1.5 Indicator Light Instructions
There are three indicator lights: Power, ACT, Online
Indicator
Status
Description
Power
Off
Power off
On
Power is normal
ACT
Off
No data communication
On
Data communication
Online
Off
Offline
Flash once a second, then off for a
second
Can’t find a card
Flash twice a second, then off for a
second
Dial-up failure
Flash triple a second, then off for a
second
Dial-up success
Lighting form

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
9
2. Configuration
To get into RTU’s web configuration page, please connect your computer and RTU via
a ethernet cable. And set your computer to get IP by DHCP. Then type the 192.168.1.2 in
browser’s URL box. The default username and password are: admin/admin.
2.1 Basic
2.1.1 WAN
Center/APN/Username/Password: These parameters have been set when leaving
factory. Under normal condition, they are can be left as default. But if there is using the
VPDN, please type they according to the info provided by operator.
Notice: If there is PIN or other parameters need to be typed, please check
“Advance”, then fill them according to the info provided by operator.
Work Mode: there are four modes can be chosen for RTU to dial to Internet -- SIM
Dial/PPPoE ADSL Dial/Static Address/Static Master SIM Backup.
User/Password: They are available if the work mode is PPPoE ADSL Dial. Please
check them with operator.
Static IP: It’s available if the work mode is Static Address. Please type it with a

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
10
available IP address of a LAN.
GW IP: It’s available if the work mode is Static Address. Please type it with the
gateway IP of this LAN.
2.1.3 LAN
As default, CM RTU’s LAN is 192.168.1.0/24, and its default LAN IP is 192.168.1.2.
You can leave it as default.
Notice: If you want to change LAN segment, please make sure that RTU’s LAN1
IP is between Start IP and End IP.
2.1.3 DDNS
There are four service provider can be chosen.
Disable:
Don’t setup this function.
Dyndns:
Host: Domain name registrated from dyndns.
User: Username to log in dyndns server.
Password: Password to log in dyndns server.

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
11
88ip:
Server1/2: 88IP supply DNS server address, check:
http://www.88ip.cn/Info/list.asp?Unid=89
Interval: How long to update one time.
Username: Username to log in 88ip server.
Password: password to log in 88ip server.
Oray:
Username: Username to log in Oray.
Password: Password to log in Oray.

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
12
2.1.4 Keep Alive
It’s a feature to detect the state of data transmission channel between RTU and Internet
in every few minutes automatically. If it detects an abnormal network state, RTU will restart
and re-dial automatically. This is used to achieve a function that router will keep online all
the time even if without administrator’s monitoring.
Please according to practical situation, type a reachable IP address in “Destination IP
1/2”. “Check Interval” and “Check Timeout” can be left in default value.
Notice:
a. If this function has been closed, then the RTU will not detect the network state, so
RTU will not restart and re-dial even if it’s offline.
b. The destination IP should be stable and reachable for RTU, for if destination is
unstable then it’ll cause the router to reboot constantly.
c. This function is used for public as default, so in private network, destination IP
should be modified.
2.2 Advance
2.2.1 Filter
It mainly used to filter wireless network data transmitting and receiving, to prevent
illegal and invalid data from gateway. It admits and refuses computers of LAN connected
with gateway to get access to WAN, or admits and refuses WAN to get access to LAN
connected with gateway.

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
13
Filter mode: Client IP filtering and MAC address filtering, client can select
according to their actual need.
Client IP filtering: Filter data according to IP address base on appointed policy to
admit or prevent corresponding IP address data.
MAC filtering: Filter data according to MAC address base on appointed policy to
admit or prevent corresponding MAC address data.
Running Rules: This device has two kinds running rules.
Discard matching following rule data packets: data packets comply to following
rules are not allowed to go through, other data packets can go through. Receiving matching
following rule data packets: only receive data packets comply to following rule, others are
discarded.
IP Filter
To realize IP address filtering rules appointing, revising and deleting.
Rule name：it is limited to use characters0-9.a-z.A-Z，also can’t repeat name.
LAN IP：Wireless gateway connected LAN IP address.
LAN Ports：LAN IP address host corresponding ports scope. Valid value is
0~65535, please input from small to large.
WAN IP：Data packet destination IP address.
WAN Ports：Data packet destination ports scope. Valid value is 0~65535，please
input from small to large.
Protocol: data packet protocol, here are 3 types:
ALL : All types data packet.
TCP : All TCP packet.
UDP : All UDP packet.
Direction：data packet direction, used to decide which is original address, there are 3

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
14
types.
IN : From outside network to gateway.
OUT : Transmit from gateway LAN.
IN/OUT: Include IN and OUT
Interface: Data packet go through interface, such as br0，PPP0 and so on.
Example 1 of IP address filtering:
1. If select “start client IP address filtering”
2. Running rules select: “discard packets matching following rules ”，click “Apply” to save
running rule.
Instruction: If select “discard packets matching following rules”, default rule is: wireless
gateway allows all data to go through, but not allowed data packet to go through.
3. Input parameters in IP rule.
This example parameter is:
Name：enableipfilter01
LAN IP：192.168.1.23
WAN IP：121.204.201.13
Protocol：all
Direction：IN
Interface：PPP0
Read picture 4-2-3，then click “submit” to save IP filtering rule.
4. Explanation and Introduction
After this rule built, gateway will start IP address filtering function.According to running
rule “Discard packet matching following rule”, gateway discards all protocol data packets
(select “ALL”) from WAN “121.204.201.13”(select “IN”direction) in PPP0 interface
(select “PPP0”interface), but other IP address data packets don’t comply to this rule can
come and go normally.

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
15
Picture 4-2-3
Example 2 of IP address filtering:
1、select “setup client IP filter”
2、Running rule: “receive packet matches following rules”, click “Apply” to save.
Instruction：if running rule select “receive packet matches following rules”, default rule is :
Gateway forbids all data packet go through except data packet of picture
3. Input parameters in IP rule.
This example parameter:
Name：enableipfilter02
LAN IP：192.168.1.23
WAN IP：121.204.201.13
Protocol：all
Direction：IN/OUT
Interface：PPP0
Read picture 4-10-3，then click “Submit” to save.
4、Explanation and Instruction
After this rule built, gateway will start IP address filtering function. According to running
rule “Receive packet matching following rule”, gateway forbid all data packet to go
through, but only allow protocol data packets (select “ALL”) from WAN
“121.204.201.13”(select “IN/OUT” direction) to go through PPPO interface (select PPP0

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
16
interface). Usually this rule shields invalid IP address to go through gateway, can reduce
data flow, or as bank application, can shield other IP address access to bank IP address to
realize filtering functional and reduce data flow.
MAC Address Filter
Rule name：it is limited to use characters 0-9.a-z.A-Z，also can’t repeat name
MAC：Block or permit device MAC address, input format is“00:12:23:34:45:56”
Example 1:
1. If select “setup MAC address filtering”
2. Running rule select: “discard packet matching following fule ”
3. Input“00:00:23:34:45:56”in MAC.
So gateway will discard all data packet of MAC address “00:00:23:34:45:56”,
meanwhile permit all data packet which MAC address is not“00:00:23:34:45:56”to go
through.
Example 2 :
1. If select “setup MAC address filtering”
2. Running rule select: “receive packet matching following rule”
3. Input“00:00:23:34:45:56”in MAC.
So gateway only receive data packet which MAC address is “00:00:23:34:45:56”, and
discard all other data packet which MAC address is not “00:00:23:34:45:56”.
2.2.2 NAT/DMZ
NAT
The full name of NAT is “Network Address Translation”, also means port mapping. It’s

厦 门 才 茂 通 信 科 技 有 限 公 司
Xiamen Caimore Communication Technology Co.,Ltd
17
a technology that map private IP addresses to a WAN address’s different ports, which makes
devices in LAN can be accessed by Internet.
By setting these parameters, it’ll transfer the data from Internet to a specified host and
port in the LAN via port mapping.
Name: It’s used to identify different rules, so each name should be different. Please
name it with 0-9,a-z,A-Z, other characters will not be supported.
Protocol: There are three protocols can be chosen -- TCP, UDP and TCP/UDP.
External Port: WAN port.
Internal IP Address: The private IP address you want to map to external.
Internal Port: The port of internal host you want to map to external.
DMZ
In order to achieve the both-way communication, DMZ will expose a specified internal
host to Internet, that also means the host will play a role of virtual server. When there are
external users who wanting to visit the public IP address that mapped by the virtual server,
then router will transfer the data to virtual server directly.
If there is a host in LAN who wants to connect Internet directly, DMZ is a simple method to
achieve this purpose.
DMZ：Set form is to select “Start DMZ”directly, then input virtual server IP in the
IP address bar. Click “Apply”to save.
