CalderaSpas CANTABRIA User manual

2015 OWNER’S MANUAL • 50Hz

Owner’s Manual
This Owner’s Manual will acquaint you with the operation and general maintenance of your new spa. We suggest that you take
some time to carefully review all sections. Please keep this manual available for reference.
If you have any questions about any aspect of your spa’s set-up, operation or maintenance, contact your authorized
CALDERA dealership. They are trained professionals who are familiar with the product as well as new spa ownership
concerns. Their expertise will facilitate the enjoyment of your new CALDERA spa.
The serial number/identification label is located within the equipment compartment of your CALDERA spa. The serial number
should also be documented on the delivery receipt from your dealer.
IMPORTANT: Watkins Manufacturing Corporation reserves the right to change specifications, or design, without notification
and without incurring any obligation.
DATE PURCHASED: ____________________________________
DATE INSTALLED: ______________________________________
DEALER: _____________________________________________
ADDRESS: ____________________________________________
TELEPHONE:__________________________________________
SPA MODEL/SERIAL NUMBER: ___________________________
COVER SERIAL NUMBER: _______________________________
In most cities and counties, permits will be required for the installation of electrical circuits or the
construction of exterior surfaces (decks and gazebos). In addition, some communities have adopted
residential barrier codes which may require fencing and/or self-closing gates on the property to prevent unsupervised access to a pool (or spa) by
children under 5 years of age. Your CALDERA spa is equipped with a locking cover that meets the ASTM F1346-91 Standard for Safety Covers, and as
a result, is usually exempt from most barrier requirements. As a general practice, your local Building Department will inform you of any applicable barrier
requirements at the time a permit is obtained for the installation of an electrical circuit. Your CALDERA dealer can provide information on which permits
may be required.
WELCOME
Watkins Manufacturing Corporation congratulates you on your decision to enjoy the finest spa
available... Welcome to the growing family of Caldera®Spa owners.
NOTE: This is an example. Your spa’s
label will contain different information.
Peel off top sticker and place here.
MODEL: GENEVA
SERIES: UTOPIA
SERIAL: GEBE1S1001
RATINGS: 240V, 60Hz, 40A
1280 Park Center Dr., Vista, CA 92081
Watkins Manufacturing Corp.
GEBE1S1001
GEBE1S1001
GEBE1S1001
GEBE1S1001

TABLE OF CONTENTS
SAFETY INSTRUCTIONS
• Important Safety Instructions .................................................................... 1
• Important Spa Instructions ........................................................................ 3
INSTALLATION
• Site Preparation......................................................................................... 3
• Outdoor and Patio Installation................................................................... 3
• Deck Installation ........................................................................................ 4
• Indoor/Basement Installation..................................................................... 4
• Ground and Spa Leveling Preparation..................................................... 4
• Delivery Access ......................................................................................... 5
• Spa Cover Installation ............................................................................... 5
DIMENSIONS
• Cantabria™................................................................................................. 6
• Geneva™and Niagara™............................................................................ 7
• Tahitian™................................................................................................... 8
• Makena™and Salina™............................................................................. 9
• Martinique™.............................................................................................. 10
• Kauai™...................................................................................................... 11
CONTROLS AND EQUIPMENT
• CANTABRIA............................................................................................ 12
• GENEVA.................................................................................................. 13
• NIAGARA ................................................................................................ 14
• TAHITIAN
(WITH ATLAS MASSAGE SYSTEM) .......................... 15
• TAHITIAN
(WITHOUT ATLAS MASSAGE SYSTEM) ................. 16
• MAKENA ................................................................................................. 17
• SALINA.................................................................................................... 18
• MARTINIQUE ......................................................................................... 19
• KAUAI ..................................................................................................... 20
ELECTRICAL INSTALLATION
• Electrical Requirements and Precautions (CANTABRIA)..................... 21
• Electrical Requirements and Precautions (Utopia™ and Paradise™) . 22
START-UP AND REFILL PROCEDURES .......24
CUSTOMIZING YOUR MASSAGE
• Diverter Valves......................................................................................... 25
• Acquarella™Waterfall Valve.................................................................... 25
• Atlas™Neck Jet Valve ............................................................................. 25
• Air Controls .............................................................................................. 25
• Hydro Jets................................................................................................ 25
• Air Jets ..................................................................................................... 26
JET MENUS
• CANTABRIA............................................................................................ 27
• GENEVA ................................................................................................. 28
• NIAGARA ............................................................................................... 29
• TAHITIAN
(WITH ATLAS MASSAGE SYSTEM) .......................... 30
• TAHITIAN
(WITH ATLAS MASSAGE SYSTEM) .......................... 31
• MAKENA ................................................................................................. 32
• SALINA.................................................................................................... 33
• MARTINIQUE.......................................................................................... 34
• KAUAI ..................................................................................................... 35
UTOPIA OPERATING INSTRUCTIONS
• Main Control Panel..................................................................................... 36
• Temperature Control .................................................................................. 37
• Locking Features........................................................................................ 38
• Jets Control................................................................................................. 38
• Light Control ............................................................................................... 39
• Additional Functions................................................................................... 40
• Audio Control ................................................................................ 41
• Auxiliary Control ......................................................................................... 42
• UltraMasseuse™Control Panel Buttons .................................................. 43
PARADISE OPERATING INSTRUCTIONS
• Main Control Panel Buttons and Display ............................................... 45
• System Mode........................................................................................... 46
• Clean Cycle ............................................................................................. 46
• Tools Menu .............................................................................................. 46
• Audio Controls (Optional)........................................................................ 48
EQUIPMENT COMPARTMENTS
• CANTABRIA............................................................................................ 51
• GENEVA, NIAGARA, and TAHITIAN.................................................... 53
• SALINA, MARTINIQUE, and KAUAI .................................................... 55
MAINTENANCE
• Filter Maintenance ................................................................................... 57
• Diverter Valve Maintenance .................................................................... 57
• VersaSsage™and Orbissage™Jets Maintenance................................. 58
• Draining Your Spa ................................................................................... 58
• Prevention of Freezing ............................................................................ 59
• Winterizing Your Spa ............................................................................... 59
• Care of the Spa Pillows........................................................................... 59
• Care of the Exterior ................................................................................. 59
• Care of the Spa Cover ............................................................................ 59
WATER QUALITY AND MAINTENANCE
• Water Terminology................................................................................... 61
• General Information................................................................................. 61
• Methods for Testing the Spa Water ........................................................ 62
• The Watkins Spa Water Maintenance Program .................................... 62
• FROG®Water Care System ................................................................... 62
• Bromine.................................................................................................... 65
• Supplemental Water Maintenance ......................................................... 66
• Common Water Chemistry Questions.................................................... 68
• Spa Water Maintenance Troubleshooting Guide ................................... 69
SERVICE
• Miscellaneous Service Information......................................................... 70
• Acts Invalidating Warranty....................................................................... 70
• Disclaimers .............................................................................................. 70
• Watkins Customer Service...................................................................... 70
SPA TROUBLESHOOTING ..............................................71
SPA SPECIFICATIONS.....................................Back Cover

1
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
AVOIDING THE RISK TO CHILDREN
DANGER:
RISK OF CHILD DROWNING. Extreme caution must be exercised to prevent unauthorized access by children. To avoid accidents, ensure that children cannot use a
spa unless they are supervised at all times.
WARNING:
• To reduce the risk of injury, do not permit children to use this spa unless they are closely supervised at all times.
• To reduce the risk of injury, lower water temperatures are recommended for young children. Children are especially sensitive to hot water.
DO:
• Make sure you always lock the child resistant locks after using the spa for your children’s safety. Every CALDERA spa is equipped with a locking cover that
meets the ASTM F1346-91 Standard for Safety Covers.
• Test the water temperature with your hand before allowing children to enter the spa to be sure that it’s comfortable. Children are especially sensitive to hot
water.
• Remind children that wet surfaces can be very slippery. Make sure that children are careful when entering, or exiting the spa.
DON’T:
• Allow children to climb onto the spa cover.
• Allow children to have unsupervised access to the spa.
AVOIDING THE RISK OF ELECTROCUTION
DANGER - RISK OF ELECTROCUTION
• Connect only to a grounded source.
• Do not bury the power cord. A buried power cord may result in death, or serious personal injury due to electrocution if direct burial-type cable is not used, or if
improper digging occurs.
• A ground terminal (pressure wire connector) is provided on the control box inside the unit to permit connection of a minimum 6 mm²(No. 10 AWG) solid
copper bonding conductor between this point and any metal equipment, metal water pipe, metal enclosures of electrical equipment, or conduit within 1.5 m (5
feet) of the unit as needed to comply with local requirements.
• Do not operate the main audio/video button controls on any external media devices such as a CD or DVD player while inside in the spa. Operation of
integrated audio/video equipment through the spa control panel or wireless remote is permitted and acceptable.
• Do not connect any auxiliary components (for example, cable additional speakers, headphones, additional audio components) to the audio system unless
approved by Watkins Manufacturing Corporation .
• Do not self service audio component by opening spa door as this may expose dangerous voltage or other risk of injury. Refer all servicing to qualified service
personnel.
• Do not attach an external antennae to a spa audio system unless installed by a licensed electrician in accordance with National Electric Code.
WARNING:
• To reduce the risk of electrical shock, replace a damaged cord immediately. Failure to do so may result in death or serious personal injury due to electrocution.
• Always test the Ground Fault Circuit Interrupter (GFCI) before each use of the spa. If the GFCI does not perform properly, a ground current is flowing indication
the possibility of electric shock. Disconnect power to the spa until the fault has been identified and corrected.
• NOTE: Failure to wait 30 seconds before resetting the GFCI may cause the spa’s Power Indicator (on the control panel) to blink. If this occurs, repeat the GFCI
test procedure.
• Install the spa so proper drainage is provided for the compartment containing the electrical components.
DANGER: RISK OF ELECTRICAL SHOCK
• Install spa at least 1.5 m from all metal surfaces. A spa may be installed within 1.5 m of a metal surface if each metal surface is permanently connected by a
minimum 8.4 mm2(8 AWG) solid copper conductor attached to the wire ground connector on the terminal box that is provided for this purpose.
• Do not permit any electrical appliances, such as a light, telephone, radio, or television within 1.5 m of a spa. Failure to maintain a safe distance may result in
death, or serious personal injury due to electrocution, if the appliance should fall into the spa.
• Install your spa in such a way that drainage is away from the electrical compartment and from all electrical components.
SAFETY INSTRUCTIONS

2
DO:
• Be sure your spa is connected to the power supply correctly - use a licensed electrical contractor.
• Disconnect the spa from the power supply before draining the spa or servicing the electrical components.
• Test the Ground Fault Circuit Interrupter(s) before each use.
• Replace audio components only with identical components (if your spa is equipped with an audio component).
DON’T:
• Use the spa with the equipment compartment door removed.
• Place electrical appliances within 1.5m of the spa.
• Use an extension cord to connect the spa to its power source. The cord may not be properly grounded and the connection is a shock hazard. An extension
cord may cause a voltage drop, which will cause overheating of the jet pump motor and motor damage.
• Attempt to open the electrical control box. There are no user serviceable parts inside.
RISKS TO AVOID
DANGER: RISK OF INJURY
• To reduce the risk of injury to persons, DO NOT remove floating weir, basket and filter located in the filter compartment while the spa is running.
• Never replace a suction fitting with one rated less than the flow rate marked on the original suction fitting.
• There is a danger of slipping and falling. Remember that wet surfaces can be very slippery. Take care when entering or exiting the spa.
• Never operate spa if the suction fittings are broken or missing.
• People with infectious diseases should not use the spa.
• Keep any loose articles of clothing or hanging jewelry away from rotating jets or other moving components.
INCREASED SIDE EFFECTS OF MEDICATION
• The use of drugs, alcohol or medication before or during spa use may lead to unconsciousness with the possibility of drowning.
• Persons using medications should consult a physician before using a spa; some medication may cause a user to become drowsy, while other medication may
affect heart rate, blood pressure, and circulation.
• Persons taking medications which induce drowsiness, such as tranquilizers, antihistamines, or anticoagulants should not use the spa.
HEALTH PROBLEMS AFFECTED BY SPA USE
• Pregnant women should consult a physician before using spa.
• Persons suffering from obesity, or with a medical history of heart disease, low or high blood pressure, circulatory system problems, or diabetes should consult a
physician before using spa.
UNCLEAN WATER
• Keep the water clean and sanitized with correct chemical care. The recommended levels for your CALDERA spa are:
Bromine: 1.0 - 2.0 ppm Water pH: 7.2 - 7.6
Total Alkalinity: 40 - 120 ppm Calcium Hardness: 50 - 150 ppm
(Refer to Water Quality and Maintenance section for complete instructions.)
IMPORTANT: Turn on the clean cycle when adding ANY spa water chemicals into or in front of the filter compartment.
• Clean the filter cartridge at least monthly to remove debris and mineral buildup which may affect the performance of the hydromassage jets, limit the flow, or
trip the high limit thermostat, which will turn off the entire spa.
AVOIDING THE RISK OF HYPERTHERMIA
Prolonged immersion in hot water can result in HYPERTHERMIA, a dangerous condition which occurs when the internal temperature of the body reaches a level above
normal (37°C). The symptoms of hyperthermia include unawareness of impending hazard, failure to perceive heat, failure to recognize the need to exit the spa, physical
inability to exit the spa, fetal damage in pregnant women, and unconsciousness resulting in a danger of drowning.
WARNING:
The use of alcohol, drugs, or medication can greatly increase the risk of fatal hyperthermia in hot tubs and spas.
TO REDUCE THE RISK OF INJURY:
• The water in the spa should never exceed 40°C. Water temperatures between 38°C and 40°C are considered safe for a healthy adult. Lower water
temperatures are recommended for extended use (exceeding ten minutes) and for young children. Extended use can cause hyperthermia.
SAFETY INSTRUCTIONS

• Pregnant or possibly pregnant women should limit spa water temperatures to 38°C. Failure to do so may result in permanent injury to your baby.
• Do not use spa immediately following strenuous exercise.
AVOIDING THE RISK OF SKIN BURNS:
• To reduce the risk of injury, before entering a spa, the user should measure the water temperature since the tolerance of temperature-regulating devices
varies.
• Test the water with your hand before entering the spa to be sure it’s comfortable.
SAFETY SIGN
Each CALDERA spa is shipped with a SAFETY SIGN in the owner’s package. The sign, which is required as a condition of Product Listing, should be permanently
installed where it is visible to the users of the spa. To obtain additional SAFETY SIGNS, contact your CALDERA dealer and request Part #33869.
IMPORTANT SPA INSTRUCTIONS
The following contains important spa information, and we strongly encourage you to read and apply them.
DO:
• Use and lock the cover when the spa is not in use, whether it is empty or full.
• Follow the Spa Care and Maintenance recommendations stated in this manual.
• Use only approved accessories and recommended spa chemicals and cleaners.
DON’T:
• Leave the CALDERA spa exposed to the sun without water or the cover in place. Exposure to direct sunlight can cause solar distress of the shell material.
• Roll or slide the spa on its side. This will damage the siding.
• Lift or drag the vinyl cover by using the cover lock straps; always lift or carry the cover by using the handles.
• Attempt to open the electrical control box. There are no user serviceable parts inside. Opening of the control box by the spa owner will void the warranty. If you
have an operational problem, carefully go through the steps outlined in the Troubleshooting section. If you are not able to resolve the problem, contact your
authorized CALDERA dealer. Many problems can easily be diagnosed over the telephone by an Authorized Service Technician.
SAVE THESE INSTRUCTIONS
SITE SELECTION AND PREPARATION
• You probably have a spot picked out for your new spa, whether it’s indoors or outdoors, on a patio or on a deck. Just
make sure you check the following:
• Always put your spa on a structurally sound, level surface. A filled spa is very heavy. Make certain that the location you
choose can support the weight of your filled spa.
• Don’t forget to level your spa before filling it. (See the Spa Leveling Preparation section of this manual.)
• Locate your equipment compartment, which houses all of the electrical components, in a place where water will drain away
from it. Allowing water into the equipment compartment can damage the electronics, or may result in tripping your house’s
circuit breaker.
• Never let water get into the subpanel. Your 230 volt spa’s subpanel is rain tight when installed correctly with the door closed.
• Leave access to the entire front of the spa (the removable panel provides access to the spa’s equipment) for periodic spa
care and maintenance.
• Note that on the Utopia™Series spas, the SpaGlo™exterior lighting fixtures are located on only three sides. The side
opposite the main control panel has no lighting.
WARNING: Damage to the spa’s equipment compartment components or internal plumbing as a result of rodent
infestation is NOT covered under your warranty!
OUTDOOR AND PATIO INSTALLATION
No matter where you install your new spa, it’s important that you have a solid foundation to support it. Structural damage to the spa,
resulting from incorrect installation, or placement on an inadequate foundation, is not covered under the spa’s limited warranty.
If you install the spa outdoors, we recommend a reinforced concrete pad at least ten centimeters thick. The reinforcing rod or mesh in the pad should be attached to a
bond wire.
WARNING
WARNING
Watkins Manufacturing
Corporation recommends
that the CALDERA spa
be installed above ground.
Lowering the top of the
spa to ground level, or
employing decking which
raises standing level
toward the top of the spa
substantially increases
the hazard of accidental
entry. Consult a licensed
building contractor to design
or evaluate your custom
decking requirements.
3
SAFETY INSTRUCTIONS
INSTALLATION

4
DECK INSTALLATION
To be certain your deck can support your spa, you must know the deck’s maximum load capacity. Consult a qualified building contractor or structural engineer. To find
the weight of your spa, its contents and occupants, refer to the Spa Specification chart on back page. This weight per square foot must not exceed the structure’s rated
capacity, or serious structural damage could result.
INDOOR/BASEMENT INSTALLATION
Be aware of some special requirements if you place your spa indoors. Water will accumulate around the spa, so flooring materials must provide a good grip when wet.
Proper drainage is essential to prevent a build-up of water around the spa. When building a new room for the spa it is recommended that a floor drain be installed. The
humidity will naturally increase with the spa indoors. Water may get into woodwork and produce dry rot, mildew, or other problems. Check for airborne moisture’s effects
on exposed wood, paper, etc. in the room. To minimize these effects, it is best to provide plenty of ventilation to the spa area. An architect can help to determine if more
ventilation must be installed.
CALDERA spas are equipped with a jet pump shroud to remove excessive heat from the equipment compartment. Find this vent and be sure the vent is not blocked by
anything, including carpeting.
Your CALDERA dealer can help you with local information such as zoning regulations and building codes.
WARNING: Please keep the area around your spa well ventilated when it is installed indoors or in a confined area. Inadequate ventilation around the spa could
cause a build-up of a higher-than-normal concentration of spa chemicals and/or bacterial fragments. These dispersed spa chemicals and/or bacterial fragments can be
inhaled, and may result in breathing difficulties or lung damage in certain people suffering from a compromised immune system or respiratory infection. If you or other bathers
are affected by this condition, please seek medical attention as soon as possible.
In addition to the above, properly clean and maintain your spa as follows:
• Follow all procedures in this owner’s manual and printed instructions on all water care (chemical) products packaging.
• Test the water regularly to ensure proper levels of sanitizers, pH, and other water care requirements.
• Drain, clean, and refill your spa with fresh water on a regular schedule, and in accordance with this owner’s manual.
• Clean the filter(s) at least once per month.
• Check to make sure you have proper circulation throughout your spa water system.
• Have spa users bathe before entering the spa water.
GROUND AND SPA LEVELING PREPARATION
Your CALDERA spa has been engineered to perform on several types of common yard surfaces.
While a concrete slab is best for long-term use, other foundations are acceptable as long as a level
base is prepared prior to delivery. Two foundation base pictures, shown at right, represent examples
of alternatives to a concrete slab for spas installed without gazebos or other accessories.
NOTE: A reinforced concrete pad at least four inches thick or structurally sound deck able to support
the “dead weight” found in the spa specification chart is required for the CANTABRIA, GENEVA,
NIAGARA, and SALINA spas, and recommended for the TAHITIAN, MARTINIQUE,and KAUAI
spas. The reinforcing rod or mesh in the pad should be attached to a bond wire.
INSTALLATION NOTES:
• Concrete sloped at 1.5 centimeters per 3 meters is preferred so that rain water and water
spillover will run off and not puddle underneath the spa (water under the spa for long
periods of time may cause the wood to deteriorate).
• If stepping stones or railroad ties are selected for the spa foundation, they should be
placed and leveled below the entire spa to maintain even distribution of the spa weight.
• It is important to note that soft surfaces, even when stepping stones are used to distribute the weight of the spa as evenly as possible, will still have a tendency
to settle unevenly, resulting in an unlevel spa.
NOTE: Placing the spa on grass or dirt may increase the amount of debris which is inadvertently brought into the spa water and may cause harm to your equipment as
well as the spa surface, which is not covered under warranty.
RAILROAD TIES
PRE-CAST
STEPPING STONES
PEA GRAVEL
OR CRUSHED ROCK
FOUNDATIONS FOR SPAS ONLY
(No gazebo)
CONCRETE PADS
BRICK SURFACES
WOOD DECKING
FOUNDATIONS FOR SPAS
WITH GAZEBOS
Stepping stones or brick may settle causing the spa to be unlevel.
Slope 1.5 cm (1/2 inch) per 3 m (10 ft.) for proper
drainage.
1.5 cm
(1/2 inch)
3 m (10 ft.)
LEVEL
INSTALLATION

5
DELIVERY ACCESS
NOTE: It may be necessary to allow for additional over-head clearance if the spa will be rolled up or down an incline or
moved up or down a short flight of stairs.
Use the information in the chart on the next page to determine the requirements for access to your desired location. It may
be necessary to remove a gate, part of a fence, or other movable obstructions in order to roll the spa to its installation site.
About ten percent of the time, a crane is the only way to install the spa by lifting it to its final destination.
If the spa has to be taken off of the cart to go over a wall (either because the entry area is too narrow, the eaves are too low,
the corner is too tight, or the stairway is too steep), a crane will be required. Don’t be alarmed!
The crane has a truck-mounted boom which can fit right in your driveway. It is run by a licensed and insured operator. For
a charge, the crane operator will lift your spa over walls, buildings, or any other obstruction and place it as close to the
installation site as possible. The CALDERA spa delivery personnel will supervise the crane delivery and complete the spa
installation. Crane delivery typically takes an average of 30 minutes to complete.
NOTE: If your spa delivery requires the use of a crane, you may be required to pay for its services at the completion of the
delivery.
SPA DIMENSIONS
Model Heigth Length Width
CANTABRIA 97 cm 274 cm 231 cm
GENEVA 97 cm 226 cm 226 cm
NIAGARA 97 cm 226 cm 226 cm
TAHITIAN 91 cm 213 cm 213 cm
MAKENA 91 cm 226 cm 226 cm
SALINA 91 cm 226 cm 226 cm
MARTINIQUE 86 cm 226 cm 193 cm
KAUAI 74 cm 213 cm 165 cm
SPA COVER INSTALLATION
• Place the cover squarely on the spa.
• Position the tie-down locks included with your cover on the side of the spa so that they are easily reached by the cover tie-down straps. Allow for about 1.5 cm
to 2 cm of slack in the straps to make it easy to insert straps into locks and to compensate for vinyl shrinkage in cold weather.
• Attach the locks with the screws provided and insert the cover tie-down straps into the locks.
NOTE: Keeping the cover in place any time the spa is not in use will reduce the amount of time
the heater operates, thereby minimizing operating costs.
How is your width and height clearance?
Protruding electric meters
A/C units
Do you have sufficient
overhead clearance?
Check low roof eaves,
overhanging branches,
rain gutters
Is the path clear?
Move away branches, dog
houses, firewood, etc.
If there is a 90 turn, can we
clear it? (The spa will not bend.)
No more than 6 consecutive
stairs without a landing
to accommodate the spa
Gas meters
Check all gates
HOUSE
BACK YARD
STREET
DANGER. RISK OF INJURY.
• Never leave a spa uncovered or unattended.
• Never leave a spa cover unlocked.
• Do not stand, sit, or lie on the cover.
COVER INSTALLATION
TIE-DOWN STRAP
LOCK
COVER
KEY
SCREW (2)
INSTALLATION

6
231
274
NOTE:Watkins Manufacturing Corporation requires that the CANTABRIA be installed on a minimum 10 cm thick reinforced concrete pad or structurally sound deck able
to support the “dead weight” found in the spa specification chart.
WARNING:The CANTABRIA must not be shimmed in any manner.
CANTABRIA
NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions.
DIMENSIONS
External Sconce Light

7
NOTE:Watkins Manufacturing Corporation requires that the GENEVA and NIAGARA be installed on a minimum 10 cm thick reinforced concrete pad or structurally
sound deck able to support the “dead weight” found in the spa specification chart.
WARNING: The GENEVA and NIAGARA must not be shimmed in any manner.
GENEVA AND NIAGARA
NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions.
DIMENSIONS
FRONT VIEW
ELECTRICAL
OUTLET
(BOTH SIDES)
SPA DRAIN
DOOR DOOR
AIR VENTS
DO NOT BLOCK
OVERALL
PEDESTAL
DOOR
BOTTOM VIEW
ELECTRICAL OUTLET
AIR VENT
AIR VENT
AIR VENT
ELECTRICAL OUTLET
OVERALL
PEDESTAL
External Sconce Light

8
(84 cm)
33”
(91 cm)
36”
NOTE:Watkins Manufacturing Corporation recommends that the TAHITIAN be installed on a minimum 10 cm thick reinforced concrete pad or structurally sound deck
able to support the “dead weight” found in the spa specification chart.
WARNING:The TAHITIAN must not be shimmed in any manner.
TAHITIAN
NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions.
DIMENSIONS
FRONT VIEW
ELECTRICAL
OUTLET
SPA DRAIN
DOOR DOOR
AIR VENTS
DO NOT BLOCK
OVERALL
PEDESTAL
DOOR
BOTTOM VIEW
ELECTRICAL OUTLET
DOOR SIDE
AIR VENT
AIR VENT
ELECTRICAL OUTLET
OVERALL
PEDESTAL
External Sconce Light (TAHITIAN only)

9
NOTE:Watkins Manufacturing Corporation requires that the MAKENA / SALINA be installed on a minimum 10 cm thick reinforced concrete pad or structurally sound
deck able to support the “dead weight” found in the spa specification chart.
WARNING:The MAKENA / SALINA must not be shimmed in any manner.
MAKENA / SALINA
NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions.
DIMENSIONS
FRONT VIEW
ELECTRICAL
OUTLET
(BOTH SIDES)
SPA DRAIN
DOOR DOOR
AIR VENTS
DO NOT BLOCK
OVERALL
PEDESTAL
DOOR
BOTTOM VIEW
ELECTRICAL OUTLET
AIR VENT
AIR VENT
AIR VENT
ELECTRICAL OUTLET
OVERALL
PEDESTAL
DOOR SIDE

10
(79 cm)
31”
(86 cm)
34”
5.5” (14cm)
64.9” (165cm) 5.0”
(13cm)
1.5”
(4cm)
89”
(226cm)
87”
(221cm)
76”
(193cm)
72”
(183cm)
NOTE:Watkins Manufacturing Corporation recommends that the MARTINIQUE be installed on a minimum 10 cm thick reinforced concrete pad or structurally sound deck
able to support the “dead weight” found in the spa specification chart.
WARNING:The MARTINIQUE must not be shimmed in any manner.
MARTINIQUE
NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions.
DIMENSIONS
FRONT VIEW
ELECTRICAL CUTOUT
SPA DRAIN
DOOR
AIR VENTS
DO NOT BLOCK
OVERALL
PEDESTAL
ELECTRICAL
CUTOUT
BOTTOM VIEW
ELECTRICAL OUTLET
DOOR SIDE
AIR VENT
AIR VENT
ELECTRICAL
OUTLET
OVERALL
PEDESTAL

11
80.375” (204cm)
84” (213cm)
61.25”
(156cm)
5.5” (14cm) 5.5”
26”
(66 cm)
29”
(74 cm)
65”
(165cm)
DOOR
51.25”
(130cm)
NOTE:Watkins Manufacturing Corporation recommends that the KAUAI be installed on a minimum 10 cm thick reinforced concrete pad or structurally sound deck able
to support the “dead weight” found in the spa specification chart.
WARNING:The KAUAI must not be shimmed in any manner.
KAUAI
NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions.
DIMENSIONS
FRONT VIEW
ELECTRICAL CUTOUT
SPA DRAIN
AIR VENTS
DO NOT BLOCK
OVERALL
PEDESTAL
ELECTRICAL
CUTOUT
BOTTOM VIEW
ELECTRICAL
OUTLET
DOOR SIDE
AIR VENT
AIR VENT
ELECTRICAL
OUTLET
OVERALL
PEDESTAL

12
CONTROLS AND EQUIPMENT
1
UTOPIA CANTABRIA
OVERHEAD VIEW
1. Air Control
2. Temperature Sensor
3. Euro Directional Jet
4. Euro-Pulse
™
Jet
5. ULTRAMASSEUSE
Control Panel
6. AdaptaSsage
™
Jet
7. VERSASSAGE Jet
8. Euphoria
™
Jet
9. Ozone Jet / Heater
Return
10. Diverter Valve
11. Suction Screen
12. Light
13. Speaker (optional)
14. Spa Control Panel
15. Pillow
16. Filter Compartment
17. Grab Rail
18. Air Jet
19. Waterfall Valve
20. ACQUARELLA
Waterfall
21. Auxiliary Control
Panel
22. FROG Housing
23. ATLAS Neck Jet
Valve
24. ATLAS Neck Jet
Pillow
25. ORBISSAGE Jet
1
3
3
3
3
3
3
3
3
3
3
3
18
18
18
18
18
18
18
3
4
4
4
4
1
1
1
20
19
13
10
10
15 15
24
11
11
11
7
7
7
6
6
8
22
14
21
18
12
5
17
3
3
19
23
20
2
9
11
13
15
16
25
13 13 13
13
13
13

13
CONTROLS AND EQUIPMENT
1
1
1
1
34
4
4
4
4
6
5
7
7
18
12
13
14
15
25
16
19
16
21
20
17
22
2
2
3
3
4
4
4
8
3
3
3
3
4
UTOPIA GENEVA
10
23
24
12
12
3
3
1
OVERHEAD VIEW
1. Air Control
2. EURO-PULSE Jet
3. Euro Directional Jet
4. Air Jet
5. ADAPTAFLO Jet
6. ADAPTASSAGE
Jet
7. VERSASSAGE Jet
8. ORBISSAGE Jet
9. Whirlpool Jet
10. EUPHORIA Jet
11. Diverter Valve
12. Suction Screen
13. Light
14. Ozone Jet / Heater
Return
15. Control Panel
16. Pillow
17. ACQUARELLA
Waterfall
18. Auxiliary Panel
19. Grab Rail
20. ATLAS Neck Jet
Valve
21. ATLAS Neck Jet
Pillow
22. Temperature Sensor
23. Waterfall Valve
24. Filter Lid
25. FROG Housing
26. Speakers
(Optional)
3
3
4
9
11
11
11
26
26
26
26
26
26

14
CONTROLS AND EQUIPMENT
OVERHEAD VIEW
UTOPIA NIAGARA
1. Air Control
2. EURO-PULSE Jet
3. Euro Directional Jet
4. Air Jet
5. ADAPTAFLO Jet
6. VERSASSAGE Jet
7. ORBISSAGE Jet
8. Whirlpool Jet
9. EUPHORIA Jet
10. Diverter Valve
11. Suction Screen
12. Light
13. Ozone Jet / Heater
Return
14. Control Panel
15. Pillow
16. Filter Compartment
17. Auxiliary Panel
18. Grab Rail
19. ATLAS Neck Jet Valve
20. ATLAS Neck Jet Pillow
21. Temperature Sensor
22. Waterfall Valve
23. ACQUARELLA
Waterfall
24. FROG Housing
25. Speakers (Optional)
10
20
19
17
15
15
18
15
16
14
11
11
12
13
1
11
9
1
2
2
3
3
3
3
3
3
4
4
4
4
4
4
6
6
6
5
8
21
7
22
4
23
24
3
1
3
10 10
15
1
7
6
25
25
25
25
25
25

15
CONTROLS AND EQUIPMENT
11
3
33
3
4
4
4
4
5
6
7
7
9
10
12
12
12
13
19
24
24
16
18
17
3
3
4
4
4
3
3
UTOPIA TAHITIAN (WITH ATLAS MASSAGE SYSTEM)
14
2
8
20
21
4
3
3
OVERHEAD VIEW
1
1. Air Control
2. Temperature
Sensor
3. Euro Directional Jet
4. Air Jet
5. ADAPTASSAGE
Jet
6. ADAPTAFLO Jet
7. VERSASSAGE Jet
8. ORBISSAGE Jet
9. Whirlpool Jet
10. EUPHORIA Jet
11. Diverter Valve
12. Suction Screen
13. Light
14. Ozone Jet /
Heater Return
15. Control Panel
16. ATLAS Neck Jet
Pillow
17. Filter Compartment
18. Auxiliary Panel
19. Grab Rail
20. Waterfall Valve
21. ACQUARELLA
Waterfall
22. FROG
Housing
23. Speakers (Optional)
24. Pillow
11
15
4
3
4
11
22
1
1
11
23
23
23
23
23
23

16
1. Air Control
2. Temperature
Sensor
3. Euro Directional Jet
4. Air Jet
5. ADAPTASSAGE
Jet
6. ADAPTAFLO Jet
7. VERSASSAGE Jet
8. ORBISSAGE Jet
9. Whirlpool Jet
10. EUPHORIA Jet
11. Diverter Valve
12. Suction Screen
13. Light
14. Ozone Jet /
Heater Return
15. Control Panel
16. ATLAS Neck Jet
Pillow
17. Filter Compartment
18. Auxiliary Panel
19. Grab Rail
20. Waterfall Valve
21. ACQUARELLA
Waterfall
22. FROG
Housing
23. Speakers (Optional)
24. Pillow
11
3
33
3
4
4
4
4
5
6
7
7
9
10
12
12
12
13
19
16
16
16
18
17
3
3
4
4
4
3
3
UTOPIA TAHITIAN (WITHOUT ATLAS MASSAGE SYSTEM)
14
2
8
20
21
4
3
3
OVERHEAD VIEW
1
1. Air Control
2. Temperature
Sensor
3. Euro Directional Jet
4. Air Jet
5. ADAPTASSAGE
Jet
6. ADAPTAFLO Jet
7. VERSASSAGE Jet
8. ORBISSAGE Jet
9. Whirlpool Jet
10. EUPHORIA Jet
11. Diverter Valve
12. Suction Screen
13. Light
14. Ozone Jet /
Heater Return
15. Control Panel
16. Pillow
17. Filter Compartment
18. Auxiliary Panel
19. Grab Rail
20. Waterfall Valve
21. ACQUARELLA Waterfall
22. FROG Housing
23. Speakers (Optional)
11
15
4
3
4
11
22
1
1
11
23
23
23
23
23
23
CONTROLS AND EQUIPMENT

17
CONTROLS AND EQUIPMENT
PARADISE MAKENA
OVERHEAD VIEW
1. Air Control Valve
2. Temperature Sensor
3. Euro Directional Jet
4. VERSASSAGE Jet
5. ADAPTAFLO Jet
6. EUPHORIA Jet
7. Diverter Valve
8. Drain
9. Ozone Jet / Heater
return
10. Control Panel
11. Pillow
12. Filter Compartment
13. ACQUARELLA Waterfall
14. Waterfall Valve
15. Assist Bar
16. FROG
Housing
17. Speaker (Optional)
11
1
1
7
2
33
3
3
3
4
4
4
4
5
6
33
3
3
8
8
8
9
10
1111
11
12
13
14
15
16
17
17
17 17
