Calea Ambix Activ User manual

Quick Reference Guide
Ambix Activ
Ambulatory Pump & Accessories
Freephone 24 hour Advice Line 0800 121 8300Freephone 24 hour Advice Line 0800 121 8300
Ambix Activ Ambulatory Pump and Accessories - Quick Reference Guide
Alarms and Safety Features
Set Insertion
The set is not inserted correctly.
The wrong set used.
Remedy
Check the positioning.
Clean the clamp.
Use an Ambix activ giving set.
Line Empty
The bag is empty.
The set is not fully primed.
The air sensor area is contaminated.
Remedy
Stop the infusion, change, and check the bag and set.
Prime the set.
Clean.
Door Open
The pump door or lever is open.
The pump door is installed incorrectly.
The pump door mechanism is defective.
Remedy
Close the pump door and lever.
Remove the door and re-hang.
Contact Calea Patient Services or the helpline.
Battery is depleted
There is no external power available.
Remedy
Check the installation in the holder.
Check the contact pins and the pump.
Check the cable and connect to the mains.
Plug into the mains to complete.
Batteries are not charging properly
The pump is plugged in at the mains.
Remedy
Contact Calea Patient Services or the helpline.
Batteries are low
The battery power will last for 30 minutes.
Remedy
Plug the pump in to the mains.
Pump Mechanism Blocked
Contact Calea Patient Services or the helpline.
Downstream Occlusion
The infusion will stop.
Check below the pump for the following:
Kink/blockage/clamps/air particles.
Remedy
Remove the kink/blockages/clamps/air particles.
Upstream Occlusion
The infusion will stop.
Check above the pump for the following:
Kink/blockage/clamps/air particles.
Remedy
Remove the kink/blockages/clamps/air particles.
CAL099

PRIMING THE SET MANUALLY:
You will need to prime your Ambix activ giving set slowly.
Close the Ambix activ clamp.
Spike your bag with the Ambix activ giving set and hang up.
Hold the line taught.
Create an ‘S’ shape with the line.
Open the Ambix activ clamp to start priming the line. The blue cap on the end
will prevent any leakages.
Close the Ambix activ clamp when the line is fully primed. Remove blue cap
prior to connection.
INSERTING THE GIVING SET.
Open the door with the lever.
Match up the green mark on the Ambix activ giving set to green mark on the Ambix
activ pump. Make sure the foot of the clamp is facing outwards.
Position the top of the blue section on the Ambix activ giving set into the blue section on
the Ambix activ pump.
Close the pump door.
REMOVING THE GIVING SET.
Press STOP/ESC.
Press ON/OFF for 3 seconds or more.
Open the pump door.
Remove the giving set
Dispose of the set, following the guidelines in the main guide.
Ambix Activ Ambulatory Pump and Accessories - Quick Reference Guide
Freephone 24 hour Advice Line 0800 121 8300
Priming, Inserting & Removing
the Ambix activ giving set
How to use your Ambix activ pump How to clean your Ambix activ pump
Switch the pump on.
Press MODE and choose from Volume/Time, Continuous,
Intermittent, or Ramp modes (see manual) as discussed by your clinical team.
Start the infusion.
(To retrieve the last infusion volume, press the information button)
Before cleaning your pump, make sure your pump is disconnected from you and the
power mains.
It is very important that you clean your pump
When contamination occurs.
At least once a week.
Once cleaned leave the pump to dry for approximately 5 minutes before using.
Pump and Holder
Clean using:-
Lint-free, damp cloth or lint-free cloth soaked in disinfectant.
Contact pins with cotton wool soaked in disinfectant.
Keypad lock
Switch pump on
Start the pump
Hold to reset for
new information
Stop the pump or
silence the alarm
Alarm silence Pump priming
Mode:
Volume/Time
Continuous
Intermittent
Ramp
Reset to factory
settings
Set flow rate
Set time threshold
Set target volume
1
1
2
2
3
3
4
4
