Calrec SUMMA User manual

calrec.com Putting Sound in the Picture
Networked Audio Production System
SUMMA INSTALLATION MANUAL

Calrec Audio Ltd
Nutclough Mill
Hebden Bridge
West Yorkshire
England UK
HX7 8EZ
Tel: [phone]
Fax: [phone]
Email: [e-mail]
calrec.com
No part of this manual may be reproduced
or transmitted in any form or by any means,
electronic or mechanical, including photocopying
and scanning, for any purpose, without the prior
written consent of Calrec Audio Ltd.
Whilst the Company ensures that all details in this
document are correct at the time of publication,
we reserve the right to alter specifications and
equipment without notice. Any changes we make
will be reflected in subsequent issues of this
document. The latest version will be available
upon request. This publication is for International
usage.
Calrec Audio Ltd reserve the right to change
specifications without notice. E & O.E.
The established policy of Calrec Audio
Ltd. is to seek improvements to the design,
specifications and manufacture of all products.
It is not always possible to provide notice outside
the company of the alterations that take place
continually.
Despite considerable effort to produce up to
date information, no literature published by
the company nor any other material that may
be provided should be regarded as an infallible
guide to the specifications available nor does
it constitute an offer for sale of any particular
product.
Apollo, Artemis, Summa, Hydra Audio Networking
and Bluefin High Density Signal Processing
(HDSP) are trade marks of Calrec Audio Ltd.
Dolby®E is a registered trade mark of Dolby
Laboratories, Inc. All other trade marks are
acknowledged.
© 2016 Calrec Audio Ltd. All Rights Reserved.

SUMMA
CONTENTS
Information 5
Health and Safety 8
Package Contents 9
Getting Started 11
Connecting the Surface to the Core 12
Hydra IDs 14
ID configuration 14
Changing an I/O Box’s HID 14
Port Labels and SW-P-08 Settings 14
Duplicate HIDs 14
Spare/Replacement I/O Boxes 14
Setting Hydra IDs for Fixed Format I/O 15
Address 2 15
Setting Hydra IDs for Modular I/O 16
Connecting I/O to the core 17
Hardware Power Connections 19
Connecting the Laptop to the Core 20
Setting the Date and time 21
Configuring LAN Ports 22
Upgrading from v2.1 23
Control Surface 25
Surface Measurements 26
Surface components 29
Headphone and Talkback Microphone Connections 31
Talkback Mic and Headphone Connections 31
Surface Power Supply Unit 33
Connecting the Surface PSU 33
Disconnecting the Surface PSU 33
Power Distribution 33
Surface Button Caps 35
Processing Core 37
Core Dimensions and Mounting 38
Airflow 38
Support 38
Card types & Layout 39
Connections 39
Card layout 39
Installing / removing cards 39
Redundancy 39
Reset & sync interface card 40
Standard status LEDs 40
Control Processor Module 40
DS P 41
Router 41
Power supply 41
Pre-2015 Cores 42
Standard status LEDs 42
Obsolete Control Processor 42
Airflow 43
Support 43
Setting Console IDs for 2015 Processing Cores 44
Customer ID 44
Core ID 44
Excluded customer IDs 44
Connection Information 45
Small Form-Factor Pluggable (SFP) Overview 46
SFP slot orientation 46
SFP latching and extraction 46
SFP slot covers 47
Loose SFP storage 47
Copper SFP Connectivity 48
Shielded cables and connectors 48
Maximum cable length 48
Cable routing considerations 48
Termination - strain relief 48
Termination - pin-out 49
Testing/certification 49
Temporary / reusable cables 49
Fibre SFP Connectivity 50
Singlemode vs Multimode 50
Identification 50
Duplex Connectors / Terminations 50
Single Strand, Bi-Directional SFPs 50
SFP Fibre Specifications 50
Fibre - General Rules 52
Testing / Certification 52
Areas of Loss 52
Fibre Handling Practise 52
Ruggedised Fibre 52
Cleaning and Preventative Maintenance 52

4 SUMMA Networked Audio Production System
Cleaning Fibre Optic Cables and Connectors 53
Cleaning Procedure 53
Additional Notes 53
Cleaning Optical Transceivers 53
Cleaning Procedure 53
Synchronization 54
Audio I/O Connections 55
Audio Formats 55
Power 55
ID configuration 55
Modular I/O card slots 55
Hydra2 connection 55
GPIO Connections 58
GPI (inputs) 58
GPO (outputs) 58
Dry closure only outputs 58
Connecting to Other Consoles/Routers 62
Remote Control and Production Automation 65
SW-P-08 Source to Destination Router Remote Control 66
Connection and redundancy 66
Connection configuration 66
SW-P-08 I/O mapping configuration 66
Ember Remote Control 67
Remote Control–Calrec Serial Control Protocol 68
CSCP versions 68
Faders controlled by CSCP 68
Controls available via CSCP 68
Connection 68
Secondary connections 68
Multiple consoles 68
Connecting via Corporate LAN 68
Configuration 70
User & boot up enable/disable 70
RS232/422 Serial to TCP/IP Conversion 71
Perle IOLAN Configuration 72
Telnet IP configuration 72
Main configuration - Web Manager 73
Setup - User Logging 77
User Control Logging Setup 78
Path Controls Logged 79
User Logs 81
Specifications 83
General Specifications 84
Power/Environmental Specifications 85
Audio Performance Specification 90
Unit List 94
Small Parts List 95

calrec.com
Putting Sound in the Picture
SUMMA
INFORMATION

6 SUMMA Networked Audio Production System Information
Should you require any technical
assistance with your Calrec product
please contact your regional Calrec
distributor. Customers within the
UK or Ireland should contact Calrec
directly.
For a complete list of worldwide
distributors by region, go to www.
calrec.com or contact us for more
information.
For pre-delivery technical enquiries, UK
and Ireland customers should contact the
Calrec project manager assigned to their
order. Post delivery, the Calrec Customer
Support team will take care of your
technical enquiries.
Our UK customer support team works
closely with our global distributor network
to provide the highest level of after sales
support. Your distributor should be your
first point of contact and will often be
able to provide an instant solution, be it
technical advice, spares or a site visit by
an engineer.
Calrec UK customer support and our
global technical team provide free of
charge technical support and advice to all
customers by phone or e-mail.
Calrec after sales support includes:
• Free of charge comprehensive
technical advice and support by phone
and e-mail.
• Repairs.
• Quick supply of replacement or loan
hardware in the event of a failure.
• Provision of export documentation for
the return of faulty parts.
• Operational training.
• Maintenance / technical training.
• Supply of replacement components.
• Supply of documentation.
• Service contracts.
We offer a range service contracts to our
UK and Ireland customers, from 24/7
telephone support, regular health checks
and extended warranty, amongst other
benefits. Please contact our customer
support team for more information on
service contracts.
Product Warranty
A full list of our conditions and warranties
relating to goods services is contained in
Calrec’s standard terms and conditions.
A copy of this is available on request.
Repairs
If you need to return goods to Calrec for
whatever reason, please contact your
regional distributor, or Calrec customer
support beforehand for guidance, as
well as to log the details of the problem
and receive a reference number. For
customers outside the UK and Ireland,
shipping via the distributor saves
customers from dealing with exportation
paperwork. If there is a need to send
direct to Calrec, contact us beforehand to
log the incoming repair and for assistance
with exportation documents.
Standard of Service
Ensuring the highest standards is a
priority, if you have any comments on
the level of service, product quality or
documentation offered to you by Calrec,
please contact the Calrec Customer
Support team in the UK who will
endeavour to address your issues. Calrec
welcomes all customer feedback.
For feedback specific to this document,
please contact [e-mail].
Whenever you contact Calrec
Customer Support please have the
following information to hand:
• Name.
• Company.
• Email Address.
• Full details of enquiry (e.g. fault report).
• Serial number of faulty hardware (if
applicable).
Once this information has been provided,
a service ticket will be created to log your
enquiry. The service ticket reference
number will be given via email.
Serial Numbers
All units produced by Calrec are given
a serial number and are booked into
a central record system at the time
of manufacture. These records are
updated whenever a piece of hardware is
dispatched to or received from a customer.
When contacting Calrec Customer
Support with a hardware inquiry it
is important that the correct Calrec
serial number is provided to enable the
customer support team to provide a high
level of service. Summa serial numbers
can be found on the label on the rear of
the chassis as shown below.
Telephone:
(9:00am-5.30pm)
[phone]
Email - Technical: [e-mail]
Email - General:
[email protected]
Postal Address:
Calrec Audio Ltd.
Nutclough Mill,
Hebden Bridge,
West Yorkshire,
HX7 8EZ,
UK
Fax:
[phone]
Website: www.calrec.com
Made in UK by CALREC AUDIO Ltd.
Nutclough Mill, Hebden Bridge, West Yorkshire, HX7 8EZ
Email: [email protected] Tel: [phone] www.calrec.com
36+8 fader
123456
JAN 2014
100-240V AC ~
2.16-1.00A RMS
50/60Hz
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
interference received, including interference that may cause undesired operation.
WARNING: THIS APPARATUS MUST BE EARTHED
DO NOT RESTRICT VENTILATION HOLES
ENSURE ALL COVERS & SCREWS ARE FITTED
MAX. AMBIENT OPERATING TEMPERATURE 40OC
Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan.
Apparatet må tilkoples jordet stikkontakt.
Apparaten skall anslutas till jordat uttag.
!
MODEL:
SERIAL NO:
DATE OF
MANUFACTURE:
INPUT RATING
(MAX):
S U M M A C A L R E C
by
EXAMPLE OF LABEL ON REAR OF CHASSIS SHOWING SERIAL NUMBER

CALREC Putting Sound in the Picture 7
After Sales Modifications
Please be aware that any modifications
other than those made or approved by
Calrec Audio Limited or their agents, may
invalidate the console’s warranty. This
includes changes to cabling provided by
Calrec and variations to the recommended
installation as detailed in Calrec
documentation.
Modifications to this equipment by any
party other than Calrec Audio Limited
may invalidate EMC and safety features
designed into the equipment. Calrec
Audio Limited can not be liable for any
legal proceedings or problems that may
arise relating to such modifications.
If in doubt, please contact Calrec Audio
Limited for guidance prior to commencing
any modification work.
Installation
In many installations the AC power
connectors will not be readily accessible,
effectively making the equipment
permanently connected. The installation
should be carried out in accordance with all
applicable installation rules and regulations.
Service Personnel
The AC power disconnect devices are
the 2 x IEC (IEC60320-1 C13/C14)
couplers located at the rear of each unit.
WARNING: The apparatus has a dual
power system. It is essential that BOTH
AC power IEC couplers are disconnected
to prevent exposure to hazardous voltage
within the unit.
Third Party Equipment
Integrating third party equipment into
a Calrec system may compromise the
product’s ability to comply with the
radiated emission limits set in the EMC
(Electro Magnetic Compatibility) standard
EN55022.
Calrec Audio Limited can not be
responsible for any non-conformities
due to use of third party equipment. If
in doubt, please contact Calrec Audio
Limited for guidance prior to integrating
any third party equipment.
ESD (Static) Handling Procedures
In its completed form, this equipment has
been designed to have a high level of
immunity to static discharges. However,
when handling individual boards and
modules, many highly static sensitive
parts are exposed. In order to protect
these devices from damage and to protect
your warranty, please observe static
handling procedures, for example, use an
appropriately grounded anti-static wrist
band. Calrec will supply an electrostatic
cord and wrist strap with all of its digital
products.
All modules and cards should be returned
to Calrec Audio Limited in anti-static
wrapping. Calrec Audio Limited can
supply anti-static wrapping upon request.
This applies particularly to digital products
due to the types of devices and very
small geometries used in their fabrication,
analogue parts can, however, still be
affected.
RoHS Legislation
In order to comply with European RoHS
(Reduction of Hazardous Substances)
legislation, Calrec PCB and cable
assemblies are produced with lead-free
(tin/copper/silver) solder instead of tin/
lead solder.
In the unlikely event of a customer
having to carry out any re-soldering on
Apollo, Artemis or Hydra2 hardware,
it is imperative that lead-free solder is
used; contaminating lead-free solder with
UKAS AND RAB REGISTRATION
LEAD FREE STICKER
LEAD FREE
leaded solder is likely to have an adverse
effect on the long-term reliability of the
product. Circuit boards assembled with
lead-free solder can be identified (in
accordance with IPC/JEDEC standards)
by a small oval logo (see below) on the
top-side of the circuit board near the PCB
reference number (8xx-xxx). The same
logo is used on the connector hoods of
soldered cable assemblies.
If in doubt, please check with a Calrec
customer support engineer before
carrying out any form of re-soldering
ISO 9001 and RAB Registered
Calrec Audio Ltd has been issued
the ISO9001: 2008 standard by the
Governing Board of ISOQAR.
The award, for both UKAS and RAB
registration (see below), is the most
comprehensive of the ISO9000
international standards. Granted in
recognition of excellence across design,
development, manufacture and after-
sales support, the certification follows a
rigorous and thorough review of Calrec’s
internal and external communication and
business procedures.

8 SUMMA Networked Audio Production System Information
HEALTH AND SAFETY
Important Safety Instructions:
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
• Do not install near any heat sources
such as radiators, heat registers,
stoves, or other apparatus (including
amplifiers) that produce heat.
• Protect the power cord from being
walked on or pinched particularly at
the plugs, convenience receptacles,
and the point where they exit from the
apparatus.
• Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used,
use caution when moving the cart/
apparatus combination to avoid injury
from tip-over.
• Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in
any way, such as power-supply cord
or plug is damaged, liquid has been
spilled or objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does not
operator normally, or has been dropped.
• Warning: To reduce the risk of fire
or electric shock, do not expose this
apparatus to rain or moisture.
• Not intended for outdoor use.
• This equipment must be EARTHED.
• Before starting any servicing operation,
equipment must be isolated from the
AC power supply. The disconnect
devices are the 2 x IEC connectors
(IEC 60320-1 C13/C14 couplers).
• Do not allow ventilation slots to be
blocked.
• Do not leave the equipment powered
up with the dust cover fitted.
Cleaning
For cleaning the front panels of the
equipment we recommend using a soft
anti-static cloth, lightly dampened with
water if required.
Explanation of Warning Symbols
Triangular warning symbols contain a
black symbol on a yellow background,
surrounded by a black border.
The lightning flash with arrow head
symbol within an equilateral triangle, as
shown on this page, is intended to alert
the user to the presence of dangerous
voltages and energy levels within the
product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock or injury.
The exclamation mark within an
equilateral triangle, as shown on this page,
is intended to prompt the user to refer
to important operating or maintenance
instructions in the documentation supplied
with the product.
Earthing
This is a Class I product. An Earth
connection MUST be provided in each AC
power cord.
The Earth Bolt connection at the rear of
the console is provided for those users
who wish to have a separate ground/earth
connection using Earth cable at least
6 mm2 in cross section (10 AWG).
As the Summa surface has very low
leakage / touch current power supplies,
this connection is optional and is NOT
a requirement to comply with safety
standards.
Lithium Battery Replacement
Caution: Danger of explosion if battery is
incorrectly replaced. Replace only with
the same or equivalent type. Batteries
must not be exposed to excessive heat
such as sunshine, fire or the like
This device complies with part 15 of
the FCC Rules. Operation is subject to
the following two conditions:
1. This device may not cause harmful
interference.
2. This device must accept any
interference received, including
interference that may cause undesired
operation.
DANGEROUS VOLTAGES
IMPORTANT INSTRUCTIONS

CALREC Putting Sound in the Picture 9
PACKAGE CONTENTS
There are a number of options when ordering Summa systems: surface size, connectivity type and I/O options.
Every system includes a control surface and Summa Core processing core. Small format pluggable transceivers (SFPs) are required
for both surface to core connections, and Hydra2 I/O box connections and can be provided by Calrec. I/O packages are optional.
The following table shows all Summa options:
Surface and Core Packs
Summa Surface
All Summa surfaces have a number of faders, each with dedicated metering
and two control cells above, and eight Master section faders. Alps faders
a r e s u p p l i e d a s s t a n d a r d , w i t h P e n n y a n d Gi l e s f a d e r s a v a i l a b l e o n r e q u e s t .
The surface size options are: 12 + 8, 24 + 8 or 36 + 8
Summa comes with CUT button caps fitted for each fader and an equal quantity of ON
button caps are also be provided for instances when CUT/ON buttons are switched to
‘ON’ functionality from the user interface. 12 user button caps are fitted, under which
customised labels can be inserted.
Summa Core Power, Router, Control Processor, and DSP redundancy is optional for a Summa with 128
channels, and is provided as standard for a Summa with 180 channels.
SFPs One of the following four options: LX SFP Pack; SX SFP Pack; Bi-Directional SFP Pack;
none, you supply your own.
PC
A laptop with connecting cable and copper SFP are provided for accessing PC based
software interfaces and for managing the Hydra2 network via H2O. A USB to Ethernet
adapter is also provided.
Cabling Three 2.4m IEC Y-Cords for supplying power to the surface, the core and the PC.
One 2m Ethernet cable to connect the PC to the core.
I/O packs
I/O
One Modular I/O box fitted with the following modules:
2 x Analogue Mic/Line Input (balanced 8 in, 37-way D-type)—AD6057
2 x Analogue Line Output (balanced 8 out, 37-way D-type)—DA5839-3
1 x GPIO (8 in, 16 out, 50-way D-type)—WY5859-3
SFPs One of the following SFP pack options: LX SFP Pack; SX SFP Pack; Bi-Directional SFP
Pack; Copper SFP Pack; none, you supply your own.
Cabling One 2.4 m IEC Y-Cord for supplying power to the Modular I/O Box
SFP Packs
LX SFP Pack 4 x Single Mode SFPs
SX SFP Pack 4 x Multimode SFPs
Bi-Directional SFP Pack 2 x bi-directional SFPs (type A) and two bi-directional SFPs (type B)
Copper SFP Pack 4 x copper SFPs

10 SUMMA Networked Audio Production System

calrec.com
Putting Sound in the Picture
SUMMA
GETTING STARTED

12 SUMMA Networked Audio Production System Getting Started
CONNECTING THE SURFACE TO THE CORE
The Summa surface requires fibre
connections to the core via singlemode
or multimode LC SFPs. For a
redundant system two connections
are required, primary and secondary.
In the diagram on the next page the
primary connection is the solid line
and the secondary connection is the
dashed line. If you are running a
non-redundant Summa 128, only the
primary connection is required and the
cards on the right of the core will be
replaced by blanking plates.
Calrec do not provide interconnecting
fibres/cables, as the length, type and
quality will vary for each installation.
SFPs can be supplied with your Summa
system if specified at the time of order.
SUMMA CONSOLE TO CORE CONNECTIONS
To Primary Control
Processor ‘Surface
1’ connection
To Secondary Control
Processor ‘Surface 1’
connection
Status LEDs
To Control Processor
Talkback
Microphone
Output
Headphone
Inputs
Left Right
1 2
1
2
For more information on fibre and
different connection types please see
“Connection Information” on page 45.
The two control surface connections are
located on the back panel next to the
P S U u n i t a n d b e l o w t h e X L R c o n n e c t o r s .
The left hand SFP, when viewed from
the back of the surface, is the primary
connection and on the right is the
secondary connection.
In the processing core, the left hand
Control Processor is the primary, the right
hand is the secondary.
A fibre connection should be fitted
between the primary surface connection
and the primary Control Processor’s
‘Surface 1’ connector. Unless a non-
redundant system has been chosen,
a backup connection should be fitted
between the secondary surface
connection and the secondary Control
Processor’s ‘Surface 1’ connector for
redundancy.
Note, the ‘surface 1’ connection is labelled
‘MAC 7’ on some control processor
models.
It is important to ensure that these
connections are made correctly - primary
to primary, secondary to secondary and
using the correct fibre SFPs.

CALREC Putting Sound in the Picture 13
SUMMA CONSOLE TO CORE CONNECTIONS – 2

14 SUMMA Networked Audio Production System Getting Started
HYDRA IDs
Hydra2 I/O boxes with valid Hydra
IDs (HIDs), are automatically detected
and added to the Hydra database
when first plugged in to the network.
This database entry will remain until
it is manually deleted via the network
management organiser, H2O.
It is important that careful consideration is
given to HID settings prior to connecting
any I/O boxes to the network, especially if
future networking of standalone systems
is a possibility.
As an example, consider two Calrec
systems, each with several I/O boxes with
HIDs starting at ‘1’ and set in ascending
numerical order. If you later decide to
network these two systems together you
will have multiple I/O boxes with the same
HIDs on the network.
In this scenario when a Show/Memory
containing patches is loaded, there is
no way of controlling which patches will
be made to which I/O box. Instead we
recommend using a separate numbering
range for each standalone system so no
conflicts can arise in the future.
ID configuration
Each I/O box in a system needs to be
given a unique hydra ID (HID), set using
DIP switches accessible from the rear of
a fixed format box, or on the side of the
controller card within a modular I/O box.
I/O box IDs are pre-set to ‘0’ at the Calrec
factory to effectively set the boxes into
an ‘off’ state to avoid issues in the event
of multiple boxes being placed on the
network with the same HID.
Before connecting each I/O box to the
network ensure you set a unique HID by
following the instructions on the following
pages.
Note, Some customers may find
that their I/O boxes have been pre-
configured with unique HIDs at the
Calrec factory, prior to dispatch.
Changing an I/O Box’s HID
If you have already connected and
powered up an I/O box and then wish to
change its HID you will need to follow
these steps:
1. Power off the I/O box.
2. Change the HID to a new, unique value
by following the instructions on the
following pages.
3. Remove the I/O box from the console’s
required list (see Summa User Manual)
4. Remove the I/O box from Hydra
database in H2O (‘I/O box and port
labels’ tab).
5. Remove Shows/memories/patches
which reference the I/O box.
6. Reset the router by simultaneously
pressing ENABLE and ROUTER on
the front of the core.
7. Once the reset has completed, power
up the I/O box.
If you plan to reuse the original HID it
is important that you follow these steps
including removing patches (or entire
Show/memories) which patch to the
original I/O box, otherwise these patches
may be made to the ‘new’ I/O box next
time the Show/Memory containing the
patch is loaded.
Port Labels and SW-P-08 Settings
When you change a box’s HID, its
associated port labels and SW-P-08
settings will be lost. If you would like to
back them up to re-associate with the
I/O box once you have changed the HID,
simply follow these steps:
1. Open Chrome and navigate to H2O.
2. Export Label and SW-P-08 information
to a CSV file by following the
instructions in the ‘Label & SW-P-08
Data Import/Export’ section of the
H2O User Guide.
3. Open the CSV file in an editor, such as
Microsoft Excel.
4. For each entry, update the HID to your
new value.
5. Import the CSV file back in to H2O for
the correct I/O box.
Duplicate HIDs
What happens if you connect two I/O
boxes with the same HID to your Hydra2
network?
Firstly, the system will be unpredictable
in terms of its use of the ports across the
two boxes. A patch to output port 1 could
pick either box’s output port to patch to,
and each time the patch is made, either
port may be chosen.
Secondly, there will be confusion between
different I/O types. For example, in the
scenario above one I/O box may be
analogue and the other digital.
Spare/Replacement I/O Boxes
Replacement I/O boxes of equivalent
type should be set with the same IDs
as the units they are replacing to allow
them to function as drop-in replacements
with existing user memories, requiring no
further configuration.
Care should be taken when setting HIDs
to avoid accidentally duplicating the same
HID on more than one box.
Do not add extra I/O to the system
unless you are confident it will not
cause a conflict on the network.

CALREC Putting Sound in the Picture 15
SETTING HYDRA IDsFOR FIXED FORMAT I/O
The 8-way DIP switch on the rear
of all fixed format I/O boxes is set
as an 8-bit binary representation
of the HID value with the left hand
switch used for the most significant
bit, and the right hand switch for
the least significant bit. A switch in
the down/off position represents a
binary 0 and a switch set in the up/
on position represents a binary 1.
Each switch/binary-bit equates to a
decimal value, starting at 1, for the
least significant bit. The remaining
switches are double the value of their
less significant neighbour, making the
8th/most significant bit equate to a
decimal value of 128.
All fixed format I/O box ID switches are
orientated the same way, though some
boxes, such as MADI units, use a different
style switch with more pronounced
labelling. Ignore any labels on the switch
itself and always refer to the Calrec
labelling on the surrounding panel which
will show the most significant bit switch on
the left and the binary 1 position as up.
Address 2
Some I/O boxes, such as MADI units,
are fitted with 2 banks of DIP switches—
Address 1 and Address 2—to provide a
16 bit ID and therefore a greater range
of values. Please note that only ID
values between 0 and 255 are currently
supported. Any DIP switches labelled
Address 2 should all be set to the off ‘0’
position.
SETTING THE HID ON A FIXED FORMAT I/O BOX

16 SUMMA Networked Audio Production System Getting Started
SETTING HYDRA IDsFOR MODULAR I/O
The HID for modular I/O boxes is set
by a DIP switch on the controller card
and is only accessible by removing
the card. Refer to the Hydra2
installation manual and ensure ESD
precautions are observed before
removing any modular I/O box cards.
Ignore any labelling on the DIP switch
itself and refer to the Calrec labelling
printed on the circuit board around the
switch to clarify its orientation.
When viewing the card from the side, the
most significant bit is on the left and the
least significant bit on the right. Pulling a
switch towards you sets it as a binary 1,
away from you as a binary 0.
The following illustration shows the ID
switch on the modular I/O controller card.
A decimal value of 39 is used for the
example. These illustrations, along with
simple instructions, are displayed on the
top of the modular I/O box itself.
REMOVING A MOD I/O CONTROLLER CARD AND SETTING ITS HID

CALREC Putting Sound in the Picture 17
CONNECTING I/O TO THE CORE
All I/O that you wish to use with
your summa system should be
connected to the console core router
card(s) using fibre or copper cable
connected via the correct SFP for your
connection type.
For a redundant system, two connections
are required, primary and secondary. In
the diagram below the primary connection
is the solid line and the secondary
connection is the dashed line and if you
are running a non-redundant Summa 128,
only the primary connection is required.
See “Audio I/O Connections” on page
55 for more information on connecting
I/O
CONNECTING MODULAR I/O TO THE CORE

18 SUMMA Networked Audio Production System Getting Started
CONNECTING FIXED FORMAT I/O TO THE CORE
Note:- The connections to the
Pre 2015 core and 2015 core
are the same.

CALREC Putting Sound in the Picture 19
HARDWARE POWER CONNECTIONS
POWER CONNECTIONS TO THE SURFACE
POWER CONNECTIONS TO THE 2015 CORE
All Summa Hydra2 hardware requires mains power via standard IEC connections.
While Calrec hardware can be run off one power connection, it is advised, for redundancy, that you connect a separate power source to
the primary and secondary power inlets. In the following diagrams the primary power connection is indicated by a solid arrow and the
secondary connection by a dashed arrow.
POWER CONNECTIONS TO A MODULAR I/O BOX
POWER CONNECTIONS TO A FIXED FORMAT I/O BOX

20 SUMMA Networked Audio Production System Getting Started
CONNECTING THE LAPTOP TO THE CORE
The support laptop provides access to
software applications and diagnostic
tools for interacting with the Summa
system and the wider Hydra2 network.
The laptop has one gigabit ethernet
port which should be connected to the
‘Surface 2’ (MAC 6 on some models)
connection on the primary control
processor which is located in the Summa
Core.
A USB to Ethernet adapter is provided for
all other networking needs.
CONNECTING THE SUPPORT LAPTOP
