Cambridge Audio iD100 User manual

E GLISH
Digital Docking Station for iPod®
User’s manual
2
Your music +our passion
iD100

2
Contents
Introduction ...........................................................................3
Important safety instructions...............................................4
Limited warranty ...................................................................7
Rear panel connections........................................................8
Front panel ..........................................................................10
Connections ........................................................................12
Remote control....................................................................14
Operating instructions ........................................................17
Technical specifications .....................................................18
Troubleshooting ..................................................................19
Make sure you register your purchase!
Visit: www.cambridgeaudio.com/sts
By registering, you’ll be the first to know about:
 Future product releases
 Software upgrades
 ews, events and exclusive offers plus competitions!
This guide is designed to make installing and using this product as
easy as possible. Information in this document has been carefully
checked for accuracy at the time of printing; however, Cambridge
Audio's policy is one of continuous improvement, therefore design
and specifications are subject to change without prior notice.
This document contains proprietary information protected by
copyright. All rights are reserved. No part of this manual may be
reproduced by any mechanical, electronic or other means, in any
form, without prior written permission of the manufacturer. All
trademarks and registered trademarks are the property of their
respective owners.
© Copyright Cambridge Audio Ltd 2011
iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks
of Apple Inc., registered in the U.S. and other countries. iPad is a
trademark of Apple Inc.
“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that
an electronic accessory has been designed to connect specifically to
iPod, iPhone, or iPad, respectively, and has been certified by the
developer to meet Apple performance standards. Apple is not
responsible for the operation of this device or its compliance with
safety and regulatory standards. Please note that the use of this
accessory with iPod, iPhone, or iPad may affect wireless performance.

3
iD100
E GLISH
Thank you for purchasing this Cambridge Audio iD100
digital iPod®dock. We are confident that you will enjoy
many years of listening pleasure from it. Like all
Cambridge Audio products the iD100 adheres to three core
principles – stunning performance, ease of use and
incredible value.
The iD100 enables you to get the very best audio and video
quality from most variants of the iPod. The iD100 also works
with the iPod feature of the iPhone®and iPad™.
The iD100 accesses the audio on the docked Apple product
digitally providing a bit-perfect low jitter digital output via
S/P DIF, Toslink or AES/EBU connections. These can be
connected to the digital inputs of a suitable DAC, Digital
Amplifier or the digital inputs on many A/V Receivers etc.
The iD100 allows the digital output of any audio file your
Apple product itself supports including lossless files for
unprecedented sound quality.
In addition, video outputs via Composite Video, S-Video or
Component Video* allow the viewing of video content.
The supplied remote allows browsing of the iPod / iPad /
iPhone via its own display.
Charging and Syncing of the iPod can both be turned On or
Off via the remote which can also control basic features of
Cambridge Audio Amplifiers and Receivers. The iD100 also
features an environmentally friendly low power (<1w)
standby circuit.
Introduction
Ultimate sound quality depends on the whole of your system
your dealer can also supply excellent quality Cambridge
Audio interconnects to ensure your system realises its full
potential.
Thank you for taking the time to read this manual; we do
recommend you keep it for future reference.
Matthew Bramble
Cambridge Audio Technical Director
and the iD100 development team.
* Composite / Component lead supplied

4
Important safety instructions
For your own safety please read the following important safety instructions
carefully before attempting to connect this unit to the mains power supply. They
will also enable you to get the best performance from and prolong the life of
the unit:
1. Read these instructions.
2. Keep these instructions.
3. eed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding type plug. A
polarized plug has two blades with one wider than the other. A grounding-
type plug has two blades and a third grounding prong. The wide blade or
the third prong are provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched, particularly at
plugs, convenience receptacles and the point where they exit from the
apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use with only the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a cart
is used, use caution when moving the cart/ apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long
periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as the power-supply cord
or plug having been damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
WAR I G
– To reduce the risk of fire or electric shock, do not expose this unit to rain or
moisture.
– Batteries (battery pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, fire or the like.
The unit must be installed in a manner that makes disconnection of the mains
plug from the mains socket outlet (or appliance connector from the rear of the
unit) possible. Where the mains plug is used as the disconnect device, the
disconnect device shall remain readily operable. Only use the mains cord
supplied with this unit.
Please ensure there is ample ventilation (at least 10cm clearance all round). Do
not put any objects on top of this unit. Do not situate it on a rug or other soft
surface and do not obstruct any air inlets or outlet grilles. Do not cover the
ventilation grilles with items such as newspapers, tablecloths, curtains, etc.
This unit must not be used near water or exposed to dripping or splashing water
or other liquids. No objects filled with liquid, such as vases, shall be placed on
the unit.

5
iD100
E GLISH
The lightning flash with the arrowhead symbol within an equilateral triangle is
