Cambridge casual Hq-24759 User manual

White Oak Adirondack Chair With Ottoman

E. Right armrestF. Left armrestQTY: 1pc

G. Seat board

QTY: 2pcs QTY: 4pcs A. SeatB. Backrest

C. Right leg frameD. Left leg frame

QTY: 6pcsQTY: 4pcs QTY: 10pcs H. 1 1/4" BoltI. 1 1/2" Bolt

J. Wood pinK. Allen key

QTY: 1pc1

L. OttomanM1. Front leg frame(long)2M2. Back leg frame(short)QTY: 1pc QTY: 2pcs QTY: 2pcs QTY: 8pcs H. 1 1/4" Bolt

AGHKCHK

STEP 1STEP 2STEP 3STEP 4STEP 5STEP 6

HKHK

HKJ

Wood pin

Attach the seat board (G) into seat (A).and secure with 1 1/4" bolt (H) as shown. Tighten the bolts using Allen key (K). Attach the Right leg frame (C) into seat (A). And secure with 1 1/4" bolt (H) as shown.Tighten the bolts using Allen key (K). Attach the Backrest (B) into seat (A).And secure with 1 1/4" bolt (H) as shown.Tighten the bolts using Allen key (K). Attach the Left leg frame (D) into seat (A).and secure with 1 1/4" bolt (H) as shown.Tighten the bolts using Allen key (K). Insert the Wood pin (J) into Right/left leg frame and Backrest as shown.Attach the Backrest (B) into seat (A).And secure with 1 1/4" bolt (H) as shown.Tighten the bolts using Allen key (K).

STEP 7STEP 8STEP 9STEP 104

IKEFHK

ASSEMBLY COMPLETE.THE ADIRONDACK IS NOW READY FOR USE.

LM1M2

ASSEMBLY COMPLETE.Put the Ottoman (L) face down on clean ﬂat surface.Attach the Front leg frame/long (M1) and Back leg frame/short (M2) into Ottoman (L). And secure with 1 1/4" bolt (H) as shown.Tighten the bolts using Allen key (F).Attach the Right/Left armrest (E/F) into assembly frame. And secure with 1 1/2" bolt (I) as shown.Tighten the bolts using Allen key (F).Make sure all parts are correctly connected and tighten all bolts completely using Allen key.
