Grange Fencing Elite Arch User manual

ELITE
ARCH
2.1m 2.2m
1m 0.45m
Will fit paths
up to 895mm
wide
Elite Arch illustrated with feet
bedded into ground approx. 300mm
FRONT
ELEVATION
SIDE
ELEVATION
ELITE ARCH (ELITEARCH)
PLAN
Grange Code: ELITEARCH
GRANGE FENCING LIMITED Halesfield 21, Telford TF7 4PA
Tel: [phone] Fax: [phone] Email: [email protected] Web: www.grangefen.co.uk
OUT OF HOURS MESSAGE SERVICE: 01952 588088
APR.’08 - ISSUE 1
Mixed Sources
Product group from well-managed
forests and other controlled sources.
Cert No. SGS-COC-0100
www.fsc.org
© 1996 Forest Stewardship Council
A5 label (Mar.'07) 24/4/08 12:05 Page 1

BEFORE YOU START
ASSEMBLY
•Check the pack/s and make sure that you have
all of the parts listed above. If not, contact
your retailer who will be able to help you.
•When you are ready to start, make sure you
have the right tools to hand, plenty of space
and a clean, dry area for assembly.
It is advisable for two people to carry out
the work
The Elite Arch is made of pressure treated and FSC certified
timber and as such is guaranteed against rot for a minimum of
15 years. However, it must be remembered that as a natural
product, timber is subject to movement and weathering as it
seasons. It is not uncommon for small splits to occur when
drying and warping when timber is allowed to dry too rapidly.
These will normally go back when humidity rises. It is nature
at work and not considered a fault.
Its colour will also change with time. A retreatment, as
required with a proprietary wood treatment is recommended.
CARE OF YOUR ARCH
Ref.
POZIDRIVE SCREWDRIVER - ELECTRIC DRILL - SPIRIT LEVEL
PARTS SUPPLIED
TOOLS REQUIRED (not supplied)
Description Qty.
A
B
C
ARCH
SIDE
SECTIONS
CURVED
ROOF
SECTIONS
DOWLING
BEAMS
2
2
9xScrews 8 x 3.5 8
1x HARDWARE PACK:
SITE PREPARATION
Excavate a 300mm square
hole (approx) for each post
to a depth of at least
300mm. (see Fig.A.right)
This will give your structure
adequate stability.
STEP 1
Take one of the Curved Roof Sections (B) and
insert one of the Dowling Beams (C) into each
of the holes provided.
STEP 2
Take the second Curved Roof Section and position
it onto the free end of the Dowling Beams.
STEP 3
Carefully position
the roof assembly
to enable one of the
Side Sections (A) to
be fitted. Using two
screws (x) in each
side, attach the
Side Section to the
roof assembly.
STEP 4
Turn this assembly
to allow the other
side assembly to be
fitted.
STEP 5
The arch may now
be positioned into
the prepared holes.
STEP 6
Ensure the arch is
vertical and square.
STEP 7
Fill the holes with
the chosen method
of fixing.
Fig A.
300mm
STEP 1-2
B
B
C
A
x
B
STEPS
3-4
SCREW
THROUGH
INSIDE OF
POSTS
=
=
B
A
ELITE ARCH
