CAMELBACK Displays Zig-Zag Mesh User manual

(4) Female Poles with End Cap
(6) Horizontal Poles, snap button at both ends
(4) Male Poles
(2) Sta ar Ells (2) Sta ar 3-Ways
Parts:
Poles:
(3) Mesh Panels
Zig-Zag Mesh Panel Frame Instructions
Hardware:
(2) Ell Joints (2) 3-Way Joints
Plus: (6) Black Ball Bungees for Bundling Poles
(20) Thumbscrews for StaBar Joints
1. Assemble legs as illustrated, sliding joints onto leg pole. Assemble 2 legs using -way joints and
2 legs with Ell joints. Be sure to slide StaBar joints up past button at bottom of female pole.
3. Insert horizontal poles into
open stubs of -way joints on the
right, then add third leg to them
using Ell joints.
4. Tip unit to the right to
expose remaining set of
open -way stubs.
2. Assemble first frame flat on
floor, using 2 legs with -way
joints. Orient left-side set of
-way joints facing down and
right-side set facing up.

5. Now stand the entire unit up by
tipping it towards you.
*Remember to finger-tighten all thumbscrews to achieve the
most stability.
4. Insert last set of
horizontal poles into -way
joints and add final leg.
6.Attaching the mesh panels to
the frame:
Be sure all thumbscrews are finger-
tight before attaching panels.
1.Working from one side of frame,
place aluminum hooks over upper
horizontal poles and allow mesh
panel to hang.
2.Snap buckle-straps around bottom
StaBars and pull free end to tighten,
pulling entire panel flat and smooth.
3.Finally, wrap hook and loop straps
around legs, pulling panels snug as
you go.
Ready to hang artwork!
