Camon LS42 User guide

ORIGINAL INSTRUCTION MANUAL
CAMON Lawn Scarier
LS42
Before commissioning the machine, read operang instrucons
and observe warning and safety instrucons.
Manufactured by Tracmaster Ltd

CAMON LS42 Lawn Scarier
LS42 Lawn Scarier
Manufacturer Details
Tracmaster Ltd
Units 6-7 Winterpick Business Park
Hurstpierpoint Road
Wineham
Heneld
BN5 9BJ
UNITED KINGDOM
Tel: +44 (0)1444 247689
www.tracmaster.co.uk
info@tracmaster.co.uk
Machine Details
Model: CAMON LS42 Lawn Scarier
Serial No: B 0 1 - 11111
Engine Serial No: GAAAA -1111111
Purchase Date: D D -M M -2020
Supplier:

CAMON LS42 Lawn Scarier
LS42 Lawn Scarier Page 1
Table of Contents
1.0 Introducon .............................................................................................................................2
1.1 Welcome ................................................................................................................................2
1.2 About This Manual ................................................................................................................2
2.0 What the Machine is Designed For............................................................................................3
2.1 Applicaons ...........................................................................................................................3
3.0 Specicaons............................................................................................................................4
4.0 Unpacking and Assembly..........................................................................................................5
4.1 Major Components Diagram .................................................................................................5
4.2 Unpacking Instrucons ..........................................................................................................5
5.0 Safety Instrucons – Pre-Operaon ..........................................................................................6
5.1 Basic Safety Instrucons ........................................................................................................6
5.2 Main Components and Operang Elements .........................................................................6
5.3 Engine and Drive ....................................................................................................................6
5.4 Operang Lever .....................................................................................................................6
5.5 Height Adjustment.................................................................................................................6
5.6 Collecon Bag ........................................................................................................................6
5.7 Rotor Sha .............................................................................................................................7
5.8 Commissioning ......................................................................................................................7
5.9 General Safety Instrucons ...................................................................................................7
5.10 Engine Specic Safety Instrucons ........................................................................................8
5.11 Machine Safety Scker Explanaons .....................................................................................8
6.0 Safety Instrucons Starng and Operang.............................................................................. 10
6.1 To Start the Engine ..............................................................................................................10
6.2 To Stop the Engine ...............................................................................................................11
6.3 Safety Equipment ................................................................................................................11
6.4 Operaon.............................................................................................................................11
6.5 Procedure for Unexpected Shut Down ................................................................................13
6.6 How to Clear Unwanted Debris from the Underside of the Machine .................................13
6.7 Residual Risks of the LS42 Scarier ......................................................................................13
7.0 Maintenance .......................................................................................................................... 14
7.1 Schedule ..............................................................................................................................14
7.2 Basic Maintenance ..............................................................................................................14
7.3 Advanced Maintenance .......................................................................................................14
7.3.1 Belt ............................................................................................................................14
7.3.2 Rotate Rotor ..............................................................................................................15
7.3.3 Blades ........................................................................................................................16
7.4 Engine ..................................................................................................................................17
7.4.1 Check Engine Oil Level ..............................................................................................17
7.4.2 Change Engine Oil .....................................................................................................17
7.4.3 Air Filter ....................................................................................................................17
7.4.4 Spark Plug .................................................................................................................18
7.5 Cleaning ...............................................................................................................................18
7.6 Troubleshoong ...................................................................................................................18
7.6.1 Machine ....................................................................................................................18
7.6.2 Engine ......................................................................................................................19
7.6.3 Lubricants ..................................................................................................................19
8.0 Transportaon, Storage and Handling.....................................................................................20
8.1 Transportaon .....................................................................................................................20
8.2 Storage.................................................................................................................................20
8.3 Handling ..............................................................................................................................20
9.0 Spare Parts ............................................................................................................................. 21
9.1 Parts Diagrams .....................................................................................................................21
10.0 Service Record........................................................................................................................ 22
11.0 EC Declaraon of Conformity.................................................................................................. 23
12.0 Warranty Informaon............................................................................................................. 24

CAMON LS42 Lawn Scarier
Page 2 LS42 Lawn Scarier
1.0 Introducon
1.1 Welcome
Welcome to Tracmaster and thank you for choosing CAMON.
We are condent that you will be more than happy with your machine.
Your machine is covered by a comprehensive warranty. However, the lifespan of
your CAMON machine depends on a number of factors. It is important that you read
this manual carefully and follow the instrucons regarding operaon, maintenance,
and care.
1.2 About This Manual
It is crucial that you read this manual carefully and understand it. Reading and
understanding this manual should prevent you from operang the LS42 incorrectly
and so extend the life of the machine.
This manual also contains important safety informaon about your machine.
You must observe all safety instrucons at all mes. CAMON machines are oen
updated and improved so models may vary due to dierences in specicaons.
Any illustraons, descripons, specicaons, and technical data in this manual is
correct at the me of prinng.
For any quesons relang to this manual please contact us.
During oce hours (UK) we can be contacted on:
Phone: +44 (0)1444 247689
Email: info@tracmaster.co.uk
Website: www.tracmaster.co.uk
!
IMPORTANT READ THIS MANUAL
CAREFULLY

CAMON LS42 Lawn Scarier
LS42 Lawn Scarier Page 3
2.0 What the Machine is Designed For
2.1 Applicaons
The CAMON LS42 Lawn Scarier has been designed by Tracmaster for removing the
dead thatch and moss from lawns and other grassed areas.
The benet of scarifying a lawn is that it allows air, water and nutrients to reach the
roots of the grass whilst removing unwanted dead and foreign material.
The blades of the CAMON LS42 Scarier are designed to pass through the grass
ONLY - they are NOT designed to make contact with solid ground at any point during
operaon.
The machine will be damaged should blades connuously come into contact with
solid ground.
DO NOT use the CAMON LS42 Scarier for cung grass or sling the ground.
Both operaons will result in damage to the machine.
Operang the machine on non-grass surfaces such as concrete or tarmac will cause
damage to the LS42 Scarier.
DO NOT scarify your lawn if there is a likelihood of high temperatures or drought.
Irrigate the lawn if necessary to ensure that the grass benets from its treatment.

CAMON LS42 Lawn Scarier
Page 4 LS42 Lawn Scarier
3.0 Specicaons
ENGINE
Engine Manufacturer Honda
Engine Model GX160
Engine Type 4-stroke OHV, single cylinder
Net Engine Power 3.6kW (4.8hp) @ 3600rpm
Engine Sha Size ¾” straight
Spark Plug BPR6ES (NGK) / W20EPR-U (DENSO)
Spark Plug Gap 0.70 - 0.80mm
Engine Ignion Type Recoil
Cold Start System Choke
Fuel Tank Capacity 3.1 litres
Fuel Type Unleaded
Fuel Consumpon 1.4 litres per hour @ 3600rpm
Air Filter Paper and foam
Rated Engine Speed 3600rpm
Working RPM 2800rpm
Engine Oil 10w/30 API SJ or equivalent
Engine Oil Capacity 0.6 litres
Dry Weight 15.1kg
The power rang of the engine indicated in this table is the net power output tested on a producon engine for
the engine model and measured in accordance with SAE J1349 at a specied rpm.
MACHINE
Model LS42
Working Width 42cm
Cartridge Types Free Swinging Fixed Spring Rake Renovaon
Number of Blades 30 15 30 15
Direcon of Rotor Rotor rotates in the same direcon as travel
Clutch Type Centrifugal
Height Adjustment From 0mm above ground to 20mm
Discharge Onto ground or into bag if ed
Wheel Types Solid rubber
Steering Handle Foldable
Noise Level 101 dB(A)
Vibraon Acceleraon Value 6.2ms2
Max Gradient for Operaon on Slope 20 degrees
Weight 68kg
Dimensions (l x w x h) 120 x 59 x 98cm

CAMON LS42 Lawn Scarier
LS42 Lawn Scarier Page 5
4.0 Unpacking and Assembly
4.1 Major Components Diagram
① Operang Lever
② Throle
③ Top Handlebar
④ Engine
⑤ Locang Pin
⑥ Height Adjuster Knob
⑦ Belt Guard
⑧ Wheels
⑨ Front Axle
⑩ Throle Cable
4.2 Unpacking Instrucons
Open the top of cardboard box.
Cut the box open by using a sharp knife to cut down through the four corners of
the box.
Swivel the folded top part of the handlebar unl it locates into posion extending
from the lower handlebar arms and lock in posion with the locang pin.
Push the four wheels onto the axles of the Scarier and fasten in place using the
penny washer, M8 spring washer, and M8 x 16 bolt provided.
Push the machine forward safely and gently o the pallet.
Dispose of the cardboard box and other padding material, please reuse or recycle
where possible.
⑩
⑨
⑧
⑦
⑤
②
④
⑥
③
①

CAMON LS42 Lawn Scarier
Page 6 LS42 Lawn Scarier
5.0 Safety Instrucons – Pre-Operaon
5.1 Basic Safety Instrucons
Before starng the machine, read and understand these operang instrucons.
5.2 Main Components and Operang Elements
Below is a descripon of the main components of the LS42 Lawn Scarier and how
they operate.
5.3 Engine and Drive
The Honda GX160 is a four stroke engine that runs on
standard unleaded fuel.
The engine is air cooled and therefore it is important that
the grille covering the recoil rope is kept clear from debris.
The engine air lter cleans the air sucked in by the engine.
A clogged air lter will reduce performance.
The engine is ed with a fuel on/o lever and a
choke lever. Read the engine operang instrucons to
understand the operaon of these levers.
5.4 Operang Lever
The LS42 Lawn Scarier rotor sha is engaged by using the lever located underneath
the top of the handlebar. PLEASE NOTE THAT THIS IS A TWO STAGE LEVER. THE
GREY BUTTON MUST BE DEPRESSED BEFORE THE MAIN LEVER CAN BE PULLED UP.
This lever increases the engine speed to a level that will engage the centrifugal
clutch ed to the engine drive sha. Once the clutch has been engaged it will
transfer the engine power to the rotor sha that will rotate at high speeds within
the chassis of the Scarier.
5.5 Height Adjustment
The height of the blades of LS42 Scarier is altered using the two large knobs at the
front of the machine.
The top knob is connected to the centre of the front axle via a threaded rod. Rotang
the knob in each direcon will raise or lower the front axle in relaon to the main
chassis of the machine and in turn alter the height of the blades with the chassis.
The second knob located below the top knob on the threaded rod is used to x the
posion of the threaded rod and consequently the height of the blades relave to
the front axle.
5.6 Collecon Bag
If ed, the collecon bag will collect the thatch and moss that is removed.

CAMON LS42 Lawn Scarier
LS42 Lawn Scarier Page 7
Use the central liing handle when connecng or disconnecng the bag from the
machine.
Always stop the engine and wait for the blades to stop rotang by removing or
replacing the collecon bag.
To aach the collecon bag onto the machine, rst li the safety back ap on
the rear of the machine chassis with one hand. Then whilst holding the bag with
your other hand guide the two small metal rods protruding from either side of the
collecon bag frame into the two channels that have been formed to hold the bag.
5.7 Rotor Sha
The main rotor sha holds three rods with each rod holding 10 hardened steel
blades.
The blades are separated using spacers and springs. Each set of 10 blades on a rod
is oset from the other two rods.
5.8 Commissioning
Prior to operaon it is necessary to check the engine oil level and add engine oil
level to the levels indicated in the table in secon 6.1.
The engine fuel tank will not contain fuel so will need lling to the recommended
level before use.
5.9 General Safety Instrucons
Be aware of all the safety requirements for the machine.
Visually check the machine for operaonal safety, complete components and xed
guarding prior to each use.
Read and be aware of the warning and instrucon signs located on the machinery.
Cordon o the work area to access from the general public.
Before starng work clear the area of any objects that may cause damage to the
machine.
Do not operate the machine if you are under the inuence of alcohol or drugs. This
equipment must only be operated by persons who are medically t both physically
and mentally.
Only work in good light and visibility.
Wear the correct personal protecon equipment as instructed by this manual.
Operator clothing should not be loose and footwear should oer good grip.
Know how to stop the machine in an emergency.

CAMON LS42 Lawn Scarier
Page 8 LS42 Lawn Scarier
5.10 Engine Specic Safety Instrucons
Petrol is highly ammable. Always stop the engine and ensure the fuel tap
is turned o before refueling, or when transporng, cleaning, or making
adjustments to the machinery.
Do not smoke or use a naked ame when refueling.
Use only unleaded petrol from fuel containers designed for this purpose. Refuel
outdoors only and replace the fuel tank cap securely.
Do not mix oil with the fuel.
Leave one inch of space in the fuel tank during relling.
Clear up any petrol spillages immediately.
Always start the engine in the open air. Starng an engine within a conned space
can lead to the inhalaon of toxic substances.
Avoid contact with the engine during operaon as it will become hot. Leave the
engine to cool prior to contact and storage.
Never interfere with the control sengs of the engine.
5.11 Machine Safety Scker Explanaons
Danger – moving blades.
Keep hands and feet away.
Warning: Rotang blade hazard.
Do not operate with guard
removed.
Always remove the spark plug
before servicing.
Ensure safety guards are in place. Machine MUST NOT
be operated without guards.
!

CAMON LS42 Lawn Scarier
LS42 Lawn Scarier Page 9
Maximum sound power level (LWA).
Ear protecon must be worn when operang the machine.
ALWAYS wear suitable Personal Protecve Equipment
(PPE):
• Ear Defenders
• Eye Protecon
• Foot Protecon
• Safety Gloves
Read operang instrucons before use.
Remove spark plug before servicing or
performing maintenance.
Warning: Keep bystanders away.
Machine idencaon label. Indicates
compliance with European standards (CE
mark). Includes unique serial number, machine
weight, power output, and month and year of
manufacture.
It is important that these sckers are in good condion, are legible, and are in the
correct posions on the LS42 Lawn Scarier. If any of these sckers are missing or
damaged then they must be replaced. They can be obtained from Tracmaster Ltd.
1
2
3
1
2
3

CAMON LS42 Lawn Scarier
Page 10 LS42 Lawn Scarier
6.0 Safety Instrucons Starng and Operang
6.1 To Start the Engine
Using the dipsck provided,
check the engine oil level. Top
up with SAE 10W/30 oil, API SJ
or equivalent, if the dipsck is
clear of oil.
Check the fuel level. Rell as
necessary and as determined
by the fuel tank type – see
diagram.
Switch the engine ignion
switch to the ON posion.
Turn the fuel tap located on
the engine carburetor to the
ON posion. If the engine is
cold or has not been operated
recently set the choke lever
on the carburetor to the ON
posion.
Pull the engine recoil handle slowly unl it engages then pull hard and fast to start
the engine.
Aer the start, guide the cord back into its posion. Do not let it snap back.
Once the engine has started, if the choke lever has been used, return this to its OFF
posion aer the engine has run for a few seconds.

CAMON LS42 Lawn Scarier
LS42 Lawn Scarier Page 11
6.2 To Stop the Engine
Release the operang lever.
Switch the engine ON/OFF switch to the “O” OFF posion.
Turn the fuel tap lever to the OFF posion.
Ensure the blades have stopped prior to moving the machine.
WARNING: THE EXHAUST COVER MAY BE HOT – DO NOT TOUCH.
6.3 Safety Equipment
The LS42 operator must be wearing:
• Ear Defenders
• Gloves
• Protecve Footwear
• Safety Glasses
6.4 Operaon
Before scarifying can be carried out the grass must be cut short and be cleared of
any objects such as stones or scks that would damage the Scarier, or be picked
up and thrown by the rotang blades.
WARNING: SCARIFYING LONG GRASS WILL QUICKLY CAUSE DAMAGE TO
COMPONENTS OF THE MACHINE. WE RECOMMEND THE GRASS IS CUT PRIOR TO
SCARIFYING.
Do not operate the Lawn Scarier on wet lawns or in wet weather.
Do not operate the engine in a conned space where dangerous carbon monoxide
fumes can collect.
Operate the machine only in daylight or in good arcial light.
Always be sure of foong on slopes.
Walk never run.
Exercise extreme cauon when changing direcon on slopes.
Use extreme cauon when reversing or pulling the machine towards you.
Stop the blades if the machine has to be lted for transportaon. Do not operate
the blades when crossing surfaces other than grass and when transporng the
machine to and from the working area.
Never operate the machine with defecve guards, or without safety devices, for
example deectors and or catchers in place.
Do not change the engine governor sengs or over speed the engine.

CAMON LS42 Lawn Scarier
Page 12 LS42 Lawn Scarier
Disengage all levers, by releasing them, before starng the engine.
Start the engine carefully according to the instrucons.
Do not lt the machine when starng the engine.
Do not put hands or feet near or under the rotang parts. Keep clear of the discharge
opening at all mes.
Never pick up or carry the machine whilst the engine is running.
Avoid operang the machine in bad weather condions especially if there is the
risk of lightning.
Set the operang height by screwing the top adjuster knob either up or down and
locking the desired height with the locking handle.
WARNING: THE BLADES MUST NOT BE ALLOWED TO TOUCH THE GROUND AT ANY
POINT DURING OPERATION.
If using the collecon bag, ensure that it is mounted correctly and is secure.
Li the operang lever to engage the rotor sha and walk at a slow steady pace
pushing the machine ahead of you.
To turn the LS42 Scarier 180o, release the operang lever, put light downwards
pressure on the handlebars and rotate the machine on its rear wheels.
Do not work the Scarier on slopes of more than 20o and always work across the
slope, not up and down it.
Once the collecon bag has become full, release the operang lever, turn o the
engine and ensure the rotor sha has stopped turning. Remove the collecon bag
and empty. Re-aach the bag securely and re-start the engine to connue scarifying.
Stop the engine and disconnect the spark plug wire before:
a) Clearing blockages
b) Checking, cleaning or working on the machine
c) Aer striking a foreign object
d) If the machine starts to vibrate abnormally.
Stop the engine and disconnect the spark plug wire
a) Whenever you leave the machine
b) Before refueling
Reduce the throle seng during engine shut down and turn the fuel o on the
engine at the conclusion of scarifying.

CAMON LS42 Lawn Scarier
LS42 Lawn Scarier Page 13
6.5 Procedure for Unexpected Shut Down
Release the operang lever.
Turn the engine operang switch located on the handlebars to the OFF posion.
Ensure the rotor sha and blades have stopped rotang prior to moving the
machine.
6.6 How to Clear Unwanted Debris from the Underside of the Machine
Ensure that the engine has been turned o, remove the spark plug wire and the
rotor sha has stopped turning.
Turn the engine fuel tap to the o posion.
Aach a liing hoist to the top handlebar and li the machine so that it lts forward
onto its front wheels. As the underneath of the chassis becomes exposed it is
possible to see and remove any unwanted debris.
WARNING: ALWAYS TILT THE LS42 SCARIFIER FORWARDS TO AVOID OIL IN THE
ENGINE FLOODING INTO AREAS WHERE IT WILL CAUSE DAMAGE.
6.7 Residual Risks of the LS42 Scarier
The rotor sha will connue to rotate for a couple of seconds once the operang
lever has been released. Ensure that the blades have stopped rotang prior to
moving or lng the machine.
The LS42 Scarier is designed to be pushed by the operator both during
transportaon and operaon. It has no brake system and therefore the operator
must hold rmly onto the machine on sloped areas.

CAMON LS42 Lawn Scarier
Page 14 LS42 Lawn Scarier
7.0 Maintenance
Important! Before undertaking any maintenance ensure that the engine is
o and the fuel tap is o.
7.1 Schedule
Operaon Daily Every
Week Every
Month
Engine Check engine oil level SAE 10W/30 API SJ or equivalent X X
See separate engine manual
Machine
Check condion of blades X
Check condion of blade rods X
Check belt condion X
Check operang lever and cable X
Check collecon bag condion X
Check rotor sha bearings X
Lubricate wheel bearings X
Tighten all nuts and bolts X
7.2 Basic Maintenance
Check that all guards are ed securely.
Ensure the cable connecng the operang lever to the engine is securely fastened
at both ends and shows no sign of wear.
Ensure the wheels are held securely and the xed pin that holds the wheels onto
the axles is in place.
Check that the wheels rotate smoothly and without hindrance.
7.3 Advanced Maintenance
We strongly recommend that an Authorised Representave is consulted prior to
any major machine maintenance projects.
7.3.1 Belt
Inspecon Check:
Check every 25 hours that the drive belt is not frayed or cracked. If it appears
frayed or cracked then it is me to replace the belt.
Changing the Belt:
Remove the three bolts that aach the belt guard to the chassis and remove
the belt guard.
!

CAMON LS42 Lawn Scarier
LS42 Lawn Scarier Page 15
Release the tension from the belt by using the engine plate tension screws
at the rear of the engine plate.
The drive belt has now become slack.
Grab the right-hand side of the belt close to the boom pulley and pull as if
you are trying to pull the belt o the boom pulley.
With your other hand slowly and carefully rotate the pulley in an anclockwise
direcon and ease the belt o the pulley.
The belt is now free from the machine.
To t the new belt, start by locang the new belt in the groove of the
centrifugal clutch.
Stretch the new belt ght by pulling it downwards to the boom pulley.
Locate one side of the belt in posion on the boom pulley.
Slowly rotate the boom pulley so that the belt is slowly eased into its place
sing in the groove of the boom pulley.
Pull the belt towards you and pull the tension pulley past the belt, now
release the belt and the using the tensioning bolts at the rear of the engine
pate readjust the belt tension.
Re-aach the belt guard using the original cap screw bolts.
7.3.2 Rotate Rotor
To access the underneath of the chassis you must use a liing hoist to li the
handlebars of the machine so that it lts forward over its front axle.
Remove both the belt guard and rotor sha guard by undoing the fastening
nuts and bolts.
Remove the belt as instructed above in secon 7.3.1.
Remove the taper lock pulley from the rotor sha by completely removing
the two grub screws in the middle of the pulley, then using one of the
removed grub screws insert it into the single hole between the 2 holes that
the grub screws were removed from, as you ghten the grub screw it should
push the pulley o the bush.
WARNING: Do not lose the woodru key at this stage.
Remove the bolt holding the protecon plate, rotate the protecon plate
over on the front axle to gain access to the chassis rotor sha removal slots.
Remove the bolts of the pillow block bearings.

CAMON LS42 Lawn Scarier
Page 16 LS42 Lawn Scarier
Once the bearing bolts have been removed the blade rotor will be able to be
removed from the chassis by sliding it out of the chassis slots.
Rotate the blade rotor through 180o and reinsert into the chassis.
Ret the pillow block bearings with the bolts to x the pillow block bearings
to the chassis.
Locate the boom taper lock pulley onto the end of the rotor sha ensuring
the woodru key is ed. Once the pulley is situated beneath the centrifugal
clutch x the taper lock pulley into posion by ghtening the 2 grub screws
evenly in the original holes when the taper lock was removed.
Re-aach the belt and belt guard as described in 7.3.1.
7.3.3 Blades
Inspecon Check:
Blades that have been worn so that they have become rounded must be
changed in order for the LS42 Scarier to funcon properly.
Changing the Blades:
Safety glasses and gloves must be worn.
Remove the rotor as described in secon 7.3.2.
Remove the one split pin from the end of just one rod.
Slide the rod through the spiders being careful to remove the springs and
blades as the rod is removed from each secon.
Once the worn blades have been removed the rod should be checked for
wear and if serviceable can be reinserted and the new blades located.
Reinsert the rod slowly and in each secon between spiders pass the rod
through the springs and blade in the correct order.
Connue this unl each secon has been lled with a blade and springs and
the rod is showing through the last spider.
Renew and spread the split pin to secure the rod.
Repeat this process with the remaining two rods.
WARNING: Take note of the spring and blade layout from the parts diagram
enclosed.
Re-aach rotor to the chassis as described in secon 7.4.1.

CAMON LS42 Lawn Scarier
LS42 Lawn Scarier Page 17
7.4 Engine
7.4.1 Check Engine Oil Level
This is to be checked prior to each use and every 8 hours during operaon.
Check only when the engine is o and in a horizontal posion.
Clean the oil ller plug and its surrounding parts.
Remove the oil ller plug. Clean the dipsck with a clean cloth and put the
oil ller plug all the way back into the engine. Remove the oil ller plug and
check the oil level.
Rell the oil if indicator shows more is required. For the Honda GX160 the
recommended oil is SAE 10W/30 API SJ or equivalent.
7.4.2 Change Engine Oil
Refer to the engine manufacturer’s manual for locaon of components and
more detailed assistance.
Do not change the oil if the engine is hot.
The rst oil change is aer 50 hours of work.
Subsequent oil changes should be made aer each 100 hours of work.
At extreme temperatures or condions change the oil aer every 50 hours.
Open the drain plug on the engine and the lling plug and drain the oil into
a suitable container or use a sucon pump to remove oil through ller neck.
Ensure the waste oil is disposed of properly.
Re-t the drain plug and ghten.
Fill fresh engine oil through the oil lling opening. Use a funnel or similar
device for ease of lling.
Replace the oil ller plug and ghten.
7.4.3 Air Filter
Inspecon Check:
Remove the air cleaner cover and inspect the lter elements.
Cleaning:
See diagram below containing informaon provided by Honda.

CAMON LS42 Lawn Scarier
Page 18 LS42 Lawn Scarier
7.4.4 Spark Plug
Clean and replace.
7.5 Cleaning
Aer cleaning, parcularly if a pressure washer has been used, ensure any
lubricaon points are re-lubricated.
Clean the engine with a cloth only. Avoid spraying the engine with jets of water as
this may leak into the fuel and ignion systems.
7.6 Troubleshoong
7.6.1 Machine
Have all serious malfuncons on the machine and engine repaired by an
authorised Tracmaster or Honda agent.
Problem Possible Cause Remedy
No drive to blades Broken belt Replace belt
Poor moss and
thatch removal
Worn blades Check condion of blades
- if worn rotate or replace
Incorrect blade height
adjustment
Check height adjustment
knob and readjust if too
high
Other manuals for LS42
1
Table of contents
Other Camon Lawn And Garden Equipment manuals
Popular Lawn And Garden Equipment manuals by other brands

MASSEY FERGUSON
MASSEY FERGUSON MF9280 - HP 500 brochure

Fiamma
Fiamma 98655Z040 Installation and usage instructions

Outdoor Essentials
Outdoor Essentials HOMESTEAD RUSTIC 2X8 ELEVATED GARDEN PLANTER Assembly instructions

MASSEY FERGUSON
MASSEY FERGUSON 160V - brochure

Meec tools
Meec tools 721-440 operating instructions

Jumbl
Jumbl JUM7230 user guide
