Camp Chef Weekender DJ60LW User manual

Tank Sold Separately
Read and follow all warnings and instructions in included instruction manual before assembly and use of appliance.
MAX POT DIAMETER 10”
KEEP FOR FUTURE REFERENCE FOR OUTDOOR USE ONLY
Regulator Model
150/451, R329, RA329, RJ-A
JY70-003, JY95A7A (JY95-007)
RYQ Series (RYQF01)
THIS INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION NECESSARY FOR THE PROPER ASSEMBLY AND SAFE USE OF THIS PRODUCT.
Weekender
Model: DJ60LW
• Two 40,000 BTU Cast Aluminum Burners
• Suitcase Style Lid Design
• Detachable Legs
• Convenient Cooking Height
DJ60 INSTRUCTIONS AND TROUBLE SHOOTING
1. Open stove lid, remove, grate and retrieve legs from the inside of the stove.
Reinstall the grate.
2. Turn stove upside down and assemble leg extensions to stove as shown by
inserting the threaded bolt on the legs into the threaded fastener on the corner of
the stove and tightening. (See Fig. 1)
3. Stand stove upright. Open lid. Fold windscreens out and locate the tab on the
windscreens into the cutout on the top edge of the stove. Use the latch to hold
the windscreens in place. (See Fig. 2)
BURNERS WILL NOT IGNITE
1. Make sure there is propane in the tank and turn propane tank is turned on.
2. Follow all instructions in instruction manual for lighting the burner
YELLOW FLAME
1. Adjust Air Shutter until burner has blue flame - Some yellow tipping of the flame
is normal.
2. See Instruction Manual for Cleaning the burner
FLAME IS VERY SMALL AND WON’T INCREASE.
1. Make sure there is propane in the tank and turn propane tank is turned on a
minimum of 3 full turns
2. Follow all instructions in manual for leak testing the stove.
3. Turn all valves on the stove to the off position. Turn the Propane Tank off.
Disconnect regulator from the tank. Reconnect regulator to the tank. Slowly turn
tank on. Follow all instructions in the manual for leak testing the stove. If no
leaks are found follow all instructions in the manual for lighting the appliance.
LATCHES ARE TOO LOOSE TO HOLD LID OR WINDSCREEN TIGHT.
Use a pair of pliers and bend the latch hook slightly to tighten up the fit. Try
latching the lid and windscreen and if either it is still loose try bending the hook a
little more.

M3 X 6 MACHINE SCREW (4)
DJ60LW -2 PARTS LIST
0713DJ60parts
BURNER SHORT (2)
0808-AS
AIR VENT(2)
0826L
LP SPRING (2)
0980
VALVE (2)
DJ60-2
KNOB (2)
330092
GRATE (1)
106678
HEAT DEFLECTOR (1)
DJ60-1
MANIFOLD (1)
330024
1/4-20 RETAINER NUT (4)
0758
24" LEG EXTENSION (4)
SSL-24
LID LA
TCH (2)
ATS-4
1/4 THUMB SCREW (4)
SSL-1
#10 SCREW (1)
0799
LP REGULATOR
HRL
FIG. 1 FIG. 2

How to Convert a Fire Pit,
Stove , &
Smoker to Natural Gas

NGKIT, which is our Natural Gas
Conversion Kit, is needed to
convert any Low Pressure Stove,
Smoke Vault, or Fire Pit.

Fire Pit Conversion to Natural Gas
Safety first! Make sure
everything is shut off and
that hose is removed
from propane tank.
Remove knob and valve
cover.
Remove valve from
burner, unscrew from
thermocouple wire, and
disconnect electrode
wire.
Once valve is
removed from fire
pit, drill the orifice
with a 1/8th drill bit.
Reassemble.

Stove Conversion to Natural Gas
Start by making
sure all is shut off
and that hose is
removed from
propane tank.
Remove knobs and
front panel. At this
point all you need
to do is remove
the manifold from
the valves..
Once valve is
removed from
burner, drill it’s
orifice with a #45
drill bit.
Reassemble.
NOTE: Only low
pressure stoves
(30,000BTU or
less) can be
converted to be
used with natural
gas.

Smoke Vault Conversion to Natural Gas
To convert the Smoke
Vault to natural gas you’ll
need the NGKIT and a #51
drill bit.
If you haven’t assembled
your smoker yet, remove
the valve from the burner
and use the specified drill
to widen the valve’s orifice.

If your smoker is
already assembled and
has been used, make
sure everything is
turned off and
disconnect the hose
from your smoker. Then
lay the smoker on it’s
back and remove the
burner. This will give
you access to the valve.
Drill valve’s orifice with
a #51 drill bit.
