Campbell Hausfeld CE3000 User manual

Two Stage Air Compressors
Operating Instructions and Parts Manual
EN
Models: CE3000 and CE3001
IN568800AV
8/15
© 2015 Campbell Hausfeld
A Marmon/Berkshire Hathaway Company

REGISTER YOUR PRODUCT ONLINE NOW! http://www.ch-commercial.com/registration/
READ AND FOLLOW ALL INSTRUCTIONS • SAVE THESE INSTRUCTIONS • DO NOT DISCARD
Please read and save these instructions. Read carefully before attempting to
assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply
with instructions could result in personal injury and/or property damage! Retain
instructions for future reference.
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to
this manual or file it for safekeeping.
Model #: _______________________
Serial #: ________________________
Purchase Date: _________________
For parts, product & service
information
visit www.campbellhausfeld.com
Campbell Hausfeld
100 Production Drive
Harrison, Ohio 45030

BEFORE YOU BEGIN
Introduction
The Campbell Hausfeld two-stage air compressors are oil lubricated reciprocating compressors.
General Purpose Series Models Include:
• Compressor pump
• ASME air receiver with safety valve
• Electric motor
• Pressure switch
Quick Reference
Recommended Oil (2 Options)
Single viscosity SAE 30 ISO100 nondetergent compressor oil. Part number
ST125303AV (0.5 qt) or ST126701AV (4 qt).
10W30 synthetic oil such as Mobil 1®or CE0032 (1 qt).
Oil Capacity
Approximately 0.5 quarts
UNPACKING
Do not lift or move unit without appropriately rated equipment. Be sure
the unit is securely attached to lifting device used. Do not lift unit by holding onto
tubes or coolers. Do not use unit to lift other attached equipment.
After unpacking the unit, inspect carefully for any damage that may have occurred during transit. Check for
loose, missing or damaged parts. Check to be sure all supplied accessories are enclosed with the unit. In case of
questions, damaged or missing parts, please visit www.campbellhausfeld.com for customer assistance.
Do not operate unit if damaged during shipping, handling or use. Damage
may result in bursting and cause injury or property damage.
Required Items - Not Included
• Oil
1
MAINTENANCE / REPAIR
TROUBLESHOOTINGOPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS
GETTING STARTED

2
Figure 1 - General Purpose Series Compressor
Getting To Know Your Compressor - General Purpose Series
Air Filter Beltguard
Pressure Switch
Compressor Pump
Motor
Manual Tank Drain
MAINTENANCE /
REPAIR TROUBLESHOOTING OPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS GETTING STARTED

3
GENERAL SAFETY INSTRUCTIONS
Safety Guidelines
This manual contains information that is very important to know and understand. This information is provided
for SAFETY and to PREVENT EQUIPMENT PROBLEMS. To help recognize this information, observe the
following symbols.
Danger indicates an imminently hazardous situation which, if not avoided,
WILL result in death or serious injury.
Warning indicates a potentially hazardous situation which, if not avoided,
COULD result in death or serious injury.
Caution indicates a potentially hazardous situation which, if not avoided,
MAY result in minor or moderate injury.
Notice indicates important information, that if not followed, may cause
damage to equipment.
IMPORTANT: Information that requires special attention.
Safety Symbols
The following Safety Symbols appear throughout this manual to alert you to important safety hazards and
precautions.
California Proposition 65
This product or its power cord may contain chemicals known to the State
of California to cause cancer and birth defects or other reproductive harm. Wash
hands after handling.
You can create dust when you cut, sand, drill or grind materials such as wood,
paint, metal, concrete, cement, or other masonry. This dust often contains
chemicals known to cause cancer, birth defects, or other reproductive harm. Wear protective gear.
Important Safety Information
Please read and save these instructions. Read carefully before attempting to assemble, install,
operate or maintain the product described. Protect yourself and others by observing all safety
information. Failure to comply with instructions could result in personal injury and/or property
damage! Retain instructions for future reference.
This manual contains important safety, operational and maintenance information. If you have any questions,
please visit www.campbellhausfeld.com for customer assistance.
Since the air compressor and other components (material pump, spray guns, filters, lubricators, hoses, etc.) used
make up a high pressure pumping system, the following safety precautions must be observed at all times:
Risk of
Moving
Parts
Risk of
Hot Parts
Risk of
Explosion
Risk of
Fumes
Risk of
Pressure
Risk of
Shock
MANUAL
Read
Manual
First
Risk of
Fire
Wear Eye
and Mask
Protection
MAINTENANCE / REPAIR
TROUBLESHOOTINGOPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS
GETTING STARTED

4
Important Safety Information (Continued)
BREATHABLE AIR WARNING
This compressor/pump is not equipped and should not be used “as is” to supply breathing quality
air. For any application of air for human consumption, the air compressor/pump will need to be
fitted with suitable in-line safety and alarm equipment. This additional equipment is necessary to
properly filter and purify the air to meet minimal specifications for Grade D breathing as described
in Compressed Gas Association Commodity Specification G 7.1, OSHA 29 CFR 1910. 134, and/or
Canadian Standards Associations (CSA).
DISCLAIMER OF WARRANTIES
In the event the compressor is used for the purpose of breathing air application and proper in-line
safety and alarm equipment is not simultaneously used, existing warranties shall be voided, and the
manufacturer disclaims any liability whatsoever for any loss, personal injury or damage.
General Safety
• Read all manuals included with this product carefully. Be thoroughly familiar with the controls and the proper
use of the equipment.
• Follow all local electrical and safety codes as well as the United States National Electrical Codes (NEC) and
Occupational Safety and Health Act (OSHA).
• Only persons well acquainted with these rules of safe operation should be allowed to use the compressor.
• Keep visitors away and NEVER allow children in the work area.
• Wear safety glasses and use hearing protection when operating the unit.
• Do not stand on or use the unit as a handhold.
• Before each use, inspect compressed air system and electrical components for signs of damage,
deterioration, weakness or leakage. Repair or replace defective items before using.
• Check all fasteners at frequent intervals for proper tightness.
Motors, electrical equipment and controls can cause electrical arcs that will
ignite a flammable gas or vapor. Never operate or repair in or near a flammable
gas or vapor. Never store flammable liquids or gases in the vicinity of the compressor.
Never operate compressor without a beltguard. This unit can start automatically
without warning. Personal injury or property damage could occur from contact
with moving parts.
• Do not wear loose clothing or jewelry that will get caught in the moving parts of the unit.
Compressor parts may be hot even if the unit is stopped.
• Keep fingers away from a running compressor; fast moving and hot parts will cause injury and/or burns.
• If the equipment should start to vibrate abnormally, STOP the engine/motor and check immediately for the
cause. Vibration is generally an indication of trouble.
• To reduce fire hazard, keep engine/motor exterior free of oil, solvent, or excessive grease.
An ASME code safety relief valve with a setting no higher than the Maximum
Allowable Working Pressure (MAWP) of the tank MUST be installed in the air lines
or in the tank for this compressor. The ASME safety valve must have sufficient flow and pressure
ratings to protect the pressurized components from bursting. The flow rating can be found in the parts
manual. The safety valve in the intercooler does not provide system protection.
Maximum operating pressure is 175 psi for two-stage compressors. Do not
operate with pressure switch or pilot valves set higher than 175 psi (two-stage).
• Never attempt to adjust ASME safety valve. Keep safety valve free from paint and other accumulations.
MANUAL
MAINTENANCE /
REPAIR TROUBLESHOOTING OPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS GETTING STARTED

5
Important Safety Information (Continued)
Never attempt to repair or modify a tank! Welding, drilling or any other
modification will weaken the tank resulting in damage from rupture or explosion.
Always replace worn, cracked or damaged tanks.
Drain liquid from tank daily.
• Tanks rust from moisture build-up, which weakens the tank. Make sure to drain tank regularly and inspect
periodically for unsafe conditions such as rust formation and corrosion.
• Fast moving air will stir up dust and debris which may be harmful. Release air slowly when draining moisture
or depressurizing the compressor system.
Spraying Precautions
Do not spray flammable materials in vicinity of open flame or near
ignition sources including the compressor unit.
• Do not smoke when spraying paint, insecticides, or other flammable substances.
• Use a face mask/respirator when spraying and spray in a well ventilated area to prevent health and fire
hazards.
• Do not direct paint or other sprayed material at the compressor. Locate compressor as far away from the
spraying area as possible to minimize overspray accumulation on the compressor.
• When spraying or cleaning with solvents or toxic chemicals, follow the instructions provided by the chemical
manufacturer.
Save These Instructions
Do Not Discard
The DANGER, WARNING, CAUTION, and NOTICE notifications and instructions in this manual cannot
cover all possible conditions and situations that may occur. It must be understood by the operator that
caution is a factor which cannot be built into this product, but must be supplied by the operator.
MAINTENANCE / REPAIR
TROUBLESHOOTINGOPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS
GETTING STARTED

6
SPECIFICATIONS
CE3000 CE3001
Motor HP 5 5
Power 230 208-230
Phase 1 3
Displacement CFM 17.3 17.3
Air Delivery CFM 13.7 @ 175 PSI 13.7 @ 175 PSI
Max PSI 175 175
Pump RPM 1190 1190
Tank Capacity 80 80
Unit Weight 460 lb 460 lb
Amp Draw 22 14.2-12.8
Max Duty Cycle 80/20 80/20
Tank Outlet 3/4 (F) NPT 3/4 (F) NPT
DIMENSIONS
CE3000 CE3001
Length 35 inches 35 inches
Width 27 inches 27 inches
Height 71 inches 71 inches
MAINTENANCE /
REPAIR TROUBLESHOOTING OPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS GETTING STARTED

7
INSTALLATION INSTRUCTIONS
Disconnect, tag and lock out power source then release all pressure from the
system before attempting to install, service, relocate or perform any maintenance.
Do not lift or move unit without appropriately rated equipment. Be sure the unit is
securely attached to lifting device used. Do not lift unit by holding onto tubes or
coolers. Do not use unit to lift other attached equipment.
Never use the wood shipping skids for mounting the compressor.
Picking the Location
Install and operate unit at least 24 inches from any obstructions in a
clean, well ventilated area. The surrounding air temperature should
not exceed 100° F. This will ensure an unobstructed flow of air to
cool compressor and allow adequate space for maintenance.
Do not locate the compressor air inlet
near steam, paint spray, sandblast areas
or any other source of contamination.
NOTE: If compressor operates in a hot, moist environment, supply
compressor pump with clean, dry outside air. Supply air should be
piped in from external sources.
Tank Mounting
The tank should be bolted into a flat, even, concrete floor or on a
separate concrete foundation. Vibration isolators should be used
between the tank leg and the floor. Model MP345700AJ isolator pads
are recommended for vertical units.
When using isolator pads, do not draw bolts tight. Allow the pads
to absorb vibrations. When isolators are used, a flexible hose or
coupling should be installed between the tank and service piping.
Failure to properly install the tank can
lead to cracks at the welded joints and
possible bursting.
Piping
Never use plastic (PVC) pipe for
compressed air. Serious injury or death
could result.
Any tube, pipe or hose connected to the unit must be able to
withstand the temperature generated and retain the pressure. All
pressurized components of the air system must have a pressure
rating of 200 psi or higher. Incorrect selection and installation of any
tube, pipe or hose could result in bursting and injury. Connect piping system to tank using the same size fitting as
the discharge port.
Minimum Pipe Size For Compressed Air Line
CFM
Length Of Piping System
25 feet 50 feet 100 feet 250 feet
10 1/2 inch 1/2 inch 3/4 inch 3/4 inch
20 3/4 inch 3/4 inch 3/4 inch 1 inch
40 3/4 inch 1 inch 1 inch 1 inch
60 3/4 inch 1 inch 1 inch 1 inch
100 1 inch 1 inch 1 inch 1-1/4 inch
Figure 3 - Isolator Pad
≥ 24 inches
≥ 24 inches
≥ 24
inches
Figure 2 - Location
MAINTENANCE / REPAIR
TROUBLESHOOTINGOPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS
GETTING STARTED

8
INSTALLATION INSTRUCTIONS (CONTINUED)
Installing A Shut-Off Valve
A shut-off valve should be installed on the discharge port of the tank to control the air flow out of the tank. The
valve should be located between the tank and the piping system.
Never install a shut-off valve between the compressor pump and the tank.
Personal injury and/or equipment damage may occur. Never use reducers in
discharge piping.
When creating a permanently installed system to distribute compressed
air, find the total length of the system and select pipe size from the chart.
Bury underground lines below the frost line and avoid pockets where
condensation can gather and freeze.
Apply air pressure to the piping installation and make sure all joints are
free from leaks BEFORE underground lines are covered. Before putting
the compressor into service, find and repair all leaks in the piping, fittings
and connections.
Wiring
All wiring and electrical connections must be performed by a qualified electrician
familiar with induction motor controls. Installations must be in accordance with
local and national codes.
Overheating, short circuiting and fire damage will result from inadequate wiring.
Wiring must be installed in accordance with National Electrical Code and local codes and standards that have
been set up covering electrical apparatus and wiring. These should be consulted and local ordinances observed.
Be certain that adequate wire sizes are used, and that:
1. Service is of adequate ampere rating.
2. The supply line has the same electrical characteristics (voltage, cycles and phase) as the motor. Refer to
motor name plate for electrical ratings and specifications.
3. The line wire is the proper size and that no other equipment is operated from the same line. The chart gives
minimum recommended wire sizes for compressor installations.
Minimum Wire Size (Use 75°C Copper Wire)
Make sure voltage is correct with the motor wiring.
NOTE: If using 208 volts single phase, make sure the motor name plate states it is rated
for 208 volts single phase. 230 volt single phase motors do not work on 208 volts unless
they have the 208 volt rating.
Single Phase Three Phase
HP Amps 230V 208/230V 460/575V
SPL up to 22.0 10 AWG
5.0 8 AWG 12 AWG 14 AWG
7.5 8 AWG 10 AWG 12 AWG
10.0 N/A 8 AWG 12 AWG
15.0 N/A 6 AWG 10 AWG
25.0 N/A 3 AWG 8 AWG
Recommended wire sizes may be larger than the minimum set up by local ordinances.
If so, the larger size wire should be used to prevent excessive line voltage drop. The
additional wire cost is very small compared with the cost of repairing or replacing a
motor electrically “starved” by the use of supply wires which are too small.
Figure 4 - Shut-off Valve
MAINTENANCE /
REPAIR TROUBLESHOOTING OPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS GETTING STARTED

9
INSTALLATION INSTRUCTIONS (CONTINUED)
Grounding
Improperly grounded electrical
components are shock hazards.
Make sure all the components are properly
grounded to prevent death or serious injury.
This product must be grounded. Grounding reduces the
risk of electrical shock by providing an escape wire for
the electric current if short circuit occurs. This product
must be installed and operated with a power cord or
cable that has a grounding wire.
Breakers and Fuses
The entire electrical system should be checked by a
certified electrician. Time delay breakers and fuses are
required for this compressor. A tripped breaker or blown
fuses may indicate a direct short to ground, high current
draw, improper wiring, incorrect fuse or breaker size
and/or type. This needs to be evaluated by a certified
electrician.
Motor Hookup and Starter Installation
Branch circuit protection must be provided as specified
in the United States National Electrical Code, Chapter
2, “Wiring Design and Protection.” Article 210, using the
applicable article “For Motors and Motor Controllers,”
(Article 430, Table 430-1 52).
IMPORTANT: Overload protection is required for all
motors. Certain motors have this protection built-in. To
determine if a motor has built-in overload protection, refer
to the frame size on the motor nameplate.
Motors with frame size R56HZ, Y56Y or L143T include
built-in overload protection. No additional protection is
required. Use Figure 5 wiring diagram.
Motors with frame sizes 184T, 215T, 254T or 284T do not
have built-in overload protection. A magnetic starter is
required. Use Figure 6 wiring diagram.
MAINTENANCE / REPAIR
TROUBLESHOOTINGOPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS
GETTING STARTED

10
L1 L2
T2T1
X2
L1 L2
Pressure
Switch Thermal
Units (3)
L3
T2
c
uit Breaker or
s
ed Disconnect
X2
Motor
Over
Load
Coil
T3
T1
Figure 5 - For Motor Frame Sizes
R56HZ, Y56Y or L143T.
Refer to Motor Nameplate
Motor
Ground
L3 (for 3 phase wiring only)
L2
L1
Single Phase / Three Phase
Wiring Diagram
Figure 6 - For Motor Frame Sizes 184T, 215T, 254T or 284T.
Refer to Motor Nameplate
Single Phase
Wiring Diagram
Motor
Circuit
Breaker
or Fused
Disconnect
Three Phase
Wiring Diagram
Motor
Coil
Coil
Circuit
Breaker
or Fused
Disconnect
Over
Load
Over
Load
Thermal
Unit
Thermal
Units (3)
Pressure
Switch
Pressure
Switch
INSTALLATION INSTRUCTIONS (CONTINUED)
MAINTENANCE /
REPAIR TROUBLESHOOTING OPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS GETTING STARTED

11
INSTALLATION INSTRUCTIONS
(CONTINUED)
Direction of Rotation
NOTE: Improper rotation will result in reduced compressor
life.
The direction of rotation must be counterclockwise (as
shown by the arrow on the flywheel in Figure 7) while facing
the flywheel side of the pump. The motor nameplate will
show wiring information for counterclockwise rotation.
The proper direction is very important. The direction of
rotation of 3 phase motors can be reversed by interchanging
any two motor-line leads. For single phase motors, refer to
the motor nameplate.
Lubrication
This unit contains no oil.
Before operating compressor, fill
to the center of the sight gauge (see Figure 8).
Using any other type of oil may
shorten pump life and damage
valves.
Recommended Oil (2 Options)
Single viscosity SAE 30 ISO100 nondetergent
compressor oil. Part number ST125303AV (0.5 qt) or
ST126701AV (4 qt).
10W30 synthetic oil such as Mobil 1®or CE0032 (1 qt).
Oil Capacity
Approximately 0.5 quarts
Fill the pump with oil to the center of the sight gauge
using oil fill opening (see Figure 8). Do NOT fill the
pump through the breather cap opening as this may
cause oil to leak and spray out during operation.
NOTE: Some residual oil may still be in the pump from
factory testing leaving a thin coat on the sight gauge;
however, there is not enough oil to operate the unit.
Figure 8
Breather Cap
Oil Drain Plug
Sight Gauge
Full
Low
Figure 7- Direction of rotation
Oil Fill
MAINTENANCE / REPAIR
TROUBLESHOOTINGOPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS
GETTING STARTED

12
OPERATING INSTRUCTIONS
IMPORTANT: Check motor rotation before operating the compressor.
All lubricated compressor pumps discharge some condensed water and oil with the compressed air. Install
appropriate water/oil removal equipment and controls as necessary for the intended application.
Failure to install appropriate water/oil removal equipment may result in
damage to machinery or workpiece.
Guarding
The belt guard provided must be installed before operating the unit.
All moving parts must be guarded. All electrical covers must be installed before turning on the power.
Recommended Break-In Period
The compressor should be run continuously for one hour to allow proper seating of the piston rings.
1. Open drain cock completely and run the compressor for 60 minutes.
2. Turn off the compressor and close drain cock. The compressor is now ready for use.
Pressure Switch, Start - Stop
NOTE: This compressor has a maximum operating pressure of
175 PSI for two-stage compressors or 135 PSI for single stage
compressors. Do not alter pressure settings on control components
above this limit.
The compressor unit starts and stops based on preset pressure switch
settings. The pressure switch contains an unloader which is a small
valve that vents air to allow the motor to start easily (See Figure 9).
Crankcase Breather
During severe operating conditions or initial start-up, some oil may
accumulate at the crankcase breather opening. This is normal and
will diminish as the pump accumulates run time and the piston rings
become fully seated.
Draining Tank
Condensation must be drained from the tank daily.
Duty Cycle
Each pump on this compressor is designed to operate up to 75% of the time. Long-term or on-time operation
over 75% could decrease the life of the pump and motor.
Figure 9 - Pressure Switch
To tank pressure
Unloader
MAINTENANCE /
REPAIR TROUBLESHOOTING OPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS GETTING STARTED

13
NOTES
MAINTENANCE / REPAIR
TROUBLESHOOTINGOPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS
GETTING STARTED

14
TROUBLESHOOTING CHART
Symptom Possible Cause(s) Corrective Action
Motor hums and runs
slowly or not at all
1. Low voltage or no voltage 1. Check with voltmeter, check overload relay in magnetic starter or reset
switch on motor. If overload or reset switch trips repeatedly, find and
correct the cause. See next item
2. Shorted or open motor winding 2. Replace motor
3. Malfunctioning check valve or
unloader valve
3. Replace check valve or unloader valve
4. Malfunctioning pressure switch -
contacts will not close
4. Repair or replace pressure switch
Reset mechanism
cuts out repeatedly or
fuses blow repeatedly
1. Pressure switch set too high 1. Replace pressure switch
2. Malfunctioning check valve 2. Clean or replace faulty valve
3. Incorrect fuse size or magnetic starter
heaters
3. Be sure that fuses and heaters are rated properly
4. Malfunctioning motor 4. Replace motor
5. Loose Wiring 5. Check all electrical connections
Excessive noise in
operation
1. Loose pulley, flywheel, belt, belt
guard, etc
1. Tighten
2. Lack of oil in crankcase 2. Check for damage to bearings, replenish oil
3. Compressor floor mounting loose 3. Shim to level and tighten or place on islolator pads
4. Malfunctioning check valve 4. Replace check valve
5. Unit not on vibration pads 5. Install vibration pads under compressor feet
Milky oil in oil
crankcase
1. Low usage of compressor - water is
condesing in the crankcase
1. Run the compressor continuously for 1 hour. The heat generated during
this running period will evaporate the moisture out of the oil
2. Wrong type of oil 2. Do not use SAE-30 automotive type oil. Using the wrong oil can cause
various problems with the pump and will void the warranty. Only use the
oils that the operating manual recommends
3. Improper environment 3. Unit should not be installed in a poorly vented area or exposed to
extreme cold or hot conditions. Normal operating range should be
between 32°F and 100°F
4. Rotation incorrect 4. Check to make sure the compressor is running the direction of the
flywheel arrow. Air flow should be so that the flywheel directs air across
the head of the pump. Standing in front of the compressor (non-belt
guard side) air should flow back to front
5. Slight leakage of tank check valve 5. Air cools and condensates, then leaks back into the pump. Draining tank
of air after use will normally take care of this situation
Excessive oil
consumption or oil in
air lines
1. Be sure there is a problem 1. Diagnose oil contamination problems by testing the discharge air or
measuring oil consumption from the crankcase
2. Restricted air intake 2. Clean or replace air filter
3. Wrong oil viscosity 3. Drain oil. Refill with oil of proper viscosity
4. Worn piston rings 4. Replace rings
5. Oil leaks 5. Tighten bolts, replace gaskets or o-rings
6. Scored cylinder 6. Replace cylinder
Water in discharge air 1. Excessive water in tank 1. Drain tank
2. Hot, humid weather 2. Purchase dryer
Air blowing out of inlet 1. Broken first stage inlet valve (two-
stage unit)
1. Replace valve assembly
2. Broken inlet valve (single stage unit) 2. Replace valve assembly
Insufficient pressure 1. Air demand too high 1. Limit air usage
2. Leaks or restrictions in hoses or
piping
2. Check for leaks or restriction in hose or piping
3. Slipping belts 3. Tighten belts
Tank does not hold
pressure when
compressor is off and
shutoff valve is closed
1. Worn check valve 1. Replace check valve
Do not disassemble check valve with air
in tank
2. Check all connections and fittings for
tightness
2. Tighten
3. Check tank for cracks or pin holes 3. Replace tank. Never repair a damaged tank
MAINTENANCE /
REPAIR TROUBLESHOOTING OPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS GETTING STARTED

15
Symptom Possible Cause(s) Corrective Action
Excessive belt wear.
(Light dust from start
is normal. Worn belts
separate at layers)
1. Pulley out of alignment 1. Realign motor pulley
2. Belts too tight or too loose 2. Adjust tension
Tank pressure builds
slowly
1. Dirty air filter 1. Clean or replace filter element
2. Blown cylinder head gasket 2. Install new gasket
3. Worn/broken intake/discharge valves 3. Install new valve plate assembly
4. Air leaks 4. Tighten joints
Tank pressure
builds up quickly on
compressor
Excessive water in tank Drain tank, check speed. See Performance table
ASME safety valve
pops open while
compressor is running
1. Pressure switch setting to high 1. Replace pressure switch
2. Malfunctioning ASME safety valve 2. Replace ASME safety valve
3. Pressure switch contacts welded 3. Replace pressure switch
Pressure switch
continuously blows air
out the unloader valve
Malfunctioning check valve Replace the check valve if the unloader valve bleeds off constantly
Pressure switch
unloader valve does
not release air when
the unit shuts off
Malfunctioning unloader valve on
pressure switch
Replace the pressure switch if the unit does not hiss for a short period
of time when the unit shuts off
Interstage safety valve
pops off while the unit
is running
1. Head gasket or the gasket in the
valve plate assembly blown
1. Replace valve plate and gaskets
2. Valve not seating properly 2. Replace valve plate and gaskets
3. Malfunctioning safety valve 3. Replace safety valve
Interstage safety valve
pops off after the unit
shuts off
Malfunctioning tank check valve Replace the check valve
MAINTENANCE / REPAIR
TROUBLESHOOTINGOPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS
GETTING STARTED

16
MAINTENANCE AND INSPECTION INSTRUCTIONS
Disconnect, tag and lock out power source then release all pressure from the
system before attempting to install, service, relocate or perform any maintenance.
In order to maintain efficient operation of the compressor system, check the air filter and oil level before each
use. The ASME safety valve should also be checked daily (see Figure 10). Pull ring on safety valve and allow the
ring to snap back to normal position. This valve automatically releases air if the tank pressure exceeds the preset
maximum. If air leaks after the ring has been released, or the valve is stuck and cannot be actuated by the ring,
the ASME safety valve must be replaced.
Do not tamper with the ASME safety valve.
Tank
Never attempt to repair or modify a tank! Welding, drilling or any other
modification will weaken the tank resulting in damage from rupture or explosion.
Always replace worn, cracked or damaged tanks.
Drain liquid from tank daily.
The tank should be carefully inspected at a minimum of once a year. Look for cracks forming near the welds. If a
crack is detected, remove pressure from tank immediately and replace.
Compressor Lubrication
See Installation. Add oil as required. The oil should be changed every three months or after every 500 hours of
operation; whichever comes first.
If the compressor is running under humid conditions for short periods of time, the humidity will condense in the
crankcase and cause the oil to look creamy. Oil contaminated by condensed water will not provide adequate
lubrication and must be changed immediately. Using contaminated oil will damage bearings, pistons, cylinders
and rings and is not covered under warranty. To avoid water condensation in the oil, periodically run the
compressor with tank pressure near 150 psi for two-stage compressors or 120 psi for single stage compressors
by opening the drain cock or an air valve connected to the tank or hose. Run the pump for an hour at a time at
least once a week or more often if the condensation reoccurs.
IMPORTANT: Change oil after first 50 hours of operation.
Air Filter
Never run the compressor pump without an intake air filter or with
a clogged intake air filter. The air filter element should be checked
monthly (see Figure 11). Operating compressor with a dirty filter can
cause high oil consumption and increase oil contamination in the
discharge air. If the air filter is dirty it must be replaced.
Figure 10 - ASME Safety Valve
Figure 11
MAINTENANCE /
REPAIR TROUBLESHOOTING OPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS GETTING STARTED

17
MAINTENANCE AND INSPECTION INSTRUCTIONS (CONTINUED)
Intercooler
Intercooler fins are sharp, always wear gloves and use care when
you clean or work near the intercooler.
Weekly, check the intercooler to be sure all fittings are secure and tight. Clean all dirt, dust and other
accumulations from the intercooler fins.
Components
Turn off all power and clean the cylinder head, motor, fan blades, air lines, intercooler and tank on a monthly
basis.
Belts
Lock out and tag the power then release all pressure from the tank to prevent
unexpected movement of the unit.
Check belt tension every 3 months. Adjust belt tension to allow 3/8 inch to 1/2 inch deflection with normal thumb
pressure. Also, align belts using a straight edge against the face of the flywheel and touching the rim on both
sides of the face. The belts should be parallel to this straight edge (see Figure 12). Dimension A should be the
same as B and C to ensure proper alignment of the belts.
Slots in the bed-plate allow for sliding the motor back and forth to adjust belt tension.
AB
C
Figure 12 - Top View
Air Compressor
Motor
Flywheel
Straight Edge
Motor Drive
Pulley
Setscrew
Maintenance Schedule
Operation Daily Monthly 3 Months
Check Safety Valve ●
Drain Tank ●
Check Oil Level ●
Clean or Change Air Filter ●
Check Intercooler ●
Clean Unit Components ●
Check Belt Tightness ●
Change Oil (see Figure 8 ) ●
MAINTENANCE / REPAIR
TROUBLESHOOTINGOPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS
GETTING STARTED

26
28
35
31
30
27
29
2
1
10
32
9
13
4
3
5
16
11
14
12
15
6
7
20
25
18
23
24
21
8
19
17
22
38 39
40
18
For Repair Parts, visit www.campbellhausfeld.com
24 hours a day – 365 days a year
Please provide following information:
-Model number
-Serial number (if any)
-Part description and number as shown in parts list
REPAIR PARTS ILLUSTRATION FOR CE3000 and CE3001
MAINTENANCE /
REPAIR TROUBLESHOOTING OPERATION
ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS GETTING STARTED
