Campbell Hausfeld FP2052 User manual

Visit us online: www.chpower.com
6
Air Compressors
Air Compressors
• Compact design with maintenance-free
oil-less pump; ideal for the home
workshop
• Hose wrangler system keeps hose coiled
when not in use for easy transportation
and compact storage
• On-board accessory storage
keeps small accessories organized
and readily available
• Includes wall-mounting bracket
and hardware, 25 ft. recoil hose,
tire chuck, 2 inflation nozzles,
inflation needle, and an inflation
needle adapter
Wall-Mountable Air Compressor FP2052
Cordless Air Compressor FP2071
• Cordless design is great for work and play.
Use at home for inflation, brad nailing,
stapling, air brushing and more.
• Shoot over 600 brad nails or inflate 9 tires
from flat to full on a single charge
• Take camping to inflate air mattresses and
use the 12V power source. Or, use by the
pool to inflate children’s toys and listen
to the radio.
• 1.5 gallon tank
• 2 powerful 7.5 amp hour batteries
• On-board 12V power source, AM/FM
radio, and accessory storage

7
Or call CH Compressors at: 1- 800-543-6400
Air Compressors
• Lightweight and easy-to-carry with
maintenance-free oil-less pump
• Easy-to-use control panel with
large easy-to-read gauges
• Built-in accessory storage for
clutter-free work area
• Includes 25 ft. recoil hose and
industrial coupler
4 Gallon Portable Air Compressor FP2080
Model
No
Tank
Capacity
Voltage
requirements
ISO 1217 Free Air Delivery
scfm*@40/90 PSI
MAX
Pressure
FP2028 1 Gallon 120V .51/.39 100 PSI
FP2049 3 Gallon 120V .51/.39 100 PSI
FP2080 4 Gallon 120V 1.4/1.03 135 PSI
FP2052 2 Gallon 120V 1.4/1.03 135 PSI
Air Compressors
Consider these easy-to-use air compressors for your
next project, such as tire inflation, brad nailing and
stapling. These maintenance-free, oil-less air compres-
sors feature easy-to-read gauges, comfortable handles,
accessory storage, and built-in hose management. Their
lightweight, portable design makes them easy to store
in your garage or workshop.
• Built-in accessory storage to keep
accessories organized and readily
available
• Easy-to-read gauge allows for easy
monitoring of air flow
• Includes 25 ft. recoil hose, tire chuck,
2 inflation nozzles, inflation needle,
and an inflation needle adapter
1 Gallon Portable Air Compressor FP2028
• Lightweight and easy to carry with
maintenance-free oil-less pump
• Perfect compressor for home usage
such as inflation, brad nailing,
stapling, air brushing and more
• Includes 25 ft. recoil hose, tire
chuck, 2 inflation nozzles, inflation
needle, and an inflation needle
adapter
Portable Air Compressor FP2049
Portable Air Compressor FP2090
FP2090 2 Gallon 120V .51/.39 100 PSI
FP2071 1.5 Gallon 12V 1.4/1.03 135 PSI
Why Use Air Compressors?
*SCFM (Standard Cubic Feet per Minute) measures air flow delivered by compressor

Visit us online: www.chpower.com
8
Air Compressors
• Built-in tool and accessory storage
helps organize the garage
• Easy-to-operate controls with
descriptive icons and oversized gauges
for quick reference
• Large air reservoir for extra storage
during heavy-duty tasks around the home
• Maintenance-free oil-less pump with
hot/moving parts covered by a
durable shroud
13 Gallon, ASME Code, Air Compressor WL6501
20 Gallon, ASME Code, Air Compressor WL6502
Air Compressors
• Built-in tool and accessory storage helps organize
the garage
• Vertical orientation saves 50% more space
• Easy-to-operate controls with descriptive icons and
oversized gauges for quick reference
• Large air reservoir for extra storage during
heavy-duty tasks around the home
• Maintenance-free oil-less pump with
hot/moving parts covered by a
durable shroud
• Built-in tool storage
helps organize
the garage
• Easy-to-read and easy-to-
use control panel
• Large air reservoir for extra
storage during heavy-duty
tasks around the home
• Maintenance-free
oilless pump
• Hot/moving parts
are covered by
durable shroud
15 Gallon, ASME Code, Vertizontal *Air Compressor WL6514
26 Gallon, ASME Code, Vertizontal Air Compressor WL6506
26 Gallon, ASME Code, Air Compressor WL6111
*CAN BE OPERATED AND STORED IN A
VERTICAL OR HORIZONTAL POSITION

9
Or call CH Compressors at: 1- 800-543-6400
Air Compressors
Air Compressors
• Everything you need to get started with
automotive repairs
• Includes: 8 gallon oil-lubricated
compressor, 1/2” impact wrench, gen-
eral purpose spray gun, 3/8” ratchet,
2-in-1 nailer/stapler, tire inflation
gun with gauge, 64 piece hand
tool kit, hose reel, 25’ PVC air
hose, 25 piece accessory kit,
impact sockets, safety glasses,
dust mask and ear plugs
• Oil-lubricated, CAST IRON
cylinder compressor pump
for long lasting, reliable
performance
• Large air reservoir for extra
storage during heavy duty
tasks around the home
Ultimate Garage Kit HL410199
• Oil-lubricated, CAST IRON cylinder compressor
pump for long lasting, reliable performance
• The 1.3 running HP motor combined with the
Campbell Hausfeld pump stands for high quality per-
formance and starting capabilities
• Large air reservoir for extra storage during heavy
duty tasks around the home
8 Gallon, Oil-Lubricated, Air Compressor HL5501
• Oil-lubricated, CAST IRON cylinder compressor pump
for long lasting, reliable performance
• The 1.3 running HP motor combined with the
Campbell Hausfeld pump stands for high quality per-
formance and starting capabilities
• 4 gallon twinstack tank for efficient air storage
4 Gallon, Oil-Lubricated, Air Compressor HL5502
Model
No
Tank
Capacity
Voltage
requirements
ISO 1217
Free Air Delivery
scfm** @40/90 PSI
MAX
Pressure
WL6501 13 Gallon 1.7 120V 5.6/3.8 125 PSI Oilless
WL6502 20 Gallon 1.7 120V 5.6/3.8 125 PSI Oilless
WL6111 26 Gallon 1.7 120V 5.6/3.8 125 PSI Oilless
WL6514 15 Gallon 1.7 120V 5.6/3.8 135 PSI Oilless
WL6506 26 Gallon 1.7 120V 5.6/3.8 125 PSI Oilless
Running
HP
HL5501 8 Gallon 1.3 120V 4.5/3.7 125 PSI Oil- Lubed
HL5502 4 Gallon 1.3 120V 4.5/3.7 125 PSI Oil-Lubed
Pump
These award-winning, popular air compressors are
designed for your serious home and auto projects.
Wheeled for portability, they feature powerful motors that
operate on household electrical current and quality-built
air tanks. Most units include a built-in control panel for
easy operation and control. They also feature shrouds to
protect motors, gauges and other parts.
Why Use Air Compressors?
HL410199 8 Gallon 1.3 120V 4.5/3.7 125 PSI Oil-Lubed
** SCFM (Standard Cubic Feet per Minute) measures air flow delivered by compressor

Visit us online: www.chpower.com
10
* Based on B-10 bearing rating
Air Compressors
10 Gallon, ASME Code, Oil-Lubricated Air Compressor HL4210
20 Gallon, ASME Code, Oil-Lubricated, Air Compressor VT6290
• Heavy-Duty CAST IRON,
oil-lubricated, twin cylinder pump
• Powers a variety of air tools for the serious
do-it-yourselfer, professional, or contractor
• Product life: up to 5,000 hours*
• Quietest operation
• Durable and safe ASME code tank
CAST IRON Air Compressors
15 Gallon, ASME Code, Oil-Lubricated Vertical Air Compressor HL4315
• Oil-lubricated pump with CAST IRON cylinder
• Oil sight glass allows visual monitoring
of oil level for convenient pump main-
tenance and improved performance
• Low amp draw motor for high quality
performance with fewer tripped circuit
breakers
•Durable and safe ASME code tank
• Oil-lubricated pump with CAST IRON cylinder
• Powers a variety of air tools for the serious
do-it-yourselfer
• Low amp draw motor for high quality
performance with fewer tripped
circuit breakers
• Durable and safe ASME code tank

11
* Based on B-10 bearing rating
**SCFM (Standard Cubic Feet per Minute) measures air flow delivered by compressor
Or call CH Compressors at: 1- 800-543-6400
Air Compressors
Model
No
Tank
Capacity
Voltage
requirements
ISO 1217
Free Air Delivery
scfm**@40/90 PSI
MAX
Pressure
Running
HP Pump
VT6290 20 Gallon 2.0 120/240V 6.5/5.5 135 PSI Twin cylinder
VT6233 26 Gallon 2.0 120/240V 6.5/5.5 125 PSI Twin cylinder
VT6271 26 Gallon 3.2 240V 11.5/10.2 135 PSI Twin cylinder
VT6275 60 Gallon 3.2 240V 11.5/10.2 135 PSI Twin cylinder
• Heavy-Duty CAST IRON, oil-lubricated,
twin cylinder “V” style pump
• Air flow (SCFM) to power a wide variety of
air tools
• Product life: up to 3,000 hours*
• Quiet operation
• Durable and safe 60 gallon ASME code
tank for greater air storage
60 Gallon, ASME Code,Oil-Lubricated, Air Compressor VH6111
CAST IRON Air Compressors
• Heavy-Duty CAST IRON, oil-lubricated,
twin cylinder pump
• High air flow (scfm) to power a wide
variety of air tools
• Product life: up to 5,000 hours*
• Quietest operation
• Durable and safe 60 gallon ASME code
tank for greater air storage
60 Gallon, ASME Code Oil-Lubricated, Air Compressor VT6275
• Easy-to-change filter for clean intake
• Solid cylinders
• Dip stick and breather
• Side port for easy oil fill
• Ball bearings for longer life
For higher output air compressors please
see page 65 for contact information.
• Heavy-Duty CAST IRON, oil-lubricated, twin cylinder pump
• Powers a variety of air tools for the serious do-it-yourselfer,
professional, or contractor
• Product life: up to 5,000 hours*
• Quietest operation
• High horsepower motor capable of
running on 120/240 volts
• Durable and safe ASME code tank
for greater air storage
26 Gallon, ASME Code, Oil-Lubricated, 120V VT6233
26 Gallon, ASME Code, Oil-Lubricated, 240V VT6271
VH6111 60 Gallon 3.2 240V 11.5/10.2 135 PSI Twin cylinder
HL4210 10 Gallon 1.3 120V 4.5/3.7 125 PSI Single cylinder
HL4315 15 Gallon 1.3 120V 4.5/3.7 125 PSI Single cylinder
