INSTRUCTION MANUAL
CM3 Pyranometer
Revision: 10/02
Copyright (c) 1999-2002
Campbell Scientific, Inc.

Warranty and Assistance
The CM3 PYRANOMETER is warranted by CAMPBELL SCIENTIFIC,
INC. to be free from defects in materials and workmanship under normal use
and service for twelve (12) months from date of shipment unless specified
otherwise. Batteries have no warranty. CAMPBELL SCIENTIFIC, INC.'s
obligation under this warranty is limited to repairing or replacing (at
CAMPBELL SCIENTIFIC, INC.'s option) defective products. The customer
shall assume all costs of removing, reinstalling, and shipping defective products
to CAMPBELL SCIENTIFIC, INC. CAMPBELL SCIENTIFIC, INC. will
return such products by surface carrier prepaid. This warranty shall not apply
to any CAMPBELL SCIENTIFIC, INC. products which have been subjected to
modification, misuse, neglect, accidents of nature, or shipping damage. This
warranty is in lieu of all other warranties, expressed or implied, including
warranties of merchantability or fitness for a particular purpose. CAMPBELL
SCIENTIFIC, INC. is not liable for special, indirect, incidental, or
consequential damages.
Products may not be returned without prior authorization. The following
contact information is for US and International customers residing in countries
served by Campbell Scientific, Inc. directly. Affiliate companies handle repairs
for customers within their territories. Please visit www.campbellsci.com to
determine which Campbell Scientific company serves your country. To obtain
a Returned Materials Authorization (RMA), contact CAMPBELL
SCIENTIFIC, INC., phone [phone]. After an applications engineer
determines the nature of the problem, an RMA number will be issued. Please
write this number clearly on the outside of the shipping container.
CAMPBELL SCIENTIFIC's shipping address is:
CAMPBELL SCIENTIFIC, INC.
RMA#_____
815 West 1800 North
Logan, Utah 84321-1784
CAMPBELL SCIENTIFIC, INC. does not accept collect calls.

i
CM3 Pyranometer Table of Contents
PDF viewers note: These page numbers refer to the printed version of this document. Use
the Adobe Acrobat® bookmarks tab for links to specific sections.
1. General Description....................................................1
2. Specifications .............................................................1
3. Installation...................................................................2
4. Wiring ..........................................................................4
5. Example Programs .....................................................6
5.1 Average Solar Radiation...........................................................................6
5.2 Total Solar Radiation................................................................................7
5.2.1 Output Format Considerations........................................................8
6. Maintenance................................................................9
7. Calibration...................................................................9
Figures
3-1. CM3 and CM3MT...................................................................................3
3-2. 015 Pyranometer Mounting Arm.............................................................3
3-3. 025 Crossarm Stand and 019ALU Crossarm...........................................4
3-4. UTKZ Leveling Fixture and Crossarm Mount and UT018
Tower Mounting Bracket and Crossarm...........................................4
4-1. CM3 Wiring.............................................................................................5
Tables
5-1. Multipliers Required for Average Flux and Total Flux Density
in SI and English Units.....................................................................6

This is a blank page.

1
CM3 Pyranometer
1. General Description
This manual provides information for interfacing Kipp & Zonen’s CM3
Pyranometer to a CR10(X), CR510, CR23X, CR7 or 21X datalogger.
The CM3 is shipped with an instruction manual provided by Kipp & Zonen that
contains information concerning the CM3’s construction, spectral sensitivity,
cosine response, and a simple sensor check out procedure. Included with the
sensor and manual is a calibration certificate with the sensor calibration
constant and serial number. Cross check this serial number against the serial
number on your CM3 to ensure that the given calibration constant corresponds
to your sensor.
The CM3 pyranometer is designed for continuous outdoor use. Due to its flat
spectral sensitivity from 300 to 3000 nm, it can be used in natural sunlight,
under plant canopies, in green houses or buildings, and inverted to measure
reflected solar radiation. Two CM3s can be used in combination with an
albedometer fixture (K&Z’s CAF 1) to measure albedos. The CM3 can also be
used to measure most types of artificial light (Xenon lamps, Halogen lamps,
etc.).
The CM3 pyranometer consists of a thermopile sensor, a housing, a dome, and
a cable. The thermopile is coated with a black absorbent coating. The paint
absorbs the radiation and converts it to heat. The resultant temperature
difference is converted to a voltage by the copper-constantin thermopile. The
thermopile is encapsulated in the housing in such a way that it has a field of
view of 180 degrees and the angular characteristics needed to fulfill the cosine
response requirements.
2. Specifications
The CM3 is an ISO Second Class pyranometer. While the worst case accuracy
for daily sums given by Kipp & Zonen is +10%, the typical accuracy is +5%.
Tests at Campbell Scientific on one CM3 indicated an accuracy of +2% when
compared to a recently calibrated Eppley PSP.
ISO SPECIFICATIONS:
Response Time 95%: 18 seconds
Zero offset due to 200 W/m2thermal
radiation: < 15 Wm-2
Zero offset due to temperature change
of 5ºK / hr: < +4 Wm-2
Non stability (% change/year): < + 1%
Non linearity (at 1000 W/m2): < + 2.5%
Directional error (at 1000 W/m2): < + 25 Wm-2

CM3 Pyranometer
2
Temperature Dependence of
sensitivity: + 6% (-10 to + 40ºC)
Tilt response (+80º) (at 1000 W/m2): < + 2%
OTHER SPECIFICATIONS
Expected accuracy for daily sums: + 10%
Spectral range (50% points, nm): 305-2800 nm
Sensitivity: 10 - 35 µV/Wm-2
Expected signal output in atmospheric
application: 0 - 50 mV
Impedance: 79 - 200 (Ω)
Operating Temperature: -40 to +80ºC
Max. irradiance: 2000 Wm-2
Detector: Copper-constantin multi junction
thermopile
Cable length: 15 feet (5 m)
Level accuracy: 1 degree
DIMENSIONS / SHIPPING DIMENSIONS
CM3: 3x3x3 in / 6x6x6 in
CM3MT: 1x5x5 in / 6x6x6 in
WEIGHT/SHIPPING WEIGHT
CM3: 0.8 lbs / 3 lbs
CM3MT: 0.6 lbs / 3 lbs
3. Installation
The CM3 should be mounted such that it is never shaded by the tripod/tower or
other sensors.
To ensure accurate measurements, the CM3 should be mounted using the
CM3MT base/leveling fixture or equivalent. The CM3MT incorporates a
bubble level and three adjustment screws. Mount the CM3 Pyranometer to the
CM3MT mount using the two long screws provided. The screws are slightly
shorter than ideal but should provide adequate holding strength.

CM3 Pyranometer
3
FIGURE 3-1. CM3 and CM3MT
Install the CM3MT Mount on either the 025 Pyranometer Cross Arm Stand, the
015 Pyranometer Mounting Arm, or the UTKZ (not yet available, please call)
before mounting them to the tower or tripod. This is done by first threading the
screws through the springs and just barely through the mounting plate. This
helps remove any paint that might have gotten into the threaded holes. Second,
remove two of the screws/springs, slide the CM3MT Mount onto the remaining
screw by slightly compressing the spring. Slide the remaining two springs
between the CM3MT and the 015 or 025 mount and install the remaining two
screws. Tighten the screws until all three springs have been compressed about
1/8 inch.
Once the pyranometer mount has been installed on the tripod or tower, tighten
the appropriate screws until the bubble indicates the sensor is level.
FIGURE 3-2. 015 Pyranometer Mounting Arm
015ARM Pyranometer
Mounting Arm
Tripod Mast or Tower Support
CM3 Sensor
CM3MT
015 Pyranometer Mounting Arm or
025 Pyranometer Crossarm Stand
PN7790(3)
Bubble Level

CM3 Pyranometer
4
FIGURE 3-3. 025 Crossarm Stand and 019ALU Crossarm
FIGURE 3-4. UTKZ Leveling Fixture and Crossarm Mount and
UT018 Tower Mounting Bracket and Crossarm
4. Wiring
Use Differential Voltage measurement instruction 2 to measure the CM3. The
CM3 wiring diagram is shown in Figure 4-1.
The red lead is connected to the high side (H) of any differential channel. The
blue lead is connected to the corresponding low (L) side of the differential
channel. On a CR10(X) or CR510, the white lead is connected to an analog
ground (AG) and the clear to ground (G). On the CR23X, 21X or CR7 both the
white and clear leads are connected to ground ( ).
While a differential measurement is better and preferred, the CM3 can be
measured on a single-ended channel using Instruction 1 if the power induced
voltages discussed in the following paragraph are prevented.
025STAND
Crossarm Stand
019ALU Crossarm
CM3
UT018 Crossarm
UT018 Tower
Mounting Bracket
Tower Support
UTKZ Leveling
Fixture and
Crossarm Mount
(includes CM3MT)
3/4” x 3/4”
N
U-RAIL 3/4” x 1”
N
U-RAIL
3/4” x 3/4”
N
U-RAIL

CM3 Pyranometer
5
If a 21X is used to measure the CM3 and it powers a 12 VDC sensor or 12
VDC radio, the current drawn off the 12 VDC supply may cause a difference in
ground potential between the 21X ground terminals and the reference ground
point in the datalogger. This ground potential results in an offset on single
ended measurements. This offset can be as large as +60 mV. Thus, single
ended measurements should be avoided. The offset does not, however, affect
differential measurements. While the 21X is the logger most susceptible to this
condition, the other dataloggers can be affected if the amount of power is too
large or the power return line is connected to analog ground (AG).
FIGURE 4-1. CM3 Wiring
Color Function CR10(X),
CR510 21X/CR7 CR23X
Red Signal Differential
Channel - H Differential Channel - H Differential Channel - H
Blue Signal Reference Differential
Channel - L Differential Channel - L Differential Channel - L
White Signal Ground AG ≡≡
Clear Shield G ≡≡
White = Signal Ground
Blue = Signal Reference
Red = Signal
Clear = Shield

CM3 Pyranometer
6
5. Example Programs
Solar radiation can be reported as an average flux density (W m-2) or daily total
flux density (MJ m-2). The appropriate multipliers are listed in Table 5-1.
Programming examples are given for both average and daily total solar
radiation.
The output from the CM3 varies from 10-35 x 10-6V / W m-2. Given a
maximum solar radiation of 1500 W m-2, the maximum sensor output voltage
will be 15 - 52.5 mV. Example:
(21.87 x 10-6 V W-1m2) ∗(1500 W m-2) = 0.03281 V or 32.81 mV
TABLE 5-1. Multipliers Required for Average Flux and
Total Flux Density in SI and English Units
UNITS MULTIPLIERS
W m-2 1
103
C∗




(average)
MJ m-2 t
C∗





109(total)
kJ m-2 t
C∗





106(total)
cal cm-2 min-1 14333
106
.
C∗




(average)
cal cm-2 t
C
∗
∗





002389
106
.(total)
C=CM3 calibration: eg. 21.87x10-6V / W m-2
t = datalogger execution interval in seconds
5.1 Average Solar Radiation
Example 1 shows the program instructions used by a CR10X to measure the
signal from the CM3. A sixty-minute average is calculated and stored in final
storage.

CM3 Pyranometer
7
Example 1
;{CR10X}
;
*Table 1 Program
01: 10 Execution Interval (seconds)
1: Volt (Diff) (P2)
1: 1 Reps
2: 24 250 mV 60 Hz Rejection Range
3: 1 DIFF Channel
4: 1 Loc [ W_m2 ]
5: 45.725 Mult ;multiplier = (1 / 0.02187 mV / W/m2)
6: 0.0 Offset
;Set negative values to zero.
;
2: If (X<=>F) (P89)
1: 1 X Loc [ W_m2 ]
2: 4 <
3: 0 F
4: 30 Then Do
3: Z=F x 10^n (P30)
1: 0.0 F
2: 00 n, Exponent of 10
3: 1 Z Loc [ W_m2 ]
4: End (P95)
5: If time is (P92)
1: 0 Minutes (Seconds --) into a
2: 60 Interval (same units as above)
3: 10 Set Output Flag High (Flag 0)
6: Real Time (P77)
1: 1220 Year,Day,Hour/Minute (midnight = 2400)
7: Average (P71)
1: 1 Reps
2: 1 Loc [ W_m2 ]
*Table 2 Program
02: 0.0000 Execution Interval (seconds)
*Table 3 Subroutines
End Program
5.2 Total Solar Radiation
In Example 2 a CR10X is used to record daily total flux density. This total flux
density is in MJ m-2 day-1to avoid the need for high resolution discussed in
5.2.1. Negative values are set to zero before they are added to the running
total.

CM3 Pyranometer
8
5.2.1 Output Format Considerations
If the solar radiation is totalized in units of kJ m-2, there is a possibility of
over-ranging the output limits. The largest number that the datalogger can
output to final storage is 6999 in low resolution and 99999 in high resolution
(Instruction 78, Set Resolution).
Assume that the daily total flux density is desired in kJ m-2. Assume an
irradiance of 0.5 kW m-2, the maximum low-resolution output limit will be
exceeded in just under four hours. This value was found by taking the
maximum flux density the datalogger can record in low resolution and dividing
by the total hourly flux density.
()()
39 6999
05 3600
2
21 1
.. hr kJm
kJm s shr
=
−
−− −
To circumvent this limitation, record an average flux (see Example 1). Then,
during post processing, multiply the average flux by the number of seconds in
the output interval to arrive at an output interval flux density. Sum the output
interval totals over a day to find a daily total flux density.
Another alternative is to record total flux using the high-resolution format
(Instruction 78, see Datalogger manual for details). The disadvantage of the
high-resolution format is that it requires four bytes of memory per data point,
consuming twice as much memory as low resolution. (Given the larger amount
of memory in today’s dataloggers, this may not matter.)
Example 2
;{CR10X}
;
*Table 1 Program
01: 10 Execution Interval (seconds)
1: Volt (Diff) (P2)
1: 1 Reps
2: 24 250 mV 60 Hz Rejection Range
3: 1 DIFF Channel
4: 1 Loc [ MJ_m2____ ]
5: 0.45725 Mult ;multiplier = [10s / (21870 mV / MJ/m2)] Step 1 of 2
6: 0.0 Offset
2: Z=X*F (P37)
1: 1 X Loc [ MJ_m2____ ]
2: 0.001 F Step 2 of 2
3: 1 Z Loc [ MJ_m2____ ]
;Set negative values to zero.
;
3: If (X<=>F) (P89)
1: 1 X Loc [ MJ_m2____ ]
2: 4 <
3: 0 F
4: 30 Then Do

CM3 Pyranometer
9
4: Z=F x 10^n (P30)
1: 0.0 F
2: 00 n, Exponent of 10
3: 1 Z Loc [ MJ_m2____ ]
5: End (P95)
6: If time is (P92)
1: 0 Minutes (Seconds --) into a
2: 60 Interval (same units as above)
3: 10 Set Output Flag High (Flag 0)
7: Real Time (P77)
1: 1220 Year,Day,Hour/Minute (midnight = 2400)
8: Totalize (P72)
1: 1 Reps
2: 1 Loc [ MJ_m2____ ]
*Table 2 Program
02: 0.0000 Execution Interval (seconds)
*Table 3 Subroutines
End Program
6. Maintenance
On a monthly basis the level of the pyranometer should be checked. Any dust
or debris on the sensor window should be removed. The debris can be removed
using water (de-ionized or distilled) or alcohol.
7. Calibration
Recalibration is suggested every two years. Calibrations can be done in one of
two ways.
One method is to calibrate the sensor in the field by placing a “transfer
standard” (a sensor that has been calibrated against a “secondary standard”)
next to the sensor being calibrated. Preferably daily totals of several days
should be compared. The calibration factor could be corrected if results differ
by more than six percent.
Another method would be to send the sensor to a facility that has a “secondary
standard”. Contact Kipp & Zonen (www.kippzonen.com) for the nearest
calibration facility, or send it to Campbell Scientific and they will have it
recalibrated.

CM3 Pyranometer
10
This is a blank page.

This is a blank page.

Campbell Scientific Companies
Campbell Scientific, Inc. (CSI)
815 West 1800 North
Logan, Utah 84321
UNITED STATES
www.campbellsci.com
[e-mail]
Campbell Scientific Africa Pty. Ltd. (CSAf)
PO Box 2450
Somerset West 7129
SOUTH AFRICA
www.csafrica.co.za
[email protected]
Campbell Scientific Australia Pty. Ltd. (CSA)
PO Box 444
Thuringowa Central
QLD 4812 AUSTRALIA
www.campbellsci.com.au
[email protected]m.au
Campbell Scientific do Brazil Ltda. (CSB)
Rua Luisa Crapsi Orsi, 15 Butantã
CEP: 005543-000 São Paulo SP BRAZIL
www.campbellsci.com.br
[e-mail]
Campbell Scientific Canada Corp. (CSC)
11564 - 149th Street NW
Edmonton, Alberta T5M 1W7
CANADA
www.campbellsci.ca
[email protected]
Campbell Scientific Ltd. (CSL)
Campbell Park
80 Hathern Road
Shepshed, Loughborough LE12 9GX
UNITED KINGDOM
www.campbellsci.co.uk
[email protected]k
Campbell Scientific Ltd. (France)
Miniparc du Verger - Bat. H
1, rue de Terre Neuve - Les Ulis
91967 COURTABOEUF CEDEX
FRANCE
www.campbellsci.fr
campbell.scientifi[email protected]r
Campbell Scientific Spain, S. L.
Psg. Font 14, local 8
08013 Barcelona
SPAIN
www.campbellsci.es
[e-mail]
Please visit www.campbellsci.com to obtain contact information for your local US or International representative.
