CanadianPond LT User manual

OWNER’S MANUAL
WATER WEEDSICKLE
MODEL – LT
CAUTION – VERY SHARP KNIVES
Before assembling or operating your Water Weedsickle, please carefully
read the SAFETY, ASSEMBLY, OPERATING INSTRUCTIONS and
WARRANTY included in this manual.
If you have any questions or require assistance, please contact us at
450-243-0976.

WATER WEEDSICKLE – LT
570 ch Knowlton, Lac-Brome, QC J0E 1V0 CANADA
T: 450 243 0976 F: 450 243 1834 [e-mail] www.canadianpond.ca Page 2 of 5
SAFETY INSTRUCTIONS
THE CUTTING KNIVES ARE EXTREMELY SHARP. Always handle the Water
Weedsickle with care.
NEVER OPERATE THE WATER WEEDSICKLE WITH PEOPLE OR PETS IN THE
WATER.
When cutting weeds, beware of objects in the water such as dock supports,
swim ladders, boat lifts, water or power lines, ropes etc. which could come
into contact with the Cutter Bar.
Do not allow children to operate the Water Weedsickle.
Do not run the Water Weedsickle out of the water.
When not in use the Water Weedsickle should be stored indoors. Always
store the machine in a manner where the cutting knives are not exposed. If
the machine is stored in an upright position attach it to a wall to prevent it
from falling over resulting in possible personal injury. (The Water
Weedsickle is top heavy due to the Gearmotor and is likely to tip over if not
secured)

WATER WEEDSICKLE – LT
570 ch Knowlton, Lac-Brome, QC J0E 1V0 CANADA
T: 450 243 0976 F: 450 243 1834 [e-mail] www.canadianpond.ca Page 3 of 5
ASSEMBLY INSTRUCTIONS
CAUTION – VERY SHARP KNIVES
Remove the following two (2) contents from the shipping carton;
 Tube Assembly
 Cutter Bar Assembly
Cutter Bar Assembly / Tube Assembly
Remove the two (2) 1/4” nuts which are loosely attached to the two (2) 1/4” bolts
located on the back of the Cutter Bar
Install the Tube Assembly to the Cutter Bar Mounting Bracket so that the two (2) 1/4”
holes line up. When positioning the Tube Assembly to the Cutter Bar make sure the
Cam Lever on the end of the Tube Assembly is fitted into the slot in the Cam Driver on
the Cutter Bar. The Cam Lever may be rotated by hand in order to position it correctly.
Reinstall the two (2) 1/4” nuts onto the two (2) 1/4” bolts and tighten both nuts
securely.

WATER WEEDSICKLE – LT
570 ch Knowlton, Lac-Brome, QC J0E 1V0 CANADA
T: 450 243 0976 F: 450 243 1834 [e-mail] www.canadianpond.ca Page 4 of 5
OPERATING INSTRUCTIONS
Clamp the Water Weedsickle to the desire location on your boat. We recommend
mounting the machine on the transom as close to the motor as possible to minimize the
drag affect of the Cutter Bar. For small boats (12’ and under) mounting the Water
Weedsickle to the transom and rowing is a very effective method of cutting weeds.
Rowing also allows for excellent control of the boat.
TIP: Rowing in reverse with the Water Weedsickle rotated 180° provides an excellent view
of where you are cutting.
It is easiest to clamp the machine to the boat in a horizontal (fully tilted) position and then
lower the Cutter Bar into the water after the clamps are tightened.
Adjust the depth of the cut and tighten the Depth Adjustment Handle securely by hand.
Make sure the Cutter Bar is clear of the motor’s lower unit and the bottom of the boat.
The machine will operate in a tilted position for cutting in shallow water. (The initial
cutting depth for fully grown weeds is two (2) feet maximum)
The forward speed of the boat is to be dependent on the density of the weed mass. A
tearing or raking effect is a clear indication of too much forward speed. The Water
Weedsickle must be allowed to cut the weeds and not tear or rake them. The maximum
fuse amperage is 20 amps. Repeated blowing of the fuse is an indication of too much
forward speed and/or the Cutter Bar touching the bottom.
DO NOT allow the Cutter Bar to be dragged along the lake bottom. This may result in
serious damage to the machine. If you are uncertain of the depth of the water, or of
underwater obstacles (stumps, rocks, etc.) we recommend rowing to minimize potential
damage to the machine.
Do not lubricate the Main Support Tube. This will affect the friction fit of the depth
adjustment.
We recommend spraying the Cutter Bar with a light lubricant (WD40, etc.) after each use
to protect to keep the cutting components moving freely. Do not leave the Water
Weedsickle in the water after use.

WATER WEEDSICKLE – LT
570 ch Knowlton, Lac-Brome, QC J0E 1V0 CANADA
T: 450 243 0976 F: 450 243 1834 [e-mail] www.canadianpond.ca Page 5 of 5
LIMITED WARRANTY
For a period of one (1) year from the date of shipment, Salmon Industries Ltd.
(hereinafter Manufacturer) warrants the goods manufactured to be free from defects
in material and workmanship to the original purchaser. During the warranty period the
Manufacturer agrees to repair or replace, at our sole discretion, defective goods or
parts without charge for material or labour.
This warranty extends only to the original purchaser and is not transferable. This
warranty is void if the product has been subject to accident, physical damage, misuse,
abuse, improper repair, unauthorized alteration or operation beyond the designed
intent.
This warranty is also void if the unit has been used for rental purposes.
The Gearmotor shall not be covered by this warranty if it has been determined to be
subjected to excessive moisture (submersion and/or left exposed to natural elements.)
To obtain warranty service you must first contact Canadianpond. Where possible
Canadianpond will attempt to provide the necessary part(s) and installation support
for the Purchaser to perform warranty repairs. If it is determined the unit is to be
returned for warranty repairs, the Purchaser shall bear all shipping, packaging,
insurance and all other costs (excluding parts and labour) to effectuate repairs under
this warranty.
In no event shall the manufacturer or Canadianpond be liable for incidental,
consequential, or other damages resulting from use of these products. This includes
but is not limited to, damage to property, damages based upon inconvenience or loss
of use of these products, use of product in violation of any laws or restrictions, or
personal injury.
All sales are final.
