Canary Products O'Breeze CE134 User manual

1
INSTRUCTION MANUAL
Model: CE134
Mist Fan, 16 Inch
110V, 60Hz, 90W
NOTE: Please read the manual carefully before using
PLEASE DO NOT RETURN BACK TO STORE,
LET US TROUBLESHOOT FOR YOU FIRST.
For any questions or concerns please email us at our parent
company [e-mail]. We will reply within less
than 24 hours.

2
WARNINGS
ATTENTION: Read this booklet carefully as it contains important
instructions for a safe installation, use, and maintenance.
1. This device must be usedonly for the purpose it was expressly
designed; any use not complying with the instructions
contained in the manual is considered inappropriate and
dangerous. The manufacturer is not responsible for possible
damages caused by the inappropriate and/or unreasonable
use.
2. This device isNOT suitable to use inanexplosive environment
(in the presence of flammable substances such as gas, vapor,
or in an atmospheric condition when, after ignition, the
combustion is spread in the air)
3. The packing materials (plastic bags, expanded polystyrene,
etc.) must be kept out of the reach of children or disabled
people since they represent potential sources of danger.
4. Place and use the device on a horizontal and stable surface.
5. Before use check the integrity of the device and power cable.
Incase you are not sure contact a qualified person.
6. Before powering the device make sure the rating (voltage and
frequency) corresponds to the grid and the socket is suitable
for the plug of the device.
7. If possible, avoid the use of adapters and/or extension cables;
if their use is necessary, use only materials in compliance with
the current safety regulations and according to the electrical
parameters of the adapters.
8. The device must not be switched on using external timers
and/or other remote-control devices which are not specified in
this manual.
9. DO NOT use or store the device near heatsources (heaters,
stoves etc.).
10. DO NOT dip the device in water or other liquids; in case of
accidental fall in the water DO NOT try to take it out, but first
unplug immediately the power cable fromthe socket.
11. If you use the device for the first time, make sure to remove
any label or protective sheet which blocks its proper
functioning.

3
12. Plugand unplug the power cable with dry hands and hold it
firmly. Before plugging make sure the start button of the
device is in the “OFF” position (turned off).
13. Always unplug the power cable to avoid the overheating and
avoid stretching it (do not pull it, tug it or use it to drag the
device to which is connected).
14. DO NOT obstruct totally nor partially the air vents or inserts
objects inside.
15. During the functioning do not touch the device with wet body
parts.
16. In case of malfunction or anomalies during the functioning,
switchoff the device immediately, turnoff the power andcheck
the cause of the anomalies, if possible, with the support of a
qualified person.
17. Avoid carrying out operations which are not specified in this
manual (such as disassembling and/or altering).
18. Always remember to unplug the power cable of the device if it
is not used for a long period, before storing, cleaning or
performing any maintenance operation.
19. Store anduse the device onlyindoors or inanycase protected
from weathering such as rain, direct radiation of the sun and
dust. The device is not design for the external use or storage.
20. The cleaning and maintenance of the device MUST NOT be
done by children without the supervision of an adult.
21. DO NOT use the device near curtains or textiles.
22. DO NOT hang the fan on the wall or ceiling unless this type of
installation is provided and explained in this manual.
23. DO NOT cover the device during functioning.
24. DONOT insert objects or bodyparts inside the protectiongrille
of the fan. DO NOT leave the device unsupervised for a long
period during functioning.
25. If the fan must be stored for a long period and is not used
regularly, place the fan in its original packaging in a dry
place.When you use it for the first time after a long period of
inactivity, make sure the fan is clean and the motor blades
turn feely (when the device not powered) without any
restraint.

4
Technical Information
1. Misting Board
2. Front Grill
3. Misting Board Lock Screws
4. Blade Lock Nut
5. Blades
6. Grill Lock Nut
7. Back Grill
8. Motor Shaft
9. Motor Cover
10. Grill Lock Nut
11. Grill Lock Screw
12. Motor Holder
13. Connection Holder
14. Main Holder
15. Holder Fixed Screw
16. Main Body
17. Water Tank
18. Water Outlet Lock nut
19. Base
20. Base Lock Nut
21. Wheels
22. Misting Tube
23. Control Panel
24. Remote Control
25. Decorate Panel
26. Water Indicator

5
Instructions for Use
1. Insert the main holder (14) into the main body (16),and tight up by the
holder fixed screw(15).
2. Insert the 5pcs wheels (21) into the base (19) and tighten up by the
base lock nut (20).
3. Put the back grill (7) on the motor shaft (8) and tighten up by the grill
lock nut (6) to the motor cover (9)
4. Insert the blades (5) on the motor shaft (8) and tighten up the blade
lock nut (4).
5. Fix the misting board (1) on the front grill (2), and tight up by misting
board lock screws (3).
6. Connect the front grill (2) and back grill(7) by grill lock screw(11) and
tighten up by grill lock nut (10).
7. Insert the misting tube (22), connection to the misting board (1)
Fill the water tank:
Unscrew the valve cover to open the tank turning it counter clockwise.
Fill the tank with cold and clean water making sure not to overfill it. To
close the tank, screw the valve cover back on securely turning it
clockwise. Turn the tank over and place it back into its designated space
at the back of the fan main body.
Loosen Tighten

6
ATTENTION!
•Make sure the product is unplugged before filling or refilling the water
tank.
•Only use water in the water tank. Do not add any chemicals, oils or
other additives.
•Only use coldor lukewarm water in the water tank. The water must not
be warmer than 40°C.
Place the fan on a dry and stable surface and insert the plug on the
socket; the unit will emit a short “BIP”sound indicating that power is
supplied. For your convenience the unit can be operated by using
control panel in the main body or by using remote control included.
Control panel Remote Control

7
Remote control is supplied with battery inside (remove the transparent
sheet fromthe battery cover before use remote control.
Whenthe batteryis over,itmustbe replaced with the same type following
the drawing on the back of remote control.
ON/OFF Button (A):
• Press On/Off button one time to activate the fan. The indicator light
will turn on the control panel. You can now press MIST (F) button to
select the misting function without fan operation (mist only).
•Press On/Off button a second time to turn on the fan: the unit will
operate at low speed and the related indicator light (4) will be on the
controlpanel. Youcannowselectother functions (speed,mode,timer,
mist).
• Press On/Off button when the unit is on to turn off it.
SPEED Button (B):
•To start the fan at lowspeed, press On/Off button (A) twice (when unit
is Off): the unit willoperate at lowspeed and the related indicator light
(6) will be on the control panel.
•Press speed button one time to select the medium speed: the related
indicator light (6) will be on the control panel.
•Press speed button another time to select the high speed: the related
indicator light (6) will be on the control panel.
MODE Button (C):
•Whenyou press the On/Off button twice,the fan will operate inNormal
mode (there isn’t any indicator light in the control panel that indicate
this mode).
•Press mode button one time to change to Natural mode: the unit
simulates a naturalbreeze mode and the related indicator light (1) will
be on the control panel.
•Press mode button another time to change to Sleeping mode: the unit
simulates a soft breeze suitable for night time use. The related
indicator light (2) will illuminate on the control panel.
Buttons:
A. On/Off
B. Speed
C. Mode
D. Timer
E. Oscillation
F. Mist
Indicator light:
1. Natural mode indicator
2. Sleeping mode indicator
3. Oscillation
4. Mist volume indicator:
minimum-medium-maximum
5. Timer
6. Speed: low-medium-high
7. Power on indicator

8
•Press again mode button to change to Normal mode (there isn’t any
indicator light in the control panel that indicate this mode).
TIMER Button (D):
•When the unit is operating, you can set the timer to switch the fan off
automatically after the set time. Press the timer button repeatedly to
select the desired time in half hour increments.
OSCILLATION Button (E):
•Press the oscillation button to activate the automatic oscillation from
right to left. The related indicator light (3) will illuminate in the control
panel.
•Press again the oscillation button to deactivate the automatic
oscillation; the indicator light (3) will off on the control panel.
MIST Button (F):
•The mist function can be selected on its own or together with the fan
operation.Whenthe mistfunctionis selectedthe related indicator light
(4) on the control panel will turn on according to the mist volume
selected: low-medium-high. There is another indicator light to indicate
that mist function is selected on the main body (26): it is blue when
there is water in the tank and turns red when the water tank is empty.
•Press the mist button one time to turn on the function at low volume.
•Press the mist button another time to turn off the mist function. The
indicator light (4) and the light on the main body (26) will off.
ATTENTION!
•Make sure the product is unplugged before filling or refilling the water
tank.
•Only use water in the water tank. Do not add any chemicals, oils or
other additives.
•Only use coldor lukewarm water in the water tank. The water must not
be warmer than 40°C.
Place the fan on a dry and stable surface and insert the plug on the
socket; the unit will emit a short “BIP”sound indicating that power is
supplied.

9
NOTED: Before cleaning the appliance always disconnect the
power plug.
1. DO NOT dip the device in water or splash it with any other
liquids.
2. DO NOT use solvents or any other chemical products for
cleaning.
3. When you have finished using the fan at the end of the season, wipe
off any dust to maintain it in good working order for the next season; if
necessary disassemble the grille and remove the fan; clean them with a
soft damp cloth.
4. Remove the water tank and clean it with lukewarm water; before
replacing the water tank in the unit make sure it is completely dry.
Draining the water out of the unit placing a container underneath the
water drain (indicated with an arrow in below picture) and let any water
remaining in the water reservoir drain out.
water drain--------------------------------

10
DISPOSAL
Used electric household devices
Further disposal instructions
Return the electrical appliance in such a condition that its later re-use or
recycling is not adversely affected. Batteries must be removed in
advance and the destruction of parts which contain fluids must be
avoided.
SPECIFICATION
Product: Metal Stand Fan
Model: CE134
Power: 90W
Voltage: 110V / 60Hz
Made in China
1. If you do not want to use your electrical appliance any longer,
return it free of charge to a recycling depot for used electric
appliances.
2. Used electric devices do not belong in the household garbage
(see symbol)
