CANchecked MFD15 User manual
Version v0.2 www.canchecked.de
Quickstart Guide
MFD15
Provided accessories
O 12V connecting/ programming cable
O 12-pins Plug C
O Pre-crimped pig tail cables
O Mounting bracket and knurled screws
O Encoder with connecting cable
O Programming adapter
O 2x Diffuse display foil
O 2x 1K1 pullup resistor (for NTC)
O Additional pins for own crimps
O Micro USB cable 1m / straight
More Informationen
More information on the display
and other products and accessories
you can find online at:
www.canchecked.de
www.canchecked.de/mfd15/
Plug A:
Molex 43025-0400
Plug B:
Molex 43025-0600
Plug C:
Molex 43025-1200
Crimp:
Molex 43030-0001
PLUG
A
A1
A2
A3
A4
PLU
G B
B1
B2
B3
B4
B5
B6
Encoder
RX
TX
5V
GND
5V
DTR
PLUG
C
C1
C2
C3
C4
C5
C6
C7
C8
C9
C10
C11
C12
MPP
1*
AIN1
AIN2
AIN3
AIN4
5V
CAN
H
CAN
L
MPP
2*
MPP
3*
MPP
4*
SGND
*future application
Version v0.2 www.canchecked.de
Installation
When installing the display, you need to pay attention to a neat cabling. The power
cable needs to be fused with 2A (optionally with 5A). The measurements for the
mounting hole and the screw holes can be found in the upper drawing.
In addition, only the can bus cables (high/low) needs to be connected.
Please make sure, to tighten the orange screws for the bracket carefully. Otherwise
you will damage the casing.
Implementation
After the start-up, the splash screen appears with the logo and an internal component
test (can bus) is run.
The display starts with the last selected view. If you press the encoder, the display
stops and shows a bar in the upper area.
1) Shift light or warning LED (RGB)
2) Menu bar (if display is stopped)
3+4) current data display depending
on the selected view
If you rotate the encoder, a red
rectangle is shown with the current
position. With another press, you
select the action:
1-8: change view
Setup: Setup / Menu
3+4: Change the sensor
The view of the data is selected in
menu under “views”. Choose
between: single value, 2 values, 4
values, 6 values, bargraph, YT
diagram, single needle, double
needle, bar+2way
On questions regarding accessories or functionality please get in contact with us via
our homepage (
www.canchecked.de
) or via email (
).
1
3
2
1
1
3
4
5
6
7
8
Setup
3540
4
0.98
RPM
Lambda1
2
