The copier is a multi-function copier capable of serving as a copier, fax, and printer.
This Service Manual provides information needed to service the copier in the field. For
information on technologies used in common with the existing copiers, refer to the "Copier
Basic Series" as necessary.
This Service Manual consists of the following chapters:
Chapter 1 General Description introduces the copier's features and
specifications, shows how to operate the copier, and explains how
copies are made.
Chapter 2 Basic Operation provides outlines of the copier's various mechanical
workings.
Chapter 3 Exposure System discusses the principles of operation used for the
copier's lens drive unit and scanner drive unit. It also explains the
timing at which these drive units are operated, and shows how they
may be disassembled/assembled and adjusted.
Chapter 4 Image Formation System discusses the principles of operation used
for the copier's image processing units. It also explains the timing at
which the various units involved in image processing are operated,
and shows how they may be disassembled/assembled and adjusted.
Chapter 5 Laser Exposure System discusses the principles of operation used for
the copier's laser unit. It also explains the timing at which the unit is
operated, and shows how they may be disassembled/assembled and
adjusted.
Chapter 6 Image Formation System discusses the principles of how images are
formed. It also explains the timing at which the various units involved in
image formation are operated, and show how they may be
disassembled/assembled and adjusted.
Chapter 7 Pick-Up/Feeding System explains the principles of picking up and
feeding copy paper in view of the functions of electrical and
mechanical units used to move copy paper and in relation to their
timing of operation. It also shows how these units may be
disassembled/assembled and adjusted.
Chapter 8 Side Paper Deck explains the principles of operation used from when
paper is picked up to when copies are delivered. It also explains the
timing at which various drive units are operated, and shows how they
may be disassembled/assembled and adjusted.
Chapter 9 Fixing System explains the principles used to fuse toner images to
transfer media in view of the functions of electrical and mechanical
units and in relation to their timing of operation. It also shows how
these units may be disassembled/assembled and adjusted.
Chapter 10 Externals/Auxiliary Mechanisms shows the copier's external parts, and
explains the principles used for the copier's various control
mechanisms in view of the functions of electrical and mechanical units
and in relation to their timing of operation. It also shows how these
units may be disassembled/assembled and adjusted.
Chapter 11 Systems explains connections and specifications related to systems
and shows how to disassemble and assemble them.
Chapter 12 Installation introduces requirements for the site of installation, and
shows how the copier may be installed using step-by-step instructions.
INTRODUCTION

ii
COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
Chapter 13 Maintenance and Servicing provides tables of periodically replaced
parts and consumables/durables and scheduled servicing charts.
Chapter 14 Troubleshooting provides tables of maintenance/inspection,
standards/adjustments, and problem identification (image fault/
malfunction).
Appendix contains a general timing chart and general circuit diagrams.
The descriptions in this Service Manual are subject to change without notice for
product improvement or other purposes, and major changes will be communicated in the
form of Service Information bulletins.
All service persons are expected to have a good understanding of the contents of this
Service Manual and all relevant Service Information bulletins, and be able to identify and
isolate faults in the machine.
For a full understanding of the copier, this Service Manual should be used side by side
with the separately available "Copier Basic Series." Refer to the descriptions in each of
the following volumes:
Volume 1
Volume 2
Volume 3
Volume 4
Volume 5
Volume 6
Volume 7

COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
iii
System Configuration
The copier may be configured with its accessories as follows:
nPick-Up/Delivery Accessories
[1] DADF-A1
[2] Finisher-C1
[3] Multi Output Tray C1
[4] Saddle Finisher C2
[5] Finisher-E1
[6] Cassette Feeding Unit-S1
[7] Cassette Feeding Unit-R1
[8] Paper Deck-B1
[3]
[2]
[5]
[8]
[4]
[6]
[7]
[1]

COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
iv
nSystem Accessories
[1] Handset-C1 [120V ONLY]
[2] Expansion Board Base Unit-C1
[3] SCSI Interface Board-D1
[4] Printer Board
[5] Super G3 FAX Board
[6] Battery Board-A1
* PDL I/F Board.
[1]
[5]
*
[4]
[3]
[2] [6]

COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
v
When Turning Off the Main Power Switch
Be sure always to turn off the main power switch and disconnect the power plug before starting
disassembly work. In addition,
1. When expanding the fax functions, the secondary battery used to retain fax memory images
will start to operate as soon as the main power switch is turned off. Be sure to complete any
work within one hour if the main power switch must be kept off. (Be sure also to keep the
machine powered at least for one week after installation.)
2. The communication memory lamp on the control panel indicates the presence/absence of fax
memory images. If it is on (indicating the presence of images), be sure to print out the images
before turning off the main power switch and disconnecting the power plug.
3. Turing off the control panel power switch will not remove power from some units. Be sure
always to turn off the main power switch before starting disassembly/assembly work.
4. The power will not be removed even when the front door is opened as long as the control panel
power switch and the main power switch are both on.
COPY FAX OPTIONS
Communication memory lamp
Control panel power switch
Main power lamp
Main power
switch
Cassette heater
switch

COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
vi
Connectors for the Pick-Up/Delivery Accessories
When connecting accessories, be sure to use the connectors indicates in the diagram. If, for
example, you connect the paper deck to the cassette pedestal connector and turn on the paper, the
fuse on the paper deck PCB will blow, at times requiring replacement with a new PCB.
For the Feeder
For the Paper deck
For the Cassette Feeding Unit
For the Finisher
Figure. Rear View of the Body

COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
vii
CONTENTS
CHAPTER 1 GENERAL DESCRIPTION
I. FEATURES ................................. 1-1
II. SPECIFICATIONS ......................1-2
A. Type .......................................1-2
B. Method................................... 1-2
C. Performance .......................... 1-3
D. Paper Deck-B1 ...................... 1-4
E. Others ....................................1-5
F. Default Ratios ........................ 1-6
G. Copying Speed ...................... 1-7
III. NAMES OF PARTS .................... 1-9
A. External view ......................... 1-9
B. Cross Section ...................... 1-11
IV. OPERATION .............................1-13
A. Turning On the Power ..........1-13
B. Control Panel ....................... 1-14
C. Special Features Modes ......1-15
D. Additional Functions ............ 1-16
V. ROUTINE MAINTENANCE BY
THE USER ...............................1-19
VI. SAFETY.................................... 1-20
A. Safety of Laser Light (CLASS 1
LASER PRODUCT) ............. 1-20
B. CDRH Regulations ..............1-21
C. Handling the Laser Unit .......1-22
D. Safety of Toner .....................1-24
VII. IMAGE FORMATION ................1-25
A. Outline .................................1-25
CHAPTER 2 BASIC OPERATION PROVIDES
I. BASIC OPERATION ................... 2-1
A. Functional Construction ......... 2-1
B. Outline of the Electrical
Circuitry .................................2-2
C. Sequence of Operations ........2-4
D. Main Motor (M1) Control
Circuit ....................................2-8
E. Inputs to and Outputs from
the Major PCBs ................... 2-10

viii
COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 4 IMAGE FORMATION SYSTEM
I. OUTLINE ....................................4-1
II.
ANALOG IMAGE PROCESSING . 4-3
A. Outline ................................... 4-3
B. CCD .......................................4-3
C. AE Processing
(ABC processing) .................. 4-4
D. A/D Conversion...................... 4-5
E. Analog Signal Processing
Block ......................................4-6
III.
DIGITAL IMAGE PROCESSING ... 4-7
A. Outline ................................... 4-7
CHAPTER 5 LASER EXPOSURE SYSTEM
I. OUTLINE ....................................5-1
II.
GENERATING THE BD SIGNAL .. 5-3
III. LASER DRIVER PCB .................5-5
A. Outline ................................... 5-5
B. Stabilizing the Laser Output .. 5-6
C. Switching the Laser Activation
Mode......................................5-7
D. Switching the Laser Output ...5-7
B. Shading Correction ................ 4-8
C. Total Processing ....................4-9
D. Density Processing ..............4-12
E. Binary Processing ............... 4-16
F. Image Memory.....................4-19
G. Overlay Copying .................. 4-21
IV. DISASSEMBLY/ASSEMBLY .....4-22
A. CCD Unit ............................. 4-23
B. IP PCB ................................. 4-24
C.
Replacing the ROM DIMM
(on the image processor PCB).
4-25
IV. CONTROLLING THE LASER
SCANNER MOTOR ....................5-8
A. Outline of Operations .............5-8
B. Turning On and Off the Laser
Scanner Motor ....................... 5-9
V. DISASSEMBLY/ASSEMBLY .....5-10
A. Laser Scanner Assembly ..... 5-11
CHAPTER 3 EXPOSURE SYSTEM
I. OUTLINE OF OPERATIONS ......3-1
A. Outline ................................... 3-1
B. Sequence of Operations
(original exposure system).....3-2
II. SCANNER DRIVE SYSTEM ...... 3-3
III. CONTROLLING THE SCANNING
LAMP .......................................... 3-4
A. Outline ................................... 3-4
B. Controlling the Pre-Heating
Mechanism ............................3-5
C. Turning On and Off the
Scanning Lamp...................... 3-5
D. Controlling the Intensity .........3-5
E. Detecting Errors..................... 3-6
IV. IDENTIFYING THE SIZE OF AN
ORIGINAL ..................................3-7
A. Outline ...................................3-7
B. Identifying the Size by the
Paper Sensors (1).................. 3-7
C. Identifying the Size by the
Paper Sensors (2).................. 3-9
D. Identifying the Size by the
Original Width/Length Sensor
of the Feeder ....................... 3-10
V. DISASSEMBLY/ASSEMBLY .....3-11
A. Scanning System................. 3-12
B. Scanner Drive Assembly ..... 3-13

COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
ix
CHAPTER 6 IMAGE FORMATION SYSTEM
I. OUTLINE OF IMAGE FORMATION
PROCESS .................................. 6-1
A. Outline ................................... 6-1
B. Sequence of Operations ........ 6-2
C. Controlling the Primary
Charging Roller Bias ..............6-3
D. Controlling the Transfer
Charging Roller Bias ..............6-8
E. Controlling the Separation
Static Eliminator Bias........... 6-12
F. Controlling the Transfer
Guide ...................................6-14
G. Primary Charging Roller
Cleaning Mechanism ........... 6-15
II. DEVELOPING ASSEMBLY ...... 6-16
A. Outline .................................6-16
B. Controlling the Developing
Bias......................................6-17
C. Controlling Toner Level
Detection .............................6-20
III. DRUM CLEANER ..................... 6-21
A. Outline .................................6-21
B. Detecting Waste Toner .........6-22
IV. DISASSEMBLY/ASSEMBLY .....6-23
A. Drum Unit ............................ 6-24
B. Transfer Charging Roller ......6-25
C. Drum Sensor Unit ................ 6-25
D. Magnet Plate .......................6-26
E. Primary Charging Roller
Cleaning Solenoid ............... 6-27
F. Developing Assembly .......... 6-28
CHAPTER 7 PICK-UP/FEEDING SYSTEM
I. OUTLINE OF OPERATIONS ......7-1
A. Outline ...................................7-1
B. Sequence of Operations
(pick-up from the cassette) ....7-4
C. Operation in Standby State . 7-16
D.
Detecting the Level of Paper . 7-18
E.
Identifying the Size of Paper .. 7-20
F. Multifeeder ...........................7-25
G. Controlling the Registration
Roller Clutch ........................7-27
H. Making Overlay Copies ........7-28
I. Operation .............................7-28
J. Delivery Assembly ...............7-40
K. Detecting Jams .................... 7-43
II. DISASSEMBLY/ASSEMBLY .....7-51
A. Pick-Up Assembly ................ 7-52
B. Multifeeder ........................... 7-55
C. Feeding Assembly ............... 7-58
D. Lower Feeding Assembly .....7-59
E.
Registration Roller Assembly .. 7-61
F. Delivery Assembly ............... 7-62
G. Lower Feeding Motor ...........7-66
H. Pick-Up Drive Assembly ......7-67
I. Vertical Path Assembly ........ 7-68
CHAPTER 8 PAPER DECK
I. PAPER DECK ............................8-1
A. Inputs to and Outputs from
the Deck Driver ...................... 8-1
B. Pick-Up .................................. 8-4
C. Detecting Paper ..................... 8-7
D. Deck Lifter .............................8-9
E. Opening/Closing the Deck
(compartment) .....................8-12
F. Controlling the Deck Motor ..8-14
II. DETECTING JAMS .................. 8-18
A. Outline ................................. 8-18
III. DISASSEMBLY/ASSEMBLY ..... 8-20
A. External Covers ................... 8-21
B. Paper Deck .......................... 8-24
C. Drive System ....................... 8-29
D. Feeding System ................... 8-36
E. Electrical System ................. 8-39

x
COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 9 FIXING SYSTEM
CHAPTER 10 EXTERNALS/AUXILIARY MECHANISMS
CHAPTER 11 SYSTEM INTEGRATION
I. OUTLINE OF OPERATIONS ......9-1
A. Outline ................................... 9-1
B. Fixing Drive Assembly ........... 9-3
C. Controlling the Fixing
Temperature ........................... 9-6
D. Protective Mechanism for the
Fixing System ......................9-10
E. Upper Fixing Roll Bias .........9-12
II. DISASSEMBLY/ASSEMBLY .....9-13
A. Fixing Assembly................... 9-14
B. Fixing Cleaner Assembly .....9-26
C. Fixing Assembly Inlet
Solenoid Assembly ..............9-28
D. Fixing Drive Assembly ......... 9-29
E. Fixing Cleaning Belt
Solenoid...............................9-29
I. CONTROL PANEL ................... 10-1
A. Outline .................................10-1
B. Operation .............................10-2
II. FANS ........................................10-4
A.
Arrangement and Functions .. 10-4
B. Sequence of Operations ......10-6
C. Detecting Errors (E805) .......10-9
III. POWER SUPPLY....................10-10
A. Outline of the Power Supply
System...............................10-10
B. Power Supply PCB ............10-11
C. Transition to and from Sleep
Mode..................................10-12
IV. COUNTERS ...........................10-14
A. Outline ...............................10-14
B. Operations of Counters ..... 10-16
V. DISASSEMBLY/ASSEMBLY ... 10-17
A. External Covers ................. 10-18
B. Removing the Front
Door/Inside Cover .............. 10-20
C. Control Panel ..................... 10-21
D. DC Controller PCB ............ 10-23
E. Composite Power Supply
PCB ................................... 10-24
F. Low-Voltage Power Supply
PCB ................................... 10-24
G. Accessories Power Supply
PCB ................................... 10-25
H. Fans ................................... 10-25
I. SYSTEM INTEGRATION .......... 11-1
A. Outline .................................11-1
II. SCSI INTERFACE BOARD ....... 11-4
A. Outline .................................11-4
B. Specifications ...................... 11-4
C. Hardware .............................11-6
III. DISASSEMBLY/ASSEMBLY ..... 11-7
A. Basic Expansion Kit .............11-8
B. SCSI Interface Board ......... 11-10
C. Battery Board ....................11-11

COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
xi
CHAPTER 12 INSTALLATION
I. SELECTING THE SITE ............ 12-1
II. UNPACKING AND
INSTALLATION ......................... 12-3
A. Unpacking and Removing
the Fixing Materials ............. 12-4
B. Supplying Toner ................... 12-7
C. Stirring the Toner ................. 12-9
D.
Setting the Drum Cartridge . 12-11
E. Setting the Cassette ..........12-14
F. Installing the Feeder (DADF
standard model only) .........12-16
G. Making Settings .................12-17
H.
Checking the Copy images.. 12-18
III.
RELOCATING THE MACHINE . 12-27
IV. INSTALLING THE CONTROL
CARD V .................................. 12-29
V. INSTALLING THE COPY DATA
CONTROLLER-A1 .................. 12-33
A. Copy Data Controller-A1....12-33
VI. INSTALLATION OF THE NE
CONTROLLER-A1 .................. 12-43
CHAPTER 13 MAINTENANCE AND SERVICING
I. PERIODICALLY REPLACED
PARTS ...................................... 13-1
II. CONSUMABLES AND
DURABLES ..............................13-1
A. Copier ..................................13-1
B. Paper Deck .......................... 13-2
III. SCHEDULED SERVICING
CHART .....................................13-3
IV. SCHEDULED SERVICING
TABLE ......................................13-5
A. Copier .................................. 13-5
B. Paper Deck .......................... 13-6
CHAPTER 14 TROUBLESHOOTING
I. MAINTENANCE AND
INSPECTION ............................14-3
A. Image Basic Adjustment
Procedure ............................14-3
B. Points of Scheduled
Servicing.............................. 14-4
II. STANDARDS AND
ADJUSTMENTS .......................14-5
A. Image Adjustment................ 14-5
B. Exposure System .............. 14-10
C. Image Formation System .. 14-13
D. Pick-Up/Feeding System ... 14-15
E. Fixing System ....................14-20
F. Electrical System ............... 14-22
III. TROUBLESHOOTING IMAGE
FAULTS ..................................14-33
A. Initial Checks ..................... 14-33
B. Sample Image Faults ......... 14-36
C. Troubleshooting Image
Faults .................................14-37
IV. TROUBLESHOOTING
MALFUNCTION ......................14-56
V. TROUBLESHOOTING
FEEDING PROBLEMS ......... 14-102
A. Paper Jams ...................... 14-102
B. Feeding Faults ................. 14-107
VI. ARRANGEMENT AND
FUNCTIONS OF ELECTRICAL
PARTS ..................................14-108
A. Clutches and Solenoids ... 14-108
B. Motors ..............................14-110
C. Fan ...................................14-112
D. Sensors ........................... 14-114
E. Switches and Counters ....14-116
F. PCBs ...............................14-118
G. Side Paper Deck ..............14-120
H. Variable Resisters,
Light-Emitting Diodes,
and Check Pins by PCB .. 14-124
VII. UPGRADING ........................ 14-131
A. Replacing the DIMM ........14-131
B. Downloading ....................14-134
VIII. SERVICE MODE .................. 14-137
A. Outline ............................. 14-137

xii
COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
B. DISPLAY Control Display
Mode................................14-143
C.
I/O Operation Check Mode .. 14-158
D.
ADJUST Adjustment Mode . 14-181
E. FUNCTION Operation
Check Mode ....................14-189
F. OPTION Settings Mode ...14-201
G. PG test Print .................... 14-209
H. COUNTER Mode ............. 14-214
I. FEEDER .......................... 14-217
J. SORTER
(finisher, saddle stitcher) ..14-221
IX. SELF DIAGNOSIS ................14-223
A. Copier ..............................14-225
B. DADF ............................... 14-231
C. Cassette Feeding
Unit-R1/S1 .......................14-232
D. Multi Output Tray-D1 ........ 14-232
E. Finisher-C1 ......................14-233
F. Saddle Finisher-C2 .......... 14-235
G. Finisher-E1 ......................14-239
H. Paper Deck-B1 ................14-241
I.
SCSI Interface Board-D1 ... 14-242
APPENDIX
A. GENERAL TIMING CHART ....... A-1
B. SIGNAL NAME/ABBREVIATION
LIST ........................................... A-3
C.
GENERAL CIRCUIT DIAGRAM ... A-7
D. SIDE PAPER DECK GENERAL
CIRCUIT DIAGRAM ................ A-13
E. SPECIAL TOOLS .................... A-15
F. SOLVENTS AND OILS ............ A-17

COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 1
GENERAL DESCRIPTION
I. FEATURES ................................. 1-1
II. SPECIFICATIONS ...................... 1-2
A. Type ....................................... 1-2
B. Method ...................................1-2
C. Performance ..........................1-3
D. Paper Deck-B1 ...................... 1-4
E. Others ....................................1-5
F. Default Ratios ........................1-6
G. Copying Speed ......................1-7
III. NAMES OF PARTS .................... 1-9
A. External view ......................... 1-9
B. Cross Section ......................1-11
IV. OPERATION .............................1-13
A. Turning On the Power ..........1-13
B. Control Panel .......................1-14
C. Special Features Modes ...... 1-15
D. Additional Functions ............1-16
V. ROUTINE MAINTENANCE BY
THE USER ............................... 1-19
VI. SAFETY .................................... 1-20
A. Safety of Laser Light (CLASS 1
LASER PRODUCT) ............. 1-20
B. CDRH Regulations .............. 1-21
C. Handling the Laser Unit ....... 1-22
D. Safety of Toner .....................1-24
VII. IMAGE FORMATION ................ 1-25
A. Outline ................................. 1-25

COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-1
CHAPTER 1 GENERAL DESCRIPITON
I. FEATURES
1. High-Speed, High-Image Quality
mCopy Speed:
405/400 40 ppm
335/330 33 ppm
mResolution
Read in copier mode 600 x 600 dpi
Write in copier mode 1200-equivalent x 600 dpi
In fax mode 600 x 600 dpi (hyper GENESIS smoothing)
mGradation 256
2. Large-Capacity Image Memory
mThe machine comes with a 32-MB image memory as standard, which may be expanded up
to 96 MB.
mThe use of an image memory has enabled making as many copies as needed with a single
scan of an original, significantly improving the efficiency of copying work.
3. New No-Stacking Duplexing Mechanism
mDouble-sided copies may be made without holding paper in the duplexing assembly,
helping to improve the efficiency of copying work. The mechanism can turn out a large
number of double-sided copies while limiting damage to the paper to a minimum.
4. Large-Capacity Paper Source
Adding accessories, the machine can be turned into a paper source holding as many as 5550
sheets.
m2 cassettes (front loading; standard) 500 x 2
mMultifeeder 50
mCassette Pedestal-S1 500 x 2
mPaper Deck-B1 3500 (A4, B5)
5. Saddle Finisher w/ Book Binding Mode/Saddle Finisher (accessory)
mThe saddle stitcher unit will prove its ability when producing booklets in book bind mode.
mThe finishers unit is capable of stapling/sorting a total of 100 sets (193.6 mm high; 1300
A4 sheets of 80 g/m2).
mThe finisher unit is capable of delivering as many as 50 sheets to the trays 1 through 3
(220.6 mm high; about 1500 sheets of 80 g/m2) and the interrupt tray.
mThe finisher unit is equipped with a job offset function to facilitate sorting work.
mThe buffer path function ensures that the host copier's productivity will not be affected by
the use of various finishing work.

CHAPTER 1 GENERAL DESCRIPITON
1-2
COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
II. SPECIFICATIONS
A. Type
B. Method
Item
Copier
Copyboard
Light source
Lens
Photosensitive medium
Specifications
Desktop
Fixed
Fluorescent lamp
Lens array
OPC drum
Item
Copying
Charging
Exposure
Copy density adjustment
Development
Pick-up
Transfer
Separation
Cleaning
Fixing
Specifications
Indirect electrostatic copying
Roller charging (AC + DC)
Laser exposure
Automatic or manual
Dry, single-component, toner projection
Cassette: Retard method (center reference)
Multifeeder: Dupro-method (center reference)
Roller charging (DC)
Static (static eliminator) + curvature
Cleaning blade
Heating roller

COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
1-3
CHAPTER 1 GENERAL DESCRIPITON
C. Performance
Resolution
Gradation
Original type
Maximum original size
AB
Inch
A
AB/Inch
Zoom
Auto
XY independent
zoom
Wait time (20°C)
First copy time
Continuous copying
Copying speed
Cassette
Multifeeder
Double-sided
Cassette
Multifeeder
Double-sided
Claw
General/
universal
600 x 600 dpi (reading)
600 x 600 dpi (during output; by smoothing, 200-equivalent x 600 dpi)
256 gradations
Sheet, book, 3-D object (2 kg max.)
A3 (297 x 420 mm)/297 x 432 mm (11"x17") max.
6R6E
5R5E
3R4E
6R6E
25% to 800% (in 1% increments)
Provided
Provided
From main power supply 77 sec or less
From sleep state 77 sec or less
From power save mode
Without recovery time 0 sec
-10% mode 9 sec or less
-25% mode 20 sec or less
-40% mode 33 sec or less
6.0 sec or less (topmost cassette, Direct, A4/LTR, auto density
adjustment, no pre-scanning)
1 to 999 copies
See Table 1-201.
A3 (297 x 420 mm)/297 x 432 mm (11"x17") to A5 (STMT)
A3 (297 x 420 mm)/297 x 432 mm (11"x17") to postcard
A3 (297 x 420 mm)/297 x 432 mm (11"x17") to A5 (STMT)
Plain paper, recycled paper, eco paper (64 to 80 g/m2)
Plain paper, recycled paper, eco paper, transparency, colored paper,
postcard, label, thick paper, tracing paper (64 to 128 g/m2)
Plain paper, recycled paper eco paper
Not used
500 sheets (average; of 80 g/m2)
Copy size
Copy size
Copy paper
type
Cassette
specifications

CHAPTER 1 GENERAL DESCRIPITON
1-4
COPYRIGHT © 1999 CANON INC. CANON imageRUNNER 400/330 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
D. Paper Deck-B1
Item
Pick-up
Paper holder
Copy paper type
Paper holding capacity
Serial number
Paper size switching
Dimensions
Weight
Power supply
Operating environment
Temperature
Humidity
Specifications
No claw (retard) method
Side tray method
 Plain paper (65 to 80 g/m2)
A4, B5, LTR
 Colored paper (Canon-recommended)
A4
385 mm high (3500 sheets of 80 g/m2)
A4 ZSKxxxxx
LTR ZSLxxxxx
Shifting the size guide plate and setting in service mode
(OPTION>ACC>DK-P)
(not including protrusions/grip cover, rail)
31 kg (approx.; body)/10 kg (approx.; rails)
By copier (DC power)
Same as copier
Multifeeder tray
Copy tray
Leading/
trailing edge
Left/right
Auto clear
Auto sleep time
Item
50 sheets
100 sheets
2.5 mm
2.5 mm
Provided
Provided
Non-image
width
Specifications
80 g/m2
80 g/m2
2 min standard; may be varied between 0 and
9 min.
10 min to 8 hr
The above specifications are subject to change for product improvement.
