PRISMAsync Controller
Black and White
Digital Production Press
Océ VarioPrint®135/120/110
Océ
PRISMAsync
Controller
Océ
PRISMAsync
Controller

Image Consistency
•True digital printing with Océ DirectPress technology
•600 x 2400 dpi, 1200 x 1200 dpi (Enhanced)*
•Océ ScreenPoint—Optimal quality, less operator intervention
•Superior front-to-back registration
Ease of Use
•Océ PRISMAsync™ Controller—Intuitive, easy-to-learn interface
•Océ Paper Logic for first-time-right output
•Synchronized settings across the entire system
•Advanced Job Management and Editing
•Easy integration into existing workflows—DPLink, KDKLink
Perfect-Fit System
•Up to 135/120/110 duplex ipm
•Post-process document insertion
•Full-bleed saddle finishing with Saddle Press Technology
•High-capacity Stacker
•Z-fold, C-fold, Accordion fold, Half-fold, Double-parallel fold
Sustainability
•
Ozone-free printing
•EPA ENERGY STAR®rated with lowest TEC value
in its class
•Reduced energy usage with Océ HeatXchange
•Smart energy usage with Océ EnergyLogic
Productivity
•Fast start-up with Océ EnergyLogic
•Plan-ahead production with intelligent job Scheduler
•Operator Attention Light** displays status so production
runs uninterrupted
•Maximum uptime with Printer Operation Care
•50-300gsm duplex, all trays
•Up to 8,600-sheet capacity
* Adobe®Postscript®3™
** Optional
2
Océ VarioPrint®135/120/110
Océ VarioPrint 135 Awarded Five Stars for Image Quality by Buyers Laboratory
The Océ VarioPrint 135 has been awarded a five-star rating for image quality, job submission, ease of use, and pre-
flight and job preparation by Buyers Laboratory Inc. The Océ VarioPrint 135 was subjected to intensive custom tests
consisting of 87,841 A4-sized impressions spanning 10 different media types. The press demonstrated a very high
level of performance across BLI’s extensive test suite. This is the first time a device has received a five-star rating
for image quality since BLI began the field testing of production units.
At-a-Glance

3
The solution designed for today's demands.
Imagine a new, highly stable technology that always delivers
consistent, quality images. A truly digital technology that doesn't
require high temperatures and electrical charges. A high-speed
production technology that produces zero ozone.
Introducing the Océ VarioPrint 135/120/110 series of monochrome
digital presses, pairing Océ DirectPress technology and PRISMAsync
operations management with Canon in-line finishing for a unified
solution that pushes print productivity even higher.
Also known as the Océ VarioPrint DP Line, these models are
based on the Océ DirectPress technology, a new, exceptionally
stable imaging technology that removes variables that can
negatively aect print quality and consistency. Combine this
with Canon in-line finishing for an end-to-end solution that
rewrites the rules for image consistency, intuitive operation,
system configurability, and performance uptime. It will help
you cut costs, reduce your environmental footprint, and expand
your capabilities and business opportunities. It simply redefines
excellence in black-and-white production printing.
Raising the bar on eciency, versatility, sustainability,
and image quality. Designed from the ground up to
deliver robust, reliable performance.
Redefining Excellence
An end-to-end solution providing:
Redefining Excellence
A unified, sustainable solution
designed for productivity and
profitability.
•Image consistency from job to job, machine to machine
•Ease of use with Océ PRISMAsync
•Perfect-fit system that provides speed, input, finishing,
and workflow configured for your needs
•Sustainability means lower environmental impact through
reduced energy consumption and ozone-free printing
•Optimal productivity via high system performance
and uptime
3

4
High production performance from one compact system
Customers want professional, finished documents, whether
they're simple booklets or complex manuals. The Océ VarioPrint
DP Line delivers, from preprinted inserting and high-capacity
stacking, folding, and punching to stapling, booklet-making,
and glue binding. All options can be integrated into one
end-to-end solution for hands-o production workflows
and quality documents that appeal to your customers.
Configurable workflow support
The Océ PRISMAsync controller and user interface can be set up
to meet your precise needs. Choose the processing modes that fit
your current workflow and add options as needed. Depending on
your production requirements, you can make the job Scheduler,
job editing, and DocBox functions available to operators. And
when your workflow requirements change or grow, additional
Océ PRISMA software modules can be added to increase system
performance and throughput.
From workflow solutions through printing and finishing, the
Océ VarioPrint DP Line delivers true digital production with
Océ DirectPress technology.
End-to-End Solutions
A complete workflow, from
start to finish, keeps you in
control of your business.
Easy integration with dierent workflows
The Océ VarioPrint DP Line is designed for full integration with
Océ PRISMA solutions to accelerate your workflow, reduce costs,
and attract more print volume. In mixed printing environments,
the Océ PRISMAsync controller provides options that let you run
jobs from Kodak® Smartboard and Xerox® FreeFlow® MakeReady
workflows, without losing job ticket settings or media attributes.
DirectPress technology
Traditional electrophotographic technology requires multiple
process steps. Océ DirectPress converts digital data into a toner
image in a single step, providing a uniform and stable image.
Océ DirectPress technology helps eliminate ozone emissions and,
through its use of a lower fusing temperature, Océ HeatXchange,
and Océ EnergyLogic, it helps reduce your business’ impact on
the environment. It’s a highly reliable technology, designed for
increased uptime in a compact footprint.
True End-to-End Solution

5
Stability and reliability
One of the hallmarks of professional-quality printing is text and
images that look and feel the same throughout every job, day
after day and run after run. The new Océ VarioPrint DP Line
uses Océ DirectPress technology to ensure consistent, high-
quality printing on a wide range of media. The result is predict-
able, oset-like output without streaks, striping, or banding—
work that satisfies customers and keeps them coming back.
Great output on a wide range of media
Océ DirectPress technology uses a low fusing temperature that
allows you to print on a wide range of media. The image is
pressed directly onto the paper, so you can use structured
or textured stock.
Advanced active registration
Duplex printed documents predominate today’s monochrome
print market, and customers know that tight registration is a
sign of quality printing. The Océ VarioPrint DP Line features an
intelligent, sensor-controlled process that enables tight front-
to-back registration. This helps ensure that you can handle the
high-visibility, quality-intensive jobs that your customers need.
Black and white in a colorful world
While most documents today are created in color, not all need to
print that way. But then not all black-and-white printers handle
color files well, either. The Océ VarioPrint DP Line uses Océ
ScreenPoint technology to reproduce color halftones and
photographs as grayscale images with excellent resolution, dense
black fills, and precise fine lines. Plus, you can adjust contrast and
control darkness and lightness, without sacrificing any detail, so
every image is sure to live up to your customers’ expectations.
Performance that makes every page a reflection of your business.
With the Océ VarioPrint DP Line, you can consistently produce high-quality
prints on a wide range of media across jobs, systems, and time.
Image Consistency
Océ DirectPress technology
helps ensure high-quality
printing on every job.
Image Consistency

6
Designed from the ground up for sustainable productivity.
The Océ VarioPrint DP Line’s innovative technologies deliver true
digital printing, energy eciency, and integrated workflow that
ramp up your business for profitability.
Designed for the Times
Booklet Trimmer Modules
Used with the Saddle-Stitch
Finisher to produce professional,
full-bleed booklets in-line.
Perfect Binder
Bind up to 400-page* book-blocks to
covers with hot glue, and trim three sides
for perfectly square, full-bleed books.
Folding Unit
In-line folding
Saddle-Stitch Finisher
Stitches up to 25 sheets,*
up to 13"x 19.2", for creation
of 100-page booklets.
V-fold up to five sheets
without saddle-stitching.
High-Capacity Stacker
Stack flat sheets professionally
and utilize a removable dolly
to transfer output to o-line
finishing or shipping departments.
C-fold Z-fold
Accordion fold Double-parallel fold

7
* 20 lb. Bond
**Optional
Document Insertion Unit
Enables insertion of color
covers and inserts.
Advanced Feeding Technologies
Air Suction and Air Separation features
provide reliable, accurate paper feeding,
similar to oset press printing.
Press Console
The award-winning Océ PRISMA
interface. Optimize productivity
with a high-performance server,
green-button ease of use, a
media-driven workflow, and up to
eight hours of production planning.
Océ ScreenPoint Technology
Optimizes the conversion of color
images to black and white and generates
smooth grayscale transitions.
Operator Attention Light**
Displays status of the press
in a convenient way, so the
operator quickly knows that
production is moving smoothly.
Paper Capacity
4,000-sheet* input is standard, with
the ability to scale up to 8,600 sheets.*
All trays accommodate all supported
media weights.
Océ HeatXchange
Printed sheets are
cooled and those
to-be-printed are
preheated in a single
process, reducing
energy consumption
by up to 30%. And already cooled
printed sheets help eliminate
curling and sticking for more
reliable finishing.
Océ DirectPress Technology
Converts digital data into a
toner image in a single step,
with no ozone emissions, fuser
oil, or developer, and virtually
no toner waste.
Océ EnergyLogic
Enables start up as soon as
sucient energy is available,
providing quick start-up. It also
helps ensure non-stop productivity
for mixed-weight jobs.
Océ
PRISMAsync
Controller
Océ
PRISMAsync
Controller
DirectPress
technology
DirectPress
technology
HeatXchange
technology
HeatXchange
technology
EnergyLogic
technology
EnergyLogic
technology

8
Operators get intuitive workflow for immediate control
and management of even the most complex jobs.
Built for user-friendly operation
Today’s customers expect better response and faster turnaround,
and the VarioPrint DP Line helps make this happen. The operator
panel combines the controller, user interface, and engine in one
integrated concept. Its large touch-screen interface makes buttons
a thing of the past, minimizing learning curves and reducing time
and money spent on training. With the intuitive, modular interface,
operators can perform a variety of functions eortlessly.
Ecient production management
PRISMAsync makes handling complex print jobs easy. The unique
user interface with intelligent job Scheduler displays every queued
job and an overview of the day’s work schedule. Jobs can be quickly
rearranged as your needs or priorities change. An intuitive, visual
interface groups jobs into a logical order by media type and displays
up-to-the minute completion status. Visible from a distance, the
Operator Attention Light displays the status of the printer. It signals
upcoming operator interventions, such as media and consumable
refills, giving you time to avoid interruptions in production.
Easy and ecient media handling
A customized, define-once media catalog drives your workflow
with all the printer settings needed to handle media consistently
and productively. Océ Paper Logic helps ensure correct media
loading, even with preprinted or prepunched stock, helping to
reduce errors and waste with first-time-right output.
Uniform, consistent operation
A single operating concept on all black-and-white and color
printers driven by Océ PRISMAsync simplifies job handling for
printing, scanning, and copying. This helps reduce training
requirements and increases productivity, because operators
can spend less time running the press and managing output,
allowing the production sta to be utilized more eectively.
Advanced job management and editing
With the optional DocBox, advanced document preparation and
editing at both the job and page levels can be managed from a
single point of control. This enables last-minute changes to a
document at the printer, without going back to prepress, thus
saving time and money.
Ease of Use
•Single point of control
•Intuitive, award-winning user
interface design
•State-of-the-art job and queue
management
•Advanced production planning—
up to eight hours
•Adobe PostScript 3, PDF 1.7,
PCL 6, XPS
•Advanced editing options at job
and page levels
•Uniform handling of copy, print,
and scan functions
Océ PRISMAsync Snapshot
8

Performance that fits
With duplex print speeds of up to 135, 120, and 110 images per
minute, the Océ VarioPrint DP Line can be easily configured to
meet your requirements for printing, scanning, paper input,
finishing options, and workflow. And no matter the speed,
automatic duplexing is available for all media up to 300gsm.
Use it to fit your needs from scanning to printing and intelligent
prepress to full, in-line production. Or, replace multiple existing
machines with a single, all-digital multipurpose production device.
Multiple scanning options
Monochrome and color scanning capabilities let you oer
services beyond black-and-white workflows. One-pass duplex
scanner options include Scan-to-File, Scan-to-USB, Scan-to-E-mail,
and Scan-to-DocBox, a repository of jobs that provides fast
storage and access to jobs that may need to be rerun at a later
date. Automated intelligence recognizes photo and text
elements on every page, so print quality can be adjusted
to deliver optimal results.
Versatile paper feed
Four standard paper trays are conveniently placed under the
engine, conserving valuable floor space. An optional four-tray
module expands capacity up to 8,600 sheets for hours of
unattended production and features air separation and suction
feed for productive, reliable feeding. The VarioPrint DP Line
oers automatic sheet-size detection in all trays and Océ Paper
Logic to help ensure correct orientation of every page. When
duplexing, intelligent sensors provide near-perfect registration
accuracy to help ensure a high-quality appearance.
Wide range of media
Every print provider wants to be able to use the widest possible
array of substrates. Yet many light production printers are not
able to run lighter or heavier-weight stocks eciently. The Océ
VarioPrint DP Line can accommodate substrates ranging from
14 lb. Bond to 110 lb. Cover (50—300gsm) in both the internal
and the external paper input modules.
Blend speed, input, finishing, and workflow to design
a system that’s the ideal match for your operation.
Perfect-Fit System
Streamlined functionality
A comprehensive and versatile range of modular, in-line finishing
options helps eliminate the need for costly, space-consuming
o-line equipment. The VarioPrint DP Line delivers labor-saving,
ecient finishing operations in a singular footprint.
Modules for saddle-stitching, stacking, folding, and in-line
trimming help you to produce and finish more jobs in-line,
without the need for operator intervention. This shortens the
time needed to complete a job and helps you to meet even
the tightest deadlines.
Perfect-Fit System
Versatility from input to output lets you configure a system
that fits your business and keeps you ahead of the pack.

Energy Efficient Technology
Unique Océ technologies lower your energy
consumption while providing efficient production
and a cleaner work environment.
Océ DirectPress Océ HeatXchange Océ EnergyLogic
Cleaner, greener, and ozone-free
The Océ VarioPrint DP Line is designed to lower your environ-
mental impact and help reduce consumption of energy and
resources. The streamlined printing process—with no electrical
charge used—provides a cleaner work environment, without
ozone emissions, selenium, fuser oil, or developer, and virtually
no toner waste or particle emissions. The result is a cleaner work
environment and approach to printing. It helps you stand out as
a responsible, environmentally sustainable business that can
attract more orders from environmentally-conscious customers.
The Océ VarioPrint DP Line helps reduce use of
resources and your environmental footprint while
staying strong, job after job.
Closing the energy loop
Océ HeatXchange makes clever use of energy by recycling the
heat used to fuse toner onto paper. Fusing heat from exiting
sheets is transferred to preheat sheets entering the print path. At
the same time, this cools the exiting sheets, helping to eliminate
sticking and curling, and prepares the sheets for finishing. By
reusing heat that would otherwise go to waste, energy consump-
tion is reduced by up to 30%. The low fusing temperatures also
allow the machine to run cooler, further reducing energy
consumption.
Smarter energy use
Océ EnergyLogic is a smart way of balancing required energy
for production with available energy. This provides a fast
first-print/copy-out time since the unit starts printing as soon
as sucient power is available. And for mixed media jobs, the
machine will not stop, only adjust the speed if needed. The result
is a little extra productivity every day, saving time as well as energy.
First-time-right output
Easy operation, reliable media handling, and Océ Paper Logic
are just some of the features that help reduce waste by ensuring
first-time-right prints.
Built to last
The Océ VarioPrint DP Line also makes better use of resources
in both manufacturing and daily use. Much of the steel used in
these systems is recycled and the main parts are designed to last
the life of the machine. This helps to conserve resources, reduce
waste, and limit the environmental impact of both logistics and
service. Customers who take advantage of the Printer Operation
Care program can also lower the carbon footprint associated
with service while increasing machine uptime.
The absence of lasers, LEDs, and associated components
helps reduce the number of parts required, lowers energy
requirements, and simplifies maintenance and service, thereby
increasing reliability and providing high system uptime.
Sustainability
DirectPress
technology
DirectPress
technology
HeatXchange
technology
HeatXchange
technology
EnergyLogic
technology
EnergyLogic
technology

Built to Perform Under Pressure
Designed from the ground up to deliver sustainability
and performance you can count on.
11
Consistent performance that lets you do more
While some systems almost grind to a halt when printing on
heavy media, the Océ VarioPrint DP Line adjusts for dierent-
weight media on the fly, so you can count on nonstop perfor-
mance with high print quality. Océ EnergyLogic measures the
fusing requirements of incoming media and adjusts the fusing
and print speed to match, so production can continue without
interruption for mixed media documents.
Start printing immediately
Océ EnergyLogic also enables the system to start printing
as soon as sucient power is available. The system gradually
accelerates until it's fully warmed up.
Intuitive workflow for nonstop productivity
Océ PRISMAsync provides intelligent job scheduling controls
for uninterrupted production and smooth workload planning.
The 15-inch, full-color, touch-screen operator panel provides full
control for scheduling, printing, scanning, copying, and even
advanced job editing. The display shows the complete production
schedule, indicating when each job will be finished. It also
provides color-coded alerts to inform operators of upcoming
requirements, such as toner or media refills, to help keep
production moving.
Take control of your press's uptime
No service call is the best service call. You can increase your
uptime by taking advantage of the Printer Operation Care
program. Requiring no training, this program allows operators
to replace certain parts themselves in an easy and secure way.
When service intervention is needed, an innovative service
concept helps ensure the shortest turnaround time.
Productive printing is more than just speed.
System availability, reliability, uptime, and
ecient media handling all play a part.
Productivity
Designed for success
The Océ VarioPrint DP Line is designed from the ground up to
deliver the robust, reliable performance needed in CRDs, in-plant
print shops, and busy printing businesses. Each model oers
powerful features and options that let you turn demanding,
time-sensitive jobs more easily and help keep your customers
coming back. No matter which versatile, durable model you
choose, the VarioPrint DP Line redefines excellence in black-
and-white printing.

Océ VarioPrint®135/120/110
Product Specifications
MAIN UNIT
Marking Engine
Technology: DirectPress
Print Resolution: Engine: 600 x 2400 dpi, 200 lpi
PCL: 600 x 600 dpi
Adobe PostScript 3: 1200 x 1200 dpi
(Enhanced), 600 x 2400 dpi
Simplex Print Speed
(ipm):
120/110/100 (Letter)
63/57/52 (11" x 17")
Duplex Print Speed
(ipm): 135/120/110 (Letter)
70/63/57 (11" x 17")
First-Copy-Out Time: 3.9 Seconds (Letter)
Paper Size
Minimum: See paper capacity for iPIM and ePIM
Maximum: 12.6" x 19.2"
Standard Paper
Capacity (iPIM):
4,000 Sheets (80gsm)
2 x Bulk Tray: 1,500 Sheets (Letter)
2 x Multisize Tray: 500 Sheets
from 5.5" x 7.17" to 12.6" x 19.2"*
Paper Weight: 14 lb. Bond to 110 lb. Cover
(50gsm to 300gsm) (All trays)
Duplex: Up to 300gsm (Maximum)
Feeding (iPIM): Roller-fed
Power Source: 208V/20A
Dimensions
(H x W x D):
56.3" x 44.5" x 30.1"
(1430mm x 1130mm x 765mm)
Weight: 579.8 lb. (263kg)
Toner Yield: 48,000 impressions**
Color Image Reader
(Includes Single-pass Duplex Document Feeder)
Capacity: 300 Sheets (80gsm)
Automatic Paper
Size Detection:
Statement, Letter, Legal, 11" x 17"
Custom Sizes (ADF): 5.5" x 5.04" to 17" x 12"
Resolution: Up to 600 x 600 dpi
Scanning Speed
BW/Color:
BW:
Up to 120 ipm (300 x 300 dpi)
Up to 100 ipm (600 x 600 dpi)
Color: Up to 105 ipm (600 x 300 dpi)
Up to 25 ipm (600 x 600 dpi)
Power Source: From Main Unit
INPUT ACCESSORIES
ePIM (Optional External Paper Input Module)
Feeding Technology: Air Separation, Suction-fed
Standard Paper
Capacity:
4,600 Sheets (80 gsm)
Tray 1/2: 600 Sheets
Tray 3/4: 1,700 Sheets
Acceptable Size: 8" x 8" to 12.6" x 19.2"
Paper Weight: 14 lb. Bond to 110 lb. Cover
(50gsm to 300gsm)
Power Source: 120V/15A
Dimensions
(H x W x D):
40.9" x 38.6" x 29.5"
(1040mm x 980mm x 750mm)
Weight: 440.9 lb. (200kg)
Document Insertion Unit-F1 (Optional)
Paper Capacity: 400 Sheets (200 x 2) (20 lb. Bond)
Paper Size: 13” x 19.2” (Maximum)
Paper Weight: 14 lb. Bond to 110 lb. Cover
(50gsm to 300gsm)
Dimensions
(H x W x D):
55.37” x 29.37” x 31.25”
(1407mm x 746mm x 793mm)
Weight: 134 lb. (61kg)
Power Source: 120V/15A
FINISHING ACCESSORIES
Finisher-AF1/Saddle Finisher-AF2 (Optional)
Number of Trays: 2/3
Top Tray Capacity: Up to 3,000 Sheets (20 lb. Bond)
Lower Tray Capacity: Up to 2,000 Sheets (20 lb. Bond)
Saddle-Stitch Tray: 30 Booklets or Limitless
Staple Positions: Corner-Stapling, Double-Stapling
Paper Weight
Saddle Finisher: 14 lb. Bond to 110 lb. Cover
(50gsm to 300gsm)
Paper Size
Stapling: Executive, Letter-R, Letter, Legal, 11" x 17"
Sheet Stacking: Up to 13" x 19.2"
Saddle Finisher: Letter-R, Legal, 11" x 17",
12" x 18", custom sizes up to 13" x 19.2"
Stapling Capacity: Up to 100 Sheets (Letter, Maximum)
Booklet Stapling
Capacity: Up to 25 Sheets, Saddle-Stitched
Dimensions
(H x W x D):
46.5" x 31.25" x 35.37"
(1180mm x 800mm x 792mm)
Weight
Finisher: 287 lb. (130kg)
Saddle Finisher: 396 lb. (180kg)
Power Source: 120V/15A
Puncher Unit-BQ1
(Option for Finisher-AF1/Saddle Finisher-AF2)
Paper Weight: 14 lb. Bond to 73 lb. Cover
(50gsm to 200gsm)
Paper Size
2-Hole: Legal, Letter-R
3-Hole: 11" x 17", Letter, Executive
Punch Speed: Up to 135 ppm
(Depends on Speed of Marking Engine)
Weight: 6.7 lb. (3kg)
Power Source: From Finisher
High-Capacity Stacker-E1 (Optional)
Offset Stack Capacity: 10,000 Sheets (Letter) (20 lb. Bond)
Top Tray Capacity: 1,000 Sheets (20 lb. Bond)
Paper Size: 13" x 19.2" (Maximum)
Paper Weight: 14 lb. Bond to 110 lb. Cover
(50gsm to 300gsm)
Max. Connectivity: Up to 2 Units at Once
Dimensions
(H x W x D):
53.62" x 39.25" x 31.25"
(1362mm x 997mm x 792mm)
Weight: 463 lb. (210kg)
Power Source: 120V/15A
Booklet Trimmer-D1 (Optional)
Margin Trimming: Fore-Edge Trim
Trim Amount: 0.08" to 0.78" (2mm to 20mm)
Trim Thickness: 100 Sheets
Waste Tray Capacity: 1 ,500 Sheets with 0.78" trim (20 lb. Bond)
Paper Weight: 14 lb. Bond to 110 lb. Cover
(50gsm to 300gsm)
Output Tray Capacity: 30 Booklets
Dimensions
(H x W x D):
41" x 62" x 30.37"
(1040mm x 1575mm x 770mm)
Weight: 335 lb. (152kg)
Power Source: From Saddle Finisher
Two-Knife Trimmer-A1 (Optional)
Margin Trimming: Top and Bottom Trim
Trim Amount: 0.08" to 0.59" (2mm to 15mm)
Trim Thickness: 100 Sheets
Waste Tray Capacity: 750 Sheets (Two-sided Trimmed)
Paper Weight: 14 lb. Bond to 110 lb. Cover
(50gsm to 300gsm)
Output Tray Capacity: 30 Booklets
Dimensions
(H x W x D):
41" x 21.12" x 30.37"
(1040mm x 536mm x 770mm)
Weight: 319 lb. (145kg)
Power Source: 120V/15A
Perfect Binder-C1 (Optional)
Cutting Method: Stack Rotation 3-Direction
or 1-Direction Cut
Finished Book Width: 8" to 11.62" (203mm x 297mm)
Finished Book Length: 5.37" to 8.5" (138mm x 216mm)
(After 3-Direction Cut)
Body Paper Weight: 14 lb. Bond to 90 lb. Index
(50gsm to 163gsm)
Cover Weight: 24 lb. Bond to 110 lb. Cover
(90gsm to 300gsm)
Book Thickness: 10 to 200 Sheets (20 lb. Bond) (Up to 25mm)
Glue Warm-Up Time: 440 Seconds
Trim Range: Adjustable in .0197" (0.5mm) Increments
Side: 0.26" to 1.94" (6.5mm to 49mm)
Top and Bottom: 0.52" to 3.11" (13mm to 79mm)
Dimensions
(H x W x D):
51.25" x 36.97" x 31.12"
(1300mm x 922mm x 791mm)
Weight: 675 lb. (306kg)
Power Source: 208V/15A
Paper Folding Unit-F1 (Optional)
Double Parallel Fold: Legal, Letter-R
C/Accordion Fold: Letter-R
Z-Fold: 11" x 17"
Supported Media
Weights:
14 lb. Bond to 28 lb. Bond
(50gsm to 105gsm)
Power Source: From Finisher
Dimensions
(H x W x D):
46.87" x 13.25" x 31.25"
(1190mm x 336mm x 793mm)
Weight: 157 lb. (71kg)
*Tray 3: Maximum size up to 12.6" x 18".
** Estimated yield based on Letter pages at 6% coverage.
Canon Business Solutions
Sales • Service • Supplies
1-800-815-4000
solutions.canon.com
As an ENERGY STAR®Partner, Canon U.S.A., Inc. has determined that these products meet the ENERGY STAR®guidelines for energy
efficiency. ENERGY STAR and the ENERGY STAR mark are registered U.S. marks. Océ is a registered trademark owned by Océ
Technologies B.V. PANTONE®and other PANTONE®, LLC trademarks are the property of PANTONE®, LLC. CANON, IMAGERUNNER,
and the GENUINE logo are registered trademarks of Canon Inc. in the United States and may also be registered trademarks or trade-
marks in other countries. IMAGEANYWARE is a trademark of Canon. All other referenced product names and marks are trademarks
of their respective owners and are hereby acknowledged. Some items may not be available at this time; please check for availability.
Specifications and availability subject to change without notice. All output is simulated.
©2012 Canon U.S.A., Inc. All rights reserved.
0164W988
0212R2-135/120/110-10M-LIH
