Canon PIXMA MP620 series Manual

Hardware Setup
Follow setup instruction on pages 2-8 of the Getting Started Guide
Wireless LAN Setup
Before starting please locate and write down your access point settings:
Network Name (also called SSID):
Network password (if applicable):
1345
2
Use the Easy-Scroll Wheel (A) or the
or button to select Settings,
then press the OK button.
Select Device
settings, then press
the OK button.
Select LAN settings,
then press the OK
button.
Select Change
wireless/wired, then
press the OK button.
Select Wireless LAN
active, then press the
OK button.
USB
23
1
Turn on the computer, then
insert the Setup CD-ROM into
the CD-ROM drive.
Connect one end of the USB cable
to the computer and the other to the
machine.
Make sure the machine is turned on.
Double-click the Setup icon.
If the CD-ROM folder does
not open automatically,
double-click the CANON_IJ
icon on the desktop.
4
Canon
(A)
Makesure to read this manual before using the machine. Please keep it in hand for future reference.
Getting Started
=Read Me First=
series
Photo All-In-One
3
1
2
For USB, Wired LAN and all Windows connections see Getting Started Guide.
PIXMA MP620
Macintosh Wireless Setup
Driver/Software Install
For information on setup when printing from multiple
computers, see the Getting Started Guide.
Enter your Administrator
Name and Password.
Click OK.
If you do not know your
administrator name or
password, click .
ame
k
continue

Click Easy Install. Click Restart.
When computer restarts, Canon IJ
Network Tool starts automatically.
Follow on-screen instructions.
a. On the Canon IJ Network Tool
screen, select LAN connection
b. Click OK
a. Select Setup in the drop down menu
b. Select MP620 series in Printers
c. Click OK
a. Turn off the printer
b. Disconnect the USB cable and
place the printer where it will be used
c. Turn the printer back on
d. Click Next
a. When the Access Points screen
appears, select an access point (SSID)
b. Enter your Network Password
(if applicable)
c. Click Connect
3
4A
Driver/Software Install
For Users With One Access Point
For Users With Multiple Access Points (Wireless Routers) Proceed to Section 4B
1
3
2
4
continued...
576
Proceed to section 5

Proceed to section 5
Click Manual Setup
a. Enter the Network Name (SSID) that
you would like the printer to join
b. Choose your Encryption Method
from the drop down menu
c. Click Connect
a. Check the Authentication Type
b. Click Next
a. Enter your Passphrase
b. Click Next
Check the settings and click Finish Click Connect
4BFor Users With Multiple Access Points
(For example: AirPort Extreme AND Time Capsule)
a. On the Canon IJ Network Tool
screen, select LAN connection
b. Click OK
a. Select Setup in the drop down menu
b. Select MP620 series in Printers
c. Click OK
13
45
7
6
8 9
2
a. Turn off the printer
b. Disconnect the USB cable and
place the printer where it will be used
c. Turn the printer back on
d. Click Next

Proceed to page 56 of the Getting Started
Guide, “Loading Paper”
Apple, AirPort Extreme, Macintosh and Time Capsule are
trademarks of Apple, Inc., registered in the U.S. and other
countries.
To check whether the
new location is better,
click Remeasurement.
Measurement of the
communication status is
performed again.
Confirm the measurement results,
then click Finish.
Ensure that is displayed in
Connection performance between
the printer and the access point.
The Printer Setup Utility and Canon
IJ Network Scanner Selector will
start up.
On the Connection Performance
Measurement dialog box, click
Next.
a. Wait for a while, then select
Canon MP620 series
b. Click Add
The alphanumeric string after Canon
MP620 series is the machine's MAC
address.
If the machine has not been detected,
make sure of the following.
The machine is turned on.–
The firewall function of any security–
software is turned off.
Wireless LAN Connection: The–
computer is connected to the access
point.
The machine is not set to use access–
control (MAC address filtering).
a. Confirm that a check mark
is displayed
b. Click Exit to close the dialog
box
a. On the Canon IJ Network
Scanner Selector screen
select Canon MP620
series Network in TWAIN
Data Source Name and the
MAC address of the machine
in Network Device List
b. Click Apply to use the
machine as a scanner
Measure Wireless Performance
Complete the Setup
Getting Help from Canon
Visit www.canontechsupport.com
Call 1-800-828-4040
Monday - Friday (excluding holidays), during the warranty period
