Getting Your Multifunction
Back On Your Network
After A Router Or Network Change
PIXMA MX860
Windows OS
1

If any of the following situations exist, you will need to
Uninstall and Re-Install the MP Drivers
•You have replaced your Router or Access Point
•You want to use a different wireless network
•Router settings have been changed.
2
<< Previous Next >>

<< Previous Next >>
Uninstalling and Re-installing Your Multifunction
to Your Network
PIXMA MX860
Windows OS
Uninstalling the Multifunction Drivers 4
Preparing to Connect My Multifunction to My Network 6
Network Requirements 6
Important Information You Need Before Adding Your Multifunction 7
Preparing Your Multifunction 8
Downloading & Installing the Drivers 11
Downloading the Driver 11
Installing the Driver 13
Setup the Machine and the Computer 15
3

Note: Login as a user with Administrator privileges to uninstall . Turn off any programs running in the background, such as
antivirus programs and firewalls before beginning.
Uninstalling the Multifunction Drivers << Previous Next >>
4
1. Select 'Program' (for Windows 2000), or 'All
Programs' (for Windows XP / Vista / 7) from the Start
menu.
2. Select the name of the printer model to remove and
select 'MP Drivers Uninstaller.‘

3. When the MP Drivers Uninstaller window is
displayed, click 'Execute.‘
Uninstalling the Multifunction Drivers << Previous Next >>
5
4. When the confirmation window is displayed, click
'Yes.'
5. When the Uninstallation Complete window is
displayed, click 'Complete.'

Network Requirements
Before connecting the machine to the network, make sure that configuration of the computer and access point or router is
complete, and that the computer is connected to the network.
Notes on Network Connection
•The configuration, router functions, setup procedures and security settings of the network device vary depending on your
system environment. For details, refer to your device's instruction manual or contact its manufacturer.
•The machine cannot be used over a wireless and wired connection at the same time.
Wireless Connection
Connect to your network environment over a wireless connection.
Preparing to Connect My Multifunction
To My Network
6
<< Previous Next >>

Preparing to Connect My Multifunction
To My Network
Be sure to prepare an access point.
Important Information You Need Before Adding Your Multifunction
The following information is required to connect to your access point or router.
•Access Point Name/Network Name:
Also referred to as SSID. A name to identify the specific access point.
•Network Key:
Also referred to as encryption key, WEP key or WPA/WPA2 passphrase, Pre-Shared key.
A password is required to prevent unauthorized access to communication.
Check your access point or router for the following information, and then write it down.
NOTE: For details on how to check the following information, refer to the manual of your access point or router, or contact its manufacturer.
An "Ad-hoc connection,"which establishes a direct
connection to the computer over a wireless connection
without using an access point, is not supported.
7
<< Previous Next >>

Preparing Your Multifunction
Preparing Your Multifunction
Note : The procedures below are for Wireless LAN setups not using the WPS (Wi-Fi Protected Setup)or WCN (Windows Connect Now) setup
methods
At this point the USB cable should not be connected between the computer and printer.
8
Step One
Press the Menu button (A).
Step Two
Use the or button to select Settings, then press the
OK button.
<< Previous Next >>

Preparing Your Multifunction
9
Step Three
Select Device settings, then press the OK button.
Step Four
Select LAN settings, then press the OK button.
<< Previous Next >>

Preparing Your Multifunction
10
Step Seven
Press the On button to turn off the printer. Connect the USB
cable to the printer and computer
Step Five
Select Change wireless / wired, then press the OK
button.
Step Six
Select Wireless LAN active, then press the OK button.
<< Previous Next >>

Downloading and Installing the Drivers
Downloading the Driver
To use the machine by connecting it to a computer, software including the drivers needs to be copied (installed) to the computer's hard disk. The
installation process takes about 20 minutes. (The installation time varies depending on the computer environment or the number of applications
to be installed.)
11
Step One
Go to the Canon USA Download Library
Click here to go MX860 download library page
Step Two
In the Drivers / Software Selection section, select
your operating system in the Select OS dropdown menu.
<< Previous Next >>

Downloading and Installing the Drivers
12
Step Three
In the Drivers section, click the link* (red printing) for the MP
Driver for Network
Step Four
On the next screen, read the information and instructions and
click I Agree - Begin Download
Once the file has been downloaded, double-click it to begin the
installation process
IMPORTANT:
•Quit all running applications before installation.
•Log on as the administrator (or a member of the
Administrators group).
•Do not switch users during the installation process.
•Internet connection may be required during the installation.
Connection fees apply.
•It may be necessary to restart your computer during the
installation process. Follow the on-screen instructions. The
installation resumes once your computer has restarted.
If the firewall function of your security software is turned on, a
warning message may appear that Canon software is
attempting to access the network. If such a warning message
appears, set the security software to always allow access.
<< Previous Next >>
NOTE: The driver names will vary based on operating
system (OS) selected. Make sure you have selected the
correct OS and select the driver that states “for Network.”

Step One
Click Easy Install.
Step Two
Click Install.
Installing the Driver
NOTE: If a User Account Control screen appears, click Continue or Yes (depending on Windows version) to continue.
NOTE: If the same screen reappears in subsequent steps, click Continue or Yes.
Downloading and Installing the Drivers
13
<< Previous Next >>

Step Four
Click Yes on the License Agreement.
If the Please Allow All Install Wizard Processes screen appears, click
Next.
Installation starts. Follow any on-screen instructions to install the
software.
Step Three
Select Use the Printer on network and click Next.
Downloading and Installing the Drivers
14
<< Previous Next >>

Step Two
When the Printer Connection screen appears, connect the
machine to the computer with a USB cable, then turn on the
machine.
Set up the machine over a USB connection until the network
connection is complete.
Step One
On the Setup Method screen, select Connect printer to
the network for the first time, then click Next.
Setup the Machine and the Computer
Downloading and Installing the Drivers
15
<< Previous Next >>

Step Four
Detect Access Point.
When the Access Points screen appears, select an access point to use,
then click Connect.
When an access point is detected automatically, the Access Points
screen does not appear. Go to step 5.
To connect to the access point with WEP or WPA displayed in the
Encryption column, enter the network key (WEP key or WPA key) in
Network Key, then click Connect.
Step Three
When the Setup Preparations dialog box appears,
confirm that preparation is complete, then click Next.
16
Downloading and Installing the Drivers << Previous Next >>

Step Six (Windows XP/2000 Only)
When the Network Setup of the Card Slot dialog box appears,
specify the drive letter, then click Next.
Step Five
Detect the Machine
When the Set Printer IP Address screen appears, click
Connect.
If the machine is detected automatically, the Set Printer
IP Address screen does not appear.
17
Downloading and Installing the Drivers << Previous Next >>

Step Eight
Turn off the machine, place the machine in the location where
you will use it, and turn it back on again.
Step Seven
When the Setup Completion dialog box appears, remove
the USB cable, then click Next.
18
Downloading and Installing the Drivers << Previous Next >>

Step Ten
Confirm the measurement results, then click Finish.
Ensure that is displayed in Connection performance between the printer and the
access point
If any symbol other than is displayed, refer to displayed comments and Help for
improving the status of communication link.
To check whether the new location is better, click Remeasurement. Measurement of
the communication status is performed again.
When any message on Overall network performance appears in the measurement
results, rearrange the printer and other network devices following the instructions on
the screen.
Step Nine
On the Connection Performance Measurement screen,
click Next.
Measuring of the communication status starts, and the
results are displayed.
Measuring takes a few minutes. You can cancel
measuring by clicking Cancel. You also examine the
detailed status of the communication link after setup by
using the Canon IJ Network Tool.
19
Downloading and Installing the Drivers << Previous Next >>

Step Eleven
Click Exit. Setup is complete
