Canon MV700i User manual

Your technical bit.
DIGITAL CAMCORDERS
Our technical bit.
REC

Technology
made simple.
AS EASY AS 1, 2, 3
MV700 series camcorders have
an ergonomic design that fits
comfortably in your hand, putting
total control at your fingertips.
Operation is made easy thanks
to the large viewfinder and bright,
2.5" LCD.
An 8-language menu option
even lets you choose your
preferred language, making
navigation simple and letting
you personalise your camcorder
even further. Choose from
English, French, German, Italian,
Spanish, Russian, Chinese
and Japanese.
TECHNICALLY SPEAKING, IT’S BRILLIANT
The MV700 series is exactly what you need for recording,
playing and editing, with a vast array of new technology
helping you to get the very best out of your movie-making.
DIGIC DV provides superior images while new sound
technology gives crystal-clear audio. One-touch controls
make all this technology available instantly, while a
REC end-search feature remembers where you stopped
recording, so previously recorded precious footage need
never be lost.
The MV700 series. Slim, stylish and easy to use.
Wouldn’t it be great to have fantastic technology and sleek design in one?
Just think of what you could do with a camcorder that has all the latest
high-tech gadgetry but is low-tech to use. A camcorder that lets you record
home movies at the touch of a button and send them to friends and family.
With outstanding technology, stunning looks, a metal finish and a shape
that’s slim enough to fit into any bag, the MV700 series lets you do just that.

With up to 22x zoom, the MV700
series lets you get even closer to
your family and friends. Developed
over 60 years, it’s one of the best
zooms on the market, allowing you
to capture outstanding detail without
having to get in close yourself.
With an 800,000 pixel CCD combined with DIGIC DV,
image resolution is razor-sharp. All MV700 series models
have an Image Stabilizer to reduce camera shake.
For stunning panoramic clips you can use the optional
wide-angle accessory. So now you’ve read the fine detail,
you’re ready to make some great films.
STOP AND LISTEN
The MV700 series’ sound technology matches its imaging
technology, with newly-designed AIF4 bringing superb
aural clarity to your movie masterpieces.
Normal
Zoom mode 22x
It’s all in the detail.
Wide angle using 0.6x wide attachment

A mode for every mood.
Whatever mood the weather’s in (or you’re in for that matter), MV700 camcorders
have a mode for it. Whether you’re shooting at night, in the pitch black or even in
sand or snow, you can shoot with complete confidence.
SUPER NIGHT MODE
Super Night Mode (only available with
the MV750i) means you can capture
colours in the pitch black, so even if
you can’t see, the camera can.
SKIN MODE
Skin Mode picks up the tone of skin and gives a
more soft-focus feel. Skin looks more delicate and
marks or wrinkles are less noticeable.
NIGHT MODE
Night Mode means you can shoot
great colours at night –the camcorder
automatically adjusting to the darkness.
EXTENDED MOTION
JPEG RECORDING
You can record up to 60-minute
long Motion JPEG recordings and
store them to MultiMedia or
SD Memory card (only available
in MV750i and MV730i models).
SIMULTANEOUS DIGITAL
STILL RECORDING
Not all your recordings have to be
full-length epics. The MV700 series
lets you capture digital stills and store
them to MultiMedia or SD Memory card
at the same time as you’re shooting
a video (only available in MV750i and
MV730i models).
DIGITAL ANIMATION MIX
If you want to be more adventurous,
try Digital Animation Mix Mode, where
you can mix live image recordings with
animation (only available in MV750i
and MV730i models).

When it comes to unveiling your movie masterpiece, it couldn’t be simpler.
Whether you show it on the camcorder itself, on TV or even on the net, the
MV700 series lets you do it all.
Play, Print, Send.
WHAT’S ON TV TONIGHT?
You are. This is your premiere and everyone’s invited.
Just connect the S-Video lead from your camera to
your TV and you can begin. No fiddling with knobs
and switches, and no tuning-in either.
GET CONNECTED
IEEE1394 connectivity gives you a direct connection to
your PC, so downloading award-winning recordings of
your children is a lot easier than getting them to
behave. You can also convert analogue movies to
digital and vice-versa –so converting your old VHS
tapes is simple. Once they’re converted you can save
them onto DVD’s or a PC. DV Messenger software
allows MV700 series camcorders to function as
webcams, so you can get face-to-face with your
friends even if you’re in different countries.
PRINT, SAVE, SEND
Printing digital stills is completely straightforward. All
you do is connect to a Canon printer (or any PictBridge
compatible printer), select the image you want and print.
Sending Motion JPEGs via the Internet couldn’t be easier
either –just connect, download and send. You can even
transfer movies from miniDV tape to Multimedia or SD
Memory card.

There’s more. Much more.
A vast range of MV700 series accessories means that when it comes to
extending your movie-making range, you’re spoilt for choice.
CG-570
Battery Charger
WD-30.5
0.7x Wide-Converter
FS-30.5U
ND8 Filter,
Protector Filter Set
TL-30.5
1.9x Tele-Converter
CA-570
Charger Adaptor
CB-570
Car Battery Cable
BP-508
Battery Pack
8MB
SD Memory Card
(Only with MV750i
and MV730i)
Software:
• ZoomBrowser EX (for Windows)
• ImageBrowser (for Macintosh)
• DV Messenger2
(Only with MV750i and MV730i)
WA-30.5
Wide Attachment
(Only with MV750i)
WL-D82A
Wireless Controller
(Only with MV750i
and MV730i)
SC-2000
Soft Case
BP-514
Battery Pack
BP-522
Battery Pack
BP-535
Battery Pack

Specifications MV750i / MV730i / MV700i / MV700
MV750i MV730i MV700i MV700
VIDEO SYSTEM MiniDV MiniDV MiniDV MiniDV
CCD
Type 1/6" 1/6" 1/6" 1/6"
Total pixels 800,000 800,000 800,000 800,000
Effective pixels Movie 400,000 400,000 400,000 400,000
Effective pixels Still 528,000 528,000 N/A N/A
Filter Complementary Complementary Complementary Complementary
LENS
Optical/Digital Zoom 22x/440x 20x/400x 18x/360x 18x/360x
Focal length movie 2.8-61.6mm 2.8-56mm 2.8-54mm 2.8-54mm
Focal length still 2.8-61.6mm 2.8-56mm N/A N/A
Maximum aperture f/1.6 f/1.6 f/1.6 f/1.6
Minimum focusing distance 10mm 10mm 10mm 10mm
Image Stabilizer YES YES YES YES
Filter diameter 30.5mm 30.5mm 30.5mm 30.5mm
LCD
View screen/pixels 2,5"/112,000 2,5"/112,000 2,5"/112,000 2,5"/112,000
Manual adjustment Brightness, audio volume Brightness, audio volume Brightness, audio volume Brightness, audio volume
Multi image screen YES YES YES YES
VIEWFINDER 0.33", CL 113,000 0.33", CL 113,000 0.33", CL 113,000 0.33", CL 113,000
MIN.ILLUMINATION 0 lux (in Super Night Mode) 2 lux (in Night Mode) 2 lux (in Night Mode) 2 lux (in Night Mode)
NIGHT MODE YES (Super Night Mode) YES YES YES
FOCUS
Auto/Manual YES YES YES YES
AE MODE
Program AE 10 8 8 8
Full auto, Auto, Sports, Portrait, Spotlight, Full auto, Auto, Sports, Portrait, Spotlight, Full auto, Auto, Sports, Portrait, Spotlight, Full auto, Auto, Sports, Portrait, Spotlight,
Sand and snow, Low light, Night Mode, Sand and snow, Low light, Night Mode Sand and snow, Low light, Night Mode Sand and snow, Low light, Night Mode
Night+ Mode, Super Night Mode
Backlight compensation Manual Control Manual Control Manual Control Manual Control
WHITE BALANCE TTL TTL TTL TTL
Auto YES YES YES YES
Set/Preset YES YES YES YES
SHUTTER SPEED
Maximum 1/2,000 sec. 1/2,000 sec. 1/2,000 sec. 1/2,000 sec.
Slow 1/6 sec. 1/6 sec. 1/6 sec. 1/6 sec.
DIGITAL EFFECT Art, Sepia, Monotone, Mosaic, Colors, Mirror, Art, Sepia, Monotone, Mosaic, Colors, Mirror, Art, Sepia, Monotone, Mosaic, Colors, Mirror, Art, Sepia, Monotone, Mosaic, Colors, Mirror,
Ball, Cube, Wave, Auto fade, Wipe fade, Ball, Cube, Wave, Auto fade, Wipe fade, Ball, Cube, Wave, Auto fade, Wipe fade, Ball, Cube, Wave, Auto fade, Wipe fade,
Flip fade, Corners fade, Tide fade, Puzzle Flip fade, Corners fade, Tide fade, Puzzle Flip fade, Corners fade, Tide fade, Puzzle Flip fade, Corners fade, Tide fade, Puzzle
fade, Beam fade, Zigzag fade, Jump fade fade, Beam fade, Zigzag fade, Jump fade fade, Beam fade, Zigzag fade, Jump fade fade, Beam fade, Zigzag fade, Jump fade
STILL IMAGE 1024x768 (XGA), (Progressive Photo) 1024x768 (XGA), (Progressive Photo) NO NO
Simultaneous Photo Recording YES YES NO NO
Selecting AF Frame Function YES YES NO NO
Photo Button YES YES NO NO
SELF TIMER YES YES YES YES
REC REVIEW/REC SEARCH YES YES YES YES
LP MODE YES YES YES YES
SEARCH
Still image YES YES YES YES
Date YES YES YES YES
MEMORY CARD
MMC YES YES NO NO
SD YES YES NO NO
Movie REC. Motion JPEG Motion JPEG NO NO
AUDIO
System PCM Digital Stereo PCM Digital Stereo PCM Digital Stereo PCM Digital Stereo
16bit-48kHz 2ch 16bit-48kHz 2ch 16bit-48kHz 2ch 16bit-48kHz 2ch
12bit-32kHz 4ch 12bit-32kHz 4ch 12bit-32kHz 4ch 12bit-32kHz 4ch
Audio Dubbing YES YES NO NO
TERMINAL
Headphone YES YES YES YES
USB YES YES NO NO
DV YES out/in YES out/in YES out/in YES out
Direct Print (USB) PictBridge PictBridge NO NO
Analogue-in YES YES YES NO
AV YES YES YES YES
S-video YES NO NO NO
ACC SHOE YES YES YES YES
PC CONNECTION KIT
USB cable YES YES NO NO
DIGITAL VIDEO SOLUTION DISK
USB Driver (Vender specific class) YES YES NO NO
ZoomBrowser EX (for Windows) YES YES NO NO
ImageBrowser (for Macintosh) YES YES NO NO
PhotoStitch YES YES NO NO
DV NETWORK SOLUTION DISK
DV Messenger YES YES NO NO
IEEE1394 file transfer YES YES NO NO
WIRELESS CONTROLLER WL-D82A WL-D82A NO NO
ANALOGUE DIGITAL CONVERTER YES YES YES NO
BUILT-IN CHARGER YES YES YES YES
BATTERY PACK
Type Li-ion Li-ion Li-ion Li-ion
Longer recording time (EVF) BP-535 BP-535 BP-535 BP-535
(using above optional long life BP) 11h45m 11h45m 11h45m 11h45m
DIMENSIONS
(WxHxD) 53.0x95.0x139.0mm 53.0x95.0x139.0mm 53.0x95.0x139.0mm 53.0x95.0x139.0mm
Weight 490g 490g 490g 490g
Some images are simulated for clarity of reproduction. All data is based on Canon’s standard testing methods. This leaflet and the specifications of the product have been developed prior to the date of product launch.
Final specifications are subject to change without notice. ™ and ®: All company and/or product names are trademarks and/or registered trademarks of their respective manufacturers in their markets and/or countries.
Take On the World!
Create A New Digital Imaging World.
Canon (UK) Ltd
Woodhatch
Reigate,
Surrey RH2 8BF
T: 08705 143 723
www.canon.co.uk
Canon Inc
www.canon.com
Canon Europa NV
www.canon-europe.com
0041W304 © Canon Europa NV 2004
