Canon LEGRIA HF R706 User manual

PUB. DIE-0488-000
HD Camcorder
Instruction Manual
R

2
Important Usage Instructions
WARNING
TO REDUCE THE RISK OF ELECTRIC SHOCKAND TO REDUCE ANNOYING INTERFER-
ENCE, USE THE RECOMMENDED ACCESSORIESONLY.
COPYRIGHT WARNING:
Unauthorized recording of copyrighted materialsmay infringe on the rightsof copyright own-
ersand be contrary to copyright laws.
Trademark Acknowledgements
•SD, SDHC and SDXC Logosare trademarks of SD-3C, LLC.
•Microsoft and Windowsare trademarks or registered trademarks of Microsoft Corporation in the United
Statesand/or other countries.
• App Store, iPad, iPhone, iTunesand Mac OSare trademarks of Apple Inc., registered in the U.S. and
other countries.
• HDMI, the HDMI logo and High-Definition Multimedia Interface are trade-
marks or registered trademarks of HDMI Licensing LLC in the United States
and other countries.
• “AVCHD”, “AVCHD Progressive” and the “AVCHD Progressive” logo are
trademarks of Panasonic Corporation and Sony Corporation.
• Google, Android, Google Play, YouTube are trademarks of Google Inc.
• Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
• Facebookisa registered trademarkof Facebook, Inc.
•IOSisa trademarkor registered trademarkof Cisco in the U.S. and other
countriesand isused under license.
• The Twitter name and marks are trademarks of Twitter, Inc.
•Wi-Fiisa registered trademarkof the Wi-Fi Alliance.
• Wi-Fi Certified, WPA, WPA2, and the Wi-Fi Certified logo are trademarks of the Wi-Fi Alliance.
•WPSasused on the camcorder’ssettings, onscreen displaysand in thismanual signifiesWi-Fi Pro-
tected Setup.
• The Wi-Fi Protected Setup Identifier Markisa markof the Wi-Fi Alliance.
•TheN-Markisa trademarkor registered trademarkof NFC Forum, Inc. in the United Statesand in other
countries.
•FlashAir isa trademarkof Toshiba Corporation.
•Othernamesand productsnot mentioned above may be trademarks or registered trademarks of their
respective companies.

3
•Thisdevice incorporatesexFAT technology licensed from Microsoft.
• “Full HD 1080” refersto Canon camcorderscompliant with high-definition video com-
posed of 1,080 vertical pixels(scanning lines).
•Thisproduct islicensed under AT&T patentsfor the MPEG-4 standard and may be
used for encoding MPEG-4 compliant video and/or decoding MPEG-4 compliant
video that wasencoded only (1) for a personal and non-commercial purpose or (2) by a video provider
licensed under the AT&T patentsto provide MPEG-4 compliant video. No license isgranted or implied
for any other use for MPEG-4 standard.

4
About thisManual and Camcorder
Thankyou for purchasing the Canon LEGRIA HF R78 / LEGRIA HF R77 /
LEGRIA HF R76 / LEGRIA HF R706. Please read thismanual carefully
before you use the camcorder and retain it for future reference. Should
your camcorder fail to operate correctly, refer to
Troubleshooting
(
A 248).
ConventionsUsed in thisManual
• The following termsare used in thismanual:
RWhen not specified as“memory card” or “built-in mem-
ory”, the term “memory” by itself refersto both.
“Scene” refersto one movie unit recorded with a single recording
operation.
Important precautionsrelated to the camcorder’sopera-
tion.
Additional notesand topicsthat complement the basic
operating procedures.
Restrictions, requirementsor preconditionsregarding the
function described.
AReference page number within thismanual.
RText that appliesonly to the model(s) shown in the icon.
>Thisarrow isused to abbreviate menu selections. For a
detailed explanation on how to use the menus, refer to
Using the Menus(A41).

5
•Brackets[ ] are used to refer to onscreen controlsyou need to touch
(menus, buttons, etc.) and to messagesasthey are displayed on the
screen.
•Thephotosincluded in thismanual are simulated picturestaken with
a still camera. Unless indicated otherwise, illustrationsand menu
iconsrefer to the T.
•Illustrationsof the camcorder’sscreen or a computer’sscreen
included in thismanual may show only relevant partsof the screen.
•Navigation buttons:The navigation bar at the bottom of the page
offersup to four buttonsto let you get quickly to the information you
want to find.
Jump to the general table of contents.
Go to a list of select functionsgrouped by their usesin real-
life situations. Thisalternative index can be very useful for
beginnerswho encounter a particular challenge but are not
sure of what function to use.
Jump to the alphabetical index.
The button with a number in it will take you to the beginning
of the current chapter, where you will find an overview of the
information and related functionscovered in that chapter.
Note that the icon itself will change depending on the chapter
you are currently reading.

6
•Observe the following precautionswhile the camcorder’s
ACCESS indicator ison or flashing. Failing to do so may result
in permanent data loss or damage to the memory.
- Do not open the memory card slot cover.
-Donotdisconnect the power source or turn off the cam-
corder.
- Do not change the camcorder’sshooting mode.
-Donotpress the ^button.
-WhenaUSB cable isconnected to the camcorder, do not
disconnect the USB cable.

7
Table of Contents
