Canon BP-110 Datasheet

Battery BP-110 Using Instruction
Take Canon camera LEGRIA HF R26 for example
1. How to use
(1).Take BP-110 battery out from package (as Picture 1), then put it into camera (as
Picture 2)
(Picture1) (Picture2)
(2). Press the power button of the camera to switch it on (as Picture 3). The camera will
display that the battery could not be connected (as Picture 4). Select “yes” to continue.
(3). There’s no power indicator because the battery is not full-decoded (as picture 5).
But it will not affect the use of the battery.

(Picture3) (Picture4) (Picture5)
2．How to charge
There’re two ways to charge this battery.
1. Use the specified charger to charge the battery;
2. Charge the battery directly in camera with AC power cord.
1)Connect AC power cord to the 5.3V charging port.
(As Picture 6)
2)In the process of charging, the camera’s CHG LED turns red and keeps on
flickering.
charging status:○→●→○→●→○→●(As Picture 7)

3)When the battery is full-charged, the CHG LED turns off. (As Picture 8)
(Picture 7) (Picture 8)
(Picture 6)
