Canon VFL-2 User manual

PUB. DIM-0914-000
Canon
t::\7~79 'J ~.J. 91' I'
Video Flash Light
Torche Video et Flash
Video-Blitzleuchte
Antorcha de video can flash
Flash-Luce Video
*~~mIAJ*~l

8-------;:...........-
§B6O)tcI:~~
• 75~Y.:l
• 5":./7 (t::7';t5-11--)
• l\lil.lb1"111tH':;
• IRAAJ'L
• ~;mlA-1~T
Bezeichnung der Teile
•Blitz
•GIOhlampe (Videoleuchte)
•Schuhverriegelung
•KOhlschlitze
•POWER-Schalter
.itj:~f$
• 1A]7'tJT
• m'E! (mf~*T)
• tfil~H!Ji;Efll.
.. tM:ML
.. ~im!*~
Names of parts
•Flash
•Lamp (video light)
•Shoe lock
•Cooling vent
•POWER switch
Nombres de partes
•Flash
•
Ulmpara (antorcha de video)
•Segura
de zapata
•Salida
de ventilaci6n
•Selector
POWER
Noms des parties
•Flash
•Lampe (torche video)
•Bague
de verrouillage du socle
•Orifice
de ventilation
•Interrupteur d'alimentation
POWER
Nomenclatura delle parti
•Flash
•Lampada (video)
•Serratura del'attaco
•Bocchetta di raffreddamento
•Selettore
POWER
o
-ON
-AUTO
<OFF)

The Canon Video Flash Light VFL-2 can be attached to a
Canon camcorder and used
as avideo light or as an
external flash. The Video Flash Light is powered by the
camcorder's power supply.
Video light: Use to record
movies or still images. The video light can be turned
on
manually, or set to detect the surrounding brightness and
turn on/off automatically as necessary.
Flash: Use to record
still images. Automatic flash according to the brightness of
the subject, Red-eye reduction flash and other flash
modes are available depending
on the camcorder's
settings.
The video flash light can be used with the HF10/HF100
after you update the camcorder's firmware. Visit your local
Canon Web site for details.
~, .
. ,~
Manl
ADVANCED SHOE
This accessory is designed for camcorders with a
mini advanced shoe.
•When recording aclose subject, the shadow of the
camcorder may appear
on the subject even if the video
light
is used.
•Available flash modes and flash operation vary depending
on the camcorder. Refer to the instruction manual of your
camcorder.
Handling Precautions
•Do not fire the flash if there is dust or foreign matters on the
light-emitting window of the flash. The heat generated may
damage the Video Flash Light.
•Do not carry the camcorder by the attached Video Flash
Light.
•
Do not apply excessive force to the bottom surface of the
Video Flash Light.
Danger
• Do not fire the flash at aperson who is driving.
•
Do not place flammable materials in close proximity to or
touching the lamp or the surrounding parts during or
immediately after use; they become very hot.
•
Do not disassemble or modify the Video Flash Light.
Refer all servicing to qualified service personnel.
•
Do not subject the Video Flash Light to strong impacts.
•Do not short-circuit by inserting metal objects into the
Video Flash Light or the shoe terminals.
• Do not store or use the Video Flash Light in places
exposed to smoke, soot, sand or dust. Avoid also humid
places. such as shower rooms.
•Keep the Video Flash Light out of the reach of children.
Caution
•Keep the cooling vents open and uncovered.
•Do not expose the front glass or lamp
to water when they
are hot. The glass may break and cause injuries.
•Always detach the Video Flash Light when storing the
camcorder in acase.
•Do not fire the flash close to someone's eyes. Keep a
distance of at least 1 m from the subject, especially when
shooting children.
•Do not fire the flash with your hand covering the flash and
do not touch the flash immediately after use.
•
Do not look directly at the lamp while the video light is on.

t::::'7~?-{ t'l:- ~ (e)
*~~~~c5Y7~BnC~*9o
ON : J~~JLJ*9o
AUTO: lffil<teI:.QCEli1!(l\JIC:,¢lnL.J. Bjj.Q<teI:.Qc§i1!(l\JIC:;l!jn~*go
OFF : J~nLJ*ttfvo
Video Light Mode (e )
The video light can be turned on/off using the switch on the
Video Flash Light.
[ON] The video light stays on.
[AUTO]: The video light turns on/off automatically according to
the surrounding brightness.
[OFF]: The video light stays off.
Mode torche video (e)
La torche video peut etre allumee/eteinte avec I'interrupteur
sur la torche video et flash.
[ON] :la torche video reste allumee.
[AUTO] :la torche video s'allume/s'eteint automatiquement
selon la luminosite ambiante.
[OFF] :la torche video reste eteinte.
Videoleuchtenmodus (e)
Die Videoleuchte lasst sich Ober den Schalter an der Video-
Blitzleuchte ein-/ausschalten.
[ON]: Die Videoleuchte bleibt eingeschaltet.
[AUTO]: Die Videoleuchte schaltet sich je nach
Umgebungshelligkeit automatisch ein und aus.
[OFF]: Die Videoleuchte bleibt ausgeschaltet.
Modo de antorcha de video (e)
La antorcha de video puede encenderse/apagarse
utilizando el interruptor
enla antorcha de video con flash.
[ON]: La antocha
de vldeopermanece encendida.
[AUTO]: La antorcha
de video se enciende/apaga
automaticamente
de acuerdo con la luz ambiente.
[OFF]: La antorcha
de video permanece apagada.
Modalita lampada video (e)
EPQssibile attivare/disattivare la lampada video utilizzando
I'apposito interruttore.
[ON): La
lampada video rimane accesa.
[AUTO]: La lampada video si accende/spegne automaticamente
in base allivello di illuminazione circostante.
[OFF] La lampada video rimane spenta.
m1t~Jm~ (e )
ffl~~~*~L~H~~~H/~m~~o
[ONl( H): mfj~nHo
[AUTOl( filM): mf~HH&t@FcJIJHt-J~fifili;IJtHf /~~ 0
[OFF]( ~I~): mftlJT~I~ 0
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for aclass Bdigital device, pursuant
to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference
in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used
in accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no
guarantee that interference will not occur in aparticular
installation.
Do not make any changes or modifications to the equipment
unless otherwise specified
in the manual. If such changes or
modifications should be made, you could be required to stop
operation of the equipment.
This Class Bdigital apparatus complies with Canadian
ICES-003
Cet appareil numerique
de la classe Best conforme a la
norme NMB-003 du Canada.

Attaching the Video Flash Light
Fixation de la torche video et flash
Anbringen der Video-Blitzleuchte
Fijacion de la antorcha de video con flash
Collegamento del flash/luce video
~~~~i.q:7Hl
OOOONiO.O
3
0Q.~
ON. -AUTO
<QIT> <QID
,
C CANON INC. 2009

1 Turn off the camcorder.
2 Set the Video Flash Light's POWER switch to [OFF].
3 Wait until the Video Flash Light has cooled down and turn the shoe
lock in the opposite direction from the LOCK arrow.
4 Remove the Video Flash Light.
Wait until the Video Flash Light has cooled down before you store it
in its pouch.
Maintenance
•Make sure that the Video Flash Light has cooled down before
cleaning
it.
•Wipe the Video Flash Light clean with asoft, dry cloth. Do not use
thinner, benzine, alcohol or other volatile solvents.
•Dirty terminals may cause apoor contact. Always keep the terminals
clean, and wipe them with asoft, dry cloth before use.
Specifications
Video Light:
Illumination angle:
Color temperature:
Required lamp:
Flash:
Guide No.:
Flash life:
Common:
Operating temperature:
Dimensions:
Weight:
Power consumption:
Approx.20°
3,000 K
5.7 V, 3 W
Approx. 15
Approx. 2,400 flash discharges
o°C - 40°C (32 -104 OF)
36 x88 x65 mm
(1.4 x3.5 x2.6 in.)
76 g(2.7 oz.)
3.5 W(Flash)
3.3 W(Video light)
Weight and dimensions are approximate. Errors and omissions
excepted. Subject to change without notice.
