Canon EXTENDER EF 2.0x Instruction Manual

EXTENDER EF 2x
REF.NO. C54-3781
PARTS
CATALOG

REF.No.C54-3781 EXTENDER EF2X
P A R T S L I S T Pg.3
NEW PARTS NO. CLASS QTY DESCRIPTION PAGE
CA1-7777-000 C 1 MOUNT, BODY 1
CA1-7780-000 E 1 INTERLOCK, LENS MOTOR 1
CA2-4583-000 D 1 CONTACT ASS'Y 2
CA2-4586-000 E 2 SCREW 2
CA4-4877-000 D 1 BARREL, LENS 2
CA4-4877-001 D 1 BARREL, LENS 2
CA4-4877-060 D 1 BARREL, LENS 2
CA4-4878-000(XXX) E 1 RING, SNAP 2
CA4-4879-000(XXX) E 1 RING, SNAP 2
CA4-4880-000(XXX) E 1 RING, SNAP 2
CA4-4881-000(XXX) E 1 RING, SNAP 2
CA4-4882-000 D 1 COLLAR, ASS'Y 2
CA4-4883-000 D 1 RING, PROTECTOR 2
CA4-4887-000 E 1 HOLDER, SW LEVER 1
CA4-4889-000 D 1 KNOB, UNLOCK 1
CA4-4890-000 D 1 FRAME, UNLOCK KNOB 1
CA4-4891-000 D 1 SLEEVE, NAME 1
CA4-4892-000 D 1 COVER, BACK 2
CA4-4893-020 E 3 SCREW 1
CA4-4894-000 E 4 PIN, GUIDE 1
CA4-4895-000 E 1 SPRING, COIL 1
CA4-5205-000 D 1 PIN, UNLOCK KNOB 1
CF1-1968-000 E 1 CONTACT INTERLOCK 1
CG9-5196-000 D 1 BARREL, MAIN 1
CP5-0145-000 E 1 LENS, G3/4/5 2
CS1-7601-000 D 1 SPRING, MOUNT 1
CY1-2178-000(XXX) E 1 WASHER, MOUNT 1
CY1-2247-000 D 1 CONTACT ASS'Y 1
CY1-2561-000(XXX) E 1 MOUNT, LENS 2
CY1-2709-000 E 1 LENS, G3/4/5 2
CY1-2748-000 C 1 LENS, G1 2
CY1-2749-000 E 1 LENS, G2 2
CY1-2750-000 E 1 LENS, G6 2
CY1-2751-000 D 1 LENS, G7 2
X91-2024-900 4 SCREW, CROSS-RECESS, PH 1
XA1-1200-559 3 SCREW, CROSS-RECESS, PH 1
XA1-6200-509 3 SCREW, MACHINE M2X5 1
XA1-7200-506 4 SCREW, CROSS-RECESS, PH 1
XA4-7170-359 3 SCREW, CROSS-RECESS, PH 1
XA4-7170-559 2 SCREW, CROSS-RECESS, PH 1
Y11-3701-000 LEAD(WHITE) 1
Y11-3706-000 LEAD(ORANGE) 1
Y11-3707-000 LEAD(YELLOW) 1
Y11-3709-000 LEAD(GREEN) 1
Y11-3711-000 LEAD(BLUE) 1
Y11-4402-000 LEAD(BLACK) 1
Y11-4403-000 LEAD(RED) 1
