Canon EF-S35MM F/2.8 MACRO IS STM User manual

Instructions
EF-S35mm f/2.8 MACRO IS STM
ENG

ENG-1
Thank you for purchasing a Canon product.
The Canon EF-S35mm f/2.8 MACRO IS
STM is a macro lens for use with EF-S lens
compatible EOS cameras*. It is equipped
with an Image Stabilizer capable of shooting
portraits, scenery, and other normal shots
as well as close-up (macro) shots with a
magnication ratio of 1:1.
* ThelenscanonlybeusedwithcompatibleEOS
cameras.Forcompatibilityinformation,please
checkthecamera’sinstructionmanual,product
catalogortheCanonwebsite.
 “IS”standsforImageStabilizer.
 “STM”standsforsteppingmotor.
Camera Firmware
 Pleaseusethelatestversionofrmwarewiththe
camerainuse.Fordetailsonwhetherthermwareis
thelatestversionornot,andfordetailsonupdatingthe
rmware,pleasechecktheCanonwebsite.
Conventions used in this instruction
 Warningtopreventlensorcameramalfunction
ordamage.
 Supplementarynotesonusingthelensand
takingpictures.

ENG-2
Precautionstoensurethatthecameraisused
safely.Readtheseprecautionsthoroughly.Make
surealldetailsareobservedinordertoprevent
risksandinjurytotheuserandotherpeople.
Warning Detailspertainingtorisksthatmay
resultindeathorseriousinjury.
 Do not look at the sun or a bright light source
through the lens or single-lens reflex camera.
Doingsocouldresultinlossofvision.Lookingatthe
sundirectlythroughthelensisespeciallyhazardous.
 Whether it is attached to the camera or not, do
not leave the lens under the sun without the
lens cap attached.Thisistopreventthelensfrom
concentratingthesun’srays,whichcouldcauseare.
Caution Detailspertainingtorisksthatmay
resultininjury.
 Do not hold the Macro Lites located on the front
of the lens close to the eyes or stare at them when
they are illuminated. Doingsomayresultineye
damage.
 Do not leave the camera in locations subject to
high or low temperatures. Thismayresultinthe
camerabecomingexcessivelyhotorcold,whichmay
causeburnsorotherinjurieswhentouched.
Caution Detailspertainingtorisksthatmay
resultindamagetoproperty.
 Donotleavethelensinexcessiveheatsuchasina
carindirectsunlight.Hightemperaturescancausethe
lenstomalfunction.
Safety Precautions

ENG-3
General Precautions
Handling Precautions
 Ifthelensistakenfromacoldenvironmentintoa
warmone,condensationmaydeveloponthelens
surfaceandinternalparts.Topreventcondensationin
thiscase,rstputthelensintoanairtightplasticbag
beforetakingitfromacoldtowarmenvironment.Then
takeoutthelensafterithaswarmedgradually.Dothe
samewhentakingthelensfromawarmenvironment
intoacoldone.
 Pleasealsoreadanylensrelatedhandlingprecautions
listedinyourcamera’sinstructionmanual.
Shooting Precautions
 Notethattherearecasesinwhichthewhiteringon
thefrontofthelensmaybereectedintophotographs
ifthelensisheldclosetoreectiveobjects(glass
surfaceonwristwatches,forexample),evenifthe
MacroLitesarenotilluminated.Thiscanbeavoidedby
attachingthehoodwhentakingphotographs.

ENG-4
Shooting Precautions
Thislensusesasteppingmotortodrivethefocusinglens.
1. Initial focus lens resetting operations
Thelensperformsaninitialresetofthefocuslenswhenthecameraisswitchedon.Whenthelensisattached
tothefollowingcameras*,aninitialresetwillbeperformed,aswhenoperationisresumedfromanautopower
offstate.
 Thelenswillmoveinandoutoffocusduringinitialreset.
2. Lens sleep mode
WhenthecameraisON,thelenswillenterthesleepmodeinordertoconservepowerifitisnotoperatedfor
acertainperiodoftime.Thelenswillalsoconstantlybeinthesleepmodewhenthecamera’sautopoweroff
functionisineffect.Thefocuslenswillnotbeoperatedwhenthelensisinthesleepmode.
 Focusingbyrotatingthefocusingringisnotpossiblewhenthelensisinthesleepmode.
Toexitsleepmode,presstheshutterbuttonhalfway.
* Applicabletothefollowingcameras:
EOS7DMarkII,
EOS7D,EOS70D,EOS60D,EOS60Da,EOS50D,EOS40D,EOS30D,EOS20D,EOS20Da,
EOSREBELT3i/600D,EOSREBELT2i/550D,EOSREBELT1i/500D,EOSREBELXSi/450D,EOSREBELT5/1200D,
EOSREBELT3/1100D,EOSREBELXS/1000D,EOSDIGITALREBELXTi/400DDIGITAL,EOSDIGITALREBEL
XT/350DDIGITAL,EOSDIGITALREBEL/300DDIGITAL
General Precautions

ENG-5
ThisdevicecomplieswithPart15oftheFCCRules.
Operationissubjecttothefollowingtwoconditions:(1)This
devicemaynotcauseharmfulinterference,and(2)this
devicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperation.
Donotmakeanychangesormodicationstotheequipment
unlessotherwisespeciedintheinstructions.Ifsuch
changesormodicationsshouldbemade,youcouldbe
requiredtostopoperationoftheequipment.
Thisequipmenthasbeentestedandfoundtocomplywith
thelimitsforaclassBdigitaldevice,pursuanttopart15
oftheFCCRules.Theselimitsaredesignedtoprovide
reasonableprotectionagainstharmfulinterferenceina
residentialinstallation.Thisequipmentgenerates,usesand
canradiateradiofrequencyenergyand,ifnotinstalledand
usedinaccordancewiththeinstructions,maycauseharmful
interferencetoradiocommunications.
However,thereisnoguaranteethatinterferencewillnot
occurinaparticularinstallation.Ifthisequipmentdoes
causeharmfulinterferencetoradioortelevisionreception,
whichcanbedeterminedbyturningtheequipmentoffand
on,theuserisencouragedtotrytocorrecttheinterference
byoneormoreofthefollowingmeasures:
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheequipmentand
receiver.
•Connecttheequipmentintoanoutletonacircuitdifferent
fromthattowhichthereceiverisconnected.
•Consultthedealeroranexperiencedradio/TVtechnician
forhelp.
CANICES-3(B)/NMB-3(B)

ENG-6
MacroLiteB(→12)
Contacts(→7)
Hoodmount(→15)
Focusingring(→7)
MacroLiteA(→12)
Focusmodeswitch(→7)
Imagestabilizerswitch(→8)
Lensmountindex(→7)
MacroLiteONbutton(→12)
 Fordetailedinformation,referencepagenumbersareprovidedinparentheses(→**).
Nomenclature

ENG-7
See your camera’s instructions for details on
mounting and detaching the lens.
 Afterdetachingthelens,placethelenswith
therearenduptopreventthelenssurfaceand
contactsfromgettingscratched.
 Contactsthatarescratched,soiled,orhave
ngerprintsonthemmayresultinfaulty
connectionsorcorrosion,whichmayleadto
malfunctions.Ifthecontactsgetsoiled,clean
themwithasoftcloth.
 Attachthelenscapanddustcapwhen
disconnectingthelens.Whenattachingthe
dustcap,alignthelensmountindexwiththe
indexofthedustcapandrotateinaclockwise
directionasshownintheillustration.Followthe
reverseproceduretodetachit.
Toshootinautofocus(AF)mode,setthefocus
modeswitchtoAF.
Touseonlymanualfocusing(MF),setthefocus
modeswitchtoMF,andfocusbyturningthe
focusingring.
 Quicklyrotatingthefocusingringmayresultin
delayedfocus.
 Focusingbyrotatingthefocusingringisnot
possiblewhenthecameraisOFF.
WhenAFoperationissetto[ONESHOT],manual
focusispossibleafterautofocusinghasbeen
completedbycontinuingtopresstheshutterbutton
halfway(Full-timemanualfocus).
Therearetimeswhencamerasettingchangesare
required.
Mounting and
Detaching the Lens
1
Setting the Focus Mode
2

ENG-8
YoucanusetheImageStabilizerinAForMF
mode.
Also,theImageStabilizerprovidesimage
stabilizationdependingonshootingconditions
(suchasshootingstillsubjects,followingshots,
andclose-ups(macro)).
1Set the STABILIZER switch to ON.
 Ifyouarenotgoingtousetheimagestabilizer
function,settheswitchtoOFF.
2 When you press the shutter button halfway,
the Image Stabilizer will start operating.
 Makesuretheimageintheviewnderisstable,
thenpresstheshutterbuttontherestoftheway
downtotakethepicture.
Image Stabilizer
3
 T heshorterthesubjectdistancefromthecamera,
thelessertheImageStabilizereffectwillbe.
 TheImageStabilizercannotcompensatefora
blurredshotcausedbyasubjectthatmoved.
 T
heImageStabilizermaynotbefullyeffectiveifyoushoot
fromaviolentlyshakingvehicleorothertransportation.
 T heImageStabilizerconsumesmorepowerwhen
setatONthannormalshootingatOFF,resulting
infewershotsandashortermovieshootingtime.
 Whenshootingastillsubject,itcompensatesfor
camerashakeinalldirections.
 Itcompensatesforverticalcamerashakeduring
followingshotsinahorizontaldirection,and
compensatesforhorizontalcamerashakeduring
followingshotsinaverticaldirection.
 Whenyouuseatripod,theImageStabilizer
shouldbeturnedofftosavebatterypower.
 E
venwithamonopod,theImageStabilizerwillbe
aseffectiveasduringhand-heldshooting.However,
dependingontheshootingconditions,therearecasesin
whichtheImageStabilizereffectmaybelesseffective.
 T heimagestabilizerfunctionalsooperateswhenthe
lensisusedwithanextensiontubeEF12IIorEF25II.
 TheImageStabilizerwilloperateevenwhenyou
pressthebuttonassignedtotheAFfunctionwith
thecamera’sCustomFunctions.

ENG-9
The image stabilizer for this lens is effective for hand-held shots in the following conditions.
Image Stabilizer
OFF
ON
OFF
ON
 Hand-heldclose-ups(macro)
 Insemi-darkenedareassuchasindoorsoroutdoors
atnight.
 Inlocationswhereashphotographyisprohibited,
suchasartmuseumsandtheaterstages.
 Insituationswhereyourfootingisuncertain.
 Insituationswherefastshuttersettingscannotbe
used.
 Whenpanningsubjectsinmotion.

ENG-10
Thislensallowsuserstofocusfrominnitytoa
magnicationratioof1:1forclose-ups(macro).
Hold the camera rmly
Holdthecamerarmlyasshownintheillustration
ontherightwhentakinghand-heldclose-ups
(macro),andtaketheshotscarefullytominimize
camerashakeandpreventfocusblurring.
Taking Photographs using AI Servo AF
ItisrecommendedthatthecameraAFissettoAI
SERVOwhentakingclose-up(macro)shots.See
thecamera’sinstructionmanualforfurtherdetails.
Itisnecessarytobecarefulofthefollowingduring
close-up(macro)shooting.
• T
hereisatendencyforcamerashaketoaffectclose-
up(macro)shotsmorethannormalshots,andthe
effectsoftheimagestabilizingfunctionarereduced.
• D epthofeldbecomesextremelyshallowwhen
takingclose-up(macros)shots,andthefocusmay
blurifthecameraismovedforwardandbackward.
Theminimumfocusingdistanceofthislens
(minimumdistancebetweenthesubjectandthe
imagesensoratwhichthelenscanfocus)is
0.13m/0.43ft.Theworkingdistanceofthislens
(minimumdistancefromthefrontofthelenstothe
subject)is30mm/1.18inch.
Useyourkneetosupport
anarmholdingthecamera
orlens.
Leanagainstasteady
objectlikeawall.
Placebothelbowsonasteadysurfacesuchasatable.
Taking Hand-held Close-ups (Macro)
4

ENG-11
Setting the Exposure
WhentakingphotographsusingTTLmetering,
noexposurecompensationisnecessarytometer
thelightcomingthroughthelens.
WithTTLmetering,AE(autoexposure)ispossible
atallfocusingdistances.Justsetthedesired
picture-takingmode,thenchecktheshutter
speedandaperturebeforetakingthepicture.
Magnification and Effective f-number
Theaperturedisplayedbythecameraassumes
thatthefocusissettoinfinity.Theactual
aperture(effectivef-number)becomesdarker
(effectivef-numberincreases)atcloserfocusing
distances(magnificationincreases).Thisdoes
notcauseexposureproblemsfornormalpicture-
taking.However,forclose-upphotography,you
cannotignorethechangeintheeffective
f-number.
 Conditionsprevalentwiththesubjectarevery
importantwhendecidingonthecorrectlevel
ofexposureforclose-up(macro)shots.Itis
thereforerecommendedthatexposurelevelsare
amendedasmuchaspossibleduringshooting,
orthattheimageofthesubjectischeckedon
thecamera’sLCDmonitor.
 Usingeithertheaperture-priorityAE(Av)mode
ormanualexposure(M)modeisrecommended
forclose-up(macro)photography,asthese
makeiteasiertoadjustthedepthofeldand
exposure.
Whenyouuseahandheldexposuremetertoset
theexposure,youmusttakeintoaccountthe
exposurefactorshowninthefollowingtable.
Magnification 0.3 0.5 0.7 1.0
FocusingDistance
(m/ft.)
0.21/
0.69
0.17/
0.56
0.14/
0.46
0.13/
0.43
Effectivef/No. 3.3 3.5 3.7 4.0
ExposureFactor(stops)*
+1/3 +2/3 +2/3 +1
+1/2 +1/2 +1/2 +1
* Uppervalues:1/3stops.Lowervalues:1/2stops.
Exposure When Taking Close-up (Macro) Shots
5

ENG-12
MacroLiteA
MacroLiteB
TheMacroLitesonthefrontofthelensshine
lightonthesubjectduringclose-up(macro)
photographytofacilitateshooting.Therearetwo
light-emittingMacroLiteslocatedonbothsides
ofthelens,anditispossibletoilluminateboth
simultaneouslyoreitherofthemindependently.
TheMacroLitescanonlybeilluminatedwhenthe
powertothecameraisswitchedon.
TheuseofasingleMacroLitewilladdshadowto
thesubjectandaddasenseofthree-dimensionality
tophotographs.
Macro Lites
6
MacroLiteONbutton
TheMacroLitesareilluminatedbypressingthe
MacroLiteONbutton.PressingtheMacroLite
ONbuttonwillilluminatetheMacroLitesfor
approximately30seconds.
 D uringLiveViewormovieshooting,theMacro
Liteswillnotturnoffuntilthecameraisturnedoff.
 RemovethehoodwhenusingtheMacroLites.
 Ifanyofthefollowingactionsareperformed
within30secondsoftheMacroLitesbeing
activated,theMacroLiteswillremainactivated
foranadditional30seconds.
•
Pressingtheshutterbuttonhalfway/completely*
• PressingtheMacroLiteONbutton
• Manualfocusoperation
* TheMacroLiteswillturnoffafterafewsecondswhenyou
removeyourfingerfromtheshutterbuttonafterahalfway/
completepressinthecaseoftheEOS30D,EOS20D,
EOS20Da,EOSDIGITALREBELXT/350DDIGITALand
EOSDIGITALREBEL/300DDIGITAL.

ENG-13
■ Both Macro Lites Illuminated
BrieypressingtheMacroLiteONbuttonwill
alternatebetweenONandOFFforbothlights,
andbetweenBrightandDim.
OFF
[Bothlightsilluminated:Bright]
[Bothlightsilluminated:Dim]
■ Macro Lites A and B Illuminated
Independently
 HolddowntheMacroLiteONbuttonwiththe
lightswitchofftoilluminateoneofthelights.
 BrieypressingtheMacroLiteONbuttonwhen
onelightisilluminatedwillalternatetheON
statustotheotherlight.
OFF
[MacroLiteAilluminated:Bright]
[MacroLiteAilluminated:Dim]
[MacroLiteBilluminated:Bright]
[MacroLiteBilluminated:Dim]
■ Switching Between Both Macro Lites
and a Single Macro Lite
 HolddowntheMacroLiteONbuttonwiththe
lightilluminatedtoalternatebetweenboth
lightsandasinglelight.
Macro Lites

ENG-14
 T heMacroLitescastshadowsfromthecamera
andlensontothesubjectduringclose-up(macro)
photographytofacilitateshootingandimprovethe
endresult.Theyarenotdesignedtoshinesufcient
lightonsubjectswhenshootingindarklocations.
 Morebatterypowerisconsumedwhenthe
MacroLitesareinusethanwhentheyare
notinuse,whichwillreducethenumberof
photographsthatcanbetakenandtheamount
oftimethatvideoscanbelmed.
 TheilluminationstatusoftheMacroLiteswillbe
savediftheyhaveturnedoffautomaticallyafter
30secondshaselapsed.PresstheMacroLite
ONbuttontoreactivatethem.Thiswillcausethe
MacroLitestobeilluminatedatthesamelevel
asbeforetheywereextinguished.
 T
heilluminationstatuswillnotbesavedifthecamera
isturnedoffandtheMacroLitesextinguished.
 TherearecasesinwhichtheMacroLiteswillbe
extinguishedwhenthecamera’spower-saving
function(AutoPowerOff)turnsoffthepower,
evenwhentheyareilluminated.Whenthis
occurs,theilluminationstatuswillnotbesaved.
 Dependingonthecameraused,therearetimes
whentheMacroLiteswillnotilluminateeven
afterpressingtheMacroLiteONbuttonduring
AutoPowerOff.
Macro Lites
 T herearecasesinwhichtheMacroLiteswillbe
extinguishedforshortperiodsoftimeduringoperations
andwhenilluminatedifimagereplay,menudisplay,
movie/stillimageswitchingandothercamerasettings
areamended.Theilluminationstatuswillnotbesaved
inthiscase.ChecktheilluminationstatusoftheMacro
Litesimmediatelypriortotakingphotographs.
 I fAForMFisselectedusingthefocusmodeswitch
whiletheMacroLitesareilluminated,theMacroLites
mayturnoffforashortperiodoftime.Theillumination
statusoftheMacroLiteswillbesavedinthiscase.
 TherearecasesinwhichtheMacroLiteswillnot
beilluminatedforseveralsecondsafterthelens
hasbeenattachedtothecamera.
 InordertoilluminatetheMacroLites
continuouslyduringintervalshooting,setthe
shootingintervalwithin30seconds.
 InordertoilluminatetheMacroLites
continuouslyduringtime-lapseshooting,setthe
shootingintervalwithin10seconds.
 A
fterpressingtheshutterbuttonhalfway,don’t
changetheMacroLitestatuswhenshooting.
Sincepressingtheshutterbuttonhalfwaylocksthe
exposure*,itmaynotbepossibletoshootinstandard
exposureiftheMacroLitestatushaschanged.
 T heMacroLiteswillbeconcealedwhenthehood
isattached,sodon’tforgettoswitchthemoff.
* Differsaccordingtothecamera’sphotometryandAFsettings.
Fordetails,pleasecheckyourcamera’sinstructionmanual.

ENG-15
TheES-27lenshoodplaysthefollowingroles:
 I
nadditiontoblockingoutdamaginglight,italsoprotects
thelensfromrain,snow,dustandotherelements.
 Itpreventsthewhiteringonthefrontofthe
lensfrombeingreectedbackintoimages.
 Itactsasanadapterwhenltersarebeingused.
Screwthehoodrmlyandcorrectlyontothe
frontofthelens.
 Attachingthehoodatananglemaydamagethe
outsideofthelens.
 I
fthehoodisnotattachedproperly,vignetting
(darkeningoftheperimeterofthepicture)mayoccur.
 RemovethehoodwhenusingtheMacroLites.
Itispossibletoattachthelenscaptothefrontof
thehoodwhenitisattachedtothelens.
Hood
Youcanattachlters(whichare49mmin
diameter)totheltermountingthreadonthe
frontofthehood.
1.Attachthehood.
2.Attachtheltertothefrontofthehood.
 Filterscannotbeusedunlessthehoodis
attached.
 Onlyoneltermaybeattached.
Hood
7Filters
(sold separately)
8

ENG-16
TheMacroRingLiteMR-14EXIIortheMacro
TwinLiteMT-24EXenablesfullyautomatic
macroashphotographyupto1xmagnication
inE-TTLautoashmode.
ForinformationonoperatingtheCanonMacroRing
LiteMR-14EXIIortheMacroTwinLiteMT-24EX,
refertotheindividualinstructionmanuals.
■ When the MR-14EX II is in use
•EffectiveFlashRange(Reference)
Aperture
Magnification
: Effective flash range
(both sides firing)
(with the Macro Lite
set at OFF)
0.5 0.7 10.3 0.5 0.7 10.3
ISO100
32
22
16
11
8
5.6
4
2.8
0.5 0.7 1
ISO400
 Therearecasesinwhichtheareassurrounding
thesubjectwillbebrighterinimagestakenclose
totheminimumfocusingdistance.
 Therearecasesinwhichvignettingmayoccur
aroundthecenterofimagestakenclosetothe
minimumfocusingdistancewitha67mmin
diameterlterattachedtothelight-emittingMicro
LitesontheMR-14EXII,whichwillmakethem
darker.Inthisevent,attacha49mmindiameter
ltertothelens.
■ When the MT-24EX is in use
TheMT-24EX’sashrangelargelydependson
theashhead’sposition.
 Intheeventofover-exposure,lowerthevalueof
theISOsensitivitysetting,orreducethesizeof
theaperture,etc.
 Dependingontheshapeandsizeofthesubject,
therearecasesinwhichthelight-emittingMacro
Liteswillinterferewiththesubjectinimages
takenclosetotheminimumfocusingdistance.
Macro Flash (sold separately)
9

ENG-17
Extension Tubes
(sold separately)
10
YoucanattachextensiontubeEF12IIorEF25
IIformagniedshots.Theshootingdistanceand
magnicationareshownbelow.
Magnication(×)
FocusingDistanceRange(mm)
(WorkingDistance)
Closedistance Longdistance Closedistance Longdistance
EF12II 1.41 0.34 133
(20)
209
(97)
EF25II 1.91 0.76 142
(15)
167
(39)
MFmodeisrecommendedforaccuratefocusing.

ENG-18
Focal Length/Aperture 35mmf/2.8
Lens Construction 6groups,10elements
Minimum Aperture f/32
Angle of View Diagonal:42°35′,Vertical:24°20′,Horizontal:35°55′
Min. Focusing Distance 0.13m/0.43ft.
Max. Magnification 1x
Field of View
Approx.15.0x22.3mm/0.59x0.88inch(at0.13m/0.43ft.)
Filter Diameter 49mm(whenlenshoodES-27isattached)
Max. Diameter and Length 69.2x55.8mm/2.72x2.20inch
Weight Approx.190g/6.7oz
Hood ES-27
Cap LensCapEF-S35,LensDustCapE
Case LP1014(soldseparately)
 Equivalentto56mminthe35mmlmformat.
 Thelenslengthismeasuredfromthemountsurfacetothefrontofthelens.Whenthelenscapand
dustcapsuppliedareattached,add34.1mmifthehoodisattachedand24.1mmifthehoodisnot
attached.
 Thesizeandweightlistedareforthelensonly,exceptasindicated.
 Extenderscannotbeusedwiththislens.Inaddition,therearenoclose-uplensesdesignedforuse
withthislens.
 Aperturesettingsarespeciedonthecamera.
 AlldatalistedismeasuredaccordingtoCanonstandards.
 Productspecicationsandappearancearesubjecttochangewithoutnotice.
Specications

CT1-D002-A 0217Ni © CANON INC. 2017
