Canon EF-S60mm f/2.8 MACRO USM User manual

Canon EF~ LENS
EF-S60mm f/2.8 MACRO USM
» ULTRASONIC
Instruction
Mode d'emploi
Bedienungsanleitung
Instrucciones
Istruzioni
~ffl*.~~,~~~~~*m~~o
~~m~~~~*~, ~.~*~~o

Thank you for purchasing aCanon USM lens.
The Canon EF-S60mm f/2.8 MACRO USM lens
is amacro lens that can be used for normal
photography and close-up pictures up to 1:1,
or life-size magnification. It has been
developed for use with digital SLR cameras*
compatible with EF-S lenses.
"USM" stands for Ultrasonic Motor.
Features
1. The three-group floating system results in
sharp and clear delineation at all focusing
distances from life-size to infinity.
2. ACanon macro flash (sold separately) makes
it easy to take close-up pictures with aflash.
The inner focusing mechanism enables AF
photography while the macro flash
is
attached.
3. USM for fast, quiet focusing.
4. Manual focusing available in autofocusing
mode (ONE SHOT AF).
E-1

~ Safety Precautions
1. Do not look at the sun or a bright light source
through the lens or camera. Doing so could
result
in loss of vision. Looking at the sun directly
through the lens
is especially hazardous.
2. Whether it is attached to the camera or not, do
not leave the lens under the sun without the
lens cap attached. This is to prevent the lens
from concentrating the sun's rays, which could
cause afire.
~ Handling Cautions
If the lens is taken from a cold environment into
awarm one, condensation may develop on the
lens surface and internal parts. To prevent
condensation in this case, first put the lens into
an
airtight plastic bag before taking it from acold to
warm environment. Then take out the lens after it
has warmed gradually.
Do the same when taking the
lens from awarm environment into acold one.
unless otherwise specified in the instructions. If such changes or
modifications should be made, you could be required to stop
operation of the equipment.
This equipment has been tested and found to comply with the
limits for aclass Bdigital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in aresidential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used
in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur
in
aparticular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Consult the dealer or an experienced radiorrV technician for
help.
This digital apparatus does not exceed the Class Blimits for
radio noise emissions from digital apparatus as set out in the
interference-causing equipment standard entitled "Digital
Apparatus", ICES-003 of the Industry Canada.
This device complies with Part 15 of the FCC Rules. Operation
is
subject to the following two conditions: (1) This device may not
cause harmful interference, and
(2) this device must accept any
interference received, including interference that may cause
undesired operation.
Do not make any changes or modifications to the equipment
E-2
CE:
The C€ Mark is aDirective conformity mark of the
European Community (EC)
N118

Nomenclature
Hood mount (-7
Filter mounting
thread (-7
9)
Focusing ring (-7 4)
"..---- Distance index
Focus mode switch
(-74)
Contacts (-74)
Lens mount index (-74)
For detailed information, reference page numbers are provided in parentheses (-7 **).
E-3

Mounting and Detaching the Lens
See your camera's instructions for details on
mounting and detaching the lens.
<$ After detaching the lens, place the lens with the
rear end up to prevent the lens surface and
electrical contacts from getting scratched.
1$ If the contacts get soiled, scratched, or have
fingerprints on them, corrosion or faulty
connections can result. The camera and lens
may not operate properly.
'*' If the contacts get soiled or have fingerprints on
them, clean them with a soft cloth.
If you remove the lens, cover it with the dust
cap. To attach it properly, align the lens mount
index and the 0index of the dust cap as shown
in the diagram, and turn clockwise. To remove
it, reverse the order.
E-4
To shoot in autofocus mode, set the focus mode
switch to AF.
To use only manual focusing, set the focus mode
switch
to MF, and focus by turning the focusing
ring.
The focusing ring always works, regardless
of the focus mode.
[l]AfterautofocusinginONESHOTAFmode,focus
manuaUyby pressing the shutter button halfway
and turning the focusing ring. (Full-timemanOal
focus) ,

Picture Taking
Normal Photography
The lens can be used as amedium-telephoto
lens equivalent to 96mm
in 35mm format for
normal photography such as snapshots and
portraits.
Closeup Photography
Close-up photos up to 1x (life-size) magnification
are possible. The minimum focusing distance of
20cm
is the distance from the subject to the film
plane. The working distance from the front of the
lens to the subject
is about 9cm.
When focusing, you can give priority to framing
or to magnification.
[Framing Priority]
While looking through the viewfinder and framing
the subject, focus with the AF or MF mode.
[Magnification Priority]
1. Set the lens' focus mode switch to MF.
2. Set the magnification.
While referring to the magnification scale on
the distance index, turn the focusing ring to
the desired magnification.
3. Focus the subject.
While look:ing through the viewfinder, move the
camera forward or back to find the point of
focus.
4. Touch up the focus.
Turn the focusing ring for fine focusing.
ojSince macro shots have avery shallow. depth of
field,focuscarefullyto.obtainipropersharpness.
Image quality deteriorates near the minimum
aperture opening.
due. to diffraction.
~
Lj]0 The magnificationrefers to the ratio between the
SUbject's size and the corresponding image size
on the image sensor plane. QnJhe distance
index,itisindicatedas1:x.
%To prevent camera shake, using aRemote
Switch.
(bothsoldseparately)andtripod. is
reco
rnrn ended.
@To checkthe depth of field, pressthe camera's
depth~of~fieldpreview button.
E-5

About Exposure
Setting the Exposure
When taking photographs using TTL
metering, no exposure compensation is
necessary to meter the light coming through
the lens.
With TTL metering, AE (autoexposure) is
possible at all focusing distances. Just set the
desired picture-taking mode, then check the
shutter speed and aperture before taking the
picture.
Magnification and Effective f-number
The aperture displayed by the camera assumes
that the focus is set to infinity. The actual aperture
(effective f-number) becomes darker (effective f-
number increases) at closer focusing distances
(magnification increases). This does not cause
exposure problems for normal picture-taking.
However, for closeup photography, you cannot
ignore the change
in the effective f-number.
When you use ahandheld exposure meter to
set the exposure, you must take into account
the exposure factor shown
in the following
table.
E-6
Magnification 1 : 5 1: 4 1 : 3 1 : 2 1:1.5
1: 1
Effective fiNo. 3.50 3.66 3.89 4.39 4.86 5.84
Exposure Factor\in +stops 1 1
+1 +1
+1+
+2
+"2 +"2
(stops)
lin +stops 22
+1 +1
+
+1t
+2
+3 +3

Macro Flash (Sold Separately)
Hood (Sold Separately)
The Canon Macro Ring Lite MR-14EX or the
Macro Twin Lite MT-24EX enables fully
automatic macro flash photography up to 1x
magnification
in E-TTL autoflash mode.
r:¥I
LjJ #For information on operating the Canon Macro
Ring Lite
MR-14EXor the Macro Twin Lite MT-
24EX, refer to the individual instruction booklets.
}Using aperture-priority AE (Av) or Manual (M) is
recommended.
Part of the picture may be blocked if the hood is
notattached properly.
@l When attaching or detaching the hood, grasp
the base
of the hood to tu rn it. To prevent
deformation, do not grasp the rim of the hood to
turn it.
The ET-67B hood can keep unwanted light out of
the lens, and also protects the lens from rain,
snow, and dust.
To attach the hood, align the hood with the lens
hood mount, then turn the hood clockwise to
secure
it.
The hood can be reverse-mounted on the lens
for storage.
•
••
•
1 : 2
1 : 5
1 : 3
Inward Angle
Magnification t--
o_
f
FI,....-aSh--,H.---ead--j
1 :1-1: 1.5 •
Flash Head Angle
Settings for MT-24EX
Flash Range (IS0100)
MR-14EX MT-24EX
E-7

Infinity Distance Mark
1:~ lJ
3 3 . ft
41 1-00 m
_\T7~", __
To compensate for shifting of the infinity focus
point that results from changes in temperature.
The infinity position at normal temperature is the
point
at which the vertical line of the L mark is
aligned with the distance indicator on the
distance scale.
o• Ror~ccurate ma.nual focusing on)subjectsat
infinitydistance, lookthrough
the viewfinder while
rotatIng the focusing ring.
E-8
Close-up Lenses (Sold separately)
Attaching a 2500, 500, or 5000 (52mm) Close-
up Lens enables close-up photography.
The magnification will be as follows:
Near Far
2500 1.33x O.25x
500/5000 O.18x O.12x
Sales of the 500 Close-up Lens may already
be terminated in some areas.
When using aClose-up Lens, focus manually.

Filters (Sold Separately)
You can attach filters to the filter mounting
thread on the front of the lens.
0 .. @ Uptotwo 52mmifilters can be attached.
@This lens can accommodate both filters and the
rnacroflashat theisametime.
If you need apolarizing filter, use Canon's PL-G
52mmpolarizing filter.
(i) To adjust the polarizing filter, first remove the
lens hood.
bWhanthe Canon's PL-G 52mm polarizing filter
is attached, the lens cap cannot be attached.
Gelatin Filter Holder (Sold separately)
With the Gelatin Filter Holder, you can use filters
to create various effects.
The Gelatin Filter Holder compatibility is shown
below.
Gelatin Filter Holder
III: Up to six hoods can be
used.
Gelatin Filter Holder
IV: Up to six hoods can
be used.
Extension Tubes (Sold Separately)
You can attach Extension Tube EF12 II or EF25
II for magnified shots. The shooting distance and
magnification are shown below.
Camera-to-Subject Magnification
Distance (mm)
Near Far Near IFar
IEF12 II
207 445 1.28x I0.20x
IEF25 II
215 289 1.61x I0.44x
Extension·Tube EF12 or EF25 cannot be
attached.
bWhen an Extension Tube is attached,focus
manually.
E-9
