Chapter 1
Introduction

About the folding device
The Océ Folder Express 3011 is an automatic online folding device which can be connected to a
variety of printers.
• Prints which should be folded may be up to 914 mm (36") wide with a length of up to 6 meters.
• Fan fold and cross fold are conducted in one pass before the finished fold package is
transported to the output.
• A 7" Android Tablet PC gives a range of opportunities to control and customize the folding
device.
• Supported standard fold styles are DIN 824 A, DIN 824 B, ANSI. With restrictions: DIN-C, ARCH,
JPN.
• Many additional fold styles beside the standards can be created with a Free Style Editor.
About the folding device
6Chapter 1 - Introduction

Safety instructions
Introduction
You can find the safety manual for this product on the download website under the product name
( "http://downloads.oce.com" ).
For your protection, please read these safety instructions and the manual completely before
operating the machine. Carefully observe all warnings, precautions and instructions on the
machine or the ones described in the operating instructions.
In order to guarantee hazard-free operations it is strongly recommended that any maintenance or
repair work is only carried out by trained personnel.
Safety instructions
Chapter 1 - Introduction 7

Installation and environment
Installation
The folder should be installed by a specially trained engineer.
Environment
The room in which the folder is to be placed should be dry and dust free. Humidity should be
about 20-80% with room temperature of 15° C to 35° C (59°F - 95°F).
The folder must stand horizontally aligned and very stable without shaking.
Make sure to place the folder in a way that does not block exits and allows an ergonomic
workflow.
Installation and environment
8Chapter 1 - Introduction

Chapter 2
Specifications

Overview
Position of sensors
Overview
10 Chapter 2 - Specifications
