INSTRUCTION MANUAL
E
Instruction Manual
Wi-Fi Adapter
W-E1

2
Wi-Fi Adapter W-E1 is an accessory that enables Wi-Fi (wireless
communication) functions when installed in the SD card slot of the
EOS 7D Mark II, EOS 5DS, or EOS 5DS R.
The wireless communication functions available with the W-E1 are as
follows.
(1)qCommunicate with a smartphone (p.21, 53)
Connect the camera to a smartphone or tablet wirelessly and use
the dedicated application “Camera Connect” to do the following.
• View images stored in the camera on a smartphone or save
viewed images to a smartphone.
• Operate the camera to shoot still photos or change camera
settings using a smartphone.
In this manual and on the camera’s LCD monitor, “smartphone”
refers to smartphones and tablets.
(2)DOperate remotely using EOS Utility (p.27, 59)
Connect the camera to a computer wirelessly and operate the
camera remotely using EOS Utility (EOS software).
Introduction
What You Can Do Using the W-E1
Images cannot be recorded on the W-E1. Be sure to prepare a CF card
for recording images.
Depending on the transmission range and connection status, image display
may be delayed, images may not be displayed smoothly, or shutter release
timing may be delayed.
Note that Canon cannot be held liable for any loss or damage from
erroneous wireless communication settings for using the W-E1. In addition,
Canon cannot be held liable for any other loss or damage caused by use of
the W-E1.
When using wireless functions, establish appropriate security at your own
risk and discretion. Canon cannot be held liable for any loss or damage
caused by unauthorized access or other security breaches.

3
In this manual, the terms “wireless” and “wireless LAN” are used as
general terms for Wi-Fi and Canon’s original wireless functions.
The term “access point” indicates wireless LAN terminals (wireless
LAN access points, wireless LAN routers, etc.) that relay wireless
LAN connection.
Read the Camera Instruction Manual and familiarize yourself with
operating the camera. Explanations in this instruction manual
assume that you are accustomed to the camera operations.
Screens in this manual are of the EOS 7D Mark II.
Icons in this Manual
<6> : Indicates the Main Dial.
<5> : Indicates the Quick Control Dial.
<9> : Indicates the Multi-controller.
<0> : Indicates the Setting button.
* In addition to the above, the icons and symbols used on the camera’s buttons
and displayed on the LCD monitor are also used in this manual when discussing
relevant operations and functionality.
(p.**) : Reference page numbers for more information.
: Warnings to prevent potential problems during operation.
: Supplemental information.
Conventions Used in this Manual

4
This manual consists of the following five sections: “Getting Started”,
“Easy Connection”, “Advanced Connection”, “When Connected”, and
“Reference”.
After preparing to connect in “Getting Started”, follow the diagram below
and see the corresponding pages according to your needs.
Structure of this Manual
Getting Started (p.9)
Explains how to register a nickname and the basic operations.
Selecting Connection Destination
qSmartphone
DEOS Utility
Easy Connection (p.19)
Explains how to connect the camera
directly to the device.
Advanced Connection (p.33)
Mainly explains how to connect using
a Wi-Fi access point.
A smartphone or computer can be
connected to a camera while
maintaining connection to an access
point.
When Connected (p.51)
Explains how to use the wireless functions such as sending images after a
connection is established.
Reference (p.73)
Describes the solutions to problems and other information. Read as necessary.

5
2
1
3
Introduction 2
What You Can Do Using the W-E1...................................................2
Conventions Used in this Manual .....................................................3
Structure of this Manual ....................................................................4
Safety Precautions............................................................................8
Handling Precautions........................................................................8
Getting Started 9
Operation Flowchart .......................................................................10
Preparation and Basic Operation 11
Preparing to Use the W-E1.............................................................12
Installing the W-E1 in the Camera ..................................................12
Basic Operation and Settings .........................................................16
Preparation for Smartphones..........................................................18
Easy Connection 19
Wireless Function Operation Flowchart (Easy Connection) ...........20
Easy Connection to a Smartphone 21
Connecting with [Easy connection]...............................................22
Easy Connection to EOS Utility 27
Connecting with [Easy connection]...............................................28
Contents

6
Contents
4
5
8
6
7
Advanced Connection 33
Wireless LAN Function Operation Flowchart (Advanced Connection) ... 34
Connecting by Selecting a Network 35
Checking the Type of Access Point................................................ 36
Connecting via WPS (PBC Mode).................................................. 37
Connecting via WPS (PIN Mode) ................................................... 41
Connecting to a Detected Network Manually ................................. 45
When Connected 51
Communicating with a Smartphone 53
Operating the Camera Using a Smartphone .................................. 54
Specifying Viewable Images .......................................................... 56
Operating Remotely Using EOS Utility 59
Using EOS Utility............................................................................ 60
Reconnecting and Adding Settings 63
Reconnecting ................................................................................. 64
Registering Multiple Connection Settings....................................... 66
Checking and Operating Connection Settings 67
Checking, Changing, or Deleting Connection Settings .................. 68
Clearing Wi-Fi Function Settings.................................................... 71

7
Contents
10
9
Reference 73
Troubleshooting Guide 75
Responding to Error Messages ......................................................76
Troubleshooting Guide....................................................................84
Wireless Function Notes .................................................................85
Security ...........................................................................................86
Checking Network Settings.............................................................87
Reference 89
Setting up the Network Manually ....................................................90
Setting up the IP Address Manually................................................92
Specifications..................................................................................94
Index ...............................................................................................96

8
The following precautions are provided to prevent harm or injury to
yourself and others. Make sure to thoroughly understand and follow
these precautions before using the product.
If you experience any malfunctions, problems, or damage to the
product, contact the nearest Canon Service Center or the dealer
from whom you purchased the product.
Safety Precautions
Warnings: Follow the warnings below. Otherwise, death or
serious injuries may result.
Before using the camera inside an airplane or hospital, check if it is allowed.
Electromagnetic waves emitted by the W-E1 may interfere with the plane’s
instruments or the hospital’s medical equipment.
Cautions: Follow the cautions below. Otherwise, physical injury
or property damage may result.
Keep the W-E1 out of the reach of children and infants. If a child or infant swallows it,
consult a physician immediately.
Do not touch the contacts with your fingers or metal objects. Do not expose the
contacts to dust or water. If a smudge adheres to the contacts, communication
failure may result.
The W-E1’s wireless functions may not work when the camera is hot, such as
immediately after prolonged movie shooting. Use the wireless functions after
the camera cools down.
If the wireless functions are used for a prolonged period, the W-E1 may
become hot due to excessive heat in the camera. When removing the W-E1,
set the camera’s power switch to <2>, then wait until the camera cools
down.
To prevent damage to the W-E1, note the following:
• Do not drop, bend, or wet it. Do not subject it to excessive force, physical shock, or
vibration.
• Do not affix any stickers, etc., on it.
• Do not store or use it near anything that has a strong magnetic field, such as a TV
set, speakers, or magnets. Also avoid places prone to having static electricity.
• Do not leave it in direct sunlight or near a heat source.
• Store it in a case, etc.
• Do not store it in hot, dusty, or humid locations.
Handling Precautions

9
Getting Started

10
This section explains how to register a nickname (for identification) and
the basic operation of the wireless functions.
Follow the procedures below.
Operation Flowchart
Install the W-E1 in the camera. (p.12)
Register a nickname. (p.13)
Set the camera’s nickname.
The default nickname (the camera name) can
be used.
Be sure to set a nickname as otherwise you
cannot set the wireless functions.
Display the [Wi-Fi function] screen.
(Steps 1 and 2 on page 16)
Select a Wi-Fi function and establish a
connection.
For further settings, see “Easy Connection” or
“Advanced Connection”.
Easy Connection (p.19)
Connect the camera directly to the
device.
Advanced Connection (p.33)
Connect using a Wi-Fi access point.

11
1
Preparation and Basic
Operation
This chapter describes the preparation necessary for
using the W-E1’s Wi-Fi functions and the basic
operations.

12
Images cannot be recorded on the W-E1. Be sure to prepare a
CF card for recording images.
If a CF card is not inserted, [Unsupported card for recording]
appears on the LCD monitor when you turn on the power or release
the shutter.
If the camera’s grip is covered by your hand, the wireless
communication speed may decrease or the wireless communication
may be terminated.
Depending on the transmission range and connection status, image
display may be delayed, images may not be displayed smoothly, or
shutter release timing may be delayed.
Insert the W-E1 into the camera’s SD card slot, and a CF card into the
CF card slot. For how to insert, refer to the Camera Instruction Manual.
Preparing to Use the W-E1
Read These First
Installing the W-E1 in the Camera
Camera’s Firmware Version
When using the W-E1, check that the camera’s firmware version is as
follows.
EOS 7D Mark II : Ver. 1.1.0
EOS 5DS/EOS 5DS R: Ver. 1.1.0
With the above firmware, it takes approx. 0.05 seconds longer than with
the previous versions for the camera to start up.
To check the firmware version, see the camera menu [54: zfirmware
ver.]. If the firmware needs to be changed, refer to the Canon Web site.
When changing the firmware, remove the W-E1 from the camera. The
firmware cannot be changed with the W-E1 installed in the camera.

13
Preparing to Use the W-E1
First, insert the W-E1 into the camera and set a nickname (for
identification) for the camera.
When you are connecting the camera to another device wirelessly, the
nickname will be displayed on the device. Be sure to set a nickname
as otherwise you cannot set the wireless functions.
1Select [Wi-Fi function].
Press the <M> button, select [Wi-
Fi function] under the [53] tab, and
press <0>.
When this setting is selected for the
first time, a screen to register a
nickname is displayed. Press <0>
and proceed to step 2.
Registering a Nickname

14
Preparing to Use the W-E1
2Enter a nickname.
For instructions on entering
characters, see the next page.
When using the default nickname (the
camera name), proceed to step 3.
Otherwise, enter any characters
between 1 to 10 characters in length.
3Exit the setting.
When you are finished, press the
<M> button.
Select [OK] on the confirmation
dialog and press <0>. The [Wi-Fi
function] screen will appear. Select
the Wi-Fi device to connect to (p.16).
Since the nickname is the information required for wireless setting, you
cannot delete all the characters.

15
Preparing to Use the W-E1
Changing the entry area
Press the <Q> button to toggle
between the top and bottom entry
areas.
Moving the cursor
Use <5> or <9> in the top area to
move the cursor.
Entering text
In the bottom area, use <5> or <9> to select a character, then
press <0> to enter it.
You can check how many characters you have entered and how
many more can be entered by referring to [*/*] on the upper right of
the screen.
Deleting a character
Press the <L> button to delete one character.
Finishing the text entry
Press the <M> button to confirm what you have entered and exit.
If a confirmation dialog is displayed, select [OK] to exit.
Canceling the text entry
Press the <B> button to cancel text entry and exit. If a
confirmation dialog is displayed, select [OK] to exit.
Virtual Keyboard Operation

16
The basic operation for using the W-E1’s Wi-Fi functions is explained
here. Follow the procedures below.
1Select [Wi-Fi function].
Press the <M> button, select [Wi-
Fi function] under the [53] tab, and
press <0>.
2Select the Wi-Fi function to
connect to.
Use <5> or <9> to select an item,
then press <0>.
When the connection settings are not
registered, the setting screen is
displayed.
When the connection settings are
already registered, the reconnection
screen is displayed (p.64).
For further connection settings, see “Easy Connection” (p.19) or
“Advanced Connection” (p.33).
Basic Operation and Settings
When multiple-exposure shooting is set, you cannot select [53: Wi-Fi
function].
Interface Cable Connection Cautions
When the W-E1 is installed in the camera, you cannot use the camera by
connecting it to Connect Station, a computer, a Wireless File Transmitter,
a printer, or another device with a cable. Remove the W-E1 from the
camera before connecting a cable.
Cards
For [q], the camera cannot be connected wirelessly if there is no CF
card in the camera.
Using the Camera with a Wireless Connection Established
When you want to prioritize the wireless connection, do not operate the
power switch, card slot cover, battery compartment cover, Mode Dial,
Live View shooting/Movie shooting switch, or other parts. Otherwise, the
wireless connection may be terminated.

17
Basic Operation and Settings
Wireless connection status can be checked on the camera’s LCD
monitor.
* is not displayed when the camera is connected with [Easy connection] or
[Camera access point mode].
* The LCD monitor turns off when you connect the camera to a smartphone.
Wireless Connection Status
Connection status Wi-Fi function Wireless signal
strength
Not connected (Off)
Connected
Sending data ()
Waiting for reconnection (Blinking)
Connection error (Blinking)
Quick Control screen
Information display
screen during playback
LCD monitor
Wireless signal strength
Wi-Fi function
Live View screen

18
To use [q] (Connect to smartphone), a smartphone on which iOS or
Android is installed is necessary. In addition, the dedicated application
Camera Connect (free of charge) must be installed on the smartphone.
Camera Connect can be downloaded from the App Store or Google
Play.
For the operating system versions supported by Camera Connect,
refer to the download site of Camera Connect.
Interface or functions of the camera and Camera Connect are
subject to change for firmware update of the camera or application
update of Camera Connect, iOS, Android, etc. In such a case,
features of the camera or Camera Connect may differ from sample
screens or operation instructions in this manual.
Preparation for Smartphones

19
Easy Connection

20
Wireless Function Operation Flowchart (Easy Connection)
q
Smartphone
D
EOS Utility
Register the camera’s nickname (p.13)
Install Camera Connect on a
smartphone (p.18) Install EOS Utility on a computer
Register connection destinations to the camera
(p.22) (p.28)
Make images viewable and shoot
remotely (p.53)
Operate the camera remotely
(p.59)
Set upUse Connect
