Canon Vb-C60 - Ptz Network Camera Guide

NETWORK CAMERA
Start Guide
Be sure to read Start Guide and Operation Guide before using.
In particular, be sure to read the "Safety Precautions" section and
use the camera correctly. Keep this guide in a readily accessible
location for future reference.
COPY

ii
Introduction
Thank you for purchasing Canon Network Camera VB-C60/VB-C60B (hereafter referred to as
VB-C60).
The only difference between VB-C60 and VB-C60B is the exterior color.
This Start Guide describes the initial settings and mounting method of the VB-C60. The detailed
procedures for using the VB-C60 are explained in the Operation Guide provided on the bundled
Setup CD-ROM. Read these guides carefully before using the VB-C60 to ensure that you make
the best possible use of this product. Also, be sure to read "Safety Precautions" in this guide.
For the latest information on this product (firmware, bundled software, operation manuals,
operating environment, etc.), visit our website.
For the latest information, please refer to Canon Web Site.
Disclaimer
Canon Inc. shall not be responsible for any financial losses that may be incurred as a
result of the loss of recorded information or images, regardless of the internal or external
cause of the loss.
EXCEPT AS SET FORTH IN THE LIMITED WARRANTY ACCOMPANYING THE VB-C60/
VB-C60B: (1) NEITHER CANON INC. NOR ANY OF ITS SUBSIDIARIES OR AFFILIATES
MAKE ANY WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARD TO THE
MATERIAL IN THIS START GUIDE OR WITH REGARD TO THE USE OF THE VB-C60/
VB-C60B INCLUDING, WITHOUT LIMITATION, IMPLIED WARRANTIES AS TO
MARKETABILITY, MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR
USE, OR NON-INFRINGEMENT AND (2) NEITHER CANON INC. NOR ANY 0F ITS
SUBSIDIARIES OR AFFILIATES SHALL BE LIABLE FOR ANY DIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES OF ANY NATURE RESULTING FROM THE USE OF THIS
MATERIAL OR THE VB-C60/VB-C60B.
Copyright
Videos, images or sounds recorded with your VB-C60 may not be utilized or published,
without consent of copyright holders, if any, except in such a way as permitted for
personal use under the relevant copyright law.
Notes
1. All rights reserved.
2. The contents of this guide are subject to change without any prior notice.
3. This document has been prepared with utmost attention to accuracy. If you have any
comment, however, please contact the Customer Service Center indicated on the back cover.
4. Canon shall assume no liability for any outcome of using this product, regardless of Items 2
and 3 above.
COPY

iii
Introduction
Notes on privacy and publicity rights regarding the
utilization of video/audio
When using the VB-C60 (for video or audio recording), it is the responsibility of the users
to take all care to protect privacy and avoid any violation of publicity rights. Canon shall
have no liability whatsoever in this regard.
Reference
Please be sure to gain approval of the building management office before installing a
camera, if copyrighted architectural structures or copyrighted premises are appear in
the frame.
Legal Notice
In some countries or regions, monitoring via a camera is banned by the law or regulation,
and the law or regulation depends on the country or region. Before using the VB-C60,
confirm the law or regulation of the country or region where the camera is used.
Trademark Notice
Canon and the Canon logo are registered trademarks of Canon Inc.
Microsoft Windows and Microsoft Internet Explorer are trademarks or registered
trademarks of Microsoft Corporation in the United States and other countries.
Windows is legally recognized as the Microsoft Windows Operating System.
Other brands or product names in this guide are trademarks or registered trademarks
of their respective companies.
Notes on Use of Bundled Software VK-Lite (Disclaimer)
Malfunction, failure of VK-Lite or other factors may cause problems, such as recording
failure, recorded data corruption or loss. Canon shall have no liability whatsoever for any
loss or damages incurred by the user as a result of such problems.
Warning
To reduce the risk of fire or electric shock, do not expose this appliance to rain or
moisture.
COPY

iv
Introduction
Notes on License Agreement for Bundled Software
See the following files in the BundledSoftware folder inside the LICENSE folder of the
bundled Setup CD-ROM for information regarding the license agreement for bundled
software.
European Union (and EEA) only.
These symbols indicate that this product is not to be disposed
of with your household waste, according to the WEEE Directive
(2002/96/EC), the Battery Directive (2006/66/EC) and/or your
national laws implementing those Directives.
This product should be handed over to a designated collection
point, e.g., on an authorized one-for-one basis when you buy a
new similar product or to an authorized collection site for recycling waste electrical and
electronic equipment (EEE) and batteries and accumulators. Improper handling of this
type of waste could have a possible impact on the environment and human health due to
potentially hazardous substances that are generally associated with EEE.
Your cooperation in the correct disposal of this product will contribute to the effective
usage of natural resources.
For more information about the recycling of this product, please contact your local city
office, waste authority, approved scheme or your household waste disposal service or
visit www.canon-europe.com/environment.
(EEA: Norway, Iceland and Liechtenstein)
Software Type File Name
VB Initial Setting Tool, VBAdmin Tools VBTools.txt
Network Video Recorder VK-Lite VK-Lite.txt
COPY

v
Introduction
MPEG-4
NOTICE ABOUT THE MPEG-4 VISUAL STANDARD: THIS PRODUCT IS LICENSED UNDER
THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-
COMMERCIAL USE OF A CONSUMER TO (i) ENCODING VIDEO IN COMPLIANCE WITH
THE MPEG-4 VISUAL STANDARD ("MPEG-4 VIDEO") AND/OR (ii) DECODING MPEG-4
VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-
COMMERCIAL ACTIVITY. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION INCLUDING THAT RELATING TO PROMOTIONAL,
INTERNAL AND COMMERCIAL USES AND ADDITIONAL LICENSING MAY BE OBTAINED
FROM MPEG LA, LLC. SEE HTTP://WWW.MPEGLA.COM.
This product is licensed under AT&T patents for the MPEG-4 standard and may be used
for encoding MPEG-4 compliant video and/or decoding MPEG-4 compliant video that
was encoded only (1) for a personal and non-commercial purpose or (2) by a video
provider licensed under the AT&T patents to provide MPEG-4 compliant video. No license
is granted or implied for any other use for MPEG-4 standard.
Open Source Software
The product (VB-C60 and bundled VK-Lite Viewer) contains Open Source Software
modules. See OpenSourceSoftware.pdf on the bundled Setup CD-ROM for details. Each
module’s license conditions are also available in the License folder on the same Setup
CD-ROM.
Software under GPL and LGPL
If you would like to obtain the source code under GPL/LGPL, please contact the dealer
where you purchased the product, or a sales agent.
COPY

vi
Contents
Introduction ..............................................................................................ii
Checking of Bundled Items ................................................................... viii
Operation Manuals ............................................................................................ ix
How to Read This Document .................................................................. x
Symbols Used for Safety Precautions ................................................................x
Safety Precautions ..................................................................................xi
Maintenance .................................................................................................... xvi
Chapter 1 Before Use
Features of VB-C60 ............................................................................. 1-2
Bundled Software ................................................................................. 1-5
VB Initial Setting Tool Ver. 5.0.1 ..................................................................... 1-5
VBAdmin Tools Ver. 5.1 ................................................................................. 1-6
VB-C60 Viewer Ver. 1.1 .................................................................................. 1-7
Network Video Recorder VK-Lite v2.2 ............................................................ 1-7
Operating Environment ...................................................................... 1-12
VB Initial Setting Tool Ver. 5.0.1, VBAdmin Tools Ver. 5.1,
VB-C60 Viewer Ver. 1.1 ............ 1-12
Network Video Recorder VK-Lite v2.2 .......................................................... 1-13
Notes on Operating Environment ....................................................... 1-14
Notes on Use When the [Windows Firewall] Function is Enabled ............... 1-14
Notes on Use with Windows Server 2003/Windows Server 2008 ................ 1-15
Notes on Use with Windows Server 2008 .................................................... 1-17
Notes on Use with Windows Vista ................................................................ 1-19
Name and Function of Each Part ....................................................... 1-20
Optional Items .................................................................................... 1-22
Ceiling Mount Cover SS60-S-VB/SS60-B-VB ............................................... 1-22
Indoor Dome Housing VB-RD51S-C/S ......................................................... 1-22
AC Adapter PA-V17 ..................................................................................... 1-23
VK-Lite Additional Viewer License ............................................................... 1-23
Network Video Recorder VK-64/VK-16 v2.2 ................................................. 1-24
COPY

vii
Contents
Chapter 2 Initial Setting and Installation of Camera
Flow of Setup ....................................................................................... 2-2
Step 1 Install the Software ................................................................... 2-4
Install the Necessary Software ....................................................................... 2-4
Step 2 Connect the Camera to the Network ........................................ 2-6
Connect the Camera to the Network and Turn On the Power ........................ 2-6
Step 3 Perform Initial Setting of the Camera ..................................... 2-10
Perform Initial Setting of the Camera ........................................................... 2-10
Check the Video Captured by the Camera .................................................. 2-13
Step 4 Install the Camera .................................................................. 2-15
Installing in the upright position ................................................................... 2-16
Installing on a Ceiling Using the Ceiling Mount Cover SS60-S-VB/
SS60-B-VB (Optional) ............... 2-17
Installing on a Ceiling Using the Indoor Dome Housing VB-RD51S-C/S
(Optional) ................................ 2-21
Chapter 3 Appendix
External Dimensions ............................................................................ 3-2
VB-C60/VB-C60B ........................................................................................... 3-2
Ceiling Mount Cover SS60-S-VB/SS60-B-VB (Optional) ................................ 3-2
Indoor Dome Housing VB-RD51S-C/S (Optional) .......................................... 3-2
Main Specifications .............................................................................. 3-3
Input/Output Terminals ........................................................................ 3-5
External Device Input/Output Terminals ........................................................ 3-5
Audio Input/Output Terminals ........................................................................ 3-7
COPY

viii
Checking of Bundled Items
This product comes with the following items. If any item is missing, contact the store where you
purchased the product.
Content of Setup CD-ROM
DOC : Folder containing operation manuals other than this document, notes, and
others*
APPLICATIONS : Folder containing the installers for bundled software (two installers
specified below)*
VBToolsInstall.exe : Installer for VB Initial Setting Tool and VBAdmin Tools*
VKLiteInstall.exe : Installer for Network Video Recorder VK-Lite*
LICENSE : Various license folder
BundledSoftware : Folder containing license terms for the software built into the camera*
OpenSourceSoftware : Folder containing license terms for the software bundled with the camera*
SOUND : Folder containing sample audio files
* Check our website for the latest versions of bundled software and operation manuals.
* For the latest information, please refer to Canon Web Site.
1. VB-C60 or VB-C60B Camera 2. Power connector 3. Rubber feet (4 pcs)
4. Setup CD-ROM 5. Start Guide (This document)
6. Warranty Card
Note
VB-C60B is a black model. Use VB-C60B if you want to install the camera using the optional
indoor dome housing (P. 1-22). You can reduce the reflection of the lens ring (periphery)
inside the shooting window of the camera.
COPY

ix
Checking of Bundled Items
Operation Manuals
The VB-C60 comes with Start Guide (this document) and Operation Guide included in the Setup
CD-ROM.
Also, Setup CD-ROM contains the VK-Lite (P. 1-7) of the simplified recording software. The
following operation manuals are available for VK-Lite.
Start Guide (This Document)
The safety precautions to be followed when using the VB-C60, types of bundled software,
operating environment, mounting method, initial setting of the camera, etc., are
explained.
Operation Guide (VBC60OG_E.pdf)
This document explains the basic setup procedure for the VB-C60, how to use VBAdmin
Tools and VB-C60 Viewer, troubleshooting, etc. Operation Guide can be found on the
Setup CD-ROM. References to Operation Guide will be given as follows.
Example: "Setting Menu" in Operation Guide
Setup Guide (VK22SUG_E.pdf)
The notes on use of VK-Lite, operating environment, system configuration, and installation
and setting methods are explained.
Administrator’s Manual (VK22AM_E.pdf)
This document explains details on how to use VK-Lite. Be sure to read this document.
Viewer Operation Guide (VK22VOG_E.pdf)
This document explains a basic operation of the VK-Lite viewer. For the detailed
operating procedures of the viewer, see Administrator’s Manual.
COPY

x
How to Read This Document
In Start Guide and Operation Guide, screens in Windows Vista are mainly used. Unless otherwise
specified, the same screens apply to Windows XP.
Symbols Used for Safety Precautions
The symbols used in this document are explained. This document uses the following symbols to
indicate the important information the user should know in order to use the product safely. Be sure
to observe these items.
Symbol Meaning
Warning
Inappropriate handling against the instruction accompanied by this
symbol may result in death or injury. Be sure to observe this
precaution to use the product safely.
Caution
Inappropriate handling against the instruction accompanied by this
symbol may result in injury. Be sure to observe this precaution to
use the product safely.
Note
Inappropriate handling against the instruction accompanied by this
symbol may result in property damage. Be sure to observe these
precautions.
This symbol indicates other action or item that requires
attention.
Supplementary information or a reference to the operation is
explained. Users are recommended to read these memos.
Note
Tip
COPY

xi
Safety Precautions
The following explains the items that must be observed when using the VB-C60.
If they are not observed, injury, death and/or property damage may occur. Read the following
information carefully and observe the instructions without fail.
Important Warnings
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The AC adapter can be connected to VB-C60 from a standard AC power outlet.
Please check your instruction manual to make sure that your VB-C60 is compatible
with this adapter.
• The socket-outlet should be installed near the equipment and should be easily
accessible.
• Unplug the equipment from the wall outlet before cleaning or maintaining.
FDA regulation
This Network Camera has not been evaluated by the Food and Drug Administration
(FDA) for use as a medical device. When incorporated into a system with medical
applications, FDA regulations may apply. Therefore, please consult your legal advisor
to determine whether FDA regulations apply.
COPY

xii
Safety Precautions
FCC NOTICE
Network Camera, Model Name: VB-C60
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with class B limits in Subpart B of Part 15
of FCC Rules.
Do not make any changes or modifications to the equipment unless otherwise
specified in the manual. If such changes or modifications should be made, you could
be required to stop operation of the equipment.
Canon U. S. A. Inc.
One Canon Plaza, Lake Success, NY 11042, U. S. A.
Tel No. [phone]
Canadian Radio Interference Regulations
This Class B digital apparatus complies with Canadian ICES-003.
COPY

xiii
Safety Precautions
Precautions for Installation
Warning
Do not install the product in the following places:
• Place receiving strong direct sunlight, near heat generating objects, or subject
to high temperature
• Place near fire sources or flammable solvents (alcohol, thinner, etc.)
• Humid or dusty place
• Place subject to lamp black or steam
• Place subject to sea wind
• Narrow, sealed place
Fire or electric shock may result.
Note
For installation or inspection of the VB-C60, consult/request the store where you
purchased the product.
• Wire the VB-C60 power supply, network, or other cables safely and securely
according to the relevant regulations such as technical standards for electrical
installations.
• When installing the VB-C60, select a ceiling surface, etc., capable of
withstanding the total weight of the camera and all options used (Recessed
Mounting Kit), provide sufficient reinforcements and use the bundled safety
wire if necessary.
• To prevent injuries and equipment damage due to falling items, periodically
check the brackets and screws for rusting and loosening.
• Installation in a place subject to significant vibration is not recommended,
because it may cause the equipment to malfunction.
• Do not hold the camera head when carrying the network camera.
• Do not install the VB-C60 on an unstable or inclined surface.
Malfunction may result.
COPY

xiv
Safety Precautions
Precautions for Use
Warning
• If smoke, abnormal noise, heat, odor or any other abnormality is detected,
immediately stop using the camera and contact your nearest Canon dealer.
Continuing to use the product may result in fire or electric shock.
• Do not disassemble or modify the camera.
• Do not put water or other liquid in the camera or splash or otherwise wet the
camera.
• Do not put foreign objects in the camera.
• Do not use sprays of flammable gases near the camera.
• When the camera is not used for a long period, disconnect the LAN cable,
external power supply and power connector for AC adapter (optional) from the
camera.
Fire or electric shock may result.
Note
• Do not use this camera for medical devices and other systems that affect human
life.
Delayed or missing image transmission may occur depending on the PC and
network environment, and thus high image transmission accuracy cannot be
assured.
Canon will assume no liability for any accident or damage resulting from use of
the VB-C60 in the aforementioned devices or systems.
• Do not capture the sun, halogen lamps and other very bright light sources or
subjects.
• Do not apply strong impact or vibration to the VB-C60.
Malfunction may result.
This installation should be made by a qualified service person and should
conform to all local codes.
COPY

xv
Safety Precautions
Notes on Use of Motion Detection, Stream for Recording and
Bundled Recording Software VK-Lite
Precautions for Use of Optional AC Adapter PA-V17
Notes on Cleaning
Note
• Avoid using Motion Detection, Stream for Recording or recording software
VK-Lite for surveillance where very high level of reliability is constantly
required.
These are support functions for monitoring. They do not guarantee monitoring with
very high accuracy, however, as they might not work as accurately as expected
under certain conditions. Canon will assume no liability for any accident or
damage resulting from use of these functions.
Warning
• Do not use any AC adapter or AC cable other than the dedicated AC adapter or
AC cable.
• Do not put heavy objects on the power cable.
• Do not pull, forcibly bend, scratch or modify the power cable.
• Do not cover or wrap the AC adapter (optional) with a cloth or thick cotton
blanket.
Fire or electric shock may result.
Be sure to read the operation manual for PA-V17 before use.
Warning
• Do not use alcohol, thinner, benzene or any other flammable solvent.
Fire or electric shock may result.
COPY

xvi
Safety Precautions
Maintenance
Turn off the power before cleaning the camera (P. 2-6).
Cleaning of Exterior
1. Dampen a soft cloth with water or diluted neutral detergent and wipe the soiled areas
gently.
2. Wipe with a dry cloth.
Cleaning of Lens
Use a commercial lens cleaner to remove soiling on the lens surface.
Auto focus may not work properly if the lens surface is dusty or dirty.
Scratches on the lens surface may result in undesirable images.
Maintenance for Indoor Dome Housing (Optional)
A soiled dome case is a cause of poor image quality, so clean the dome periodically.
1. Remove the dome by referring to steps 9 and 10 (P. 2-24) of the dome housing
installation procedure.
2. Dampen a soft cloth with water or diluted neutral detergent and wipe the soiled areas
gently.
3. Wipe with a dry cloth.
4. Install the dome by referring to steps 9 and 10 (P. 2-24) of the dome housing installation
procedure.
To prevent injuries and equipment damage due to falling items, periodically check the brackets
and screws for rusting and loosening.
For checkups, please contact the dealer where you purchased the product.
Maintenance for Ceiling Mount Cover (Optional)
To prevent injuries and equipment damage due to falling items, periodically check the brackets
and screws for rusting and loosening.
For checkups, please contact the dealer where you purchased the product.
COPY

Before Use
The following explains the features of this camera, bundled
software, operating environment, and name and function of each
part.
COPY

1-2
Features of VB-C60
The VB-C60 is a compact network camera integrating camera and server features.
Optical 40x Zoom Lens with Auto Focus and Pan and Tilt
functions
Equipped with a lens with optical 40x zoom (digital 4x), VB-C60 achieves video monitoring in
wide-ranging applications including in indoor locations such as stores and offices, as well as
in outdoor areas such as parking lots and plant facilities. Also, the auto focus function and the
pan and tilt functions that let you move the camera in left/right and up/down directions allow
for easy adjustment of viewing angle at the time of installation. These functions are also
convenient when the camera is operated remotely to monitor the condition.
High Quality Video of Moving Subjects
The VB-C60 utilizes a progressive-scan CCD to allow for the capture of noise-less, high
quality video of moving subjects.
Capturing Color Images at 0.7 lux and Day/Night Automatic
Switching
The camera can capture color images at the minimum subject illumination of 0.7 lux (1/30
sec.) Also, the day/night automatic switching function* ("Day/Night" in Operation Guide)
automatically switches the camera between the color mode during daytime when sufficient
light is available and the black & white mode during nighttime when it is dark, in order to
support video monitoring in locations where illumination changes.
* Before enabling day/night automatic switching, thoroughly check the operation.
Simultaneous Distribution of JPEG and MPEG-4
Video compression adopts JPEG/MPEG-4 to achieve high image quality/high frame rate of up
to 30 frames per second*1in VGA (640 x480). Up to 30 clients*2can view the same video
simultaneously.
*1 Note that the frame rate may drop depending on the performance of the viewer PC, number of clients
connected at the same time, network load, etc.
*2 In MPEG-4, up to 10 clients can be connected at the same time.
Multi-Streaming
In JPEG, image can be distributed in three sizes (640 x480, 320 x240, 160 x120) at the
same time.
Smart Shade Control
When the background is bright and the subject is difficult to see, you can change the contrast
of dark areas to make the subject clearer. Unlike the backlight compensation, blown out of the
background can be prevented because bright areas are not controlled. These processes are
implemented by the dedicated hardware in the camera, so drops in image quality can be
reduced and system load can be decreased compared to when the conventional shade
control is used. See "Setting the Smart Shade Control" (Operation Guide).
COPY

1-3
Features of VB-C60
1
1
Before Use
Image Stabilizer
This function compensates for shaking of image due to vibration when the camera is installed
on the ceiling, on a pole, etc. See "Camera Control" (Operation Guide).
* It does not work against significant vibration exceeding a certain level or momentary vibration. When
Image Stabilizer is used, the image quality drops and the viewing angle becomes smaller.
Install-Free VB-C60 Viewer
This camera has a built-in VB-C60 Viewer, so its data can be viewed using a browser.
Accordingly, there is no need to install a PC application. Also, three levels of user privileges
can be set, including [Administrator], [Authorized Users] and [Guest Users].
Selectable Metering Modes for Various Shooting Conditions
Images can be captured by switching the metering mode* to one of three options, including
[Center-weighted], [Average] and [Spot], according to the shooting condition of the camera.
See "Setting Exposure" (Operation Guide).
* Brightness (light quantity) of the subject is measured to adjust the exposure.
Upload and Sound Playback by Motion Detection Function
Change in video caused by movement of the subject is detected to upload the image and
play sound.
Upload, E-mail Notification
Events generated by the motion detection function or an external input device are used as
triggers to upload images temporarily recorded in the camera to the specified location via
FTP/HTTP/SMTP (e-mail), or for a notification to be sent via HTTP/SMTP (e-mail).
Panorama Image Creation
The entire shooting range of the camera can be captured as a panorama image, which can
then be registered in the camera and displayed on the viewer for visual camera control,
preset setting, etc.
Two-Way Audio (Full Duplex)
A microphone or speaker with amplifier can be connected*1to the camera to transmit/receive
audio (full duplex) via the viewer*2. You can select a desired audio input mode from LINE IN
and MIC IN by switching the setting on the Setting Page (P. 3-7).
*1 Microphones and amplifiers are sold separately.
*2 VK-Lite Viewer is the only viewer that supports two-way audio communication.
VB-C60 Viewer only supports audio reception.
COPY

1-4
Features of VB-C60
Supporting Upright and On-the-ceiling Installation
You can install the camera in a stationary state (upright) on a table or on a ceiling* (on the
ceiling) by changing the settings ("Installation Conditions" in Operation Guide).
* The camera cannot be installed in locations exposed to direct sunlight, high temperature, high humidity,
etc. (P. x i i i ) .
When installing the camera on a ceiling, use the optional indoor dome housing or ceiling mount cover
(P. 1-22).
PoE
The VB-C60 supports Power over Ethernet (PoE*) technology, which enables simultaneous
video/audio data transmission and power supply by simply connecting a PoE HUB and a
single LAN cable (P. 2-6). When connecting to a PoE HUB, you need not connect a power
adapter to the camera or perform any power wiring.
* PoE stands for Power over Ethernet. The camera is compliant with the IEEE 802.3af standard set by the
Institute of Electrical and Electronic Engineers.
Supporting Diverse Installation Applications
You can use the optional indoor dome housing or ceiling mount cover when installing the
camera on a ceiling (P. 1-22). The dome is available in two types: the smoke type that
conceals the camera, and the clear type that protects the camera from dust, etc., while
keeping the camera conspicuous.
Small-scale Video Monitoring by Simplified Recording Software
VK-Lite
This product comes with a simplified version VK-Lite of the optional Network Video
Recorder VK-64/VK-16 v2.2 (P. 1-7). Video captured by up to four cameras can be
recorded/displayed in real time, to achieve small-scale video monitoring.
COPY
