Cansec CanProx One User manual

CanProx One
INSTALLATION INSTRUCTIONS
(Reader)
August 2010

Table of Contents
Introduction...........................................................................................................................................................................3
Specifications........................................................................................................................................................................3
Reader Wiring.......................................................................................................................................................................4
Wall Mounting.......................................................................................................................................................................4
Mullion Mounting...................................................................................................................................................................5
Removing the Reader Cover.................................................................................................................................................6
Troubleshooting....................................................................................................................................................................6
© Cansec Systems Ltd., 2007
A
ll ri
g
hts reserved.
Page: 2/2
CanProx One Installation Instructions August 2010 Rev 2.6

Page: 3/3
CanProx One Installation Instructions August 2010 Rev 2.6
Introduction
The CanProx One proximity reader is mullion mountable and includes an adapter plate for wall mounting. Readers
have 26-bit and 37-bit Weigand output capability. Credentials for the Cansec/AWID-compatible reader (CA-CPIR)
include a standard, clamshell-style proximity card, ISO-thin proximity card – standard and magnetic stripe, Cansec’s
CanProx One proximity key fob, and the CanProx One dual-technology RF transmitter. (NOTE: the dual-
technology RF transmitter only works as a proximity credential with the CanProx One Reader.) Credentials for the
HID-compatible reader (CA-CP1RHID) include HID clamshell and graphics cards and the HID proximity key fob.
Read range varies between credentials and with input voltage.
Specifications*
Description: ...............................................................................................CanProx One multi-mount proximity reader
Available in AWID- and HID-compatible versions
Warranty: ........................................................Limited lifetime warranty against defects in material and workmanship
Operating Voltage: ....................................................................................................................................... 5 to 14 VDC
Current Draw: ...................................................................................................5 mA min., 45 mA typical, 80 mA max.
Output Format: ..........................................................................................................................26-bit & 37-bit Wiegand
Frequency: ........................................................................................................................................................... 125 KHz
Range: ............................................................................................up to 5” (varies with reader voltage and credentials)
Operating Temp: ......................................................................................................... -40 °C to 65 °C (-40 °F to 149 °F)
Dimensions:
Wall Mount: .....................................70mm (w) x 115mm (h) x 23mm (d) [2.8 in (w) x 4.5 in (h) x 1.0 in (d)]
Mullion Mount: .................................40mm (w) x 98 mm (h) x 17mm (d) [1.6 in (w) x 3.9 in (h) x 0.7 in (d)]
Weight: ................................................................................................................................................ approx. 85 g (3 oz)
Colour: ................................................................................................................................................................ Flat black
Housing: ................................................................................................................................................. High impact ABS
Mounting: ................................................................................................................................................ Wall or mullion
Environment: .......................................................................................................................................... Indoor/outdoor
Rated IP 67: ...........................................................................Sealed against dust; protection against powerful water jet
LED: ......................................................................................................................... Four-state (red, green, amber, off)
Beeper: ................................................................................................................................................................. Standard
Cable: .......................................... up to 7 conductors, 22 AWG, stranded, overall shield; 150 m (500 ft) max length

*Specifications subject to change without notice
Reader Wiring
Wall Mounting
1. Screw the adapter plate to a standard single gang electrical box.
2. Wire the reader module to the access control panel. Screw the reader module to the adapter plate.
3. Snap the reader cover on.
ADAPTER
PLATE
READER
MODULE
READER
COVER
Page: 4/4
CanProx One Installation Instructions August 2010 Rev 2.6

Mullion Mounting
1. The drawing on the right shows the respective
locations of each hole and their specific sizes for
mounting the reader module. Drill these holes
accordingly. For the screw holes, drill an
appropriate pilot hole for the screws you intend to
use.
CABLE FEED HOLE
7/8”
(22 mm)
SCREW
HOLE
SCREW
HOLE
1 13/16”
(
46 mm
)
13/16”
(
21 mm
)
39/64”
(16 mm)
35/64”
(14 mm)
2. Wire the reader module to the access control panel. Screw the reader module to the mullion.
3. Snap the reader cover on.
MULLION
READER
MODULE
READER
COVER
Page: 5/5
CanProx One Installation Instructions August 2010 Rev 2.6

Removing the Reader Cover
1. Insert a slotted screwdriver into the slot located at the bottom of the reader cover.
2. Gently pry the reader cover off.
Troubleshooting
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
The reader does not recognize
a card/tag (no beep, no LED
flash).
1. One or more of the readers’
wiring connections are incorrect. Power down the reader/access panel and check that your wiring is correct.
2. The reader is not receiving proper
power from the access panel. Measure the voltage at the reader. It should be between +5 VDC and +14 VDC.
3. The reader is mounted too close
to a device that radiates
electromagnetic interference.
If possible, install the readerin a different location or
move any other electronic devices away from the
reader.
4. You are using an incorrect type of
card. Make sure you are using an access card that is compatible with the reader.
The reader has a shortread
range. 1. The connection of the readers shield wire has opened somewhere. Check the shield line for openconnections. Make sure it is properly connected to the access panel.
2. The reader is mounted too close
to a device that radiateselectro-
magnetic interference.
If possible, install the readerin a different location or
move any other electronic devices away from the
reader.
3. The power supply is generating
electromagnetic interference. The power supply on the access panel must be a regulated, linear supply. Switching supplies are often
sources of electromagnetic interference.
CanProx One is compliant with the following organizations:
FCC compliance statement: This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference; and
(2) This device must accept any interference received, including interference that may cause undesired operation.
