Cansec MAP2 User manual

MAP2 Controller
INSTALLATION MANUAL
September 2020

MAP2 Page 2 of 32
Installation Manual September 2020 • Rev. 1.5
Table of Contents
Introduction ..................................................................................................................................................................3
Specifications..............................................................................................................................................................4
MAP2 Controller Layout..........................................................................................................................................7
Panel Installation...................................................................................................................................................... 10
Controller Power Connection.........................................................................................10
Entry Reader Wiring ........................................................................................................11
Entry and Exit Reader Wiring.........................................................................................12
Exit Button and Door Contact Wiring............................................................................12
Lock Output and Multi-Function Relay Wiring.............................................................15
Input and Output Point Wiring .......................................................................................17
Appendix......................................................................................................................................................................20
MAP2 System Indicators.................................................................................................21
Power Connector.............................................................................................................22
SHDN –Shutdown Button...............................................................................................23
IP Address Reset and Static IP Address Configuration..............................................23
USB IP Configuration Tool..............................................................................................26
Forced Entry Output........................................................................................................30
Door Held Open Output...................................................................................................30
Alarm Shunt Output.........................................................................................................30
Door Operator Output –All Cards.................................................................................31
Door Operator Output –Handicap Cards only.............................................................31
Copyright 2020 Cansec Systems Ltd.
All rights reserved.

MAP2 Page 3 of 32
Installation Manual September 2020 • Rev. 1.5
Introduction
Cansec Systems’MAP2 (Modular Access Panel) incorporates a mini-computer
called the Panel Logic Module (PLM) utilizing Ethernet connectivity and an Input
Output Module (IOM) which incorporates a 32-bit processor in this new
architecture. This allows for a fast, high capacity access control system with a lower
cost per reader/door system implementation. The MAP2 architecture has the ability
to flash applications and firmware updates into the control panel using the
Ethernet connection.
The standard MAP2 is provisioned with the default 2-door configuration. There are
two modes, First Access (application based) and CloudACS (cloud based). Door
configuration and mode can be upgraded. However, only one mode can be run at a
time and data cannot be shared between modes. The availability of the general-
purpose Input and Output points depends on the number of doors provisioned for
the controller. The MAP2 controller also supports elevator configurations.
The MAP2 allows for 100,000 individual cardholders, using raw Wiegand data up
to 64 bits per card ID. This allows the use of many proprietary Wiegand cards
without the need for data conversion. The readers can be Cansec’s CanProx One
Proximity Readers (AWID or HID card technology) or one of many other popular
Wiegand readers.
Note: Must have latest approved PLM and IOM firmware version for compatibility to this document.
255 Access Schedules
On board Triggers independent of host connection
Supports 100,000 individual user card IDs
Supports any Wiegand card (64 bit max.)
Supports up to 8 readers/door combinations
Supports Door Contact and RTE connection per reader/door
Supports general-purpose Input points (with or without supervision) and
Output points
Supports elevator configuration
Ease of future software/firmware upgrades
First Access mode or CloudACS mode
Key Features

MAP2 Page 4 of 32
Installation Manual September 2020 • Rev. 1.5
Specifications
See power supply notes in Appendix section for more information.
Suggested Power Supply
CA-EFLOW4N8D or CA-EFLOW6N8D or CA-EFLOW102N16D……. (see Appendix)
MAP2 Controller Power Requirements
Max. Current (including 8 proximity readers with 100 mA each)…..12VDC/1.5A
Temperature Range
Operating……………………………………………………………………………… 0˚C to 60˚C
Storage (without lithium battery) ……………………………………………-40˚C to 105˚C
Relative Humidity
Operating ………………………………………………………..……………………… 20% to 80%
Auto Resettable Fuses
MAP2 Main 12V DC………………………………………………………………………………1 A
Each Reader Pair ……………………………………………………………………………………1 A
Output Relays (See note 2 in Appendix section)
All Relays (16 per panel) Form ‘C’………..…………………………….SPDT 6 A @ 30 VDC
Inputs
Door Contact (8 per panel) ……………………………Requires normally closed contact
(On/Off door switch)
Exit Button (8 per panel) ………………..………………Requires normally open contact
(Momentary push button switch)
(M

MAP2 Page 5 of 32
Installation Manual September 2020 • Rev. 1.5
Communications and Reader Cable
RJ-45/Ethernet Cable……………………………………Standard CAT5/CAT6 cable
.....................................................................................................................
Wiegand Readers........................................ 6 conductor (twisted pair not required)
.............................................................................. 22 AWG, overall shield
........................................................................ 152 m [500 ft] max. Length
NOTE: Consult reader specifications as 12-gauge wire may be required for power.
Dimensions & Weight
MAP2 Controller……………….……………………………………………………..7” (L) x 7” (W)
[18 cm (L) x 18 cm (W)]
MAP2 Enclosure ……………………………………………..13” (W) x 19” (H) x 3 5/8” (D)
[33 cm (W) x 48 cm (H] x 9.2 cm (D)]
Controller Weight .............................................................................. 300 g [10.7 oz]
Enclosure Weight ............................................................................... 4.3 kg [9.6 lbs]
Note: Specifications subject to change without notice.
NOTE: Tech Support will only be provided where product installation guidelines
have been followed.

MAP2 Page 6 of 32
Installation Manual September 2020 • Rev. 1.5
Specification Notes
CAUTION: EMERGENCY LOCKDOWN
Emergency lockdown functions must operate totally independent of the access
control system and must not rely on operation of card readers, access control
panels, communications networks, communications devices or host software.
Cansec accepts no responsibility for direct or consequential damages resulting from
the failure of emergency lockdown functions which are dependant in any way on
the operation of card readers, access control panels, communications networks,
communications devices or host software.
Wiring Note:
Improper Wiegand cable (new or originally installed cable or missing required
shield connections) may result in high frequency noise on the data lines creating
misreads. This Wiegand misread issue is more evident on longer Wiegand reader
cables. The reader cable may have to be replaced with the correct type of Wiegand
reader cable to improve system reliability.
MAP2 and H1000 Connector Compatibility:
H1000 connectors can be used on the MAP2 controller. The wiring will have to be
adjusted to accommodate connector insertion by reading signal names on the
appropriate connectors.
Power Issue Indicator:
The controller continuously monitors the main 12 VDC coming into the controller.
In an error condition the onboard beeper sound will be as follow:
Low DC voltage (9 volts or less): 4 one-second beeps then a 2-second pause
High DC voltage (16 volts or higher): 4 half-second beeps then a 2-second pause.
The beep is continuous until the problem is resolved. Also, a message is sent to the
host software e.g. the First Access software shows event message like “DC Power
Low 9 Volts or Less”or “DC Power High 16 Volts or Higher”.

MAP2 Page 7 of 32
Installation Manual September 2020 • Rev. 1.5
MAP2 Controller Layout
Figure 1

MAP2 Page 8 of 32
Installation Manual September 2020 • Rev. 1.5
Important Installation Notes
Controller Provisioning Options:
The MAP2 controller is provisioned with the default 2-door configuration. However,
the door configuration can be upgraded. The MAP2 can run only in one mode either
First Access or CloudACS. Door configurations are as follow:
a. 2–door configuration: 2 lock relays, 2 multi-function relays, 2 REX/RTE, 2
door contacts/DPS, 12 general-purpose input points and 12 general-purpose
output points.
b. 4–door configuration: 4 lock relays, 4 multi-function relays, 4 REX/RTE, 4
door contacts/DPS, 8 general-purpose input points and 8 general-purpose
output points.
c. 6–door configuration: 6 lock relays, 6 multi-function relays, 6 REX/RET, 6
door contacts/DPS, 2 general-purpose input points and 2 general-purpose
output points.
d. 8–door configuration: 8 lock relays, 8 multi-fucntion relays, 8 REX/RET, 8
door contacts/DPS, 0 general-purpose input point and 0 general-purpose
output point.
Elevator Configuration: See MAP2 Elevator Controller Installation Guide
Electrical Information:
1. The MAP2 utilizes a mini-computer and must be operated using a battery
backed up power supply to protect the hardware, system files and data files
from corruption due to power outage. See Note 1 in Appendix section.
2. CAUTION: Do not unplug the
MAP2 Power connector if the
system is in operation as data
corruption may occur on the
MAP2 mini-computer. Please
follow the instructions from the
section “Shutdown Button”.
Figure 2

MAP2 Page 9 of 32
Installation Manual September 2020 • Rev. 1.5
3. The MAP2 allows for the control of up to 8 door combinations. Ensure that
adequate 12V DC power and current is available, especially when the same
power supply is used for the locks. See suggested power supplies in Appendix section.
4. It is highly recommended to use a separate power supply for locks as they
require a high amount of current for proper operation.
Network Information:
1. The MAP2 Controller is set to acquire an IP address automatically (DHCP).
However, it can be optionally set to a static IP address or reset if necessary. See
Appendix section for more information.
Mechanical Information:
1. If required, the MAP2 may be mounted inside of a lockable enclosure such as
the CA-MAP2ENCL if access is to be limited to the external connections.
2. If a Lockable external enclosure is used and a Tamper switch is available as in
the CA-MAP2ENCL, the
MAP2 has a Panel Tamper
input connection available.
Connecting the Tamper
switch to this input will
produce an Alarm when
opening and closing the
enclosure. This Alarm is sent
to the Host computer.
Figure 3
Figure 4

MAP2 Page 10 of 32
Installation Manual September 2020 • Rev. 1.5
Panel Installation
CONTROLLER POWER CONNECTION
Note: See Note 1 in Appendix section for suggested power supplies & backup battery.
The MAP2 requires an external battery backed-up 12 VDC power supply. However,
as many devices can be attached to the MAP2 controller, it may be more cost
effective to use a separate power supply (battery backed-up) just for the MAP2
Controller and a separate power supply which can be sized to supply the amount of
current that the attached high-current devices (locks) will require.
Figure 5
Mode Indicator: After a complete power up the BDSTAT LED on the main board flashes red. The STAT
LED on the PLM unit flashes green waiting for a host connection and stays steady green
when a connection is established. MAP2 emits beep to indicate its operating mode.
Reader LEDs reflect the number of doors provisioned for the controller.
1 Beep – First Access
3 Beeps – CloudACS
Note: Continuous beeps indicate power issue. Refer to
Power Issue section for more information

MAP2 Page 11 of 32
Installation Manual September 2020 • Rev. 1.5
ENTRY READER WIRING
The following diagram shows entry reader wiring only. For entry and optional exit
reader wiring diagram, proceed to the next section.
Figure 6

MAP2 Page 12 of 32
Installation Manual September 2020 • Rev. 1.5
ENTRY AND EXIT READER WIRING
EXIT BUTTON AND DOOR CONTACT WIRING
The MAP2 controller can be provisioned for up to 8 doors. The following shows the
input usage for each door combination.
Reader 1: uses Input 1 (Door Contact/DPS) and Input 2 (RTE/REX).
Reader 2: uses Input 3 (Door Contact/DPS) and Input 4 (RTE/REX).
Reader 3: uses Input 5 (Door Contact/DPS) and Input 6 (RTE/REX).
Reader 4: uses Input 7 (Door Contact/DPS) and Input 8 (RTE/REX).
Reader 5: uses Input 9 (Door Contact/DPS) and Input 10 (RTE/REX).
Reader 6: uses Input 11 (Door Contact/DPS) and Input 12 (RTE/REX).
Reader 7: uses Input 13 (Door Contact/DPS) and Input 14 (RTE/REX).
Reader 8: uses Input 15 (Door Contact/DPS) and Input 16 (RTE/REX).
Note: Both door contact and exit button inputs have voltage present on the circuits. Only
connect dry contact devices to these inputs.
Exit Reader:
*D1 (White) of exit reader
connects to D0 (Green) of
entry reader.
*D0 (Green) of exit reader
connects to D1 (White) of
entry reader.
Figure 7
Exit reader option must also be enabled in
the host software.

MAP2 Page 13 of 32
Installation Manual September 2020 • Rev. 1.5
Figure 8
Non-Supervised
The RTE/REX can be set to “Normally Open” or “Normally
Closed” from the host software

MAP2 Page 14 of 32
Installation Manual September 2020 • Rev. 1.5
Figure 9
Supervised
The RTE/REX can be set to “Normally Open” or “Normally
Closed” from the host software

MAP2 Page 15 of 32
Installation Manual September 2020 • Rev. 1.5
LOCK OUTPUT AND MULTI-FUNCTION RELAY WIRING
Electric Strike Lock Wiring –Up To 6 Amp, 30VDC MAX
The Multi-Function (MF) relay is configured by the user through the host software.
This relay can be set to only one of the following options:
Alarm Shunt –(factory default) Shunt the alarm system before opening lock.
Door Held Open –Door has been left open.
Forced Entry –Door opened without access-granted or exit-button-press event.
Door Operator_All –Activated on all cards (Lock Opens first).
Door Operator_HC –Activated on only Handicap cards (Lock Opens first).
DHO and Forced Entry –Activated on either DHO or Forced Entry.
Figure 10
See Note 2 in
Appendix section for
6 Amp relay rating

MAP2 Page 16 of 32
Installation Manual September 2020 • Rev. 1.5
Magnetic Lock Wiring –Up To 6 Amp, 30VDC MAX
IMPORTANT: In some jurisdictions, the use of a UL approved power supply and
connection to the fire alarm system for emergency release may be required. Installers
should contact the local authority having jurisdiction to verify the specific
requirements. Also, a building permit may be required in some jurisdictions for the
installation of magnetic locks.
Figure 11
See Note 2 in
Appendix section for
6 Amp relay rating
Note: A diode can
cause slow release of
the magnetic lock. It
is better to use a
MOV device. Some
magnetic locks have
built-in MOV devices;
in that case no diode
or additional MOV is
required. Check with
magnetic lock
supplier.
Note: See Electric Strike
Lock Wiring section for
explanation of MF relay
usage.

MAP2 Page 17 of 32
Installation Manual September 2020 • Rev. 1.5
INPUT AND OUTPUT POINT WIRING
General Layout
The MAP2 can be provisioned for all I/O which allows for 16 input points and 16
output points to be used. There is no door provisioned in this mode.
Figure 12

MAP2 Page 18 of 32
Installation Manual September 2020 • Rev. 1.5
The inputs can be individually set through the host software to be supervised or non-
supervised in future release. The default input setting is non-supervised. Supervised
input points require a Cansec CA-EOL resistor pack to be placed at the device being
monitored. Supervised input points will inform the host of 4 supervised states: Alarm ,
Secure , Trouble High and Trouble Low . These are the same 16 input points which
can be used with the door provisioning combinations, thus devices such as the Door
Contact and RTE/REX pushbutton can used in supervised mode of operation if
necessary.
Input Wiring –Supervised or Non-Supervised
Figure 13

MAP2 Page 19 of 32
Installation Manual September 2020 • Rev. 1.5
Output Wiring
Figure 14

MAP2 Page 20 of 32
Installation Manual September 2020 • Rev. 1.5
Appendix
Note 1: Suggested Power Supplies & Backup Battery
Part Number
Dimension & Weight
H x W x D approx.
Description
CA-EFLOW4N8D
(battery not included)
Accommodates up to two
(2) 12VDC/7AH batteries.
13.5” x 13” x 3.25”
(342.9mm x 330.2mm x
82.55mm)
6.7 lbs. (3.04 kg)
12/24 VDC selectable output,
4 Amp Enclosure Style Power
Supply with Backup Battery
Charger. Eight individual class
2 rated power limited outputs
rated at 2 Amp. Input 120
VAC, 60 Hz, 3.5 Amp. UL
listed.
CA-EFLOW6N8D
(battery not included)
Accommodates up to two
(2) 12VDC/7AH batteries.
13.5” x 13” x 3.25”
(342.9mm x 330.2mm x
82.55mm)
6.65 lbs. (3.02 kg)
12/24 VDC selectable output,
6 Amp Enclosure Style Power
Supply with Backup Battery
Charger. Eight individual
Class 2 rated power limited
outputs rated at 2 Amp per
output. Input 120 VAC, 60
Hz, 3.5 Amp. UL listed.
CA-EFLOW102N16D
(battery not included)
Accommodates up to two
(2) 12VDC/7AH batteries.
13.5” x 13” x 3.25”
(342.9mm x 330.2mm x
82.55mm)
6.85 lbs. (3.11 kg)
12 VDC, 10 Amp Enclosure
Style Power Supply with
Backup Battery Charger.
Sixteen individual Class 2
rated power limited outputs
rated at 2 Amp per output.
Input 120 VAC, 60 Hz, 3.5
Amp. UL listed.
PA-SLP003
3.63” x 5.88” x 2.5”
(92.20mm x 149.35mm
x 63.50mm)
5.00 lbs (2.27 kg)
Backup Battery 12 VDC 7
Amp Hour. Provides hours of
backup power for above power
supplies.
