Introduction
Cansec Systems’MAPMINI (Modular Access Panel Mini) incorporates a mini-
computer called the Panel Logic Module (PLM) utilizing Ethernet connectivity and
an Input Output Module (IOM) which incorporates a 32-bit processor in this new
architecture. This allows for a fast, high capacity access control system with a lower
cost per reader/door system implementation. The MAPMINI architecture has the
ability to flash applications and firmware updates into the control panel using the
Ethernet connection.
The standard MAPMINI is provisioned for only one door. There are three modes,
First Access (application based), Webster (web based) and CloudACS (cloud based).
The mode can be upgraded. Only one mode can be run at a time and data cannot
be shared between modes. The availability of the general-purpose Input and Output
points depends on the number of doors provisioned for the controller.
The MAPMINI allows for 100,000 individual cardholders, using raw Wiegand data
up to 64 bits per card ID. This allows the use of many proprietary Wiegand cards
without the need for data conversion. The readers can be Cansec’s CanProx One
Proximity Readers (AWID or HID card technology) or one of many other popular
Wiegand readers.
Note: Must have latest approved PLM and IOM firmware version for compatibility to this document.
255 Access Schedules
On board Triggers independent of host connection
Supports 100,000 individual user card IDs
Supports any Wiegand card (64 bit max.)
Supports one reader/door
Supports Door Contact and RTE connection
Supports Input points (with or without supervision) and Output
points
Ease of future software/firmware upgrades
First Access mode or Webster mode or CloudACS mode
Key Features

MAPMINI Page 4 of 28
Installation Manual September 2021 • Rev. 1.4
Specifications
See power supply notes in Appendix section for more information.
Suggested Power Supply
CA-EFLOW4N8D or CA-EFLOW6N8D or CA-EFLOW102N16D……. (see Appendix)
MAPMINI Controller Power Requirements
Max. Current (including 1 proximity reader with 100 mA)…..12VDC/1A
Temperature Range
Operating……………………………………………………………………………… 0˚C to 60˚C
Relative Humidity
Operating ………………………………………………………..……………………… 20% to 80%
Auto Resettable Fuses
MAPMINI Main 12V DC…………………………………………………………………………1 A
Reader Pair (Entry & Exit) ………………………………………………………………………1 A
Output Relays (See note 2 in Appendix section)
All Relays (2 per panel) Form ‘C’………..…………………………….SPDT 6 A @ 30 VDC
Inputs
Door Contact (1 per panel) ……………………………Requires normally closed contact
(On/Off door switch)
Exit Button (1 per panel) ………………..………………Requires normally open contact
(Momentary push button switch)
(M

MAPMINI Page 5 of 28
Installation Manual September 2021 • Rev. 1.4
Communications and Reader Cable
RJ-45/Ethernet Cable……………………………………Standard CAT5/CAT6 cable
.....................................................................................................................
Wiegand Readers........................................ 6 conductor (twisted pair not required)
.............................................................................. 22 AWG, overall shield
........................................................................ 152 m [500 ft] max. Length
NOTE: Consult reader specifications as 12-gauge wire may be required for power.
Dimensions & Weight
MAPMINI Controller………….……………………………4.6” (W) x 3.35” (L) x 1.5” (D)
[11.6 cm (W) x 8.5 cm (L) x 3.8 cm D)]
MAPMINI Enclosure …………………………………………..9.5" (W) x 13" (L) x 3" (D)
[24.0 cm (W) x 33.0 cm (L) x 7.5 cm (D)]
Controller Weight ................................................................................ 183 g [6.5 oz]
Enclosure Weight ............................................................................... 2.0 kg [4.5 lbs]
Note: Specifications subject to change without notice. Tech Support will only be
provided where product installation guidelines have been followed.

MAPMINI Page 6 of 28
Installation Manual September 2021 • Rev. 1.4
Specification Notes
CAUTION: EMERGENCY LOCKDOWN
Emergency lockdown functions must operate totally independent of the access
control system and must not rely on operation of card readers, access control
panels, communications networks, communications devices or host software.
Cansec accepts no responsibility for direct or consequential damages resulting from
the failure of emergency lockdown functions which are dependant in any way on
the operation of card readers, access control panels, communications networks,
communications devices or host software.
Wiring Note:
Improper Wiegand cable (new or originally installed cable or missing required
shield connections) may result in high frequency noise on the data lines creating
misreads. This Wiegand misread issue is more evident on longer Wiegand reader
cables. The reader cable may have to be replaced with the correct type of Wiegand
reader cable to improve system reliability.
Power Issue Indicator:
The controller continuously monitors the main 12 VDC coming into the controller.
In an error condition the onboard beeper sound will be as follow:
Low DC voltage (9 volts or less): 4 one-second beeps then a 2-second pause
High DC voltage (16 volts or higher): 4 half-second beeps then a 2-second pause.
The beep is continuous until the problem is resolved. Also, a message is sent to the
host software e.g. the First Access software shows event message like “DC Power
Low 9 Volts or Less”or “DC Power High 16 Volts or Higher”.

MAPMINI Page 7 of 28
Installation Manual September 2021 • Rev. 1.4
MAPMINI Controller Layout
Figure 1

MAPMINI Page 8 of 28
Installation Manual September 2021 • Rev. 1.4
Important Installation Notes
Controller Provisioning Options:
The MAPMINI controller is provisioned with the default 1-door configuration. The
MAPMINI can run only in one mode either First Access,Webster or CloudACS. The
MAPMINI can be provisioned in one of the two options below:
1. Door controller Mode
1–door configuration: 1 lock relay, 1 multi-function relay, 1 REX/RTE, 1 door
contact/DPS (Door Position Switch).
2. Input and Output controller Mode
2 general-purpose input points and 2 general-purpose output points available.
No door combination i.e. no lock relay and no multi-function relay.
Electrical Information:
1. The MAPMINI utilizes a mini-computer and must be operated using a battery
backed up power supply to protect the hardware, system files and data files
from corruption due to power outage. See Note 1 in Appendix section.
2. CAUTION: Do not unplug the MAPMINI Power connector if the system is in
operation as data corruption may occur on the MAPMINI mini-computer.
Please follow the instructions from the section “Shutdown Button”.
3. Ensure that adequate 12V
DC power and 1A of current
is available, especially when
the same power supply is used
for the locks. See suggested
power supplies in Appendix section.
4. It is highly recommended to use a separate power supply for locks as they
require a high amount of current for proper operation.
Figure 2

MAPMINI Page 9 of 28
Installation Manual September 2021 • Rev. 1.4
Network Information:
1. The MAPMINI Controller is set to acquire an IP address automatically
(DHCP). However, it can be optionally set to a static IP address or reset if
necessary. See Appendix section for more information.
Mechanical Information:
1. If required, the MAPMINI may be mounted inside of a lockable enclosure
such as the CA-SLBOX if access is to be limited to the external connections.
Figure 3

MAPMINI Page 10 of 28
Installation Manual September 2021 • Rev. 1.4
Panel Installation
CONTROLLER POWER CONNECTION
Note: See Note 1 in Appendix section for suggested power supplies & backup battery.
The MAPMINI requires an external battery backed-up 12 VDC power supply.
However, it may be more cost effective to use a separate power supply (battery
backed-up) just for the MAPMINI Controller and a separate power supply which
can be sized to supply the amount of current that the attached high-current device
e.g. lock will require.
Figure 5
Mode Indicator: After a complete power up the SHUTDN LED on the unit flashes green waiting for a
host connection and stays steady green when a connection is established. MAPMINI
emits beep to indicate its operating mode.
1 Beep – First Access
2 Beeps – Webster
3 Beeps – CloudACS
Note: Continuous beeps indicate power issue. Refer to
Power Issue section for more information

MAPMINI Page 11 of 28
Installation Manual September 2021 • Rev. 1.4
ENTRY READER WIRING
The first diagrams show entry reader wiring only. The second diagram shows optional
exit reader wiring along with the entry reader.
ENTRY AND EXIT READER WIRING
Figure 6
Exit Reader:
*D1 (White) of exit reader
connects to D0 (Green) of
entry reader.
*D0 (Green) of exit reader
connects to D1 (White) of
entry reader.
Figure 7
Exit reader option must also be enabled in
the host software.
To avoid
electrical noise,
exit reader
wires should
piggyback on
the entry reader
wires leaving
just one set of
wires connected
to the reader
port.

MAPMINI Page 12 of 28
Installation Manual September 2021 • Rev. 1.4
EXIT BUTTON AND DOOR CONTACT WIRING
Note: Both door contact and exit button inputs have voltage present on the circuits. Only
connect dry contact devices to these inputs.
Figure 8
Figure 9
The RTE/REX
can be set to
“Normally Open”
or “Normally
Closed” from the
host software

MAPMINI Page 13 of 28
Installation Manual September 2021 • Rev. 1.4
LOCK OUTPUT AND MULTI-FUNCTION RELAY WIRING
Electric Strike Lock Wiring –Up To 6 Amp, 30VDC MAX
The Multi-Function (MF) relay is configured by the user through the host software.
This relay can be set to only one of the following options:
Alarm Shunt –(factory default) Shunt the alarm system before opening lock.
Door Held Open –Door has been left open.
Forced Entry –Door opened without access-granted or exit-button-press event.
Door Operator_All –Activated on all cards (Lock Opens first).
Door Operator_HC –Activated on only Handicap cards (Lock Opens first).
DHO and Forced Entry –Activated on either DHO or Forced Entry.
Figure 10
See Note 2 in Appendix section for 6 Amp relay rating

MAPMINI Page 14 of 28
Installation Manual September 2021 • Rev. 1.4
Magnetic Lock Wiring –Up To 6 Amp, 30VDC MAX
IMPORTANT: In some jurisdictions, the use of a UL approved power supply and
connection to the fire alarm system for emergency release may be required. Installers
should contact the local authority having jurisdiction to verify the specific
requirements. Also, a building permit may be required in some jurisdictions for the
installation of magnetic locks.
Figure 11
See Note 2 in
Appendix section for
6 Amp relay rating
Note: A diode can cause slow
release of the magnetic lock. It is
better to use a MOV device. Some
magnetic locks have built-in MOV
devices; in that case no diode or
additional MOV is required. Check
with magnetic lock supplier.
Note: See Electric Strike Lock Wiring section
for explanation of MF relay usage.

MAPMINI Page 15 of 28
Installation Manual September 2021 • Rev. 1.4
INPUT AND OUTPUT POINT WIRING
The MAPMINI can be provisioned for all I/O which allows for 2 input points and 2
output points to be used. There is no door provisioned in this mode.
Input Wiring –Supervised or Non-Supervised
Figure 12

MAPMINI Page 16 of 28
Installation Manual September 2021 • Rev. 1.4
Output Wiring
Figure 13

MAPMINI Page 17 of 28
Installation Manual September 2021 • Rev. 1.4
Appendix
Note 1: Suggested Power Supplies & Backup Battery
Part Number
Dimension & Weight
H x W x D approx.
Description
CA-EFLOW4N8D
(battery not included)
Accommodates up to two
(2) 12VDC/7AH batteries.
13.5” x 13” x 3.25”
(342.9mm x 330.2mm x
82.55mm)
6.7 lbs. (3.04 kg)
12/24 VDC selectable output,
4 Amp Enclosure Style Power
Supply with Backup Battery
Charger. Eight individual class
2 rated power limited outputs
rated at 2 Amp. Input 120
VAC, 60 Hz, 3.5 Amp. UL
listed.
CA-EFLOW6N8D
(battery not included)
Accommodates up to two
(2) 12VDC/7AH batteries.
13.5” x 13” x 3.25”
(342.9mm x 330.2mm x
82.55mm)
6.65 lbs. (3.02 kg)
12/24 VDC selectable output,
6 Amp Enclosure Style Power
Supply with Backup Battery
Charger. Eight individual
Class 2 rated power limited
outputs rated at 2 Amp per
output. Input 120 VAC, 60
Hz, 3.5 Amp. UL listed.
CA-EFLOW102N16D
(battery not included)
Accommodates up to two
(2) 12VDC/7AH batteries.
13.5” x 13” x 3.25”
(342.9mm x 330.2mm x
82.55mm)
6.85 lbs. (3.11 kg)
12 VDC, 10 Amp Enclosure
Style Power Supply with
Backup Battery Charger.
Sixteen individual Class 2
rated power limited outputs
rated at 2 Amp per output.
Input 120 VAC, 60 Hz, 3.5
Amp. UL listed.
PA-SLP003
3.63” x 5.88” x 2.5”
(92.20mm x 149.35mm
x 63.50mm)
5.00 lbs (2.27 kg)
Backup Battery 12 VDC 7
Amp Hour. Provides hours of
backup power for above power
supplies.

MAPMINI Page 18 of 28
Installation Manual September 2021 • Rev. 1.4
Note 2: 6 Amp Relay Rating
Maximum current that can be switched reliably when connected to a ‘non-inductive load’ up to
30VDC. Electric strikes and magnetic locks are considered ‘inductive loads’. It is important to
have diode or MOV attached at the locking device to remove the CEMF pulse that is generated
when switching an ‘inductive load’. It is advisable to use a 50% switch factor or 3 amps as the
maximum switching current for longer relay life. An external relay should be used on larger
voltage and current requirements.
MAPMINI SYSTEM INDICATORS
12VDC POWER LED: ON indicates 12 volts DC is connected.
First Access Mode:
Mode indicator: MAPMINI emits 1 beep after powered up.
Webster Mode:
Mode indicator: MAPMINI emits 2 beeps after powered up.
CloudACS Mode:
Mode indicator: MAPMINI emits 3 beeps after powered up.
SHDN LED:
Flashing GREEN –PLM (Panel Logic Module) is waiting for a connection from
the host via Ethernet.
Steady GREEN –PLM (Panel Logic Module) is connected to a host via
Ethernet.
OFF –PLM (Panel Logic Module) is powered off.
IMPORTANT: In some jurisdictions, the use of a UL approved power supply and
connection to the fire alarm system for emergency release may be required. Installers
should contact the local authority having jurisdiction to verify the specific
requirements. Also, a building permit may be required in some jurisdictions for the
installation of magnetic locks.

MAPMINI Page 19 of 28
Installation Manual September 2021 • Rev. 1.4
POWER CONNECTOR
SHUTDN –SHUTDOWN BUTTON
As the MAPMINI contains a mini computer, a proper system shutdown is nesscessary
to prevent data corruption. DO NOT simply unplug the power connector. To shut
down follow this procedure:
1. Press and hold (4 to 8 seconds) the
SHUTDN button until the status
SHDN LED near the SHUTDN
button begins a rapid green
ON/OFF flash then release the
pushbutton. The system will start a
proper shutdown. This will take 15
to 20 seconds.
2. Wait untill the status SHDN LED (except power) and the reader LEDs are off
with a single beep from the controller then remove the power connector.
3. If the shutdown does not occur, try the procedure again. If it still does not
respond correctly as described above, a system fault has occurred. It will be
necessary to unplug the power connector and re-insert it after 10 seconds.
Figure 14
Figure 15

MAPMINI Page 20 of 28
Installation Manual September 2021 • Rev. 1.4
IP ADDRESS RESET AND STATIC IP ADDRESS CONFIGURATION
Note: The new panel is factory set to acquire an IP address automatically (DHCP). If the IP
address has been changed to static address by an installer but now unknown or
forgotten and needs to be reset, follow the instructions below.
It’s highly suggested to leave it for DHCP mode. The controller will obtain
IP address automatically from the DHCP server. Alternatively s ee USB IP
Configuration Tool section for configuring IP Address using a USB flash
drive.
1. Press and hold (4 to 8 seconds)
the IP Reset pushbutton. Wait
until the internal MAPMINI
beeper sounds then release the
button. Beeper stops sounding.
2. The system will reboot. This will take 20 to 45 seconds after which the
controller will reset all of its configurations to factory default with DHCP
enabled. Existing database will not be reset or erased.
3. Note: The end of the reboot cycle is indicated by a MAPMINI turning back on
the associated system LEDs, and at the end it will emit a series of beeps to
indicate its mode e.g. First Access, Webster or CloudACS.
Note: The end of the process is indicated by a MAPMINI turning back on the associated
system LEDs with SHDN LED flashing green along with a short series of beeps (1 or 2 or
3 beeps) to indicate its respective provisioned mode First Access, Webster or
CloudACS.
4. Plug the MAPMINI to the network with a DHCP server available.
5. Install and launch IP Configuration Tool from your computer. This tool is
available from the First Access software installation package, but is also available
as its own separate installation package which can be downloaded from
www.cansec.com/downloads.
Figure 16
