Quick Guide - V5 / V8 OXYGEN CONCENTRATOR USER GUIDE AND MAINTENANCE –Page 1
V5 / V8 OXYGEN CONCENTRATOR FRONT VIEW
Control Panel
ALARMS
Power off alarm sound:
Concentrator connected with power but the unit is in a
state of power off with alarm sound.
Check the power cord for good connection or that the
external power supply has been turned on.
Oxygen purity alarm sound:
Alarm will sound in addition to red indicator light if
oxygen concentration purity % drops.
Alarm Coding:
10000 –overheat warning
02000 –Valve Defective Warning
00300 –over pressure warning (blockage)
00040 –low pressure warning (leakage)
CONTROL PANEL
Display screen
Reset button Oxygen flow valve
Indicator lights
Stop clock/Timer buttons
INDICATOR LIGHTS
Oxygen purity
Green – Optimal
Red – Oxygen
purity % drops
Trouble indicator
Off - Working good
Red - Defective
Power indicator
Green –Power on
Red –Power off
alarm
DO NOT USE STOP CLOCK/TIMER BUTTONS
OXYGEN FLOW CONTROL VALVE
OXYGEN OUTLET
On/off Switch
Oxygen outlet
Humidifier bottle Concavity
V5: 0-5 l/min
V8: 0-8 l/min
Setting flow rate:
Turn the flow control valve:
Counter-clockwise: on
Clockwise: off
Oxygen tubing
Connect nasal
cannula/Mask direct to
oxygen outlet or via the
humidifier bottle if in
use.
MESU
DO NOT OVER TIGHTEN FLOW VALVE KNOB WHEN CLOSING!
DO NOT TAKE THE FLOW VALVE BALL TOO HIGH ABOVE THE
MAXIMUM NUMBER SHOWN!

Quick Guide - V5 / V8 OXYGEN CONCENTRATOR USER GUIDE AND MAINTENANCE –Page 2
V5 / V8 OXYGEN CONCENTRATOR REAR VIEW
Air Inlet Filter access panel
Exhaust Power cord
(under base of unit)
AIR-INTAKE FILTER ACCESS PANEL
DUST FILTER
AIR -INTAKE FILTER
The Air-intake filter needs to be replaced after every
1000 hours of use or annually (whichever comes first
for the first change). For subsequent filter changes the
device will have a label indicating total working hours
required before the next filter change. The device
needs returning to MESU for the filter changes.
During home use a replacement air-intake filter is
available from MESU.
HUMIDIFIER BOTTLE
Humidifier bottles are single patient use.
Bottles must be cleaned daily with soap and water.
Y TUBE CONNECTOR
The dust filter is located on
the rear of the Filter access
panel door.
The Dust filter can be cleaned
with mild detergent and water,
rinse to remove all residues and
air dry.
The dust filter should be
inspected every 2 weeks and
replaced when it is visibly dusty.
The white air-intake filter is
located in the air-intake
filter compartment via the
access panel.
Dust Filter
Air-intake
filter
Fill with distilled
water only.
Water must be kept
between Maximum
and minimum scale
line
Change the water
every 24hrs
Administer 15lpm from 2 x V8s
