Canvas STRETCH MASTER PLUS MULTIGUN User manual

STRETCH MASTER PLUS :: MULTIGUN
MODEL: STRETCH MASTER PLUS MULTIGUN
Stretching Size: 1m x 1m
Part N : SMPM40

STRETCH MASTER PLUS ::: MULTIGUN
USER GUIDE
Now that the machine is set up and ready to use, here are the functions of the machine and how
to use them correctly ...
1. This lever activates the clamps and is the first lever you hit when stretching.
2. This lever operates the stretching cylinders and is the second lever you hit when stretching.
3. This button actives the inner staple guns.
4. This button actives the outer staple guns
5. This nob regulates the clamps.
1
2
3
4
5

USER GUIDE
6. Now that the machine is assembled, it is time to set it up for use.
7. Connect a line from your air compressor into the bac of the control panel.
8. Ma e sure hands are away from the machine and turn the air on.
9. The top lever on the control panel is to operate your grippers.
10. The bottom lever on the control panel is to operate your stretching arms.
Adjustments:
A few adjustments will have to be made to the machine before use. These are user specific
adjustments and will not be required to be done on a regular basis.
Frame Height Adjustment:
Your frame must be level with the bar as pictured above. The adjust the frame height turn the bolt
which is located under the table top as pictured:

STRETCH MASTER MULTIGUN
STRETCHING OUR CANVAS
11. Place your canvas and frame ready to be stretched into the machine.
12. Move the left hand stretching arm until it touches the frame and using the pneumatic bra e
to loc the arm to eep it in place. This is located at the end of the left stretching arm
13. Place the canvas between the grippers on both sides of the machine.
14. Activate the CLAMP switch followed by the STRETCH switch.
There must always be some canvas left in the grippers to achieve the perfect stretch.
15. Now press the Inner Staples switch to release the staples.
16. Once this has been done push the stretch switch bac up followed by the clamp switch to
release the canvas and release pneumatic bra e.
17. Remove frame and canvas and fold the corners and then insert bac into the machine
repeating steps 13 & 14.
18. Once the second side has been stretched now staple with the Inner Staple & Outer Staple
switches, depressing both at the same time.
Pneumatic
Brake
