Capillus CAPILLUS82 Operator's manual

USER INSTRUCTION MANUAL
MODELS: CAPILLUS82™ / CAPILLUS202™ / CAPILLUSPRO™ / CAPILLUSRX™
© 2017 Capillus, LLC. All rights reserved.

IMPORTANT SAFETY INSTRUCTIONS
When using this device, basic safety precautions should always be followed, including the following:
SAVE THESE INSTRUCTIONS. PLEASE READ ALL
INSTRUCTIONS BEFORE USING
Please read all instructions before using your Capillus®device. Please keep this user manual for
future reference and be sure to follow all warning and safety information included herein. If you have
any questions regarding operation, please contact Capillus Customer Service toll-free at 1 (888)
272-9599 or via email at [email protected].
1. DO NOT STARE DIRECTLY AT LASER LIGHT OR ITS REFLECTION FOR EXTENDED PERIODS.
PROLONGED EYE EXPOSURE CAN CAUSE EYE DAMAGE.
2. Use this device only for its intended use and according to the instructions provided. Any other
use may result in injury.
3. To protect against the risk electric shock, do not immerse the appliance in water or other
liquids. Do not place or store the unit where it can fall or be pulled into a tub or sink.
4. If the unit accidentally falls into water or other liquid, unplug it from the electrical outlet imme-
diately. DO NOT REACH INTO OR TOUCH THE WATER.
5. Always connect the plug into outlet rst, then attach the power supply to the unit. Always un-
plug the power adapter from the power outlet immediately following charge. The battery pack
should always be turned off when connecting/disconnecting from power supply.
6. Do not operate the device when it or any of its components are damaged, or if the battery
pack or power supply have been dropped or damaged. To avoid the risk electric shock, do not
disassemble any part of the appliance or its accessories. Contact Capillus Customer Service
for examination and repair.
7. This device is not intended for use by persons (including children) with reduced physical, sen-
sory, or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the device by a person responsible for their safety.
8. Children should be supervised to ensure that they do not play with the device or its accessories
and components. Do not leave the device unattended while connected to battery pack.
9. Conditions that will void warranty: a) Commercial use, b) inappropriate use, c) failure to comply
with the instructions, d) connecting your battery pack to the dome incorrectly as this may cause
irreparable damage.
10. If the power supply is damaged, contact Capillus for replacement to avoid electrical hazard or
damage.
11. Do not adjust or modify the device as this may result in hazardous radiation exposure. Do not
use any power adapters or other sources of power, other than that provided with the device.
Use only the power supply provided with the device.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
1

TABLE OF CONTENTS
Important Safety Instructions .............................................................................. 1
Corporate Information.......................................................................................... 3
Regulatory Compliance ........................................................................................ 3
About the Capillus®Laser Therapy Cap .............................................................. 4
•Introduction - About the Device™
•Indications for Use
•Is Capillus Laser Therapy Right for You?
•Intended Usage
•Frequency of Use
•Duration of Use
What’s Included .................................................................................................. 5
Instructions for Charging Battery Pack ................................................................. 5
Instructions for Use ............................................................................................. 6
Safety Labels....................................................................................................... 7
Precautions ......................................................................................................... 7
Maintenance Instructions .................................................................................... 7
Operating & Storage Information.......................................................................... 7
Warranty.............................................................................................................. 7
Troubleshooting .................................................................................................. 8
Capillus®Laser Therapy Cap Specications ......................................................... 8
CORPORATE INFORMATION
Capillus, LLC
1715 NW 82 Ave., Miami, FL 33126
Toll-Free USA: 1 [phone]
Phone: [phone]
Email: [email protected]
Website: www.capillus.com
Capillus and the Capillus logo are trademarks of Capillus, LLC registered in the USA and other
countries. Patents Pending. Capillus lasers devices are made in the USA from foreign-source
raw materials. All product information and articles are intended to be for informational
purposes only.
REGULATORY COMPLIANCE
Capillus, LLC lasers comply with 21 CFR 1040 for Class 3R Laser Products as administered
by the Center for Device and Radiological Health of the US Food and Drug Administration and
standard IEC60825 of the International Electrotechnical Commission.
ISO13485:2003: Canada : Medical Devices Regulations – Part 1- SOR
98/282 and United States : 21 CFR 820, 21 CFR 803, 21 CFR 806, 21 CFR
807 (Subparts A to D). The scope of the audit encompasses the design and
development, manufacture, service, and support of devices utilizing laser
diodes for hair (re)growth promotion.
3

ABOUT THE CAPILLUS®LASER THERAPY CAP
The Capillus®laser therapy cap is a portable home-use Low-Level Laser Therapy (LLLT) device. The
device features a laser dome embedded with laser diodes (<5mW) on its interior surface, and is
powered by a certied rechargeable battery pack that connects to the dome. The laser dome is either
worn under the sports cap included with the device or any other hat of your choosing. The battery pack
can be clipped onto your waistband or belt, or slipped into your pocket. The Capillus®laser therapy cap
provides low-level laser therapy to the scalp and hair follicles to stimulate cellular activity and promote
the ow of blood. There is no need for constant user effort. The hands-free design makes it easy and
comfortable to use while performing everyday activities.
INDICATIONS FOR USE
The Capillus®laser therapy cap is intended to treat Androgenetic Alopecia and promote hair growth in
males who have Norwood Hamilton Classications of IIa-V patterns of hair loss, and to treat Androge-
netic Alopecia and promote hair growth in females who have Ludwig (Savin) scale Classications I-1 to
I-4, II-1, or frontal patterns of hair loss; both with Fitzpatrick Skin Types I to IV.
IS CAPILLUS LASER THERAPY RIGHT FOR YOU?
If your hair loss is due to heredity, Capillus laser therapy may be a great treatment option for you.
Hair loss is a serious issue that affects millions of men and women around the world. The most
common type of hair loss is a result of your genes: androgenetic alopecia (pattern baldness). It’s a
progressive condition (worsens over time) and constitutes 98% of hair loss. If you begin treatment
during the earlier stages of progression, the Capillus® laser therapy cap may stop further progression
and regrow your thinning hair.
Capillus is intended for treatment of adults with hair loss represented within the shaded areas
below.
Fitzpatrick Classication of Skin Types
Low-Level Laser Therapy has only been tested on following Fitzpatrick skin types:
TYPE 1: Highly sensitive, always burns, never tans.
TYPE 2: Very sun sensitive, burns easily, tans minimally.
TYPE 3: Sun sensitive skin, sometimes burns, slowly tans to light brown.
TYPE 4: Minimally sun sensitive, burns minimally, always tans to moderate brown.
Low-Level Laser Therapy has NOT been clinically tested on following Fitzpatrick skin types:
TYPE 5: Sun insensitive skin, rarely burns, tans well.
TYPE 6: Sun insensitive, never burns, deeply pigmented.
INTENDED USAGE
•The Capillus®device should be used only for the purpose described in this manual.
•The Capillus®device is intended for use on the human scalp only. Any other use is not
recommended.
FREQUENCY OF USE
The Capillus®laser therapy caps should be used every day. The total time of each session is 6
minutes. Exceeding the recommended times or frequency will not increase the effect of the device; and
may in fact cause a negative effect. Do not exceed recommended usage.
DURATION OF USE
Although you should see signicant results within 4 months, the Capillus®device may be used
indenitely according to the instructions above. Cessation of use may result in loss of new hair growth.
I-1 III
MALE HAIR LOSS CLASSIFICATIONFEMALE HAIR LOSS CLASSIFICATION
IIII-4
I-3
II-2 IIIa III-vertex
IV IVa V
Va VI VII
IIa
FrontalIII
I-2
II-1
Advanced
4

Capillus®Laser Therapy Device
Rechargeable Lithium-Ion Battery Pack
Adhesive Belt Clip for Battery Pack
Universal AC Adapter with 4 interchangeable
input blades for international use.
Capillus®User Manual
Sports Cap
Lightweight Carrying Case
Accessories Pouch
WHAT’S INCLUDED
DIAGRAM 1: CAPILLUS LASER THERAPY CAP COMPONENTS
B
E
A
F
G
H
CD
A
C
G
B
F
D
H
E
5
INSTRUCTIONS FOR CHARGING BATTERY PACK
Before initial use, please charge the battery pack as per the following instructions for optimal
battery life (for a full 24 hours on the initial charge). Only charge Battery Pack with provided
AC Adapter.
STEP 1
Plug provided AC Adapter (D) into power outlet
and then connect Battery Pack to AC Adapter. The
indicator lights on the top of the Battery Pack will
indicate charge level during process.
STEP 2
On subsequent charges, after the initial charge,
once all four indicator lights are turned on and static
(no blinking), the Battery Pack is ready for use.
Disconnect Battery Pack from AC Adapter for use.
Disconnect AC Adapter from power outlet and store
parts in Carrying Case (G).

INSTRUCTIONS FOR USE
The references (A-H) in this section refer to the part list shown on previous page in Diagram 1.
STEP 1
Unpack the components and make sure all the parts are present according to Diagram 1. All parts are
stored in the Carrying Case (G) with exception of this User Manual (E). Battery Pack (B), Battery Clip
(C), AC Adapter (D) are packed within Drawstring Pouch (H) inside the Carrying Case. The Laser Dome
is tted inside the Sports Cap. If there are parts missing contact customer service at 1-888-272-9599
or [email protected].
STEP 2
Please refer to charging instructions on previous page.
For optimal battery life, battery pack should be charged
completely before rst use until all 4 indicators lights on top
of battery pack are on and static (6-12 hours). Battery should
also be disconnected from laser device between uses for
optimal battery life and performance.
After initial charge, please charge Battery Pack only when
nal light is blinking.
STEP 3
Connect the Laser Dome (A) to the Battery Pack (B) by
matching up the small white indicator arrows on the cables to
each component. Important: The arrows must be aligned
for the cables to make a proper connection. Once the
arrows are aligned, push cables together and secure with
the twist lock connector.
STEP 4
Place Laser Dome on your head as shown and tap on the
Power Button on front of Battery Pack (B) to begin treat-
ment. Battery level indicators on top of Battery Pack will light.
You will hear one short beep when device turns on, followed by
two successive beeps when treatment begins. The emission
indicator light on the back of the cap will light up to indicate
that treatment has begun and lasers are operational.
Please note that there is a sensor on the inside of the
device that only allows light to be emitted when the cap is
on the head. If treatment is interrupted because the sensors
are disrupted, you will hear two short beeps intermittently until
proximity sensors are triggered. If treatment is interrupted for
10 minutes or longer, the treatment session will be reinitiated
upon start.
NOTE: The Capillus® laser device will not operate if the
Battery Pack is connected to the AC Adapter.
STEP 5
When the automatically programmed treatment session is
nished (6 minutes), you will hear three longer successive
beeps to indicate the treatment period is over, the lasers will
automatically shut off, and the emission indicator light on the
back of the Dome will turn off.
Press and hold Power Button on front of Battery Pack at
end of treatment session until all lights on battery pack
turn off. Disconnect battery pack from laser cap and store
until next use.
Fully Charged Battery Pack
Recharge is Needed
All indicators o.
Emission indicator is
red during operation.
6

SAFETY LABELS
The following laser safety label (i ) can be found on the cable of the Laser Dome (A). Label ii can be
found on the exterior of the Laser Dome (A).
Label symbols from bottom left to right (label (ii)): the rst symbol indicates the device should not be disposed of in the
normal waste stream; it should be taken to a recycling center for proper disposal.
The second symbol indicates laser light radiation as described on label (i). The third symbol indicates Type BF applied
part (60335); B=Body, F=Floating applied part. No conductive contact to patient.
The Capillus® laser therapy cap gives off no heat or harmful radiation, causes no pain and does not
require the use of drugs or topical applications.
EYE SAFETY CAUTION: Class 3R 5 MilliWatts, 650 Nanometers Red Laser Diodes. DO NOT STARE
DIRECTLY INTO THE LASER LIGHT FOR EXTENDED PERIODS.
PRECAUTIONS
•Laser therapy should not be used in conjunction with medications or products that are
photosensitizing.
•Consult with your physician before using the Capillus® laser therapy cap if: you have cancer of the
scalp; you are sensitive to light of 650 nm in wavelength.
MAINTENANCE INSTRUCTIONS
If it is necessary to clean the surfaces of your Capillus® laser therapy cap, please follow these
instructions. Note: the Capillus®laser therapy cap has no parts that can be serviced by the user.
If service is required, contact Capillus, LLC.
•DISCONNECT ALL CABLES ON THE CAPILLUS® LASER THERAPY CAP BEFORE CLEANING
•To clean the Capillus®laser therapy cap, gently wipe the inner surface of the laser dome (A) with
an alcohol wipe or a water moistened cloth. Do not use excessive pressure or force as this may
damage the unit.
•DO NOT use Acetone or any other solvents on any part of the device. Acetone and other solvents
will damage the unit and void the warranty.
OPERATING & STORAGE INFORMATION
The Capillus® laser therapy cap is designed to work in ambient temperature between 41°
and 104° F (5° and 40° C) and shipped or stored in temperatures between 41° and 104° F (5°
and 40° C). (See Pages 8). The device can be damaged and battery life shortened if stored or
operated outside of these temperature ranges.
LIMITED WARRANTY
Please refer to limited warranty details below for your Capillus laser therapy cap model.
CAPILLUS82™ CAPILLUS202™ CAPILLUSPRO™ CAPILLUSRX™
LASER DEVICE WARRANTY PERIOD
1 Year 2 Years 3 Years 5 Years
BATTERY PACK & AC ADAPTER WARRANTY PERIOD
1 Year
Capillus warrants the device against defects in materials or workmanship for a period indicated above from
the date of purchase from a Capillus authorized center. To activate your warranty, register your device within
30 days of purchase at www.capillus.com/activatewarranty.If a defect in material or workmanship exists,
Capillus will repair or replace the necessary parts with new or reworked parts at no charge. Any replacement
part will be covered under the original limited warranty. This Warranty is not transferable & does not cover
damages caused by acts of God, misuse, negligence, accident, or modication of any part of the unit as
determined by our service department. This Warranty does not cover damage due to improper operation or
maintenance, connection to improper voltage supply, or attempted repair by anyone other than the company.
Failure to use and maintain the device in accordance with the instructions in this manual will void the product
warranty.
Batteries will need to be replaced over time through Capillus. Please contact Capillus customer service should
you need to get warranty service or order replacement parts such as battery packs or AC adapter.
7
(i) (ii)

8
Do not disassemble any part of the Capillus® laser therapy cap and don’t attempt to repair the
device by yourself. Disassembling the device may damage it or may cause injury to you. If the
Capillus® device is damaged, malfunctions, or comes in contact with liquid, contact Capillus.
The lithium-ion battery should be replaced only by Capillus.
TROUBLESHOOTING
For any problems operating the Capillus® laser therapy cap, please contact Capillus Customer
Service at 1-888-272-9599 or [e-mail]. If you experience any discomfort during
or after use, please discontinue use immediately and contact your physician.
NOTICE: Do not attempt to repair any portion of the Capillus® laser therapy cap. If a malfunc-
tion occurs, disconnect the Capillus®laser therapy cap from the electrical source and contact
Capillus, LLC Customer Service toll-free at 1-888-272-9599 or email at [email protected].
DEVICE SPECIFICATIONS
Please refer to specications below for your Capillus laser therapy cap model.
CAPILLUS82™ CAPILLUS202™ CAPILLUSPRO™ CAPILLUSRX™
RLASER DEVICE
TYPE 5 mW 5 mW 5 mW 5 mW
WAVELENGTH 650 nm +/- 5 650 nm +/- 5 650 nm +/- 5 650 nm +/- 5
OUTPUT MODE Continuous Wave Continuous Wave Continuous Wave Continuous Wave
NO. OF DIODES 82 202 272 312
TOTAL OUTPUT 410 mW 1010 mW 1360 mW 1560 mW
BATTERY PACK
TYPE Lithium-Ion Lithium-Ion Lithium-Ion Lithium-Ion
INPUT DC9V/1A DC9V/1A DC9V/1A DC5V/2.5A
OUTPUT DC12V/2.5A DC12V/2.5A DC12V/2.5A DC5V/5A
CAPACITY 2500mAh/7.4V 2500mAh/7.4V 2500mAh/7.4V 5200mAh/3.7V
AC ADAPTER
INPUT AC100-240V,
50/60Hz, 0.35A
AC100-240V,
50/60Hz, 0.35A
AC100-240V,
50/60Hz, 0.35A
AC100-240V,
50/60Hz, 0.6A
OUTPUT DC9V, 1A DC9V, 1A DC9V, 1A DC5V, 3A
The power supply for the Capillus® laser therapy cap has been designed for use in the United States
and some International regions with power inputs as per above. We also include 3 alternate blades
for use in other countries. If the power outlets in your country use plugs different than the type
supplied, it will be necessary to obtain an appropriate country specic plug adapter.
AMBIENT OPERATING CONDITIONS
•Operating Temperature: 5 ºCelcius (41º Fahrenheit) ~ 40 ºCelcius
(104 º Fahrenheit)
•Humidity: 30% ~80%
•Atmospheric Pressure: 700 Pascals ~ 1060 Pascals
CLASSIFICATIONS
CDRH Classication: Class 3R/3A Laser Product; output power <5mW
FDA Medical Device Class: Class II
EYE SAFETY
Nominal Ocular Hazard Distance: 23 centimeters at 650 nanometers
UNLESS WEARING SUITABLE LASER SAFETY EYE-WEAR PROTECTION, DO NOT STARE AT THE
LASER LIGHT FOR LONG PERIODS AS IT CAN DAMAGE YOUR EYES.

WWW.CAPILLUS.COM I 1 [phone]
CAPPR1053R112717-0
