Caple C772G User manual

Gas hob
Instruction manual
C772G

Instruction manual C772G
Please keep this instruction manual for future reference
2
CONTENTS
Safety Warnings 3
Installation Warnings 6
Environmental Protection 8
Warranty 8
Operating Instructions 9
Installation 13
Overview 18
Technical Characteristics 19
Installation Dimensions 20

Instruction manual C772G
Please keep this instruction manual for future reference
3
SAFETY INSTRUCTIONS
Read these instructions carefully and completely
before using your appliance and keep the
manual in a convenient place for reference when
necessary.
-This appliance can be used by children aged from 8 years
and above.
-Persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge
must be supervised and given appropriate instruction
concerning the use of the appliance in a safe way and
understand the hazards involved.
-Children shall not play with the appliance.
-Cleaning and user maintenance should not be carried
out by children without supervision.
-The appliance is not intended to be operated by means
of an external timer or separate remote control system.

Instruction manual C772G
Please keep this instruction manual for future reference
4
WARNING:
-The appliance and its accessible parts become hot
during use. Care should be taken to avoid touching
heating elements.
-Children less than 8 years of age should be kept away
unless continuously supervised.
-Unattended cooking on a hob with fat or oil can
be dangerous and may result in fire. NEVER try to
extinguish a fire with water, but switch off the appliance
and then cover flame e.g. with a lid or a fire blanket.
-DANGER of FIRE: do not store items on the
cooking surfaces.
-Don’t use a steam cleaner for cleaning the hob.
-If the surface is cracked, switch off the appliance
to avoid the possibility of electric shock.
-This product is not designed for commercial use, it is
a household appliance only. It is not intended to be
used in:
• Staff kitchen areas in shops, offices and other working
environments.
• Bed and breakfast type environments.
• By clients in hotels, motels and other residential type
environments.

Instruction manual C772G
Please keep this instruction manual for future reference
5
CAUTION:
-Do not use the hob during cleaning
-Carefully read the instructions before installing and
using the appliance. The manufacturer cannot be held
responsible if improper installation or use of the device
causes injury or damage. Keep the instructions handy as
a reference for the future.
-Never leave the appliance unattended during food
preparation because oil and grease could cause a fire.
-When the unit is connected directly to the power supply,
you need a switch insulating omnipolar. It is necessary
that the appliance can be completely disconnected from
the network in accordance with the conditions of the
category III on the overvoltage. The earth cable is not
included.
-If the power cable is damaged, it must be replaced by
the manufacturer, by an authorized technician or by a
qualified person to avoid danger.
-When connecting the power cable, make sure it is not in
direct contact (eg. through the use of insulation sleeves)
with parts that can reach temperatures of over 50° C.

Instruction manual C772G
Please keep this instruction manual for future reference
6
INSTALLATION WARNINGS
-The installation must be carried out by experienced and
qualified personnel, in conformity with the regulations in
force.
-This appliance is not intended for use by person
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety. - Children should be supervised to ensure
that they do not play with the appliance.
-Before powering the equipment, check that it is properly
adjusted for the type of gas at disposal.
-Before carrying out the maintenance or cleaning the
equipment, turn the power supply off and ensure the
hob is not hot.
-Make sure that air circulates around the gas equipment.
Insufficient ventilation produces a lack of oxygen.
-In case of an intense or prolonged use of the equipment,
it may be necessary to improve aeration, for example by
opening a window or increasing the extraction power of
your extractor hood, if it exists.
-The products of combustion must be discharged outside
through an extractor hood or an electric fan

Instruction manual C772G
Please keep this instruction manual for future reference
7
-For any possible repair or modification, Contact Caple
service directly for help, and ensure original spare parts
only are used.
-The rating label, with the serial number and model
number included, is located on the underside of the hob.

Instruction manual C772G
Please keep this instruction manual for future reference
8
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice. This appliance is marked according to the European directive 2012/19/EU on
Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. The symbol
on the product indicates that this product may not be treated as household waste.
Instead it shall be handed over to the applicable collection point for the recycling of
electrical and electronic equipment. Disposal must be carried out in accordance with
local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this
product, please contact your local council, your household waste disposal service
or the retailer where you purchased the product.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with
all applicable legislation, Low Voltage Directive (LVD), Electromagnetic Compatibility
(EMC) and the Gas Appliance Regulation (GAR).
WARRANTY
Your new appliance is covered by warranty. The warranty card is enclosed - if it is
missing, you must provide the following information to your retailer in order to
receive a replacement: date of purchase, model and serial number. Registration can
also be completed online by visiting www.caple.co.uk.
Ensure you keep your warranty card safe, you may need to show it to Caple Service
together with proof of purchase.
If you fail to show your warranty card you will incur all repair charges.
Spare parts are only available from Caple Service and spare parts authorised centres.

Instruction manual C772G
Please keep this instruction manual for future reference
9
OPERATING INSTRUCTIONS
It is necessary that all the operations regarding the installation, adjustment and
adaptation to the type of gas available are carried out by qualified personnel, in
conformity with the regulations in force.
USING THE BURNERS
The flame symbols printed on the side of the control knobs indicate the
correspondence between the knob and the flame size on the burner.
TURNING ON THE BURNERS
Turn the corresponding knob anticlockwise up to
the maximum position (large flame, fig. 1)
and press the knob.
Once the burner has lit, keep the knob pressed for
about 6 seconds.
USING THE BURNERS
In order to obtain the maximum efficiency without
waste of gas, it is important that the diameter of the pan is
suitable for the burner potential (see the following
table) to avoid the flame reaching out past the pan
(fig. 2).
Use the maximum flame to quickly make liquids reach boiling point, and the
reduced flame to heat food or maintain boiling. To reduce gas consumption
and maximise the efficiency of the hob always cook with lids on pans. All of the
operating positions must be chosen between the maximum and the minimum ones,
never between the maximum position and ‘off.’
The gas supply can be interrupted by turning the knob clockwise up to the closing
position. If there is no power supply, it is possible to light the burners with matches,
setting the knob to the start-up point (large flame, fig. 1).
Fig1
Fig2

Instruction manual C772G
Please keep this instruction manual for future reference
10
NOTICE
- When you are no longer using the hob, always
check that the knobs are in the off position
(see fig.1).
- If the flame should blow out accidentally, the
safety valve will automatically stop the gas
supply after a few seconds. To restore
operation, set the knob to the lighting point
(large flame, fig. 1) and press.
- While cooking with fat or oil, pay the utmost attention as these substances can
catch fire when overheated.
- Do not use sprays near the appliance when in operation.
- Do not place unstable or deformed pans on the burner, so as to prevent them
from overturning or overflowing.
- Make sure that pan handles are placed appropriately to avoid knocking the pans
off from the hob.
- When the burner is started up, check that the flame is regular, and before taking
pans away, always lower the flame or put it out.
Burner Power (W) Ø Pan diameter
Auxiliary 1000 10 - 14 cm
Semi-rapid 1750 16 - 18 cm
Rapid 3000 20 - 22 cm
Dual ring 4000 22 - 24 cm
Fig1

Instruction manual C772G
Please keep this instruction manual for future reference
11
CLEANING
Before cleaning, disconnect the appliance from the electrical supply. Don’t
use a steam cleaner for cleaning the hob.
It is advisable to clean the appliance when it is cold.
ENAMELLED PARTS
- The enamelled parts must be washed with a sponge and soapy water or with a
light detergent.
- Do not use abrasive or corrosive products.
- Do not leave substances, such as lemon, tomato juice, salt water, vinegar, coffee
or milk on any surfaces for a long time.
STAINLESS STEEL PARTS
- Stainless steel can be stained if it remains in contact with highly calcareous water
or aggressive detergents for an extended period of time. The stainless steel parts
should also be cleaned with soapy water and then dried with a soft cloth.
WARNING:
- After cleaning the burner, make
sure that the burner cap is placed in
the housing.
- The two slots must be positioned
on the two tabs on the burner base
(see the arrows drawn in the burner
and lid).
- The burner cap must be positioned
flat on the burner base.
✓✗

Instruction manual C772G
Please keep this instruction manual for future reference
12
BURNERS AND PAN SUPPORTS
- These parts can be removed to make cleaning easier.
- The burners must be washed with a sponge and soapy water or with a light
detergent, wiped well and placed in their housing correctly.
- Make sure that the flame-dividing ducts on the burner base are not clogged.
- Check that the thermocouple and the ignition electrode are always perfectly
cleaned to ensure optimum operation.

Instruction manual C772G
Please keep this instruction manual for future reference
13
INSTALLATION
IMPORTANT NOTICE:
THE OPERATIONS INDICATED BELOW MUST BE FOLLOWED BY QUALIFIED
PERSONNEL ONLY, IN CONFORMITY WITH THE REGULATIONS IN FORCE.
CAPLE REFUSES ALL RESPONSIBILITY FOR DAMAGES TO PEOPLE, ANIMALS OR
OTHERS, RESULTING FROM THE FAILURE TO COMPLY WITH SUCH PROVISIONS.
INSTALLING THE HOB
The appliance is designed to be installed into heat-resistant furniture. The walls of
the furniture must be able to withstand a temperature of 75°C.
The equipment must not be installed near inflammable materials, such as curtains,
cloths,etc.
Make a hole in the worktop of the dimensions indicated in the “Installation
Dimensions” (Pg. 20-21) respecting a minimum distance of at least 50mm from the
rear edge of the hob and 100mm of the adjacent side walls.
Any wall unit or extractor over the hob must be placed
at a distance of at least 760mm from the hob. It is
advisable to isolate the appliance from the piece of
furniture below with a separator, leaving a ventilation
space of at least 120cm2.
When installing on a built-in oven without forced ventilation, ensure that there are air inlets and outlets for
ventilating the interior of the cabinet adequately.
Gas connection for gas hob
The hob should be connected to the gas-supply by a Gas safe registered installer. During installation of this
product it is essential to fit an approved gas tap to isolate the appliance from the supply for the convenience
of any subsequent removal or servicing. Connection of the appliance to the gas mains or liquid gas must be
carried out in compliance with current regulations, and only after it is ascertained that it is adaptable to the
type of gas to be used. If not, follow the instructions indicated in the paragraph headed "Adaptation to
different gas types". In the case of connection to liquid gas, by bottle/tank, use pressure regulators that
conform to current regulations in force.
Important: For safety, for the correct regulation of gas use and long life of the appliance, ensure that the
gas pressure conforms to the indications given in table 1 "Burners and injector specifications".
Connection to Gas supply by rigid metal pipe
(Copper or steel)
Connection to the gas source must be done in such a way as to not create any stress points at any part of
the appliance.
The appliance is fitted with a 1/2” gas male ‘L’ shaped union and a gasket for the attachment to the gas
supply.
Should this union have to be re-positioned, the gasket must be replaced.
Connection to flexible steel tube
The gas feed connector to the appliance is a threaded, male 1/2" connector for round gas pipe. Only use
pipes and sealing gaskets that conforms to the standards currently in force. The maximum length of the
flexible pipes must not exceed 2000 mm. Once the connection has been made, ensure that the flexible
metal tube does not touch any moving parts and is not crushed.
Check the Installation
Once the appliance has been installed, make sure all the connections are properly sealed, using liquid
detector fluid and a ‘U’ gauge. Never use a flame.
Electrical Connection
(The hob is fitted with a standard 13amp plug)
Fit the supply cable with a standard plug for the demand rate indicated on the rating plate or connect it
directly to the electrical mains. In the latter case, a single pole switch must be placed between the appliance
and the mains, with a minimum opening between the contacts of 3 mm in compliance with current safety
codes (the earth wire must not be interrupted by the switch). The power supply cable must be positioned so
that it does not reach a temperature in excess of 50~C above room temperature at any point.
Before actual connection make sure that:
fig 3

Instruction manual C772G
Please keep this instruction manual for future reference
14
If the hob is going to be installed on the top of an oven, precautions must be
taken to guarantee an installation in accordance with current accident prevention
standards. Pay particular attention to the position of the electric cable and gas pipe:
they must not touch any hot parts of the oven.
Moreover, if the hob is going to be installed on the top of a built in oven without
forced cooling ventilation, proper air vents must be installed to guarantee an
adequate ventilation, with the lower air entering with a cross section of at least
180cm2, and the higher air exiting with a cross section of at least 120cm2.
FASTENING THE HOB
Every hob is equipped with a special seal (‘S’ fig 5).
A set of fixing clips are also supplied for securing
the hob to the worktop (fig 6).
INSTALLATION ROOM
This appliance is not provided with a device for exhausting the products of
combustion. Regarding room ventilation rules where appliance is installed make
reference to the legislation, in conformity with the local regulations.
The room containing the hob should have an air supply in accordance with BS
5440: Part 2.
- All rooms require an openable window, or equivalent and some rooms will require
a permanent vent a well.
- For room volumes up to 5m3an air vent of 100cm2is required.
- For room volumes between 5m3and 10m3an air vent of 50cm2is required.
- If the room is greater than 5m3and has a door that opens directly to the outside,
then no air vent is required.
If there are other fuel burning appliances in the same room BS 5440: Part 2 should
be consulted to determine the air vent requirements.
fig 5 fig 6 fig 6.A

Instruction manual C772G
Please keep this instruction manual for future reference
15
GAS CONNECTION
Note:
The hob should be connected to the gas supply by a gas safe registered installer.
Make sure that the appliance is adjusted for the gas type available (see the
label under the appliance). Follow the instructions indicated in the chapter “gas
transformations and adjustments” for the possible adaptation to different gases.
The appliance must be connected to the gas system with rigid metal pipes or
flexible steel pipes having continuous walls, in compliance with the regulations in
force. A conical connector for the gas supply is included (Fig.7 and Fig.7.A).
Please select the type which is correct for the supply concerned. The connection
must not stress the gas ramp. Once the installation is over, check the connection
seal with a soapy solution.
ELECTRIC CONNECTION
The connection to the household mains supply must be carried out by qualified
personnel and in conformity with the regulations in force. The voltage of the
electrical system must correspond to the value indicated on the label under the
appliance. Make sure that the electrical system is provided with an effective ground
connection in compliance with the regulations and provisions of the law.
GROUNDING IS COMPULSORY.
This device must be at a suitable opening distance from the contacts in order to
allow the entire disconnection in case of overvoltage category III, in accordance with
fig 7 fig 7.A

Instruction manual C772G
Please keep this instruction manual for future reference
16
installation rules.
GAS TRANSFORMATIONS AND ADJUSTMENTS
The burner nozzles must be changed when using a different type of gas.
The choice of the nozzles to replace must be made according to the table of the
Technical Characteristics (pg.19).
To change the nozzles:
- Remove the racks and burners.
- Using a box spanner (L), unscrew the nozzle (U, fig.8) and substitute it with the
corresponding one.
- Tighten the nozzle.
- Double crown burner: (Fig. 8.A).
- Unscrew the screws (V) and remove the cover (C);
- Unscrew the injector with a spanner (L).
- Fit the corresponding gas injectors (U) instead, in accordance with the marking of
the injectors and the gas characteristics table.
- Tighten the injectors.
- Fit the cover (C) and tighten the screws.
fig 8
fig 8.A

Instruction manual C772G
Please keep this instruction manual for future reference
17
ADJUSTING THE BURNERS
The lowest flame point must always be properly adjusted and the flame must
remain on, even if there is an abrupt shift from the maximum to the minimum
position. If this is not the case, it is necessary to adjust the lowest flame setting as
follows:
- Ignite the burner.
- Turn the tap anti-clockwise to the minimum position (small flame).
- Remove the knob from the tap shaft.
- Place a flat-tip screwdriver on the by-pass screw (F, fig. 9) and adjust for the
correct level.
For G30 (LPG) the by-pass screw must be adjusted clockwise until completely
tightened on each gas tap.
MAINTENANCE
Replacing the power supply cable.
If the power supply cable should be replaced, it is necessary to use a cable with a
section of 3x0.75mm2, type H05VV-F or H05RR-F, complying with the regulations in
force. The connection to the terminal block must be as shown in fig. 10:
brown cable L (phase)
blue cable N (neutral)
green-yellow cable (ground)
fig 9
fig 10

Instruction manual C772G
Please keep this instruction manual for future reference
18
✓✗
WARNING:
- After cleaning the burner, make
sure that the lid is placed in the
housing.
- The two slots must be positioned
on the two tabs on the burner base
(see the arrows drawn in the burner
and lid).
- The burner cap must be positioned
flat on the burner base.
OVERVIEW
Burners Watts
1 Rapid burner 3000 W
2 Semi-rapid burner 1750 W
3 Auxiliary burner 1000 W
4 Dual ring burner 4000 W
4
2
3
2
1

Instruction manual C772G
Please keep this instruction manual for future reference
19
Position Burner Type burner Energy efficiency for gas burner
Left Dual ring EE gas burner 55.0%
Front middle Auxiliary EE gas burner **%
Back middle Semi rapid EE gas burner 57.8%
Front right Semi rapid EE gas burner 58.6%
Back right Rapid EE gas burner 57.8%
Energy efficiency for the gas hob EE gas hob 57.3%
TECHNICAL CHARACTERISTICS
ENERGY EFFICIENCY
Burner Gas Normal
Pressure
Normal
Rate
Injector
Diameter
Tape By
Pass
Diameter
Nominal
heat
Input (w)
N° Descriptions mbar g/h L/h 1/100mm 1/100mm Max. Min.
1Rapid G30/G31
G20
28-30 / 37
20
218
−
−
286
87
128
42
Reg.
3000
3000
950
950
2Semi-rapid G30/G31
G20
28-30 / 37
20
127
−
−
167
67
103
31
Reg.
1750
1750
600
600
3Auxiliary G30/G31
G20
28-30 / 37
20
73
−
−
95
50
78
27
Reg.
1000
1000
450
450
4Dual ring G30/G31
G20
28-30 / 37
20
291
−
−
381
45(int)-69(ext)
68(int)-101(ext)
60
Reg.
4000
4000
2300
2300
Short title or reference to the measurement and calculation methods used to
establish compliance with the above requirements.
The performance of each individual burner is calculated according to standard EN
30-2-1 (2015). The total efficiency of the hob is calculated according to the EU
Regulation 66/2014 Par. 2.2. The efficiency is calculated only for the burners with a
nominal capacity exceeding 1,16 KW (EN 30-2-1 (2015).
ENERGY SAVING TIPS:
- Use pans with a flat base
- Use a suitable size pan according to the size of the zone.
- Use pans with lids, minimize the amount of liquid or fat, when liquid starts
boiling, reduce the setting.

Instruction manual C772G
Please keep this instruction manual for future reference
20
INSTALLATION DIMENSIONS
Low profile inset installation
716 9
6
