Caple DD935BK User manual

DD935BK
Caple Downdraft Induction Hob
Technical Manual

DD935BK
Caple Downdraft Induction Hob

DD935BK
Caple Downdraft Induction Hob
Item
Part Number
Description
Quantity
1
75070007852
HOB GLASS 780x520
1
2
75070000030
INDUCTION
1
3
75070000025
TAPE FOR HOB
1
4
75159217303
BRACKETS
1
5
75070042140
BLACK GRILLE
1
6
75070030958
SUPPORT FOR FILTERS
1
7
75070000544
FLAT CABLE
1
8
75074510579
LEAD WIRE
1
9
75102450003
TOUCH CONTROL
1
10
75001799999
MAIN BOARD
1
11
75119211776
WIRING ASSEMBLY SDDH3
1
12
75021001127
UPPER PIPE 320X90
1
13
75021001124
LOWER PIPE 320X90
1
14
75021010347
JOINT 320X90
1
15
75070000801
TOUCH CONTROL HOB
1
16
75470199999
EMERGENCY SWITCH/START NEON
1
17
75007026155
MAGNET 15X5
1
18
75071503045
GREASE FILTER
1
19
75007096715
MOTOR
1
20
75071008008
MAIN PCB
1
21
75071008372
BLACK FILTERING CASE
1
22
44149940015
MAINS IN FILTER
1
23
75149940002
TRANSFORMER FROM 11/2018
1

DD935BK – Caple Downdraft Induction Hob
Error Codes
Error
Message Description Possible Error Reason Troubleshooting
E03 & Acoustic
Signal
Permanent useofkeys. Control unitcuts
off after 10 seconds.
Water or cooking utensils on the
glass above the control unit. Cleaning of the operational surface.
E21
Control unit cuts off after
controlling due to overheating to
avoid damage to electronics.
Standard algorithm reaches limit when
overheated. Ambient temperature of
electronics still to high.
Allow cavity to cool down.
Check heat sealing-off of
control unit.
E22 Defective Key evaluation.
Control unit cuts off after 3.5 – 7.5 sec.
Short-circuit or discontinuation in the
range of the key evaluation. Exchange control unit.
E20 Flash-failure. µC- faulty. Exchange control unit.
E36
NTC value is not within its
specification (value < 200mV or
> 4.9V; control unit cuts off.
Short-circuit or cut-off at NTC. Exchange control unit.
E31 Configuration data incorrect. Configuration of induction necessary. New Configuration.
E47 Communication error between
TC and induction. None or faulty communication! Ensure that connection cable is plugged on correctly and functional.
E2 Overheating of the induction coils Cooling down necessary.
U400
Secondary voltage ofthe power unit to
high (primary > 300V). Control unit cuts
off after 1 sec releasing apermanent tone. Control unit iswrongly connected. Connect tocorrect mains voltage.
E5 Error onfilter board. Exchange filter board.
E6 Error on power unit. Exchange power unit.
E9 Coil temperature sensor defective. Exchange temperature sensor.
