Caple CM106 Manual

Space for
ventilation
1
3
2
4
Minimum cabinet aperture 560mm
Fasten the "Bottom Spacer" to the MWO
base with two screws fasten the "Rear Spacer" to the MWO
rear with two screws

56
87
fasten the upper DUCT with 4 screws ensuring the
opening in the duct points to the rear of the MWO.
Fasten the 2 "Front Frame Clips" to the
left side of the oven with screws
place the oven into cabinet
Fasten the 2 "Front Frame Clips" to the
right side of the oven with screws

910
11
fasten the oven into the cabinet with 4 screws
place the oven in the middle of cabinet
Push the "Front Frame" onto the 4 "Front Frame Clips"
IMPORTANT:- ENSURE THE FRAME IS FITTED THE CORRECT WAY UP.THE
WORD"TOP"IS MARKED ON THE BACK OF THE FRAME MOULDING
TOP
TOP

12
TO REMOVE FRAME
Insert flat bladed screwdriver and pry the front
frame from the fixing clips.
Installation complete
insert pry

Art. Name Count Art. Name Count
P01 door (with inlaids) 1C01 h.v. fuse 1
P02 door window 1C02 h.v. diode 1
P03 fuse socket 1C03 h.v. capacitor 1
P04 capacitor holder 1C04 wave filter 1
P05 fan shroud 1C05 fan motor 1
P06 fan blade 1C06 lamp 1
P07 door frame 1C07 thermostat 1
P08 choke cover 1C08 magnetron 1
P09 washer 1C09 microswitch 1
P10 shaft 1C10 microswitch 1
P11 roller ring 1C11 microswitch 1
P12 glass tray 1C12 transformer 1
P13 splash shield 1C13 wiring harness 1
P14 upper hinge 1C14 power cord 1
P16 cavity 1C15 turntable motor 1
P17 label 1C16 p.c. board 1
P18 outer enclosure 1C19 thermostat 1
P19 heater holder 1C20 heater 1
P20 power cord holder 1
P21 lamp socket 1
P22 air duct 1
P23 microswitch mounting 1F01 cabinet 1
P24 shockproof rubber 1F02 upper exhaust guide 1
P25 transformer bracket 4F03 back cover board 1
P26 foot 1F04 shutter holder 4
P27 base plate 1F05 microwave oven 1
P28 lower hinge 1F06 shutter 1
P29 control panel 1F07 down cover board 1
P31 lever 1
P32 button spring 1B01 upper foam cushion 1
P33 metal shell 1B02 turntable cushion 2
P38 key pads 1B03 plastic bag 1
P39 knob 1B04 manual 1
P40 button 1B05 protection film 1
P41 baking plate 1B06 plastic bag 1
P43 button shell 1B07 lower cushion 2
P44 display 1B08 carton 1
P58 ceramic holder 1 B09 cardboard 1
Parts and Components List
CM104 - Caple Microwave Oven & Grill
