Caple CM126 User manual

Combination Microwave
Instruction Manual
CM126
Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk

Instruction manual CM126 Instruction manual CM1262 3
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
CONTENTS
Warnings 3
Environmental Protection 11
Warranty 11
Cleaning 13
Utensils 13
Setting Up Your Microwave 16
Installation 17
Operation Instructions 21
Trouble Shooting 29
Technical Data 30
Caple Contact Details 31
SAFETY INSTRUCTIONS
Read carefully all the instructions contained in this
manual. It provides you with important information
regarding the safe installation, use and maintenance of
the appliance as well as useful advice for getting the best
out of your microwave oven. Keep this booklet in a safe
place for future reference. After removing the packing,
check that the appliance is not damaged in any way.
Be careful not to leave the packing materials (plastic
sheeting, expanded polystyrene etc.) where children can
get at them, as they can be dangerous.
IMPORTANT:
Do not use the oven door handle to move the appliance,
such as to remove it from the packaging.
ATTENTION:
The microwave oven is an appliance which, for its nature,
becomes hot during use, especially the glass door.
It is therefore a good rule that children do not approach
the microwave oven when it is functioning, particularly
when the grill is in use.

Instruction manual CM126 Instruction manual CM1264 5
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
WARNING:
Accessible parts will become hot when in use. To avoid
burns and scalds children should be kept away.
During use the appliance becomes hot, care should be
taken to avoid touching heating elements inside the oven.
-If the door or door seals are damaged, the oven must
not be operated until it has been repaired by a Caple
approved engineer.
-It is hazardous for anyone other than a competent person
to carry out any service or repair operation that involves
the removal of a cover which gives protection against
exposure to microwave energy.
-Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
-Only use utensils that are suitable for use in
microwave ovens.
-When heating food in plastic or paper containers, keep an
eye on the oven due to the possibility of ignition.
-The microwave oven is intended for heating food and
beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
-The oven should be cleaned regularly and any food
deposits removed.
-Failure to maintain the oven in a clean condition could
lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a
hazardous situation.
Never roast or bake on the oven base.
This appliance is intended to be used in household and
similar applications such as:
• Staff kitchen areas in shops, offices and other
working environments.
• Farm Houses.
• By clients in hotels, motels and other residential type
environments.
• Bed and breakfast type environments.
The electrical system of this appliance may be used safely
only when it is correctly connected to an efficient earthing
system in compliance with the safety standards currently
in effect.
The manufacturer will not be held liable for any damages
that might arise out of incorrect or improper use of
the appliance.
The following items are potentially dangerous, and
therefore, appropriate measures must be taken to prevent
children and the disabled from coming into contact
with them:
-Controls and the appliance in general
-Packaging (bags, polystyrene, nails, etc.)
-The appliance immediately after use of the oven or grill
due to the heat generated.
-The appliance when no longer in use (potentially
dangerous parts must be made safe).

Instruction manual CM126 Instruction manual CM1266 7
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
WARNING:
To reduce the risk of burns, electric shock, fire, injury to
persons or exposure to excessive microwave energy:
-Make sure that all the packing materials are removed
from the inside of the door.
WARNING:
-Check the oven for any damage, such as a misaligned
or bent door, damaged door seals and sealing surface,
broken or loose door hinges and latches and dents inside
the cavity or on the door. If there is any damage, do not
operate the oven and contact Caple service immediately.
-This microwave oven must be placed on a flat, stable
surface to hold its weight and the heaviest food likely to
be cooked in the oven.
-Do not place the microwave oven where heat, moisture,
or high humidity are generated, or near
combustible materials.
-Do not operate the microwave oven when empty.
-Do not operate this appliance if it has a damaged cord
or plug, if it is not working properly or if it has been
damaged or dropped. If the supply cord is damaged, it
must be replaced by Caple or an approved engineer in
order to avoid a hazard.
-Microwave heating of liquids can result in delayed
eruptive boiling, therefore care has to be taken when
handling the container.
-Do not fry food in the microwave oven. Hot oil can
damage oven parts and utensils and even result in
skin burns.
-Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode even after microwave heating has ended.
-Pierce foods with heavy skins such as potatoes, whole
squashes, apples and chestnuts before cooking.
-The contents of feeding bottles and baby jars should
be stirred or shaken and the temperature should be
checked before serving in order to avoid burns.
-Utensils should be checked to ensure that they are
suitable for use in microwave oven.
WARNING:
Liquid or other food must not be heated in sealed
containers since they are liable to explode.
WARNING:
It is hazardous for anyone other a trained person to
carry out any service or repair operation which involves
the removal of any cover which gives protection against
exposure to microwave energy.
-This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless the have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.

Instruction manual CM126 Instruction manual CM1268 9
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
-Children should be supervised to ensure that they do not
play with the appliance.
-When heating food in plastic or paper containers, check
the oven frequently for the possibility of ignition.
-Remove wire ties from paper or plastic bags before
placing bag in oven.
-If smoke is observed. Switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
-Do not leave paper products, cooking utensils or food in
the cavity when not in use.
WARNING:
The appliance and its accessible parts become hot
during use.
Care should be taken to avoid touching heating elements.
Children less than 8 years of age shall be kept away unless
continuously supervised.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be
made by children without supervision.
During use the appliance becomes hot. Care should be
taken to avoid touching heating elements inside the oven.
WARNING:
Accessible parts may become hot during use. Young
children should be kept away.
Do not attempt to operate this oven with the door open
as this can result in harmful exposure to microwave
energy. It is important not to break or tamper with the
safety interlocks.
Do not place any objects between the oven front face and
the door or allow soiling or cleaner residue to accumulate
on sealing surfaces.
If the door or door seals are damaged, the oven must not
be operated until it has been repaired by a
competent engineer.
Electric shock hazard:
-Improper use of the grounding can result in electric
shock. Do not plug into an outlet until the appliance is
properly installed and grounded.
-This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the
electric current. This appliance is equipped with a cord
having a grounding wire with a grounding plug. The
plug must be plugged into an outlet that is properly
installed and grounded.

Instruction manual CM126 Instruction manual CM12610 11
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
-Consult a qualified electrician or engineer if the
grounding instructions are not completely understood
or if doubt exists as to whether the appliance is properly
grounded. If it is necessary to use an extension cord, only
use a 3-wire extension cord.
A short power-supply cord is provided to reduce the risks
resulting from becoming entangled in or tripping over a
longer cord.
If a long cord set or extension cord is used:
-The marked electrical rating of the cord set or extension
cord should be at least as great as the electrical rating of
the appliance.
-The extension cord must be a grounding-type 3-
wire cord.
-The long cord should be arranged so that it will not
drape over the counter top or tabletop where it can be
pulled on by children or tripped over unintentionally.
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice. This appliance is
marked according to the European Directive on Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The symbol on the product indicates that this
product may not be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal must be carried
out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local council, your household waste disposal service or the retailer where you
purchased the product.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all applicable
legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC).
UKCA DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all
applicable legislation.
WARRANTY:
Your new appliance is covered by warranty. The warranty card is enclosed - if it is missing, you
must provide the following information to your retailer in order to receive a replacement: date
of purchase, model and serial number (placed on the inside of the appliance storage drawer).
Registration can also be completed online by visiting www.caple.co.uk.
Ensure you keep your warranty card safe, you may need to show it to Caple Service together with
proof of purchase.
If you fail to show your warranty card you will incur all repair charges.
Spare parts are only available from Caple Service and spare parts authorised centres.

Instruction manual CM126 Instruction manual CM12612 13
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
ATTENTION:
› Before use, remove all plastic films protecting some parts of the appliance (fascia - panel, parts
in stainless steel, etc.)
› Do not use the appliance to heat a room.
› When the appliance is not in use, we recommend you turn it off, isolate it from the
electrical supply.
› If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded
and affect the lifespan of the apparatus and lead to a dangerous situation.
CLEANING
Be sure to unplug the appliance from the power supply before any cleaning.
1. Clean the cavity of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth
when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since
they can scratch the surface, which may result in shattering of the glass.
CLEANING TIP:
For easier cleaning of the cavity walls: Place half a lemon in a bowl, add 300ml (1/2 pint) water
and heat on 100% microwave power for 10 minutes. Wipe the oven clean using a soft, dry cloth.
UTENSILS
WARNING:
Personal Injury Hazard: It is hazardous for anyone other than a competent person to carry out any
service or repair operation that involves the removal of a cover which gives protection against
exposure to microwave energy.
There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt,
you can test the utensil in question following the procedure below.
UTENSIL TEST:
› Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil
in question.
› Cook on maximum power for 1 minute.
› Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
› Do not exceed 1 minute cooking time.

Instruction manual CM126 Instruction manual CM12614 15
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
UTENSILS REMARKS
BROWNING DISH Follow manufacturer’s instructions. The bottom of the browning dish must be at least
5mm above the turntable. Incorrect usage may cause the turntable to break.
DINNERWARE Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked or
chipped dishes.
GLASS JAR Always remove lid. Use only to heat food until just warm. Most glass jars are not heat
resistant and may break.
GLASSWARE Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use
cracked or chipped dishes.
OVEN
COOKING BAGS
Follow manufacturer’s instructions. Do not close with a metal tie. Make slits to allow
steam to escape.
PAPER PLATES
AND CUPS Use for short–term cooking/warming only. Do not leave oven unattended while cooking.
PAPER TOWELS Use to cover food for reheating and absorbing fat. Use with supervision for a short-term
cooking only.
PARCHMENT PAPER Use as a cover to prevent splattering or a wrap for steaming.
PLASTIC
Microwave-safe only. Follow the manufacturer’s instructions. Should be labelled
“Microwave Safe”. Some plastic containers soften, as the food inside gets hot. “Boiling
bags” and tightly closed plastic bags should be slit, pierced or vented as directed
by package.
PLASTIC WRAP Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow
plastic wrap to touch food.
THERMOMETERS Microwave-safe only (meat and candy thermometers).
WAX PAPER Use as a cover to prevent splattering and retain moisture.
MATERIALS YOU CAN USE IN A MICROWAVE OVEN: MATERIALS TO BE AVOIDED IN A MICROWAVE OVEN:
UTENSILS REMARKS
ALUMINIUM TRAY May cause arcing. Transfer food into microwave-safe dish.
FOOD CARTON WITH
METAL HANDLE May cause arcing. Transfer food into microwave-safe dish.
METAL OR METAL-
TRIMMED UTENSILS Metal shields the food from microwave energy. Metal trim may cause arcing.
METAL TWIST TIES May cause arcing and could cause a fire in the oven.
PAPER BAGS May cause a fire in the oven.
PLASTIC FOAM Plastic foam may melt or contaminate the liquid inside when exposed to
high temperature..
WOOD Wood will dry out when used in the microwave oven and may split or crack.

Instruction manual CM126 Instruction manual CM12616 17
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
a m
P a
supplied
to the
to
G
E D CB
F
A
SETTING UP YOUR MICROWAVE
PARTS AND ACCESSORIES:
Remove the oven and all materials from the carton and oven cavity. Your oven comes supplied
with the following accessories:
CONTENTS QUANTITY
Glass Turntable 1
Turntable Ring Assembly 1
Instruction Mw anual 1
A. Control panel
B. Turntable shaft
C. Turntable ring assembly
D. Glass turntable
E. Observation window
F. Door assembly
G. Safety interlock system
a m
P a
supplied
to the
to
GRILL RACK
(Only to be used in the grill function and to be
placed on the glass turntable)
Hub (underside)
Glass tray
Turntable ring assembly
a.
b. the
c.
must
be
d.
Caple
Turntable Installation
Turntable shaft
The guarantee is void if used in
any commercial application.
detailed
t
INSTALLATION
TURNTABLE INSTALLATION
› Never place the glass tray upside down. The glass
tray should never be restricted.
› Both the glass tray and turntable ring assembly must
always be used during cooking.
› All food and containers of food must always be
placed on the glass turntable for cooking.
› If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorised Caple
Service centre.
INSTALLATION AND CONNECTION
› This appliance is only intended for domestic use. The guarantee is void if used in any
commercial application.
› This oven is intended for built-in use only. It is not intended for counter-top use or for use inside
a cupboard.
› Please observe the detailed installation instructions.
› The appliance can be installed in a 60cm wide wall-mounted cupboard (at least 55cm deep and
85cm off the floor).
› The appliance is fitted with a plug and must only be connected to a properly installed
earthed socket.
› The mains voltage must correspond to the voltage specified on the rating plate.
› The socket must be installed and the connecting cable must only be replaced by a qualified
electrician. If the plug is no longer accessible following installation, an all-pole disconnecting
device must be present on the installation side with a contact gap of at lease 3mm.
› Adapters, multi-way strips and extension leads must not be used. Overloading can result in a
risk of fire.
WARNING:
The accessible surface may be hot during operation.
a.
b. the
c.
must
be
d.
Caple
ce
The guarantee is void if used in
any commercial application.
detailed
t

Instruction manual CM126 Instruction manual CM12618 19
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
ELECTRICAL CONNECTION
NOTE:
The oven is fitted with a plug and must only be connected to a property installed earthed socket.
The socket must only be installed and the connecting cable must only be replaced by a qualified
electrician, and in accordance with the appropriate regulations. If the plug is no longer accessible
following installation, an all-pole isolating switch must be present on the installation side with a
contact gap of at least 3mm.
BUILT-IN FURNITURE
› The fitted cabinet the appliance is being installed into must not have a back wall behind
the appliance.
› Minimum height 85cm. A gap must be maintained between the wall and the base of the unit
above. Specific gap size can be referenced by the diagrams.
› Do not cover any ventilation slots or air intake points.
(min)
500mm
450mm
600mm
+8
+2
560mm
45mm
45mm
850mm
PREPARE THE CABINET
Read the instruction on the Bottom Cabinet Template:
Put the template on the bottom plane of cabinet.
put the template on the bottom plane of cabinet.
1. Read the instruction on the BOTTOM CANINET TEMPLATE ,
2. Make the marks on the bottom plane of cabinet according to marks"a" of
of the template
aa
CENTER LINE
FRONT EDGE
LEFT EDGE
TEDGERIGH
3. Remove the bottom cabinet template and fix the bracket w
Screw A
Bracket
Bracket
Screw A
Centre line
Make the marks on the bottom plane of cabinet according to marks ‘a’ of the template
put the template on the bottom plane of cabinet.
1. Read the instruction on the BOTTOM CANINET TEMPLATE ,
2. Make the marks on the bottom plane of cabinet according to marks"a" of
of the template
3. Remove the bottom cabinet template and fix the bracket with screw A.
aa
Screw A
Bracket
Bracket
Screw A
Centre line
Remove the bottom cabinet template and fix the bracket with screw A.
put the template on the bottom plane of cabinet.
1. Read the instruction on the BOTTOM CANINET TEMPLATE ,
2. Make the marks on the bottom plane of cabinet according to marks"a" of
of the template
3. Remove the bottom cabinet template and fix the bracket w
Screw A
Bracket
Bracket
Screw A
Centre line

Instruction manual CM126 Instruction manual CM12620 21
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
INSTALL THE MICROWAVE
Install the microwave to the cabinet:
› Make sure the back of the microwave is locked by bracket.
› Do not trap or kink the power cord.
Open the door, fix the oven to the cabinet with Screw B, at the installation hole.
Then fix the Trim-kit plastic cover to the installation hole.
4. Install the oven to the cabinet
- Make sure the back of the oven is locked by bracket.
- Do not trap or kink the power cord.
5. Open the door, fix the oven to the cabinet wi tion hole.
Then fix the Trim-kit plastic cover to the installation hole.
Screw฀B฀Installation฀Hole
Bracket฀
4. Install the oven to the cabinet
- Make sure the back of the oven is locked by bracket.
- Do not trap or kink the power cord.
5. Open the door, fix the oven to the cabinet wi tion hole.
Then fix the Trim-kit plastic cover to the installation hole.
Screw฀B฀Installation฀Hole
Bracket฀
OPERATION INSTRUCTIONS
SETTING THE CLOCK:
When the microwave oven is switched on, the oven will display “0:00”, a buzzer will ring once.
› Press “CLOCK/PRE-SET“ to choose 12-hour or 24-hour.
› Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to adjust the hour figures, the input time should be within 0-23 (24-hour)
or 1-12 (12-hour).
› Press “CLOCK/PRE-SET“, the minute figures will flash.
› Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to adjust the minute figures, the input time should be within 0-59.
› Press “CLOCK/PRE-SET” to finish setting the clock. “:” will flash.
NOTE:
If the clock is not set, it will not function when powered.
During the process of clock setting, if you press “STOP/CLEAR“, the oven will go back to the
previous status automatically.
MICROWAVE COOKING:
› Press the “MICROWAVE “ key once, and “P100” display.
› Press MICROWAVE” a few times or turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
Setting the clock
“ to select the microwave power from 100% to
10%. “P100”, “P80”, “P50”, “P30”, “P10” will display in order.
› Press “START/+30SEC./CONFIRM“ to confirm.
› Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
Setting the clock
“ to adjust the cooking time. (The time setting should be 0:05- 95:00)
› Press “START/+30SEC./CONFIRM“ to start cooking.
NOTE:
When selecting a cooking duration, the timer will increase in the following quantities:
For example when selecting a cooking duration between 1 - 5 minuets,
the timer will go up in 10 second increments.
0 - 1 min 5 seconds
1 - 5 min 10 seconds
5 - 10 min 30 seconds
10 - 30 min 1 minute
30 - 95 min 5 minutes

Instruction manual CM126 Instruction manual CM12622 23
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
PRESS ONCE TWICE THRICE 4 TIMES 5 TIMES
Microwave Power 100% 80% 50% 30% 10%
INSTRUCTIONS DISPLAY MICROWAVE GRILL CONVECTION
1C - 1 • •
2C - 2 • •
3C - 3 • •
4C - 4 • • •
MICROWAVE POWER CHART:
GRILL COOKING:
› Press the GRILL/COMBI“ key once, and “G-1” display.
› Press “GRILL/COMBI” for times or turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to select the grill power. Stop turning when
“G-1” displays.
› Press “START/+30SEC./CONFIRM“ to confirm.
› Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to adjust the cooking time. (The time setting should be 0:05- 95:00)
› Press “START/+30SEC./CONFIRM “ to start cooking.
NOTE:
If half the grill time passes, the oven will sound twice to tell you to turn the food over.
You can just leave it to continue cooking. In order to have a better effect of grilling food, you
should turn the food over, close the door, and then press“START/+30SEC./CONFIRM” to
continue cooking.
COMBINATION COOKING:
› Press the “GRILL/COMBI“ key once, and “G-1” display.
› Press “GRILL/COMBI” a few times or turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to select the grill power. Stop turning when
“C-1”,”C-2”,”C-3” or “C-4” displays.
› Press “START/+30SEC./CONFIRM“ to confirm.
› Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to adjust the cooking time. (The time setting should be 0:05- 95:00)
› Press “START/+30SEC./CONFIRM“ to start cooking.
Combination Instructions:
C-1 & C-2 maintains a 160-165 internal temperature
C-3 & C-4 maintains a 195-200 internal temperature
CONVECTION COOKING (WITH PREHEATING FUNCTION):
Convection cooking can let you to cook the food as a traditional oven, and therefore the
microwave function is not used. It is recommended that you should preheat the oven to the
appropriate temperature before placing the food in the oven.
› Press the “CONVECTION“ key once, “130” flash.
› Keep pressing CONVECTION” or turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to select the convection function.
NOTE:
The temperature can be selected from 130 degrees to 220 degrees.
› Press the “START/+30SEC./CONFIRM“ to confirm the temperature.
› Press the “START/+30SEC./CONFIRM“ to start preheating. When the required preheating
temperature is reached, the buzzer will sound twice to remind you to put the food into the oven.
The preheated temperature is displayed and flashes.
› Put the food into the oven and close the door. Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to adjust the cooking time. (The
maximum setting time is 95 minutes.)
› Press the “START/+30SEC./CONFIRM“ key to start cooking.
NOTE:
Cooking time cannot be input until the preheating temperature is reached. If the temperature
arrives, door must be opened to input the cooking time.
If the time not input in 5 minutes, the oven will stop preheating. The buzzer will sound five times
and turn back to the standby state.

Instruction manual CM126 Instruction manual CM12624 25
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
CONVECTION COOKING (WITHOUT PRE-HEATING FUNCTION):
› Press the “CONVECTION“ key once, “130” flash.
› Keep pressing “CONVECTION” or turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to select the convection function
NOTE:
The temperature can be selected from 130 degrees to 220 degrees.
› Press the “START/+30SEC./CONFIRM“ to confirm the temperature.
› Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to adjust the cooking time. (The maximum setting time is 95 minutes.)
› Press the “START/+30SEC./CONFIRM“ key to start cooking.
MULTI-STAGE COOKING:
Two cooking stages can be set. If one stage is defrosting, it should be put in the first stage. The
buzzer will ring once after each stage and the next stage will begin.
NOTE:
Auto menu and preheating cannot be set as one of the multi-stage options.
EXAMPLE:
If you want to defrost the food for 5 minutes, then to cook with 80%microwave power for 7
minutes. The steps are as following:
› Press “W.T./TIME DEFROST“ twice, the screen will display “dEF2”.
› Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to adjust the defrost time of 5 minutes.
› Press”MICROWAVE” once.
› Press “MICROWAVE” four times or turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ till “P80” display.
› Press “START/+30SEC./CONFIRM” to confirm.
› Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to adjust the cooking time of 7 minutes.
› Press “START/+30SEC./CONFIRM” to start cooking.
TIMED AUTO COOKING:
› Set the clock first. (Consult the instructions for setting the clock.)
› Input the cooking program. Two stages can be set at most. Defrosting should not be set in
pre-set function. The auto menu can be set for single stage cooking only.
EXAMPLE:
If you want to cook with 80% microwave power for 7 minutes.
› Press ”MICROWAVE” once.
› Press “MICROWAVE” four times or turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to choose 80% microwave power till
“P80” display.
› Press “START/+30SEC./CONFIRM” to confirm.
› Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to adjust the cooking time of 7 minutes. After the above steps, please do not
press“START/+30SEC./CONFIRM“. Then do as following:
› Press “CLOCK/PRE-SET“, current time displays and the hour figures flash.
› Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to adjust the hour figures, the input time should be within 0-23 (24-hour)
or 1-12 (12-hour).
› Press “ CLOCK/PRE-SET “, the minute figures will flash.
› Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to adjust the minute figures, the input time should be within 0-59.
› Press “START/+30SEC./CONFIRM“ to finish setting. “:” will illuminate, the buzzer will ring twice
when the time arrives, then cooking will start automatically.
NOTE:
The clock must be set first. Otherwise the pre-set function will not work.
AUTO MENU:
› In the standby state, turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ right to select the required function, and “A1”, ”A2”, ”A3”
....”A10” will be displayed.
› Press “START/ +30 SEC./CONFIRM” to confirm the menu you need.
› Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to choose the weight of menu, and “g” indicator will light.
› Press “START/ +30 SEC./CONFIRM” to start cooking.
NOTE:
When you choose A8 cake, please do not put the cake into the oven at the beginning. The oven
needs to be preheated to 180 degrees first. After several minutes, the buzzer sounds twice
to remind you to put the cake into the oven. After putting the cake in the oven, please press
“Start/+30Sec./Confirm” again. The timer will count down, and the cake will be cooked perfectly.

Instruction manual CM126 Instruction manual CM12626 27
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
AUTOMATIC MENU CHART:
MENU WEIGHT (G) DISPLAY POWER
A 1
PREHEAT
150 150
100%
250 250
350 350
450 450
600 600
A 2
POTATO
1 (about 230g) 1
100%2 (about 460g) 2
3 (about 690g) 3
A 3
MEAT
150 150
100%
300 300
450 450
600 600
A4
VEGETABLE
150 150
100%350 350
500 500
A 5
FISH
150 150
80%
250 250
350 350
450 450
650 650
A 6
PASTA
50 (With water 450g) 50
80%100 (with water 800g) 100
150 (with water 1200g) 150
A 7
SOUP
200 200
100%400 400
600 600
A 8
CAKE 475 475 Preheat at 180 degrees
A 9
PIZZA
200 200
C - 4300 300
400 400
A10
CHICKEN
500 500
C - 4
750 750
1000 1000
1200 1200
DEFROST BY WEIGHT:
› Press “W.T./TIME DEFROST” pad once, the oven will display “dEF1”.
› Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to select the weight of food. At the same time, “g” will illuminate. The weight
should be 100-2000g.
› Press “START/+30SEC./CONFIRM” key to start defrosting “
Speed cooking
Defrost by Time
Defrost by oeight ((W.T)
Speed microwave cooking
Inquiring function
a mode and
current
then revert
the
standby mode
allowed
" "
illuminate.
standby mode the
the options
does not in the mode
I to be defrosted
and
“ and “
Speed cooking
Defrost by Time
Defrost by oeight
((W.T)
Speed microwave cooking
Inquiring function
a mode and
current
then revert
the
standby mode
allowed
Press "START/+30SEC./CONFIRM
and " "
illuminate.
standby mode the
the options
does not in the mode
I to be defrosted
and
“ indicators will
flash and “g” indicator will go out.
DEFROST BY TIME:
› Press “W.T./TIME DEFROST“ key twice, the oven will display “dEF2”.
› Turn “
Microwave Cooking
S
switched on a
the clock
will up
a few urn " " to select the microwave
power from 100% to 10%. "P100", "P80", "P50", "P30", "P10"
Setting the clock
“ to select the cooking time. The maximum allowed set time is 95 minutes.
› Press “START/+30SEC./CONFIRM” key to start defrosting. “
Speed cooking
Defrost by Time
Defrost by oeight ((W.T)
Speed microwave cooking
Inquiring function
a mode and
current
then revert
the
standby mode
allowed
" "
illuminate.
standby mode the
the options
does not in the mode
I to be defrosted
and
“ and “
Speed cooking
Defrost by Time
Defrost by oeight ((W.T)
Speed microwave cooking
Inquiring function
a mode and
current
then revert
the
standby mode
allowed
Press "START/+30SEC./CONFIRM
and " "
illuminate.
standby mode the
the options
does not in the mode
I to be defrosted
and
“ indicators
will flash.
NOTE:
If the food weight is no more than 200 grams, please place the food to be defrosted at the edge
of the glass turntable and not the centre.
SPEED COOKING:
In standby mode, press “START/+30SEC./CONFIRM” key to start microwave cooking with 100%
power for 30 seconds. Each press of the button will increase the timer by 30 seconds. The
maximum cooking time is 95 minutes.
INQUIRING FUNCTION:
› In a cooking mode, press”MICROWAVE”,”GRILL/ COMBI” or “CONVECTION”, and the current
power will be displayed for 2-3 seconds.
› In pre-set state, press “ CLOCK/PRE-SET “ to inquire the time for delay start cooking. The pre-set
time will flash for 2-3 seconds, the oven will then revert back to the clock display.
› During the cooking state, press “CLOCK/PRE-SET” to check the current time. It will be displayed
for 2-3 seconds.
CHILD SAFETY LOCK:
Lock: In standby mode, press “STOP/CLEAR” for 3 seconds, there will be a long “beep” denoting
entering into the lock state and “ “ indicator will illuminate. The LED will display the current
time or 0:00.

Instruction manual CM126 Instruction manual CM12628 29
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
Quitting Lock: In the locked state, press “STOP/CLEAR” for 3 seconds, there will be a long “beep”
denoting that the lock is now released, and the “ “ indicator will disappear.
OTHER INFORMATION:
› The buzzer will sound once when turning the knob at the beginning.
› “START/+30 SEC./CONFIRM” must be pressed to continue cooking if the door is opened during
cooking.
› Once the cooking programme has been set , if the “START/+30 SEC./CONFIRM” is not pressed
in 5 minutes. The current time will be displayed and the setting will be cancelled.
› The buzzer sounds once with every press, if a press is not recognised there will be
no response.
› The buzzer will sound five times to tell you when cooking has finished.
NORMAL
Microwave oven interring with
TV reception.
Radio and TV reception may be interfered when microwave oven operating. It is
similar to the interference of small electrical appliances like, mixer, vacuum, cleaner
and electric fan. It is normal.
Dim oven light. In low power microwave cooking, oven light may become dim. It is normal .
Steam accumulating on door,
hot air out of vents.
In cooking, steam may come out of food, most will get out form vents but some
may accumulate on a cool place such as the oven door. It is normal.
Oven started accidentally with
no food in. You must not run the unit without any food inside. It is very dangerous.
TROUBLESHOOTING
TROUBLE POSSIBLE CAUSE REMEDY
Oven can not be started.
Power cord not plugged
in tightly.
Unplug. Then plug again after
10 seconds.
Fuse blowing or circuit
breaker works.
Replace fuse of reset
circuit breaker (repaired by
professional personnel of
our company).
Trouble with outlet. Test outlet with other
electrical appliances.
Oven does not heat. Door not closed well. Close door well.
Glass turntable makes a
noise when microwave
oven operates.
Dirty roller rest
oven bottom.
Refer to “Maintenance of
Microwave” to clean
dirty parts.

Instruction manual CM126 Instruction manual CM12630 31
Please keep this instruction manual for future reference Please keep this instruction manual for future reference
TECHNICAL DATA
MODEL CM126
RATED VOLTAGE: 230V ~ 50Hz
RATED INPUT POWER 1450W
RATED OUTPUT POWER 900W
RATED GRILL INPUT
POWER 1100W
RATED INPUT POWER
(CONVECTION) 2500W
OVEN CAPACITY 25L
TURNTABLE DIAMETER 315mm
EXTERNAL DIMENSIONS
(L X W X H ) 595 x 462 x 460mm
NET WEIGHT Approx. 21.5kg

Caple Service
Fourth Way
Avonmouth
Bristol
BS11 8DW
T: 0117 938 1900
E: [e-mail]
www.caple.co.uk
