Caple CM130 User manual

Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk
Microwave & Grill
Instruction Manual
CM130

Instruction manual CM130
2Please keep this instruction manual for future reference
CONTENTS
Warnings 3
Environmental Protection 8
Warranty 8
Cleaning 10
Utensils 11
Setting up your Microwave 13
Installation 14
Operation Instructions 19
Troubleshooting 26
Technical Data 27
Caple Contact Details 28

3
Please keep this instruction manual for future reference Instruction manual CM130
SAFETY INSTRUCTIONS
Read carefully all the instructions contained in this
manual. It provides you with important information
regarding the safe installation, use and maintenance of
the appliance as well as useful advice for getting the best
out of your microwave oven. Keep this booklet in a safe
place for future reference. After removing the packing,
check that the appliance is not damaged in any way.
Be careful not to leave the packing materials (plastic
sheeting, expanded polystyrene etc.) where children can
get at them, as they can be dangerous.
ATTENTION:
-This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved.
-Children shall not play with the appliance.
-Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised.
Children less than 8 years of age shall be kept away
unless continuously supervised.
-Keep the appliance and its cord out of reach of children
less than 8 years.
-If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.

Instruction manual CM130
4Please keep this instruction manual for future reference
IMPORTANT:
-Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of
electric shock.
-It is hazardous for anyone other than a competent
person to carry out any service or repair operation that
involves the removal of a cover which gives protection
against exposure to microwave energy.
WARNING:
-Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
-When heating food in plastic or paper containers, keep
an eye on the oven due to the possibility of ignition.
-Only use utensils that are suitable for use in
microwave ovens.
-If smoke is emitted, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
-Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when
handling the container.
-The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
-Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
-The oven should be cleaned regularly and any food
deposits removed.

5
Please keep this instruction manual for future reference Instruction manual CM130
-Failure to maintain the oven in a clean condition could
lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a
hazardous situation.
-The microwave oven must be operated with the
decorative door open. (for ovens with a decorative door.)
-This appliance is intended to be used in household and
similar applications such as:
• Staff kitchen areas in shops, offices and other
working environments.
• Farm Houses.
• By clients in hotels, motels and other residential
type environments.
• Bed and breakfast type environments.
-The microwave oven is intended for heating food and
beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
-Metallic containers for food and beverages are not
allowed during microwave cooking.
-The appliance shall not be cleaned with a steam cleaner.
-Care should be taken not to displace the turntable
when removing containers from the appliance. (For fixed
appliances and built-in appliances being used equal
or higher than 900mm above the floor and having
detachable turntables. But this is not applicable for
appliances with a horizontal bottom hinged door.)
-The microwave oven is intended to be used built-in.
-Steam cleaner is not to be used.

Instruction manual CM130
6Please keep this instruction manual for future reference
-Surface of a storage drawer can get hot.
WARNING:
-The appliance and its accessible parts become hot during
use. Care should be taken to avoid touching heating
elements. Children less than 8 years of age shall be kept
away unless continuously supervised.
-During use, the appliance becomes hot. Care should
be taken to avoid touching heating elements inside the
oven.
-Accessible parts may become hot during use. Young
children should be kept away.
-The appliance must not be installed behind a decorative
door in order to avoid overheating.
-When the appliance is operated in the combination
mode, children should only use the oven under adult
supervision due to the temperatures generated.
-Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the over door glass since they can
scratch the surface, which may result in shattering of
the glass.
WARNING:
Electric shock hazard: Touching some of the internal
components can cause serious personal injury or death. Do
not disassemble this appliance.
Improper use of the grounding can result in electric shock.
Do not plug into an outlet until appliance is properly
installed and grounded.

7
Please keep this instruction manual for future reference Instruction manual CM130
This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric
current. This appliance is equipped with a cord having
a grounding wire with a grounding plug. The plug must
be plugged into an outlet that is properly installed and
grounded.
Consult a qualified electrician or appliance engineer if the
grounding instructions are not completely understood or in
doubt as to whether the appliance is properly grounded. If
it is necessary to use an extension cord, use only a 3-wire
extension cord.
A short power-supply cord is provided to reduce the risks
resulting from becoming entangled in or tripping over a
longer cord.
If a long cord set or extension cord is used:
The marked electrical rating of the cord set or extension
cord should be at least as great as the electrical rating of
the appliance.
The extension cord must be a grounding-type 3-wire cord.
The long cord should be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on
by children or tripped over unintentionally.

Instruction manual CM130
8Please keep this instruction manual for future reference
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice. This appliance is
marked according to the European Directive on Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The symbol on the product indicates that this
product may not be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal must be carried
out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local council, your household waste disposal service or the retailer where you
purchased the product.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all applicable
legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC).
UKCA DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all
applicable legislation.
WARRANTY:
Your new appliance is covered by warranty. The warranty card is enclosed - if it is missing, you
must provide the following information to your retailer in order to receive a replacement: date
of purchase, model and serial number (placed on the inside of the appliance storage drawer).
Registration can also be completed online by visiting www.caple.co.uk.
Ensure you keep your warranty card safe, you may need to show it to Caple Service together with
proof of purchase.
If you fail to show your warranty card you will incur all repair charges.
Spare parts are only available from Caple Service and spare parts authorised centres.

9
Please keep this instruction manual for future reference Instruction manual CM130
ATTENTION:
› Before use, remove all plastic films protecting some parts of the appliance (fascia - panel, parts
in stainless steel, etc.)
› Do not use the appliance to heat a room.
› When the appliance is not in use, we recommend you turn it off, isolate it from the
electrical supply.

Instruction manual CM130
10 Please keep this instruction manual for future reference
CLEANING
Be sure to unplug the appliance from the power supply before any cleaning.
1. Clean the cavity of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth
when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since
they can scratch the surface, which may result in shattering of the glass.
CLEANING TIP:
For easier cleaning of the cavity walls: Place half a lemon in a bowl, add 300ml (1/2 pint) water
and heat on 100% microwave power for 10 minutes. Wipe the oven clean using a soft, dry cloth.
UTENSILS
WARNING:
Personal Injury Hazard: It is hazardous for anyone other than a competent person to carry out any
service or repair operation that involves the removal of a cover which gives protection against
exposure to microwave energy.
There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt,
you can test the utensil in question following the procedure below.
UTENSIL TEST:
› Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil
in question.
› Cook on maximum power for 1 minute.
› Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
› Do not exceed 1 minute cooking time.

11
Please keep this instruction manual for future reference Instruction manual CM130
UTENSILS REMARKS
BROWNING DISH Follow manufacturer’s instructions. The bottom of the browning dish must be at least
5mm above the turntable. Incorrect usage may cause the turntable to break.
DINNERWARE Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked or
chipped dishes.
GLASS JAR Always remove lid. Use only to heat food until just warm. Most glass jars are not heat
resistant and may break.
GLASSWARE Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use
cracked or chipped dishes.
OVEN
COOKING BAGS
Follow manufacturer’s instructions. Do not close with a metal tie. Make slits to allow
steam to escape.
PAPER PLATES
AND CUPS Use for short–term cooking/warming only. Do not leave oven unattended while cooking.
PAPER TOWELS Use to cover food for reheating and absorbing fat. Use with supervision for a short-term
cooking only.
PARCHMENT PAPER Use as a cover to prevent splattering or a wrap for steaming.
PLASTIC
Microwave-safe only. Follow the manufacturer’s instructions. Should be labelled
“Microwave Safe”. Some plastic containers soften, as the food inside gets hot. “Boiling
bags” and tightly closed plastic bags should be slit, pierced or vented as directed
by package.
PLASTIC WRAP Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow
plastic wrap to touch food.
THERMOMETERS Microwave-safe only (meat and candy thermometers).
WAX PAPER Use as a cover to prevent splattering and retain moisture.
MATERIALS YOU CAN USE IN A MICROWAVE OVEN:

Instruction manual CM130
12 Please keep this instruction manual for future reference
MATERIALS TO BE AVOIDED IN A MICROWAVE OVEN:
UTENSILS REMARKS
ALUMINIUM TRAY May cause arcing. Transfer food into microwave-safe dish.
FOOD CARTON WITH
METAL HANDLE May cause arcing. Transfer food into microwave-safe dish.
METAL OR METAL-
TRIMMED UTENSILS Metal shields the food from microwave energy. Metal trim may cause arcing.
METAL TWIST TIES May cause arcing and could cause a fire in the oven.
PAPER BAGS May cause a fire in the oven.
PLASTIC FOAM Plastic foam may melt or contaminate the liquid inside when exposed to
high temperature..
WOOD Wood will dry out when used in the microwave oven and may split or crack.

13
Please keep this instruction manual for future reference Instruction manual CM130
SETTING UP YOUR MICROWAVE
PARTS AND ACCESSORIES:
Remove the oven and all materials from the carton and oven cavity. Your oven comes supplied
with the following accessories:
CONTENTS QUANTITY
Glass Turntable 1
Turntable Ring Assembly 1
Instruction Mw anual 1
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
Materials to be avoided in a microwave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
SETTING UP YOUR OVEN
Parts and accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes supplied with the following accessories:
1
1
Glass tray
Turntable ring assembly
Instruction Manual 1
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
Grill Rack ( Only to be used in the grill function
and to be placed on the glass tray )
9
G
E D CB
F
A
A. Control panel
B. Turntable shaft
C. Turntable ring assembly
D. Glass turntable
E. Observation window
F. Door assembly
G. Safety interlock system
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
Materials to be avoided in a microwave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
SETTING UP YOUR OVEN
Parts and accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes supplied with the following accessories:
1
1
Glass tray
Turntable ring assembly
Instruction Manual 1
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
Grill Rack ( Only to be used in the grill function
and to be placed on the glass tray )
9
GRILL RACK
(Only to be used in the grill function and to be
placed on the glass turntable)

Instruction manual CM130
14 Please keep this instruction manual for future reference
Hub (underside)
Glass tray
Turntable ring assembly
a. Never place the glass tray upside down.
The glass tray should never be
restricted.
b. Both the
glass tray and turntable ring
assembly
must always be used during
cooking.
c.
All food and containers of food must
always be placed
on the glass tray for
cooking.
d. If
glass tray or turntable ring assembly
cracks or breaks, contact your nearest
authorized Caple service center.
Turntable Installation
Turntable shaft
The accessible surface
may be hot during
operation.
Installation and connection
1.This appliance is only intended for domestic use. The guarantee is void if used in
any commercial application.
2.This oven is intended for built-in use only. It is not intended for counter-top use or for
use inside a cupboard.
3. Please observe the detailed installation instructions.
4.The appliance can be installed in a 60cm wide wall-mounted cupboard (at least55cm
deep and 85cm off the floor).
5.The appliance is fitted with a plug and must only be connected to a properly installed
earthed socket.
6.The mains voltage must correspond to the voltage specified on the rating plate.
7.The socket must be installed and connecting cable must only be replaced by a
qualified electrician.If the plug is no longer to accessible following installation,an
all-pole disconnecting device must be present on the installation side with a contact
gap of at lease 3mm.
8.Adapters,multi-way strips and extension leads must not be used. Overloading can
result in a risk of fire.
10
INSTALLATION
TURNTABLE INSTALLATION
› Never place the glass tray upside down. The glass
tray should never be restricted.
› Both the glass tray and turntable ring assembly must
always be used during cooking.
› All food and containers of food must always be
placed on the glass turntable for cooking.
› If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorised Caple
Service centre.
INSTALLATION AND CONNECTION
› This appliance is only intended for domestic use. The guarantee is void if used in any
commercial application.
› This oven is intended for built-in use only. It is not intended for counter-top use or for use inside
a cupboard.
› Please observe the detailed installation instructions.
› The appliance can be installed in a 60cm wide wall-mounted cupboard (at least 55cm deep and
85cm off the floor).
› The appliance is fitted with a plug and must only be connected to a properly installed
earthed socket.
› The mains voltage must correspond to the voltage specified on the rating plate.
› The socket must be installed and the connecting cable must only be replaced by a qualified
electrician. If the plug is no longer accessible following installation, an all-pole disconnecting
device must be present on the installation side with a contact gap of at lease 3mm.
› Adapters, multi-way strips and extension leads must not be used. Overloading can result in a
risk of fire.
WARNING:
The accessible surface may be hot during operation.
Hub (underside)
Glass tray
Turntable ring assembly
a. Never place the glass tray upside down.
The glass tray should never be
restricted.
b. Both the
glass tray and turntable ring
assembly
must always be used during
cooking.
c.
All food and containers of food must
always be placed
on the glass tray for
cooking.
d. If
glass tray or turntable ring assembly
cracks or breaks, contact your nearest
authorized Caple service center.
Turntable Installation
Turntable shaft
The accessible surface
may be hot during
operation.
Installation and connection
1.This appliance is only intended for domestic use. The guarantee is void if used in
any commercial application.
2.This oven is intended for built-in use only. It is not intended for counter-top use or for
use inside a cupboard.
3. Please observe the detailed installation instructions.
4.The appliance can be installed in a 60cm wide wall-mounted cupboard (at least55cm
deep and 85cm off the floor).
5.The appliance is fitted with a plug and must only be connected to a properly installed
earthed socket.
6.The mains voltage must correspond to the voltage specified on the rating plate.
7.The socket must be installed and connecting cable must only be replaced by a
qualified electrician.If the plug is no longer to accessible following installation,an
all-pole disconnecting device must be present on the installation side with a contact
gap of at lease 3mm.
8.Adapters,multi-way strips and extension leads must not be used. Overloading can
result in a risk of fire.
10

15
Please keep this instruction manual for future reference Instruction manual CM130
ELECTRICAL CONNECTION:
NOTE:
The microwave oven is fitted with a plug and must only be connected to a properly installed
earthed socket. The socket must only be installed and the connecting cable must only be replaced
by a qualified electrician, and in accordance with the appropriate regulations.
If the plug is not longer accessible following installation, an all-pole isolating switch must be
present on the installation side with a contact gap of at least 3mm.
WARNING:
Do not trap or bend power cable.
 
 
                
             
           
             
             
           
   
       

       
Installation Instructions
Please Read the Manual Carefully Before Installation
A gap must be maintained between the wall and the base of the unit above.
Specific gap size could be referenced by the diagrams.
Screw A
Trim-kit plastic cover
Bracket
12
Screw B

Instruction manual CM130
16 Please keep this instruction manual for future reference
BUILT IN FURNITURE
NOTE:
The fitted cabinet the appliance is being installed into must not have a back wall behind
the appliance. A gap must be maintained between a wall and the base of the unit above. Specific
gap size can be referenced by the diagrams.
Minimum installation height: 85cm
WARNING:
Do not cover ventilation slot or air intake points.
Instruction manual CM12618 Please keep this instruction manual for future reference
ELECTRICAL CONNECTION
NOTE:
The oven is fitted with a plugand must onlybe connected to a property installed earthed socket.
The socket must onlybe installed and the connecting cable must only be replaced by a qualified
electrician, and in accordance with theappropriate regulations. If the plug is no longer accessible
following installation,an all-pole isolating switch must be present onthe installation side with a
contact gap of at least 3mm.
BUILT-IN FURNITU R E
»The fittedcabinet the appliance is being installed into must not have a back wall behind
the appliance.
»Minimum height 85cm.Agap must bemaintained between the wall and the base of the unit
above. Specificgap size can bereferenced bythe diagrams.
»
11
(min)
500mm
380mm
600mm
+8
+2
560mm
45mm
45mm
Installation Instructions
Please Read the Manual Carefully Before Installation
A. Built-in furniture
B.Prepare the cabi inet
put the template on the bottom plane of cabinet.
1. Read the instruction on the BOTTOM CA INET TEMPLATE ,
2. Make the marks on the bottom plane of cabinet according to marks"a" of
of the template
aa
CENTER LINE
FRONTEDGE
LEFTEDGE
TEDGERIGH
3. Remove the bottom cabinet template and fix the bracket with screw A.
aa
Screw A
Bracket
Bracket
Screw A
Centre line
12
B
850mm
B.Prepare the cabi inet
put the template on the bottom plane of cabinet.
1. Read the instruction on the BOTTOM CA INET TEMPLATE ,
2. Make the marks on the bottom plane of cabinet according to marks"a" of
of the template
aa
CENTER LINE
FRONT EDGE
LEFT EDGE
TEDGERIGH
3. Remove the bottom cabinet template and fix the bracket with screw A.
aa
Screw A
Bracket
Bracket
Screw A
Centre line
12
B

17
Please keep this instruction manual for future reference Instruction manual CM130
PREPARE THE CABINET:
Read the instruction on the bottom of cabinet template, put the template on the bottom plane
of cabinet.
B.Prepare the cabi inet
put the template on the bottom plane of cabinet.
1. Read the instruction on the BOTTOM CA INET TEMPLATE ,
2. Make the marks on the bottom plane of cabinet according to marks"a" of
of the template
aa
CENTER LINE
FRONT EDGE
LEFT EDGE
TEDGERIGH
3. Remove the bottom cabinet template and fix the bracket with screw A.
aa
Screw A
Bracket
Bracket
Screw A
Centre line
12
B
B.Prepare the cabi inet
put the template on the bottom plane of cabinet.
1. Read the instruction on the BOTTOM CA INET TEMPLATE ,
2. Make the marks on the bottom plane of cabinet according to marks"a" of
of the template
aa
CENTER LINE
FRONT EDGE
LEFT EDGE
TEDGERIGH
3. Remove the bottom cabinet template and fix the bracket with screw A.
aa
Screw A
Bracket
Bracket
Screw A
Centre line
12
B
Make the marks on the bottom plane of cabinet according to marks”a” of the template.
Remove the bottom cabinet template and fix the bracket with screw A.
B.Prepare the cabi inet
put the template on the bottom plane of cabinet.
1. Read the instruction on the BOTTOM CA INET TEMPLATE ,
2. Make the marks on the bottom plane of cabinet according to marks"a" of
of the template
aa
CENTER LINE
FRONT EDGE
LEFT EDGE
TEDGERIGH
3. Remove the bottom cabinet template and fix the bracket with screw A.
aa
Screw A
Bracket
Bracket
Screw A
Centre line
12
B

Instruction manual CM130
18 Please keep this instruction manual for future reference
INSTALL THE MICROWAVE OVEN
Install the microwave oven to the cabinet:
› Make sure the back of the microwave oven is locked by mounting plate.
› Do not trap or kink the power cord.
C.Install the oven
4. Install the oven to the cabinet
- Make sure the back of the oven is locked by bracket.
- Do not trap or kink the power cord.
5. Open the door, fix the oven to the cabinet with Screw B, at the installation hole.
Then fix the Trim-kit plastic cover to the installation hole.
Screw B
Installation Hole
13
bracket
C.Install the oven
4. Install the oven to the cabinet
- Make sure the back of the oven is locked by bracket.
- Do not trap or kink the power cord.
5. Open the door, fix the oven to the cabinet with Screw B, at the installation hole.
Then fix the Trim-kit plastic cover to the installation hole.
Screw B
Installation Hole
13
bracket
Open the door, fix the microwave oven to the cabinet with Screw B at the installation hole.
Then fix the Trim-kit plastic cover to the installation hole.

19
Please keep this instruction manual for future reference Instruction manual CM130
OPERATION INSTRUCTIONS
SETTING THE CLOCK:
When the microwave is first turned on, the screen will display “0:00”, a buzzer will ring once.
› Press “Kitchen Timer/Clock” twice to select clock function, the hour figures will flash.
› Turn “
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1. Setting the clock
When the microwave oven is switched on, the LED will display "0:00", the buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting the clock. ":" will flash, and the time will illuminate.
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, the oven will not function when powered up.
2) ", the oven
During the process of setting the clock, if you press "
will go back to the previous status automatically.
2. Microwave Cooking
Press " " the LED will display "P100".Press " "
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn "" to set the cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
“ to adjust the hour figures, the input item should be within 0-24hr.
› Press “Kitchen Timer/Clock” the minute figures will flash.
› Turn “
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1. Setting the clock
When the microwave oven is switched on, the LED will display "0:00", the buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting the clock. ":" will flash, and the time will illuminate.
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, the oven will not function when powered up.
2) ", the oven
During the process of setting the clock, if you press "
will go back to the previous status automatically.
2. Microwave Cooking
Press " " the LED will display "P100".Press " "
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn "" to set the cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
” to adjust the minute figures, the input time should be within 0-59.
› Press “Kitchen Timer/Clock” to finish setting the clock. “:” will flash, and the time
will illuminate.
NOTE:
If the clock is not set, the oven will not function when powered.
During the process of setting the clock, if you press “Stop/Clear” the oven will go back to the
previous status automatically.
MICROWAVE COOKING:
Press “Micro/Grill/Combi” the LED will display “P100”. Press “Micro/Grill/Combi” repeatedly or
turn “
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1. Setting the clock
When the microwave oven is switched on, the LED will display "0:00", the buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting the clock. ":" will flash, and the time will illuminate.
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, the oven will not function when powered up.
2) ", the oven
During the process of setting the clock, if you press "
will go back to the previous status automatically.
2. Microwave Cooking
Press " " the LED will display "P100".Press " "
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn "" to set the cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
“ to choose the power you want, and “P100”, “P80” “P50”, “P30” or “P10” will
display for each added press. Then press ”Start/+30Sec/Confirm” to confirm, and turn “
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1. Setting the clock
When the microwave oven is switched on, the LED will display "0:00", the buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting the clock. ":" will flash, and the time will illuminate.
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, the oven will not function when powered up.
2) ", the oven
During the process of setting the clock, if you press "
will go back to the previous status automatically.
2. Microwave Cooking
Press " " the LED will display "P100".Press " "
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn "" to set the cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
“ to
set the cooking time from 0:05 to 95:00. Press ”Start/+30Sec/Confirm” again to start cooking.
EXAMPLE:
If you want to use 80% microwave power to cook for 20 minutes, you can operate the oven using
the following steps.
› Press “Micro/Grill/Combi” once, the screen display “P100”.
› Press “Micro/Grill/Combi” once again or turn”
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1. Setting the clock
When the microwave oven is switched on, the LED will display "0:00", the buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting the clock. ":" will flash, and the time will illuminate.
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, the oven will not function when powered up.
2) ", the oven
During the process of setting the clock, if you press "
will go back to the previous status automatically.
2. Microwave Cooking
Press " " the LED will display "P100".Press " "
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn "" to set the cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
“ to choose 80% microwave power.
› Press “Micro/Grill/Combi” to confirm, and the screen displays “P80”.
› Turn “
Operation Instructions
1) Press " " once, the screen display "P100".
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
3) Press " " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " " to start cooking .
1. Setting the clock
When the microwave oven is switched on, the LED will display "0:00", the buzzer will ring once.
1) Press " " twice to select clock function, the hour figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish setting the clock. ":" will flash, and the time will illuminate.
Note: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " " once again or turn" " to choose 80% microwave
power.
Note: 1) If the clock is not set, the oven will not function when powered up.
2) ", the oven
During the process of setting the clock, if you press "
will go back to the previous status automatically.
2. Microwave Cooking
Press " " the LED will display "P100".Press " "
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
"P30" or "P10" will display for each added press. Then press" "
to confirm, and turn "" to set the cooking time from 0:05 to 95:00. Press
" " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
Micro./Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Start/+30Sec./Confirm
Micro./Grill/Combi.
Micro./Grill/Combi.
Micro./Grill/Combi.
Kitchen Timer/Clock
Kitchen Timer/Clock
Kitchen Timer/Clock
14
“ to adjust the cooking time until the oven displays “20:00”.
› Press “Start/+30Sec/Confirm” to start cooking.

Instruction manual CM130
20 Please keep this instruction manual for future reference
NOTE:
When selecting a cooking duration, the timer will increase in the following quantities:
0 - 1 minute 5 seconds
1 - 5 minutes 10 seconds
5 - 10 minutes 30 seconds
10 - 30 minutes 1 minute
30 - 95 minutes 5 minutes
For example:
When selecting a cooking duration between 1- 5 minutes the timer will go up in 10
second increments.
“MICRO/GRILL/COMBI”
ORDER
PAD INSTRUCTIONS
DISPLAY
MICROWAVE
POWER
GRILL
POWER
1P100 100%
2P80 80%
3P50 50%
4P30 30%
5P10 10%
6 G 0% 100%
7C - 1 55% 45%
8C - 2 36% 64%
