Caple CM123 User manual

Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk
Combination Microwave
Instruction Manual
CM123 &
CM123BK

Instruction manual CM123 & CM123BK
2 3
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
CONTENTS
Warnings 3
Environmental Protection 10
Warranty 10
Cleaning 12
Utensils 12
Setting up your Microwave 15
Installation 16
Operation Instructions 21
Troubleshooting 28
Technical Data 29
Caple Contact Details 30
SAFETY INSTRUCTIONS
Read carefully all the instructions contained in this
manual. It provides you with important information
regarding the safe installation, use and maintenance of
the appliance as well as useful advice for getting the best
out of your microwave oven. Keep this booklet in a safe
place for future reference. After removing the packing,
check that the appliance is not damaged in any way.
Be careful not to leave the packing materials (plastic
sheeting, expanded polystyrene etc.) where children can
get at them, as they can be dangerous.
IMPORTANT:
Do not use the oven door handle to move the appliance,
such as to remove it from the packaging.
ATTENTION:
The microwave oven is an appliance which, for its nature,
becomes hot during use, especially the glass door.
It is therefore a good rule that children do not approach
the microwave oven when it is functioning, particularly
when the grill is in use.

Instruction manual CM123 & CM123BK
4 5
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
WARNING:
Accessible parts will become hot when in use. To avoid
burns and scalds children should be kept away.
During use the appliance becomes hot, Care should be
taken to avoid touching heating elements inside the oven.
-If the door or door seals are damaged, the oven must
not be operated until it has been repaired by a Caple
approved engineer.
-It is hazardous for anyone other than a competent person
to carry out any service or repair operation that involves
the removal of a cover which gives protection against
exposure to microwave energy.
-Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
-Only use utensils that are suitable for use in
microwave ovens.
-When heating food in plastic or paper containers, keep an
eye on the oven due to the possibility of ignition.
-The microwave oven is intended for heating food and
beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
-The oven should be cleaned regularly and any food
deposits removed
-Failure to maintain the oven in a clean condition could
lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a
hazardous situation.
Never roast or bake on the oven base.
This appliance is intended to be used in household and
similar applications such as:
• Staff kitchen areas in shops, offices and other
working environments.
• Farm Houses.
• By clients in hotels, motels and other residential type
environments.
• Bed and breakfast type environments.
The electrical system of this appliance may be used safely
only when it is correctly connected to an efficient earthing
system in compliance with the safety standards currently
in effect.
The manufacturer will not be held liable for any damages
that might arise out of incorrect or improper use of
the appliance.
The following items are potentially dangerous, and
therefore, appropriate measures must be taken to prevent
children and the disabled from coming into contact
with them:
-Controls and the appliance in general
-Packaging (bags, polystyrene, nails, etc.)
-The appliance immediately after use of the oven or grill
due to the heat generated.
-The appliance when no longer in use (potentially
dangerous parts must be made safe).

Instruction manual CM123 & CM123BK
6 7
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
WARNING:
To reduce the risk of burns, electric shock, fire, injury to
persons or exposure to excessive microwave energy:
-Make sure that all the packing materials are removed
from the inside of the door.
WARNING:
-Check the oven for any damage, such as misaligned
or bent door, damaged door seals and sealing surface,
broken or loose door hinges and latches and dents inside
the cavity or on the door. If there is any damage, do not
operate the oven and contact Caple service immediately.
-This microwave oven must be placed on a flat, stable
surface to hold its weight and the heaviest food likely to
be cooked in the oven.
-Do not place the microwave oven where heat, moisture,
or high humidity are generated, or near
combustible materials.
-Do not operate the microwave oven when empty.
-Do not operate this appliance if it has a damaged cord
or plug, if it is not working properly or if it has been
damaged or dropped. If the supply cord is damaged, it
must be replaced by Caple or an approved engineer in
order to avoid a hazard.
-Microwave heating of liquids can result in delayed
eruptive boiling, therefore care has to be taken when
handling the container.
-Do not fry food in the microwave oven. Hot oil can
damage oven parts and utensils and even result in
skin burns.
-Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode even after microwave heating has ended.
-Pierce foods with heavy skins such as potatoes, whole
squashes, apples and chestnuts before cooking.
-The contents of feeding bottles and baby jars should be
stirred or shaken and the temperature should be checked
before serving in order to avoid burns.
-Utensils should be checked to ensure that they are
suitable for use in microwave oven.
WARNING:
Liquid or other food must not be heated in sealed
containers since they are liable to explode.
WARNING:
It is hazardous for anyone other a trained person to
carry out any service or repair operation which involves
the removal of any cover which gives protection against
exposure to microwave energy.
-This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless the have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.

Instruction manual CM123 & CM123BK
8 9
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
-Children should be supervised to ensure that they do not
play with the appliance.
-When heating food in plastic or paper containers, check
the oven frequently for the possibility of ignition.
-Remove wire ties from paper or plastic bags before
placing bag in oven.
-If smoke is observed. Switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
-Do not leave paper products, cooking utensils or food in
the cavity when not in use.
WARNING:
The appliance and its accessible parts become hot
during use.
Care should be taken to avoid touching heating elements.
Children less than 8 years of age shall be kept away unless
continuously supervised.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be
made by children without supervision.
During use the appliance becomes hot. Care should be
taken to avoid touching heating elements inside the oven.
Electric shock hazard: Touching some of the internal
components can cause serious personal injury or death. Do
not disassemble this appliance.
Improper use of the grounding can result in electric
shock. Do not plug into an outlet until appliance is
properly installed and grounded.
This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric
current. This appliance is equipped with a cord having
a grounding wire with a grounding plug. The plug must
be plugged into an outlet that is properly installed and
grounded.
Consult a qualified electrician or appliance engineer if the
grounding instructions are not completely understood or in
doubt as to whether the appliance is properly grounded. If
it is necessary to use an extension cord, use only a 3-wire
extension cord.
A short power-supply cord is provided to reduce the risks
resulting from becoming entangled in or tripping over a
longer cord.
If a long cord set or extension cord is used:
The marked electrical rating of the cord set or extension
cord should be at least as great as the electrical rating of
the appliance.
The extension cord must be a grounding-type 3-wire cord.
The long cord should be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on
by children or tripped over unintentionally.

Instruction manual CM123 & CM123BK
10 11
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice. This appliance is
marked according to the European Directive on Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The symbol on the product indicates that this
product may not be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal must be carried
out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local council, your household waste disposal service or the retailer where you
purchased the product.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all applicable
legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC).
UKCA DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all
applicable legislation.
WARRANTY:
Your new appliance is covered by warranty. The warranty card is enclosed - if it is missing, you
must provide the following information to your retailer in order to receive a replacement: date
of purchase, model and serial number (placed on the inside of the appliance storage drawer).
Registration can also be completed online by visiting www.caple.co.uk.
Ensure you keep your warranty card safe, you may need to show it to Caple Service together with
proof of purchase.
If you fail to show your warranty card you will incur all repair charges.
Spare parts are only available from Caple Service and spare parts authorised centres.
ATTENTION:
› Before use, remove all plastic films protecting some parts of the appliance (fascia - panel, parts
in stainless steel, etc.)
› Do not use the appliance to heat a room.
› When the appliance is not in use, we recommend you turn it off, isolate it from the
electrical supply.

Instruction manual CM123 & CM123BK
12 13
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
CLEANING
Be sure to unplug the appliance from the power supply before any cleaning.
1. Clean the cavity of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth
when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since
they can scratch the surface, which may result in shattering of the glass.
CLEANING TIP:
For easier cleaning of the cavity walls: Place half a lemon in a bowl, add 300ml (1/2 pint) water
and heat on 100% microwave power for 10 minutes. Wipe the oven clean using a soft, dry cloth.
UTENSILS
WARNING:
Personal Injury Hazard: It is hazardous for anyone other than a competent person to carry out any
service or repair operation that involves the removal of a cover which gives protection against
exposure to microwave energy.
There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt,
you can test the utensil in question following the procedure below.
UTENSIL TEST:
› Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil
in question.
› Cook on maximum power for 1 minute.
› Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
› Do not exceed 1 minute cooking time.
UTENSILS REMARKS
BROWNING DISH Follow manufacturer’s instructions. The bottom of the browning dish must be at least
5mm above the turntable. Incorrect usage may cause the turntable to break.
DINNERWARE Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked or
chipped dishes.
GLASS JAR Always remove lid. Use only to heat food until just warm. Most glass jars are not heat
resistant and may break.
GLASSWARE Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use
cracked or chipped dishes.
OVEN
COOKING BAGS
Follow manufacturer’s instructions. Do not close with a metal tie. Make slits to allow
steam to escape.
PAPER PLATES
AND CUPS Use for short–term cooking/warming only. Do not leave oven unattended while cooking.
PAPER TOWELS Use to cover food for reheating and absorbing fat. Use with supervision for a short-term
cooking only.
PARCHMENT PAPER Use as a cover to prevent splattering or a wrap for steaming.
PLASTIC
Microwave-safe only. Follow the manufacturer’s instructions. Should be labelled
“Microwave Safe”. Some plastic containers soften, as the food inside gets hot. “Boiling
bags” and tightly closed plastic bags should be slit, pierced or vented as directed
by package.
PLASTIC WRAP Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow
plastic wrap to touch food.
THERMOMETERS Microwave-safe only (meat and candy thermometers).
WAX PAPER Use as a cover to prevent splattering and retain moisture.
MATERIALS YOU CAN USE IN A MICROWAVE OVEN:

Instruction manual CM123 & CM123BK
14 15
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
a m
P a
supplied
to the
to
G
E D CB
F
A
SETTING UP YOUR MICROWAVE
PARTS AND ACCESSORIES:
Remove the oven and all materials from the carton and oven cavity. Your oven comes supplied
with the following accessories:
CONTENTS QUANTITY
Glass Turntable 1
Turntable Ring Assembly 1
Instruction Mw anual 1
A. Control panel
B. Turntable shaft
C. Turntable ring assembly
D. Glass turntable
E. Observation window
F. Door assembly
G. Safety interlock system
a m
P a
supplied
to the
to
GRILL RACK
(Only to be used in the grill function and to be
placed on the glass turntable)
MATERIALS TO BE AVOIDED IN A MICROWAVE OVEN:
UTENSILS REMARKS
ALUMINIUM TRAY May cause arcing. Transfer food into microwave-safe dish.
FOOD CARTON WITH
METAL HANDLE May cause arcing. Transfer food into microwave-safe dish.
METAL OR METAL-
TRIMMED UTENSILS Metal shields the food from microwave energy. Metal trim may cause arcing.
METAL TWIST TIES May cause arcing and could cause a fire in the oven.
PAPER BAGS May cause a fire in the oven.
PLASTIC FOAM Plastic foam may melt or contaminate the liquid inside when exposed to
high temperature..
WOOD Wood will dry out when used in the microwave oven and may split or crack.

Instruction manual CM123 & CM123BK
16 17
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
Hub (underside)
Glass tray
Turntable ring assembly
a.
b. the
c.
must
be
d.
Caple
Turntable Installation
Turntable shaft
The guarantee is void if used in
any commercial application.
detailed
t
INSTALLATION
TURNTABLE INSTALLATION
› Never place the glass tray upside down. The glass
tray should never be restricted.
› Both the glass tray and turntable ring assembly must
always be used during cooking.
› All food and containers of food must always be
placed on the glass turntable for cooking.
› If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorised Caple
Service centre.
INSTALLATION AND CONNECTION
› This appliance is only intended for domestic use. The guarantee is void if used in any
commercial application.
› This oven is intended for built-in use only. It is not intended for counter-top use or for use inside
a cupboard.
› Please observe the detailed installation instructions.
› The appliance can be installed in a 60cm wide wall-mounted cupboard (at least 55cm deep and
85cm off the floor).
› The appliance is fitted with a plug and must only be connected to a properly installed
earthed socket.
› The mains voltage must correspond to the voltage specified on the rating plate.
› The socket must be installed and the connecting cable must only be replaced by a qualified
electrician. If the plug is no longer accessible following installation, an all-pole disconnecting
device must be present on the installation side with a contact gap of at lease 3mm.
› Adapters, multi-way strips and extension leads must not be used. Overloading can result in a
risk of fire.
WARNING:
The accessible surface may be hot during operation.
a.
b. the
c.
must
be
d.
Caple
ce
The guarantee is void if used in
any commercial application.
detailed
t
ELECTRICAL CONNECTION:
NOTE:
The microwave oven is fitted with a plug and must only be connected to a properly installed
earthed socket. The socket must only be installed and the connecting cable must only be replaced
by a qualified electrician, and in accordance with the appropriate regulations.
If the plug is not longer accessible following installation, an all-pole isolating switch must be
present on the installation side with a contact gap of at least 3mm.
WARNING:
Do not trap or bend power cable.
Screw฀A
Trim-kit฀plastic฀cover
Bracket
Screw฀B

Instruction manual CM123 & CM123BK
18 19
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
PREPARE THE CABINET:
Read the instruction on the bottom of cabinet template, put the template on the bottom plane
of cabinet.
2. Make the marks on the bottom plane of cabinet according to marks"a" of
aa
CENTER LINE
FRONT EDGE
LEFT EDGE
TEDGERIGH
3. Remove the bottom cabinet template and fix the bracket with screw A.
aa
Screw A
Bracket
Centre line
Make the marks on the bottom plane of cabinet according to marks”a” of the template.
Remove the bottom cabinet template and fix the bracket with screw A.
Bracket
Screw A
BUILT IN FURNITURE
NOTE:
The fitted cabinet the appliance is being installed into must not have a back wall behind
the appliance. A gap must be maintained between a wall and the base of the unit above. Specific
gap size can be referenced by the diagrams.
Minimum installation height: 85cm
WARNING:
Do not cover a ventilation slot or air intake points.
(min)
500mm
450mm
600mm
+8
+2
560mm
45mm
45mm
850mm

Instruction manual CM123 & CM123BK
20 21
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
INSTALL THE MICROWAVE OVEN:
Install the microwave oven to the cabinet:
› Make sure the back of the microwave oven is locked by bracket.
› Do not trap or kink the power cord.
5. Open the door, fix the oven to the cabinet with Screw B, at the installation hole.
Screw฀B฀Installation฀Hole
bracket
Screw฀B฀Installation฀Hole
bracket
Open the door, fix the microwave oven to the cabinet with Screw B at the installation hole.
Then fix the Trim-kit plastic cover to the installation hole.
OPERATION INSTRUCTIONS
SETTING THE CLOCK:
When the microwave oven is switched on, the LED will display “0:00”, the buzzer will ring once.
› Press “Kitchen Timer/Clock” twice to select clock function, the hour figures will flash.
› Turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to adjust the hour figures, the input item should be within 0-23hr.
› Press “Kitchen Timer/Clock” the minute figures will flash.
› Turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
” to adjust the minute figures, the input time should be within 0-59.
› Press “Kitchen Timer/Clock” to finish setting the clock. “:”will flash, and the time will illuminate.
NOTE:
If the clock is not set, the oven will not function when powered.
During the process of setting the clock, if you press “Stop/Clear” the oven will go back to the
previous status automatically.
MICROWAVE COOKING:
Press “Micro/Grill/Combi” the LED will display “P100”.Press “Micro/Grill/Combi” a few times or
turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to choose the power you want, and “P100”, “P80” “P50”, “P30” or “P10” will
display for each added press. Then press ”Start/+30Sec/Confirm” to confirm, and turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to
set the cooking time from 0:05 to 95:00. Press ”Start/+30Sec/Confirm” again to start cooking.
EXAMPLE:
If you want to use 80% microwave power to cook for 20 minutes, you can operate the oven as the
following steps.
› Press “Micro/Grill/Combi” once, the screen display “P100”.
› Press “Micro/Grill/Combi” once again or turn ”
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to choose 80% microwave power.
› Press “Start/+30Sec/Confirm” to confirm, and the screen displays “P80”.
› Turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to adjust the cooking time until the oven displays “20:00”.
› Press “Start/+30Sec/Confirm” to start cooking.

Instruction manual CM123 & CM123BK
22 23
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
NOTE:
When selecting a cooking duration, the timer will increase in the following quantities:
0 - 1 minute 5 seconds
1 - 5 minutes 10 seconds
5 - 10 minutes 30 seconds
10 - 30 minutes 1 minute
30 - 95 minutes 5 minutes
For example:
When selecting a cooking duration between 1- 5 minutes the timer will go up in 10
second increments.
“MICRO/GRILL/COMBI”
ORDER
PAD INSTRUCTIONS
DISPLAY
MICROWAVE
POWER
GRILL
POWER
1P100 100%
2P80 80%
3P50 50%
4P30 30%
5P10 10%
6 G 0% 100%
7C - 1 55% 45%
8C - 2 36% 64%
COMBINATION COOKING:
Press “Micro/Grill/Combi” the LED will display”P100” and press “Micro/Grill/Combi” a few times
or turn the “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to choose the power you want, and “G”,”C-1” or “C-2” will display for each
added press. Then press “Start/+30Sec/Confirm” to confirm and turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to set cooking time
from 0:05 to 95:00.
Press “Start/+30Sec/Confirm” again to start cooking.
EXAMPLE:
If you want to use 55% microwave power and 45% grill power(C-1) to cook for 10 minutes, you
can operate the oven as the following steps.
› Press “Micro/Grill/Combi” once, the screen display “P100”.
› Press “Micro/Grill/Combi” a few times or turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to choose combi 1 mode.
› Press “Start/+30Sec/Confirm” to confirm, and the screen displays “C-1”.
› Turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to adjust the cooking time until the oven displays “10:00”.
› Press “Start/+30Sec/Confirm” to start cooking .
NOTE:
If half the grilling time passes and the oven sounds twice, this is normal. In order to have a better
effect when grilling food, you should turn the food over, close the door, and then press
”START/ +30SEC./ Confirm” to continue cooking.
If there is no operation, the oven will continue cooking.
QUICK START:
› In standby mode, press “Start/+30Sec/Confirm” to start cooking with 100% power, each added
press will increase 30 seconds cooking time up to 95 minutes.
› In microwave, grill cooking or time defrost state, each press of “Start/+30Sec/Confirm” can
increase 30 seconds of cooking time.
› In standby mode, turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ left to set cooking time with 100% microwave power, then press
“Start/+30Sec/Confirm” to start cooking.

Instruction manual CM123 & CM123BK
24 25
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
DEFROST BY WEIGHT:
› Press “Weight/Time Defrost” once, and the oven will display “dEF1”.
› Turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to select the weight of food from 100 to 2000g.
› Press “Start/+30Sec/Confirm” to start defrosting.
DEFROST BY TIME:
› Press “Weight/Time Defrost” twice, and the oven will display “dEF2”.
› Turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to select the defrost time. The MAX time is 95 minutes.
› Press “Start/+30Sec/Confirm” to start defrosting. The defrost power is P30, this
cannot changed.
KITCHEN TIMER:
› Press “Kitchen/Timer/Clock” once, LED will display 00:00.
› Turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to enter the correct timer. (The maximum cooking time is 95 minutes).
› Press “Start/+30Sec/Confirm” to confirm setting.
› When the kitchen time is reached, the clock indicator will go out and the buzzer will ring
5 times. If the clock is set (24-hour system), the LED will display the current time.
NOTE:
The kitchen timer is different from the 24-hour system, the kitchen timer is a timer only.
AUTO MENU:
› Turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ clockwise to choose the menu, and “A-1” to “A-8” will display, which means
pizza, meat, vegetable, pasta, potato, fish, beverage and popcorn.
› Press “Start/+30Sec/Confirm” to confirm.
› Turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to choose the default weight as the menu chart.
› Press “Start/+30Sec/Confirm” to start cooking.
Example:
If you want to use “Auto Menu” to cook 350g of fish.
› Turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ clockwise till “A-6” display.
› Press “Start/+30Sec/Confirm” to confirm.
› Turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to select the weight of fish till “350” display.
› Press “Start/+30Sec/Confirm” to start cooking.
THE AUTOMATIC MENU CHART:
MENU WEIGHT DISPLAY
A-1
PIZZA
200g 200
400g 400
A-2
MEAT
250g 250
350g 350
450g 450
A-3
VEGETABLES
200g 200
300g 300
400g 400
A-4
PASTA
50g (with 450ml cold water) 50
100g (with 800ml cold water) 100
A-5
POTATO
200g 200
400g 400
600g 600

Instruction manual CM123 & CM123BK
26 27
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
MENU WEIGHT DISPLAY
A-6
FISH
250g 250
350g 350
450g 450
A-7
BEVERAGE
1 cup (120ml) 1
2 cups (240ml) 2
3 cups (360ml) 3
A-8
POPCORN
50g 50
100g 100
MULTI STAGE COOKING:
Two cooking stages can be set. If one stage is defrosting, it should be put in the first stage. The
buzzer will ring once after each stage and the next stage will begin.
NOTE:
Auto menu and preheating cannot be set as one of the multi stage options.
EXAMPLE:
If you want to defrost food for 5 minutes and then cook with 80% microwave power for 7
minutes, operate it as the following:
› Press “Weight/Time Defrost” twice, and the oven will display “dEF2”.
› Turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to select the defrost time till “5:00” display.
› Press “Micro/Grill/Combi” once, the screen display “P100”.
› Press “Micro/Grill/Combi” once again or turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to choose 80% microwave power.
› Press “Start/+30Sec/Confirm” to confirm, and the screen displays “P 80”.
› Turn “
Setting the clock
switched on the
the clock illuminate
the oven will up
the clock
Microwave Cooking
" the LED will display "P100
a few times or turn " "to choose the power you want, and "P100", "P80" "P50",
or "P10" will display for each added press.
the
./Grill/Combi.
“ to adjust the cooking time till the oven displays “7:00”.
› Press “Start/+30Sec/Confirm” to start cooking, the buzzer will sound once for the first section
and the defrosting time starts to count down. The buzzer will sound once again entering the
second section of cooking. When cooking finishes the buzzer sounds five times.
INQUIRING FUNCTION:
› In microwave, grill and combination cooking state, press “Micro /Grill/Combi” the current power
will be displayed for 3 seconds. After 3 seconds, the oven will revert back to the
former state.
› In cooking state, press “Kitchen/Timer/Clock” to inquire the time and the time will display for 3
seconds.
CHILD SAFETY LOCK:
LOCK:
In standby state, press “Stop/Clear” for 3 seconds, there will be a “beep” denoting entering the
child lock sate.
11. Child lock function
lock state.
Unlock
Will light and current time will display if the time has been set. Otherwise
the screen will display
11. Child lock function
current time will diplay
Unlock
he screen will display .
.
UNLOCK:
In locked state, press “Stop/Clear” for 3 seconds, there will be a “beep” denoting that the lock
is released.

Instruction manual CM123 & CM123BK
28 29
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
NORMAL
Microwave oven interring with
TV reception.
Radio and TV reception may be interfered when microwave oven operating. It is
similar to the interference of small electrical appliances like, mixer, vacuum, cleaner
and electric fan. It is normal.
Dim oven light. In low power microwave cooking, oven light may become dim. It is normal .
Steam accumulating on door,
hot air out of vents.
In cooking, steam may come out of food, most will get out form vents but some
may accumulate on a cool place such as the oven door. It is normal.
Oven started accidentally with
no food in. You must not run the unit without any food inside. It is very dangerous.
TROUBLESHOOTING
TROUBLE POSSIBLE CAUSE REMEDY
Oven can not be started.
Power cord not plugged
in tightly.
Unplug. Then plug again after
10 seconds.
Fuse blowing or circuit
breaker works.
Replace fuse of reset
circuit breaker (repaired by
professional personnel of
our company).
Trouble with outlet. Test outlet with other
electrical appliances.
Oven does not heat. Door not closed well. Close door well.
Glass turntable makes a
noise when microwave
oven operates.
Dirty roller rest
oven bottom.
Refer to “Maintenance of
Microwave” to clean
dirty parts.
TECHNICAL DATA
MODEL CM123 + CM123BK
RATED VOLTAGE: 230V ~ 50Hz
RATED INPUT POWER
(MICROWAVE) 1450W
RATED OUTPUT POWER
(MICROWAVE) 900W
RATED INPUT POWER
(GRILL) 1000W
OVEN CAPACITY 25L
TURNTABLE DIAMETER 315mm
EXTERNAL
DIMENSIONS 595x400x460mm
NET WEIGHT 19Kg

Instruction manual CM123 & CM123BK
30 31
Please keep this instruction manual for future reference Please keep this instruction manual for future reference Instruction manual CM123 & CM123BK
NOTES: NOTES:

Caple Service
Fourth Way
Avonmouth
Bristol
BS11 8DW
T: 0117 938 1900
E: [e-mail]
www.caple.co.uk
