Caple DDMEXT3 User manual

Instruction manual for External Motor
Contact Caple on 0844 800 3830 or for spare parts www.4caple.co.uk
Instruction manual for deluxe electronic washing machine
Model code: WMi2004
Contact Caple on 0844 800 3830 or for spare parts www.4caple.co.uk
Model code: DDMEXT3

3
The symbol on the product or on its packaging indicates that this product may not be
treated as household waste. Instead it shall be handed over to the applicable collection
point for the recycling of electrical and electronic equipment. By ensuring this product
is disposed of correctly, you will help prevent potential negative consequences for the
environment and human health, which could otherwise be caused by inappropriate
waste handling of this product. For more detailed information about recycling of this
product, please contact your local city oce, your household waste disposal service or
the shop where you purchased the product. This appliance is marked according to the
European directive 2002/96/EC on waste electrical and electronic equipment (WEEE).
GB

Warnings!
- The air outlet of the appliance must not be connected to a ue which is used for exhausting
other fumes from appliances, such as a central heating, boilers etc..
- Ensure the external exhausting of the fumes, comply with the regulations in force.
- Ventilate the room suitably according to the laws in force when the appliance is working to-
gether with gas, oil or coal burning appliances, at the same time.
- The motor of the peripheral exhausting group is powered by the cookerhood placed in the
kitchen.
- Before connecting the cooker hood to the mains supply, make sure that the voltage indicated
in the rating plate corresponds to the mains voltage in the home.
- Before carrying out any sort of maintenance or cleaning operation, make sure that the ap-
pliance is disconnected from the electrical mains.
- Appropriate maintenance ensures good working and good performance in the long run.
Advice for good performance of the appliance:
- Use an exhausting pipe with the necessary minimum length.
- A few bends with a maximun 90° bending angle.
- Materials in accordance with the directives.
- Avoid any drastic change in the section (constant diameter: ø 150 mm. advised)
- Read the mounting and operating istructions of the exhausting cooker-hood carefully.
- The manufacturer cannot be held responsible for a decrease of the air ow or for an increase
of noise level caused by non-compliance with the instructions above.
Warning!
The the DDMEXT3 suction centrals can be connected to any other products from the
same manufacturer if they are equipped with the External Motor version.
In case they are connected to products from other suppliers, the SCET-1 central unit can
command them.
The manufacturer cannot be held responsible for damages caused by incorrect use. No
garantee or indemnity will be due.
4
GB

DDMEXT3 (g. 9)
Warning! The remote tted exhausting group (external motor) is built in class I plate, the-
refore it needs the earth connection.
The appliance was designed to exhaust odours and vapours in the best way. The appliance is
to be installed on the outside wall of the house and connetted to the cookerhood which is in
the kitchen (g. 10) or to the SCET control unit 1.
Installation: the mounting of the appliance is to be made by qualied technicians. Using the
appropriate drilling jig (g. 11) drill all the holes marked on it into the external wall, by paying
attention not to damage water pipes or power lines. The holes on the wall are to be drilled with
a 8 mm. bit. Insert, step by step, the following parts in the holes drilled:
- the corresponding plastic dowels supplied (g. 11A)
- the two telescopic pipes in the hole of 160 mm.
- the plastic pipe of 40 mm. diameter.
Before leaning the appliance against the wall, insert the supply cord in the plastic pipe. Fix the
appliance without the stainless steel external body, which was previously removed from the
motor block, by matching the holes of the motor block with the holes on the wall. Tighten with
the screws supplied (g.11B).
Connection of the pipes: the appliance is fitted with an air entrance to be connected with
the telescopic pipes and an air outlet.
After xing the appliance on the external wall, connect the two telescopic pipes, which are pla-
ced inside the wall, with the cooker-hood through the exible pipes (g. 12).
The xing between the pipes have to be made with appropriate metal clamps (pipes and clamps
are supplied by the installer).
Electrical connection of the hood: the appliance is equipped with a 7m electrical cable. Make
the cable pass through the plastic hose in the wall (see g. 12E), connect it to the appliance in
the kitchen and then connect the ground wire to the screw near the connection by means of
nut and washer (see g. 14). You can otherwise make the electrical connection to the SCET-1
central unit.
Installation of the stainless steel external body: fit the stainless steel body again, by ma-
tching the air exhausting grid with the air outlet of the motor block (g. 13).
5

6
SCET - 1

7
910
14
13
11 12
DDMEXT3
